类似懂车帝汽车参数对比

<template>
  <div class="comparison_box">
    <div class="comparison_left">
      <div class="search">
        <el-input placeholder="请选择" v-model="input3">
          <i slot="suffix" class="el-input__icon el-icon-date"></i>
        </el-input>
      </div>
      <div class="system_list">
        <ul>
          <li
            v-for="(item, index) in systemList"
            :key="index"
            @click="selectSystem(index)"
            :class="{ li_active: index == selectVal }"
          >
            <span>左侧{{ item.name }}</span>
          </li>
        </ul>
      </div>
    </div>
    <div class="comparison_right" @scroll="handleScroll">
      <!-- 顶部固定列 -->
      <div class="comparison_top">
        <div class="comparison_top_title">
          <el-button icon="el-icon-plus" circle></el-button>
          <div class="text">添加对比</div>
        </div>
        <div class="comparison_top_list">
          <draggable :list="navList" class="drag-area" @end="onDragEnd">
            <div
              class="list_details"
              v-for="(item, index) in navList"
              :key="index"
              :class="{ list_details_active: index == 0 && isDing }"
            >
              <div class="fixed_tag">
                <span
                  class="tag_close"
                  v-if="index == 0 && isDing"
                  @click="cancelDing(index)"
                >
                  已钉住
                </span>
                <span class="tag" v-else @click="dingHandle(index)">
                  钉在左侧
                </span>
                <i
                  @click="moveItemUp(index)"
                  class="icon-ym icon-ym-nav-close"
                  v-if="navList.length > 1"
                ></i>
              </div>
              <div class="craft_name">{{ item.name }}{{ index }}</div>
            </div>
          </draggable>
        </div>
      </div>
      <div class="table_list" ref="scrollContainer">
        <div
          class="panel-item anchor-item"
          :ref="'anchor-' + index"
          v-for="(item, index) in systemList"
          :key="index"
        >
          <div class="panel-item-title">
            <div class="title">内容区域{{ item.name }}</div>
            <div class="panel-item_list">
              <div
                class="list_item"
                v-for="(list, i) in navList"
                :key="i"
                :class="{ list_item_active: i == 0 && isDing }"
              ></div>
            </div>
          </div>
          <div class="nav_box" v-for="(main, j) in item.list" :key="j">
            <div class="nav_left">
              <div>{{ main.title }}标题</div>
            </div>
            <div class="nav_right">
              <div
                class="nav_list"
                v-for="(nav, idx) in navList"
                :key="idx"
                :class="{ nav_list_active: idx == 0 && isDing }"
              >
                {{ nav[main.id] }}
              </div>
            </div>
          </div>
        </div>
      </div>
      <!-- 返回顶部 -->
      <div class="back_top" v-if="showBackTop">
        <el-button
          type="primary"
          icon="icon-ym icon-ym-report-icon-align-top"
          circle
          @click="scrollToTop"
        ></el-button>
      </div>
    </div>
  </div>
</template>

<script>
import draggable from 'vuedraggable'
export default {
  components: {
    draggable
  },
  data () {
    return {
      input3: '',
      systemList: [
        {
          name: '系统1',
          list: [
            {
              id: 'xitong1',
              title: '转动轴1'
            },

            {
              id: 'xitong2',
              title: '转动轴2'
            },
            {
              id: 'xitong3',
              title: '转动轴3'
            },
            {
              id: 'xitong4',
              title: '转动轴4'
            },
            {
              id: 'xitong5',
              title: '转动轴5'
            },
            {
              id: 'xitong6',
              title: '转动轴6'
            },
          ]
        },
        { name: '系统2' },
        { name: '系统3' },
        { name: '系统4' },
        { name: '系统5' },
        { name: '系统6' },
        { name: '系统7' },
        { name: '系统8' },
        { name: '系统9' },
        { name: '系统10' },
      ],
      selectVal: 0,
      showBackTop: false, // 是否显示返回顶部
      navList: [
        {
          name: '工艺参数1',
          xitong1: '10',
          xitong2: '65',
          xitong3: '1',
          xitong4: '30',
          xitong6: '40',
          xitong5: '50',
        },
        {
          name: '工艺参数2',
          xitong1: '50',
          xitong2: '6555',
          xitong3: '15',
          xitong4: '545430',
          xitong6: '440',
          xitong5: '540',
        },
        {
          name: '工艺参数3',
          xitong1: '550',
          xitong2: '655',
          xitong3: '1545',
          xitong4: '5430',
          xitong6: '44',
          xitong5: '50',
        },
        {
          name: '工艺参数4',
          xitong1: '550',
          xitong2: '655',
          xitong3: '1545',
          xitong4: '5430',
          xitong6: '44',
          xitong5: '50',
        },
        {},
        {},
        {},
        {},
        {}
      ],
      isDing: false, // 是否钉住
    }
  },
  methods: {
    dingHandle (index) {
      this.isDing = true
      this.navList.splice(0, 0, this.navList.splice(index, 1)[0]);
    },
    cancelDing () {
      this.isDing = false
    },
    onDragEnd (event) {
      // 拖拽结束后的处理逻辑
    },
    /**
     * 向前移动
     */
    moveUp (index) {
      if (index > 0) {
        this.navList.splice(index - 1, 0, this.navList.splice(index, 1)[0]);
      }
    },
    /**
     * 向后移动
     */
    moveDown (index) {
      if (index < this.navList.length - 1) {
        this.navList.splice(index + 1, 0, this.navList.splice(index, 1)[0]);
      }
    },
    selectSystem (val) {
      this.$nextTick(() => {
        this.selectVal = val
        let selector = 'anchor-' + val
        this.$refs[selector][0].scrollIntoView({ behavior: 'instant', block: 'end', inline: "nearest" })
      })
    },
    // 滚动监听器
    handleScroll (e) {
      const { systemList } = this
      let contents = document.querySelectorAll('.anchor-item')
      let nowTop = e.target.scrollTop // 滚动条目前的滚动距离
      if (nowTop > 100) {
        this.showBackTop = true
      } else {
        this.showBackTop = false
      }
      let firstTop = contents[0].offsetTop // 第一个章节的顶部位置
      let idx = null
      try { // forEach循环只能通过抛出异常的方式终止
        systemList.forEach((section, index) => {
          let contentTop = contents[index].offsetTop // 第index个章节的顶部位置
          let scrollDistance = contentTop - firstTop // 从第一个章节到第index个章节的滚动距离
          if (nowTop < scrollDistance) {
            // 滚动条已滚动的距离少于第index个章节需要的滚动距离，说明当前正文处于第(index-1)的章节
            idx = Math.max(0, index - 1)
            throw new Error(`find section:${this.selectVal}`)
          }
        })
      } catch (e) { }
      // 滚动到最后一章（该章节高度超过正文容器）时，滚动条的滚动距离超过所有章节需要的滚动距离
      this.selectVal = idx === null ? systemList.length - 1 : idx
      if (e.srcElement.scrollTop + e.srcElement.offsetHeight === e.srcElement.scrollHeight) {
        // 滚动条触底，处于最后一章（消除该章节高度低于正文容器时始终定位在倒数第二章的情况）
        this.selectVal = systemList.length - 1
      }
    },
    scrollToTop () {
      this.$nextTick(() => {
        this.selectSystem(0)
      });
    },
    moveItemUp (index) {
      console.log(55555)
      this.navList.splice(index, 1);
      console.log(this.navList)

    },
  },
  mounted () {

  }
}
</script>

<style lang="scss" scoped>
.comparison_box {
  display: flex;
  width: 100%;
  height: 100%;
  .comparison_left {
    width: 140px;
    height: 100%;
    background: #fff;
    border-radius: 5px;
    flex-shrink: 0;
    padding: 8px 0;
    overflow: hidden;
    .search {
      padding: 0 8px;
      margin-bottom: 12px;
    }
    .system_list {
      height: calc(100% - 40px);
      ul {
        height: 100%;
        overflow: auto;
        padding: 0 8px;
        li {
          list-style: none;
          padding: 8px 6px 8px 12px;
          font-size: 14px;
          border-radius: 6px;
          cursor: pointer;
          overflow: hidden;
          text-overflow: ellipsis;
          white-space: nowrap;
          background: #fff;
          &:hover {
            background: #b3d8ff;
          }
        }
        .li_active {
          color: #fff;
          background: #409eff;
        }
      }
    }
  }
  .comparison_right {
    background: #fff;
    width: calc(100% - 140px);
    margin-left: 12px;
    overflow: auto;
    .comparison_top {
      height: 100px;
      position: sticky;
      top: 0;
      z-index: 10;
      background: #fff;
      display: flex;
      .comparison_top_title {
        width: 160px;
        height: 100%;
        border: 1px solid #e5e7eb;
        position: sticky;
        left: 0;
        flex-shrink: 0;
        background: #fff;
        z-index: 8;
        display: flex;
        flex-direction: column;
        align-items: center;
        justify-content: center;
        .text {
          font-size: 12px;
          margin-top: 4px;
        }
      }
      .comparison_top_list {
        display: flex;
        .drag-area {
          display: flex;
        }
        .list_details {
          width: 160px;
          height: 100%;
          border: 1px solid #e5e7eb;
          border-left: none;
          background: #fff;
          position: relative;
          .fixed_tag {
            display: flex;
            justify-content: space-between;
            .tag {
              background-color: rgba(255, 204, 50, 0.12);
              border-bottom-right-radius: 24px;
              padding: 4px 20px 4px 6px;
              font-size: 12px;
              color: rgba(179, 125, 18);

              cursor: pointer;
            }
            .tag_close {
              background-color: #f2f4fa;
              border-bottom-right-radius: 24px;
              padding: 4px 20px 4px 6px;
              color: rgba(31, 33, 41);

              font-size: 12px;
              cursor: pointer;
            }
            > i {
              font-size: 12px;
              color: #c9cbd5;
              margin-right: 4px;
              margin-top: 4px;
              cursor: pointer;
            }
          }
          .craft_name {
            margin-top: 16px;
            text-align: center;
            font-size: 14px;
            font-weight: 600;
          }
        }
        .list_details_active {
          position: sticky;
          left: 160px;
          background: #fff;
          z-index: 6;
        }
      }
    }
    .table_list {
      height: 100%;
      .panel-item {
        display: flex;
        flex-direction: column;
        .panel-item-title {
          height: 36px;
          display: flex;
          align-items: center;
          .title {
            width: 160px;
            height: 100%;
            line-height: 36px;
            position: sticky;
            left: 0;
            font-size: 14px;
            font-weight: 600;
            background: rgba(242, 244, 250);
            padding-left: 16px;
            border-bottom: 1px solid #e5e7eb;
            flex-shrink: 0;
          }
          .panel-item_list {
            height: 100%;
            display: flex;
            .list_item {
              width: 160px;
              height: 100%;
              background: rgba(242, 244, 250);
              border-bottom: 1px solid #e5e7eb;
            }
            .list_item_active {
              position: sticky;
              left: 160px;
              background: rgba(242, 244, 250);
            }
          }
        }
        .nav_box {
          display: flex;
          height: 32px;
          .nav_left {
            height: 100%;
            position: sticky;
            left: 0;
            border: 1px solid #e5e7eb;
            border-top: none;
            width: 160px;
            line-height: 32px;
            padding-left: 16px;
            color: rgba(96, 99, 112);
            flex-shrink: 0;
            z-index: 8;
            background: #ffff;
            font-size: 14px;
          }
          .nav_right {
            display: flex;
            height: 100%;
            .nav_list {
              width: 160px;
              height: 100%;
              flex-shrink: 0;
              border: 1px solid #e5e7eb;
              border-top: none;
              border-left: none;
              line-height: 32px;
              padding-left: 16px;
              font-size: 14px;
            }
            .nav_list_active {
              position: sticky;
              left: 160px;
              background: #fff;
            }
          }
        }
      }
    }
    .back_top {
      position: fixed;
      bottom: 50px;
      right: 60px;
    }
  }
}
</style>
