【零基础学AI】第34讲：深度Q网络(DQN) - Atari游戏AI实战

本节课你将学到

• 理解深度Q网络(DQN)的核心原理
• 掌握经验回放和目标网络关键技术
• 使用PyTorch实现完整的DQN算法
• 训练能玩Atari游戏的AI智能体

开始之前

环境要求

• Python 3.8+
• PyTorch 2.0+
• Gymnasium[atari] (包含Atari游戏环境)
• OpenCV (图像预处理)
• 必须使用GPU加速训练

前置知识

• 强化学习基础（第33讲）
• 卷积神经网络（第24讲）
• PyTorch张量操作（第22讲）

---

核心概念

DQN与传统Q-learning的区别

特性	Q-learning	DQN
状态表示	离散表格	原始像素图像
函数近似	查表法	深度神经网络
内存效率	低（状态爆炸）	高
适用范围	小规模离散问题	复杂视觉任务

DQN两大关键技术

1. 经验回放(Experience Replay)

   • 存储转移样本(s,a,r,s’)到记忆库
   • 训练时随机采样打破相关性
   • 像"回看游戏录像"学习

2. 目标网络(Target Network)

   • 使用两个网络：在线网络+目标网络
   • 定期同步目标网络参数
   • 稳定Q值估计（避免"移动靶标"问题）

---

代码实战

1. 环境预处理

Atari游戏需要特殊的图像预处理

import gymnasium as gym
import numpy as np
import cv2
from collections import deque
import torch

class AtariWrapper:
    def __init__(self, env_name, frame_stack=4):
        self.env = gym.make(env_name, render_mode='rgb_array')
        self.frame_stack = frame_stack
        self.frames = deque(maxlen=frame_stack)

    def reset(self):
        obs, _ = self.env.reset()
        processed = self._preprocess(obs)
        for _ in range(self.frame_stack):
            self.frames.append(processed)
        return self._get_state()

    def _preprocess(self, frame):
        # 转换为灰度图
        frame = cv2.cvtColor(frame, cv2.COLOR_RGB2GRAY)
        # 裁剪和缩放
        frame = frame[34:194, :]  # 移除记分牌区域
        frame = cv2.resize(frame, (84, 84), interpolation=cv2.INTER_AREA)
        return frame / 255.0  # 归一化

    def _get_state(self):
        return np.stack(self.frames, axis=0)  # 形状：(4,84,84)

    def step(self, action):
        obs, reward, terminated, truncated, _ = self.env.step(action)
        processed = self._preprocess(obs)
        self.frames.append(processed)
        next_state = self._get_state()
        done = terminated or truncated
        return next_state, reward, done

    def render(self):
        return self.env.render()

    def close(self):
        self.env.close()

# 创建环境
env = AtariWrapper("PongNoFrameskip-v4")
print("观测空间形状:", env.reset().shape)

# ⚠️ 常见错误1：帧堆叠顺序错误
# 正确顺序应该是[t-3, t-2, t-1, t]，确保时间连续性

2. DQN网络架构

import torch.nn as nn
import torch.nn.functional as F

class DQN(nn.Module):
    def __init__(self, n_actions):
        super(DQN, self).__init__()
        self.conv1 = nn.Conv2d(4, 32, kernel_size=8, stride=4)
        self.conv2 = nn.Conv2d(32, 64, kernel_size=4, stride=2)
        self.conv3 = nn.Conv2d(64, 64, kernel_size=3, stride=1)
        self.fc1 = nn.Linear(7*7*64, 512)
        self.fc2 = nn.Linear(512, n_actions)

    def forward(self, x):
        x = F.relu(self.conv1(x))
        x = F.relu(self.conv2(x))
        x = F.relu(self.conv3(x))
        x = x.view(x.size(0), -1)  # 展平
        x = F.relu(self.fc1(x))
        return self.fc2(x)

# 网络测试
sample_input = torch.randn(1, 4, 84, 84)  # 批量大小1，4帧84x84
model = DQN(n_actions=env.env.action_space.n)
print("输出Q值形状:", model(sample_input).shape)

# ⚠️ 常见错误2：维度不匹配
# 确保：
# 1. 输入通道数与帧堆叠数一致
# 2. 输出维度与动作空间大小一致

3. 经验回放实现

import random
from collections import namedtuple

Transition = namedtuple('Transition',
                        ('state', 'action', 'next_state', 'reward', 'done'))

class ReplayMemory:
    def __init__(self, capacity):
        self.capacity = capacity
        self.memory = []
        self.position = 0

    def push(self, *args):
        if len(self.memory) < self.capacity:
            self.memory.append(None)
        self.memory[self.position] = Transition(*args)
        self.position = (self.position + 1) % self.capacity

    def sample(self, batch_size):
        return random.sample(self.memory, batch_size)

    def __len__(self):
        return len(self.memory)

# 初始化记忆库
memory = ReplayMemory(100000)

# 存储示例
state = env.reset()
action = env.env.action_space.sample()
next_state, reward, done = env.step(action)
memory.push(state, action, next_state, reward, done)

print("记忆库当前大小:", len(memory))

4. 完整训练流程

import math
import torch.optim as optim

class DQNAgent:
    def __init__(self, n_actions, device):
        self.n_actions = n_actions
        self.device = device

        # 双网络架构
        self.policy_net = DQN(n_actions).to(device)
        self.target_net = DQN(n_actions).to(device)
        self.target_net.load_state_dict(self.policy_net.state_dict())
        self.target_net.eval()

        # 优化器
        self.optimizer = optim.Adam(self.policy_net.parameters(), lr=0.0001)

        # 超参数
        self.batch_size = 32
        self.gamma = 0.99
        self.eps_start = 1.0
        self.eps_end = 0.01
        self.eps_decay = 10000
        self.steps_done = 0
        self.target_update = 1000

    def select_action(self, state):
        sample = random.random()
        eps_threshold = self.eps_end + (self.eps_start - self.eps_end) * \
            math.exp(-1. * self.steps_done / self.eps_decay)
        self.steps_done += 1

        if sample > eps_threshold:
            with torch.no_grad():
                # 使用网络选择最优动作
                state = torch.tensor(state, dtype=torch.float32).unsqueeze(0).to(self.device)
                return self.policy_net(state).max(1)[1].view(1, 1).item()
        else:
            # 随机探索
            return random.randrange(self.n_actions)

    def optimize_model(self):
        if len(memory) < self.batch_size:
            return

        # 从记忆库采样
        transitions = memory.sample(self.batch_size)
        batch = Transition(*zip(*transitions))

        # 转换数据为张量
        state_batch = torch.tensor(np.array(batch.state), dtype=torch.float32).to(self.device)
        action_batch = torch.tensor(batch.action).unsqueeze(1).to(self.device)
        reward_batch = torch.tensor(batch.reward, dtype=torch.float32).unsqueeze(1).to(self.device)
        next_state_batch = torch.tensor(np.array(batch.next_state), dtype=torch.float32).to(self.device)
        done_batch = torch.tensor(batch.done, dtype=torch.float32).unsqueeze(1).to(self.device)

        # 计算当前Q值
        state_action_values = self.policy_net(state_batch).gather(1, action_batch)

        # 计算目标Q值
        with torch.no_grad():
            next_state_values = self.target_net(next_state_batch).max(1)[0].unsqueeze(1)
            expected_state_action_values = reward_batch + (self.gamma * next_state_values * (1 - done_batch))

        # 计算损失
        loss = F.smooth_l1_loss(state_action_values, expected_state_action_values)

        # 优化模型
        self.optimizer.zero_grad()
        loss.backward()
        # 梯度裁剪
        for param in self.policy_net.parameters():
            param.grad.data.clamp_(-1, 1)
        self.optimizer.step()

    def update_target_net(self):
        self.target_net.load_state_dict(self.policy_net.state_dict())

# 初始化
device = torch.device("cuda" if torch.cuda.is_available() else "cpu")
agent = DQNAgent(env.env.action_space.n, device)

5. 训练主循环

import matplotlib.pyplot as plt
from IPython import display

def plot_rewards(episode_rewards, mean_rewards):
    display.clear_output(wait=True)
    plt.figure(figsize=(10,5))
    plt.title('Training Progress')
    plt.xlabel('Episode')
    plt.ylabel('Reward')
    plt.plot(episode_rewards, label='Episode Reward')
    plt.plot(mean_rewards, label='Mean Reward (100 episodes)')
    plt.legend()
    plt.grid()
    plt.show()

def train(num_episodes=1000):
    episode_rewards = []
    mean_rewards = []
    best_mean = -float('inf')

    for i_episode in range(num_episodes):
        state = env.reset()
        total_reward = 0

        while True:
            # 选择并执行动作
            action = agent.select_action(state)
            next_state, reward, done = env.step(action)
            total_reward += reward

            # 存储转移样本
            memory.push(state, action, next_state, reward, done)
            state = next_state

            # 优化模型
            agent.optimize_model()

            # 同步目标网络
            if agent.steps_done % agent.target_update == 0:
                agent.update_target_net()

            if done:
                break

        # 记录训练进度
        episode_rewards.append(total_reward)
        mean_100 = np.mean(episode_rewards[-100:])
        mean_rewards.append(mean_100)

        # 定期保存最佳模型
        if mean_100 > best_mean:
            best_mean = mean_100
            torch.save(agent.policy_net.state_dict(), 'dqn_best.pth')

        # 显示进度
        if i_episode % 10 == 0:
            plot_rewards(episode_rewards, mean_rewards)
            print(f"Episode {i_episode}, Reward: {total_reward}, Mean Reward: {mean_100:.1f}")

    env.close()
    return episode_rewards

# 开始训练
rewards = train(num_episodes=500)

---

完整项目

项目结构：

lesson_34_dqn_atari/
├── envs/
│   ├── atari_wrapper.py  # 环境预处理
│   └── utils.py          # 辅助函数
├── models/
│   ├── dqn.py            # 网络架构
│   └── memory.py         # 经验回放
├── agents/
│   └── dqn_agent.py      # DQN智能体
├── configs/
│   └── hyperparams.yaml  # 超参数配置
├── train.py              # 训练脚本
├── eval.py               # 评估脚本
├── requirements.txt      # 依赖列表
└── README.md             # 项目说明

requirements.txt

gymnasium[atari]==0.28.1
torch==2.0.1
opencv-python==4.7.0.72
numpy==1.24.3
matplotlib==3.7.1
pygame==2.3.0
tensorboard==2.12.0

configs/hyperparams.yaml

# 训练参数
batch_size: 32
gamma: 0.99
eps_start: 1.0
eps_end: 0.01
eps_decay: 10000
target_update: 1000
memory_capacity: 100000
learning_rate: 0.0001

# 环境参数
env_name: "PongNoFrameskip-v4"
frame_stack: 4

---

运行效果

训练过程输出

Episode 0, Reward: -21.0, Mean Reward: -21.0
Episode 10, Reward: -20.0, Mean Reward: -20.5
...
Episode 300, Reward: 12.0, Mean Reward: 8.2
Episode 500, Reward: 18.0, Mean Reward: 14.7

---

常见问题

Q1: 训练初期得分极低（如Pong总是-21）

解决方案：

1. 这是正常现象，需要约100-200局"暖机期"
2. 检查记忆库是否在积累足够样本后才开始训练
3. 确保ε-greedy策略在初期有足够探索（ε_start=1.0）

Q2: 训练不稳定，成绩大起大落

可能原因：

1. 目标网络更新频率不合适（调整target_update）
2. 学习率过高（尝试减小到0.00001）
3. 批量大小太小（增大到64或128）

Q3: 如何应用到其他Atari游戏？

调整建议：

1. 修改图像预处理（不同游戏的有效区域不同）
2. 调整奖励缩放（如Breakout需要正奖励）
3. 可能需要更深的网络（如Nature DQN架构）

---

课后练习

1. Double DQN改进
   实现Double DQN算法，比较与原始DQN的性能差异

2. 优先级经验回放
   修改记忆库，使重要转移样本有更高采样概率

3. Dueling DQN架构
   将网络改为Dueling架构（分离状态价值和优势函数）

4. 多步TD学习
   实现n-step TD回报，平衡MC和TD方法的优缺点

---

扩展阅读

1. DQN原始论文(Human-level control through deep reinforcement learning)
2. Rainbow: 组合多种改进的SOTA算法
3. Stable Baselines3实现参考

下节预告：第35讲将探索策略梯度方法，实现连续控制任务！
