index.js
import React, { Component } from 'react'
import styles from './index.css'
var width = 300
var height = 300
var direction = '-1' //方向 -1 横向顺时针 1 横向逆时针 -2 纵向顺时针 2 纵向逆时针
var speed = 600 //速度
var color = ['#2D4DB6', '#04B67C', '#D1AF07', '#E27914', '#CB4A4D', '#B02690']
export default class index extends Component {
state = {
contentEle: [],
timer: null,
data: ['云图', '是个啥', '他啥都不是', '他就是词云', '就是他呆子', '傻子和疯子', '营养快线', '哈哈哈到家', '瑞士军刀', 'DW情侣对表', '清风抽纸', '这一刻更清晰', '债券评级', '呵呵旧宫style', '云图', '是个啥', '他啥都不是', '他就是词云', '就是他呆子', '傻子和疯子', '营养快线', '哈哈哈到家', '瑞士军刀', 'DW情侣对表', '清风抽纸', '这一刻更清晰', '债券评级', '呵呵旧宫style']
}
render() {
const { data } = this.state
return (
<div id="main">
<div className={styles.wordCloud__tagBall}>
{
data.map((it, idx) => this.renderContent(it, idx))
}
</div>
</div>
)
}
// 内容
renderContent = (it, idx) => {
const { contentEle } = this.state
if (contentEle[idx]) {
return (
<span className={styles.wordCloud__tag}
key={idx}
style={{
color: color[idx % color.length],
opacity: contentEle[idx].style.opacity,
transform: contentEle[idx].style.transform,
zIndex: contentEle[idx].style.zIndex
}}>
{it}</span>
)
} else {
return (
<span className={styles.wordCloud__tag} key={idx}> ss</span>
)
}
}
// 初始位点
renderInit = () => {
const { contentEle, data } = this.state
const RADIUSX = (width - 50) / 2
const RADIUSY = (height - 50) / 2
for (let i = 0; i < data.length; i += 1) {
const k = -1 + (2 * (i + 1) - 1) / data.length
const a = Math.acos(k)
const b = a * Math.sqrt(data.length * Math.PI)
const x = RADIUSX * Math.sin(a) * Math.cos(b)
const y = RADIUSY * Math.sin(a) * Math.sin(b)
const z = RADIUSX * Math.cos(a)
const singleEle = {
x,
y,
z,
style: {},
}
contentEle.push(singleEle)
this.setState({
contentEle: contentEle
})
}
this.animate()
}
// 动画
animate = () => {
this.rotateX()
this.rotateY()
this.move()
// window.requestAnimationFrame(this.animate)
}
// X轴
rotateX = () => {
const angleX = ['-1', '1'].includes(direction)
? Math.PI / Infinity
: Math.PI / ((Number(direction) / 2) * Number(speed))
const cos = Math.cos(angleX)
const sin = Math.sin(angleX)
let contentEle = this.state.contentEle.map((t) => {
const y1 = t.y * cos - t.z * sin
const z1 = t.z * cos + t.y * sin
return {
...t,
y: y1,
z: z1,
}
})
this.setState({
contentEle: contentEle
})
}
// y轴
rotateY = () => {
const angleY = ['-2', '2'].includes(direction)
? Math.PI / Infinity
: Math.PI / (Number(direction) * Number(speed))
const cos = Math.cos(angleY)
const sin = Math.sin(angleY)
let contentEle = this.state.contentEle.map((t) => {
const x1 = t.x * cos - t.z * sin
const z1 = t.z * cos + t.x * sin
return {
...t,
x: x1,
z: z1,
}
})
this.setState({
contentEle: contentEle
})
}
// 样式
move = () => {
const CX = width / 2
const CY = height / 2
let contentEle = this.state.contentEle.map((singleEle) => {
const { x, y, z } = singleEle
const fallLength = 500
const RADIUS = (width - 50) / 2
const scale = fallLength / (fallLength - z)
const alpha = (z + RADIUS) / (2 * RADIUS)
const left = `${x + CX - 15}px`
const top = `${y + CY - 15}px`
const transform = `translate(${left}, ${top}) scale(${scale})`
const style = {
...singleEle.style,
opacity: alpha + 0.5,
zIndex: parseInt(scale * 100, 10),
transform,
}
return {
x,
y,
z,
style,
}
})
this.setState({
contentEle: contentEle
})
}
// 定时器
iTimer = () => {
const { data } = this.state
this.setState({
timer: setInterval(() => {
this.renderInit()
data.map((it, idx) => this.renderContent(it, idx))
}, 50),
});
};
componentDidMount() {
this.renderInit()
setTimeout(this.iTimer, 0);
}
componentWillUnmount() {
this.state.timer && clearTimeout(this.state.timer);
}
}
index.css
.wordCloud__tagBall {
width: 300px;
height: 300px;
margin: 50px auto;
position: relative;
}
.wordCloud__tag {
display: block;
position: absolute;
left: 0px;
top: 0px;
color: green;
text-decoration: none;
font-size: 15px;
font-family: '微软雅黑';
font-weight: bold;
cursor: pointer;
}
.wordCloud__tag:hover {
color: red !important;
}
参考: js 转换为react
[转]插件链接:
https://github.com/jyoketsu/3d-tag-cloud-for-react-withclick
https://github.com/mcc108/TagCloud
https://github.com/crazylxr/3d-tag-cloud-for-react
