2024年Linux下NTP时间同步服务器搭建_ntpserver怎么设置多个ip

sudo systemctl enable --now chronyd

服务状态应该显示正在运行

systemctl status chronyd

3. 在RHEL8或者CentOS8系统上配置Chrony服务用于时间同步
安装之后,您可以对Chrony主配置文件/etc/chrony.conf进行更改

您可以进行的一个主要配置更改是设置离您最近的时间服务器。

sudo vi /etc/chrony.conf

注释掉第一行,并添加一个NTP服务器列表。

#pool 2.rhel.pool.ntp.org iburst
server 0.cn.pool.ntp.org iburst
server 1.cn.pool.ntp.org iburst
server 2.cn.pool.ntp.org iburst
server 3.cn.pool.ntp.org iburst

如果附近没有NTP服务器,您也可以添加CentOS官方NTP服务器。

server 0.centos.pool.ntp.org iburst
server 1.centos.pool.ntp.org iburst
server 2.centos.pool.ntp.org iburst
server 3.centos.pool.ntp.org iburst

RHEL8或CentOS8设置NTP同步,用于同步时间

sudo timedatectl set-ntp true

更改后重新启动chronyd服务。

sudo systemctl restart chronyd

您还可以指定允许访问NTP服务器的IP地址或网络地址块。

# Allow NTP client access from local network.
allow 192.168.25.0/24

如果您有活动的firewalld服务,请允许ntp端口(123/udp)。

sudo firewall-cmd --add-service=ntp --permanent
sudo firewall-cmd --reload

检查NTP服务器是否正常工作。

chronyc sources

4. 配置CentOS8或RHEL8的NTP客户端
现在已经安装和配置了Chrony NTP服务器,可以配置NTP客户机了。

设置时区:

sudo timedatectl set-timezone "Asia/Shanghai"

安装chrony并将其配置为NTP客户端。

sudo yum -y install chrony

编辑配置文件以设置NTP服务器以指向新配置的NTP服务器。

sudo vi /etc/chrony.conf
server time1.aliyun.com iburst
server time2.aliyun.com iburst
server time3.aliyun.com iburst

允许 192.168.1.0/24 内的客户端通过这台服务器获取时间
allow 192.168.1.0/24

或者
server 192.168.25.3

设置NTP同步时间。

sudo timedatectl set-ntp true

开启并设置服务自启动

sudo systemctl enable --now chronyd
systemctl restart chronyd.service
systemctl enable chronyd.service

使用以下命令验证设置:

chronyc sources

使用ss -tlunp | grep chrony或者 lsof -i:123命令检查chrony服务使用的123/udp端口是否启动成功

更多介绍 :centos8使用chrony作为NTP服务器 :https://www.linuxprobe.com/centos8-chrony-ntp.html

企业内部时间同步服务器为其他主机提供时间同步服务

在这里插入图片描述

  • centos8 10.0.0.8 ntp/chrony server
  • centos7 10.0.0.7 other server

chrony server 10.0.0.8 启动chronyd服务

root@8  ~]# systemctl enable --now chronyd
root@8  ~]# systemctl is-active chronyd.service
active
root@8  ~]# systemctl is-enabled chronyd.service
enabled

chrony server 10.0.0.8 修改配置文件

root@8  ~]# awk '!/^(#|$)/{print}' /etc/chrony.conf
pool ntp1.aliyun.com iburst
pool ntp2.aliyun.com iburst
driftfile /var/lib/chrony/drift
makestep 1.0 3
rtcsync
allow 10.0.0.0/24   #允许该网段同步时间服务
#allow 0.0.0.0/0 #如果想为所有机器提供同步服务 需要设置0.0.0.0/0
keyfile /etc/chrony.keys
leapsectz right/UTC
logdir /var/log/chrony

root@8  ~]# systemctl restart chronyd

root@8  ~]# ss -lnu|awk '{print}'
State     Recv-Q    Send-Q       Local Address:Port        Peer Address:Port
UNCONN    0         0                 10.0.0.8:53               0.0.0.0:\*
UNCONN    0         0                127.0.0.1:53               0.0.0.0:\*
UNCONN    0         0                  0.0.0.0:123              0.0.0.0:\*
UNCONN    0         0                127.0.0.1:323              0.0.0.0:\*
UNCONN    0         0                127.0.0.1:323              0.0.0.0:\*
UNCONN    0         0                    [::1]:53                  [::]:\*
UNCONN    0         0                    [::1]:323                 [::]:\*
UNCONN    0         0                    [::1]:323                 [::]:\*
#修改配置文件后 重启服务
#123/udp端口是10.0.0.8作为服务端提供时间同步服务给其他公司内部服务器的
#323/udp端口是10.0.0.8作为客户端与阿里云同步的

other server 10.0.0.7故意修改错误时间 进行时间同步

root@7  ~]# yum -y install chrony
root@7  ~]# systemctl enable --now chronyd

root@7  ~]# date
Sat Jan  2 23:50:37 CST 2021
root@7  ~]# date -s '1day'
Sun Jan  3 23:50:43 CST 2021
root@7  ~]# date
Sun Jan  3 23:50:48 CST 2021

root@7  ~]# sed -r '/^(#|$)/d' /etc/chrony.conf
server 10.0.0.8 iburst
driftfile /var/lib/chrony/drift
makestep 1.0 3
rtcsync
logdir /var/log/chrony

root@7  ~]# systemctl restart chronyd

root@7  ~]# chronyc sources -v
210 Number of sources = 1

  .-- Source mode  '^' = server, '=' = peer, '#' = local clock.
 / .- Source state '\*' = current synced, '+' = combined , '-' = not combined,
| /   '?' = unreachable, 'x' = time may be in error, '~' = time too variable.
||                                                 .- xxxx [ yyyy ] +/- zzzz
||      Reachability register (octal) -.           |  xxxx = adjusted offset,
||      Log2(Polling interval) --.      |          |  yyyy = measured offset,
||                                \     |          |  zzzz = estimated error.
||                                 |    |           \
MS Name/IP address         Stratum Poll Reach LastRx Last sample
===============================================================================
^\* 10.0.0.8                      3   6    17     1  -3454ns[ +288us] +/-   23ms

root@7  ~]# date
Sat Jan  2 23:51:31 CST 2021

二、通过命令设置时间同步

获取时区TZ值
要更改 Linux 系统时区首先得获知你所当地时区的 TZ 值,使用 tzselect 命令即可查看并选择已安装的时区文件。
执行 tzselect 命令
在这里插入图片描述
通过向导选择你所在大洲、国家和城市
tzselect 最终将以 Posix TZ 格式(例如 Asia/Shanghai)输出你所在的时区值,将此记录下来。
在这里插入图片描述
更改每个用户的时区
Linux 用户一个多用户系统,每个用户都可以配置自己所需的时区,你可以为自己新增一个 TZ 环境变量:

<strong>export TZ='Asia/Shanghai'</strong>

执行完成之后需要重新登录系统或刷新 ~/.bashrc 生效。

<strong>source ~/.bashrc
</strong>

更改Linux系统时区
要更改 Linux 系统整个系统范围的时区可以使用如下命令:

<strong>sudo rm -f /etc/localtime
sudo ln -s /usr/share/zoneinfo/Asia/Shanghai /etc/localtime</strong>

注意:/usr/share/zoneinfo/Asia/Shanghai 中的具体时区请用自己获取到的 TZ 值进行替换。

使用Systemd更改Linux系统时区
如果你使用的 Linux 系统使用 Systemd,还可以使用 timedatectl 命令来更改 Linux 系统范围的时区。在 Systemd 下有一个名为 systemd-timedated 的系统服务负责调整系统时钟和时区,我们可以使用 timedatectl 命令对此系统服务进行配置。

sudo timedatectl set-timezone 'Asia/Shanghai'

在这里插入图片描述
date 设置时间
用 -s选项可以设置系统时间:

#date -s "20201015 10:10:15"                  #设置具体系统时间
#date           #查看时间和日期

hwclock命令参数:

  • -r, --show 读取并打印硬件时钟(read hardware clock and print result)
  • -s, --hctosys 将硬件时钟同步到系统时钟(set the system time from the hardware clock)
  • -w, --systohc 将系统时钟同步到硬件时钟(set the hardware clock to the current system time)

显示硬件时钟

[root@ ~]# hwclock
2010年11月06日 星期六 21时09分28秒  -0.134840 seconds
[root@~]# hwclock -r
2010年11月06日 星期六 21时09分33秒  -0.469123 seconds
[root@ ~]# hwclock --show
2010年11月06日 星期六 21时09分45秒  -0.127548 seconds

修改日期并同步到硬件时钟

[root@new55 ~]# date
2010年 11月 06日 星期六 21:11:57 CST
[root@new55 ~]# date 11062112     <== 格式 mmddHHMM,即 月日时分
2010年 11月 06日 星期六 21:12:00 CST
[root@new55 ~]# hwclock -w
[root@new55 ~]# hwclock
2010年11月06日 星期六 21时12分13秒  -0.648818 seconds

注:要使系统时间准确,最好还是使用ntp方式。

ntpdate命令是使用NTP协议来从网络同步时间的命令。NTP=Network Time Protocol 网络时间协议。

[root@ ~]# ntpdate 0.rhel.pool.ntp.org
 6 Nov 21:17:55 ntpdate[4829]: step time server 123.146.124.28 offset -1.025258 sec
[root@ ~]# date
2010年 11月 06日 星期六 21:17:59 CST
[root@ ~]# hwclock -w

三、Ubuntu配置Linux的时钟同步

Ubuntu系统默认的时钟同步服务器是ntp.ubuntu.com,Debian则是0.debian.pool.ntp.org等, 各Linux发行版都有自己的NTP官方服务器。身在中国,使用这些都会有高延迟,但对时钟同步这件事来说影响不大。
安装

一般timesync是预装的。如果没有,可以使用以下命令手动安装。

sudo apt install systemd-timesyncd

#它和ntp是冲突的,二者只能安装一个。

配置

修改/etc/systemd/timesyncd.conf,把NTP设为华为内绿区可达的NTP服务器。

[Time]
NTP=ntp7.aliyun.com
NTP=ntp6.aliyun.com

修改完成后,需要restart后这个配置才生效。

sudo systemctl restart systemd-timesyncd.service

如果以上systemd-timesyncd.service因为什么原因而不存在,则可通过以下命令修复:

sudo dpkg-reconfigure systemd-timesyncd

查看效果

一般查看日期与时间是使用date。使用timedatectl可以查看到更多时钟同步相关信息。

$ timedatectl status
               Local time: 二 2020-09-22 20:06:05 CST
           Universal time: 二 2020-09-22 12:06:05 UTC
                 RTC time: 二 2020-09-22 12:06:05
                Time zone: Asia/Shanghai (CST, +0800)
System clock synchronized: yes
              NTP service: active
          RTC in local TZ: no

国内NTP服务器列表

以下给出一些阿里云的NTP列表,可以通过ping择优使用。

ntp1.aliyun.com
ntp2.aliyun.com
ntp3.aliyun.com
ntp4.aliyun.com
ntp5.aliyun.com
ntp6.aliyun.com
ntp7.aliyun.com

四、Ubuntu时区及语言环境设置(亲测)

  1. 修改系统时区设置
dpkg-reconfigure tzdata,选择城市(Shanghai)就可以.

  1. 修改locale(语言)

  2. 修改/var/lib/locales/supported.d/local,直接改成:

zh_CN.UTF-8 UTF-8

  1. dpkg-reconfigure locales
  2. 修改/etc/default/locale:
LANG="zh\_CN.UTF-8"
LANGUAGE="zh\_CN:zh"

  1. reboot

扩展

NTP时间服务器配置

yum install ntp ntpdate -y

NTP服务器监听端口为UDP的123,那就需要在本地防火墙开启运行客户端访问123端口

# vi /etc/sysconfig/iptables

-A INPUT -m state NEW -m udp -p udp --dport 123 -j ACCEPT

修改ntp.conf配置文件

#cp /etc/ntp.conf /etc/ntp.coonf.bak

vi /etc/ntp.conf 只修改如下两行,把#号去掉即可

server 127.127.1.0       # local clock
fudge 127.127.1.0 stratum 10

以守护进程启动ntpd

#/etc/init.d/ntpd start 即可
#ntpq -p

(注意 * : ntpd启动后,客户机要等几分钟再与其进行时间同步,否则回提示"no server suitable for synchronization found"错误。)
配置时间同步客户机

#crontab -e

增加一行,在每天的6点10分与时间同步服务器进行同步

10 06 * * * /usr/sbin/ntpdate ntp-server 的ip >>/usr/local/logs/crontab/ntpdate.log

备注 : 如果客户机没有ntpdate,可以yum -y install ntp即可!
以下是ntp服务器配置文件内容(局域网NTP,如果需要跟外网同步,添加外网server即可)

#driftfile /var/lib/ntp/drift
#restrict default kod nomodify notrap nopeer noquery
restrict -6 default kod nomodify notrap nopeer noquery
restrict 127.0.0.1
restrict -6 ::1
server 127.127.1.0 # local clock
fudge 127.127.1.0 stratum 10
includefile /etc/ntp/crypto/pw
keys /etc/ntp/keys

下面是参数详解:
在这里插入图片描述
自此 NTP 服务搭建完毕,然后在所有客户端 crontab 里面添加如下语句:

0 0 * * * /usr/sbin/ntpdate 10.0.0.155 >>/data/logs/ntp.log 2>&1

NTP 时间服务器安装配置

NTP 服务器监听端口为 UDP 的 123,那就需要在本地防火墙开启运行客户端访问 123
端口,vi /etc/sysconfig/iptables 添加如下规则:

-A INPUT -m state --state NEW -m udp -p udp --dport 123 -j ACCEPT

关闭防火墙的命令:
service stop firewalld
关闭 Selinux 软件服务:
Setenforce 0 临时关闭
Sestatus 查看 selinux 的状态,为 disabled 就 OK 了。

NTP 时间服务器配置:

yum install ntp ntpdate -y 即可!

修改 ntp.conf 配置文件

cp /etp/ntp.conf /etc/ntp.conf.bak
vi /etc/ntp.conf 只修改如下两行,把#号去掉即可!
server 127.127.1.0 # local clock
fudge 127.127.1.0 stratum 10

以守护进程启动 ntpd
/etc/init.d/ntpd start 即可
(注意*: ntpd 启动后,客户机要等几分钟再与其进行时间同步,否则会提示“no server suitable for synchronization found”错误。)

配置时间同步客户机

crontab -e

增加一行,在每天的 6 点 10 分与时间同步服务器进行同步

10  06  \*  \*  \*  /usr/sbin/ntpdate  ntp-server 的
ip >>/usr/local/logs/crontab/ntpdate.log

备注:如果客户机没有 ntpdate,可以 yum –y install ntp 即可!
以下是 ntp 服务器配置文件内容(局域网 NTP,如果需要跟外网同步,添加外网 server 即
可)

driftfile /var/lib/ntp/drift
restrict default kod nomodify notrap nopeer noquery
restrict -6 default kod nomodify notrap nopeer noquery
restrict 127.0.0.1
restrict -6 ::1
server 127.127.1.0 # local clock
fudge 127.127.1.0 stratum 10
includefile /etc/ntp/crypto/pw
keys /etc/ntp/keys

自此 NTP 服务搭建完毕,然后在所有客户端 crontab 里面添加如下语句:

0 0 \* \* \* /usr/sbin/ntpdate 10.0.0.155 >>/data/logs/ntp.log 2>&1

centos修改时区,同步时间

查看当前系统时区

ls -la /etc/localtime

查看支持的时区

timedatectl list-timezones    # 查看所有时区
timedatectl list-timezones | grep Asia  # 查看亚洲时区

修改时区

修改为上海时区

timedatectl set-timezone Asia/Shanghai

查看修改后的时区

timedatectl

在这里插入图片描述
同步时间

安装 ntpdate

yum install ntpdate

查看ntp服务器的时间

ntpdate -q time.windows.com

同步时间

ntpdate time.windows.com

写入硬件时间

查询硬件时间

sudo hwclock -r

把当前时间写入硬件

sudo hwclock -w

Linux服务器时间同步那些事

内外网集群的时间同步①

  • Server端:可以访问外网的机器
  • Client端:在内网里的机器
    一、server端安装ntp校时包,修改独立主机
    rm -rf /etc/localtime #先清除原有的链接文件
    ln -s /usr/share/zoneinfo/Asia/Shanghai /etc/localtime #修改时区到东8区。
    date -R #查看的时区设置。
    接下来调整系统时间与时间服务器同步

Debian系统安装NTP校时包:
代码如下:

apt-get install ntpdate #安装ntp

CentOS系统安装NTP校时包:
代码如下:

yum -y install ntpdate ntp #安装ntp

Ubuntu系统安装NTP校时包:
代码如下:

sudo apt-get install -y ntpdate ntp

二、server端修改/etc/ntp.conf配置文件
编辑 /etc/ntp.conf

server cn.pool.ntp.org
restrict default nomodifynotrapnoquery
restrict 127.0.0.1   # 开启内部递归网络接口 lo
restrict 192.168.9.0 mask 255.255.255.0 nomodify notrap #在内部子网里面的客户端可以 进行网络校时,但不能修改NTP服务器的时间参数

由于配置的是本地时间 ,所以还需要配置一个使用系统时钟作为时间源的NTP服务器,需要在/etc/ntp.conf文件中添加如下的记录

server 127.127.1.0
fudge 127.127.1.0 stratum 10

然后保存退出
接着输入下面的命令:

ntpdate -d cn.pool.ntp.org #调试查看时间差异
ntpdate cn.pool.ntp.org #手动校准系统时间
date -R # 检查时间是否同步

三、server端修改ntpd 的系统配置

vi /etc/sysconfig/ntpd
SYNC_HWCLOCK=yes #同步独立主机的硬件时钟

然后:wq退出

chkconfig --levels 235 ntpd on #配置开机启动ntp服务,定期同步时间
/etc/init.d/ntpd start#启动ntp同步

四、client端配置ntpd服务
注:client端保证与server端的网络通畅
编辑/etc/ntp.conf文件,前面的这两行注释掉

#restrict default kod nomodify notrap nopeer noquery
#restrict -6 default kod nomodify notrap nopeer noquery

#server 0.centos.pool.ntp.org iburst
#server 1.centos.pool.ntp.org iburst
#server 2.centos.pool.ntp.org iburst
#server 3.centos.pool.ntp.org iburst

在里面加上

restrict 服务端地址 nomodify
server 服务端地址 prefer
service ntpd start启动ntpd服务
chkconfig ntpd on 加入开机启动项

五、检查ntpd的工作情况(网络连通性(是否开放了123端口)和同步情况)

ntpq -p查看是否能正确输出
date -R 每台机器查看时间
linux下防火墙规则如果极严格的话可能会影响ntpd对时,打开 sport 123 即可
iptables -I INPUT -p udp -m udp --sport 123 -j ACCEPT

**先自我介绍一下,小编浙江大学毕业,去过华为、字节跳动等大厂,目前在阿里**

**深知大多数程序员,想要提升技能,往往是自己摸索成长,但自己不成体系的自学效果低效又漫长,而且极易碰到天花板技术停滞不前!**

**因此收集整理了一份《2024年最新Linux运维全套学习资料》,初衷也很简单,就是希望能够帮助到想自学提升又不知道该从何学起的朋友。**
![img](https://img-blog.csdnimg.cn/img_convert/a4c6e41b9b9ac7c339d6db62366ef958.png)
![img](https://img-blog.csdnimg.cn/img_convert/01fa643297638d108a8567b63174d62d.png)
![img](https://img-blog.csdnimg.cn/img_convert/aa60d9a693a225570337b8f540ffa293.png)
![img](https://img-blog.csdnimg.cn/img_convert/6fc7d23be700416508f0af61cd174ca5.png)
![img](https://img-blog.csdnimg.cn/img_convert/0b926d6a7ade1fe90df162404c0acc5f.png)

**既有适合小白学习的零基础资料,也有适合3年以上经验的小伙伴深入学习提升的进阶课程,涵盖了95%以上运维知识点,真正体系化!**

**由于文件比较多,这里只是将部分目录截图出来,全套包含大厂面经、学习笔记、源码讲义、实战项目、大纲路线、讲解视频,并且后续会持续更新**

**[需要这份系统化的资料的朋友,可以点击这里获取!](https://bbs.csdn.net/topics/618542503)**

.centos.pool.ntp.org iburst

在里面加上

restrict 服务端地址 nomodify
server 服务端地址 prefer
service ntpd start启动ntpd服务
chkconfig ntpd on 加入开机启动项

五、检查ntpd的工作情况(网络连通性(是否开放了123端口)和同步情况)

ntpq -p查看是否能正确输出
date -R 每台机器查看时间
linux下防火墙规则如果极严格的话可能会影响ntpd对时,打开 sport 123 即可
iptables -I INPUT -p udp -m udp --sport 123 -j ACCEPT

**先自我介绍一下,小编浙江大学毕业,去过华为、字节跳动等大厂,目前在阿里**

**深知大多数程序员,想要提升技能,往往是自己摸索成长,但自己不成体系的自学效果低效又漫长,而且极易碰到天花板技术停滞不前!**

**因此收集整理了一份《2024年最新Linux运维全套学习资料》,初衷也很简单,就是希望能够帮助到想自学提升又不知道该从何学起的朋友。**
[外链图片转存中...(img-EYfBDAYF-1714463545980)]
[外链图片转存中...(img-mkFtibSu-1714463545981)]
[外链图片转存中...(img-KKSRpoSy-1714463545981)]
[外链图片转存中...(img-VvA7Q7vB-1714463545981)]
[外链图片转存中...(img-fFqt3nAq-1714463545982)]

**既有适合小白学习的零基础资料,也有适合3年以上经验的小伙伴深入学习提升的进阶课程,涵盖了95%以上运维知识点,真正体系化!**

**由于文件比较多,这里只是将部分目录截图出来,全套包含大厂面经、学习笔记、源码讲义、实战项目、大纲路线、讲解视频,并且后续会持续更新**

**[需要这份系统化的资料的朋友,可以点击这里获取!](https://bbs.csdn.net/topics/618542503)**

  • 14
    点赞
  • 25
    收藏
    觉得还不错? 一键收藏
  • 0
    评论

“相关推荐”对你有帮助么?

  • 非常没帮助
  • 没帮助
  • 一般
  • 有帮助
  • 非常有帮助
提交
评论
添加红包

请填写红包祝福语或标题

红包个数最小为10个

红包金额最低5元

当前余额3.43前往充值 >
需支付:10.00
成就一亿技术人!
领取后你会自动成为博主和红包主的粉丝 规则
hope_wisdom
发出的红包
实付
使用余额支付
点击重新获取
扫码支付
钱包余额 0

抵扣说明:

1.余额是钱包充值的虚拟货币,按照1:1的比例进行支付金额的抵扣。
2.余额无法直接购买下载,可以购买VIP、付费专栏及课程。

余额充值
