extern “C” JNIEXPORT jboolean JNICALL

Java_com_bailun_kai_rtmplivedemo_RtmpPack2Remote_connectLiveServer(JNIEnv *env, jobject thiz,

jstring url) {

// 首先 Java 的转成 C 的字符串，不然无法使用

const char *live_url = env->GetStringUTFChars(url,0);

int result;

do {

// 结构体对象分配内存

livePack = (LivePack *)(malloc(sizeof(LivePack)));

// 清空内存上的脏数据

memset(livePack,0,sizeof(LivePack));

// Rtmp 申请内存

livePack->rtmp = RTMP_Alloc();

RTMP_Init(livePack->rtmp);

// 设置 rtmp 初始化参数，比如超时时间、url

livePack->rtmp->Link.timeout = 10;

LOGI(“connect %s”, url);

if (!(result = RTMP_SetupURL(livePack->rtmp,(char *)live_url))){

break;

}

// 开启 Rtmp 写入

RTMP_EnableWrite(livePack->rtmp);

LOGI(“RTMP_Connect”);

if (!(result = RTMP_Connect(livePack->rtmp,0))){

break;

}

LOGI("RTMP_ConnectStream ");

if (!(result = RTMP_ConnectStream(livePack->rtmp, 0)))

break;

LOGI(“connect success”);

}while (0);

if (!result && livePack){

free(livePack);

livePack = nullptr;

}

env->ReleaseStringUTFChars(url,live_url);

return result;

}

发送数据到直播服务器

有意思的是，Rtmp 协议中不需要传递分隔符(h264 分隔符为 0 0 0 1),并且推流的第一个 Rtmp 包的内容为 sps、pps 等

// 发送 rtmp 数据到服务器

extern “C”

JNIEXPORT jboolean JNICALL

Java_com_bailun_kai_rtmplivedemo_RtmpPack2Remote_sendData2Server(JNIEnv *env, jobject thiz,

jbyteArray buffer, jint length,

jlong tms) {

int result;

// 拷贝数据

jbyte *bufferArray = env->GetByteArrayElements(buffer, 0);

result = sendDataInner(bufferArray,length,tms);

//释放内存

env->ReleaseByteArrayElements(buffer,bufferArray,0);

return result;

}

int sendDataInner(jbyte *array, jint length, jlong tms) {

int result = 0;

//处理 sps、pps

if (array[4] == 0x67){

// 读取 sps，pps 数据，保存到结构体中

readSpsPps(array,length,livePack);

return result;

}

//处理 I帧，其他帧

if(array[4] == 0x65){

RTMPPacket * spsPpsPacket = createRtmpSteramPack(livePack);

sendPack(spsPpsPacket);

}

RTMPPacket* rtmpPacket = createRtmpPack(array,length,tms,livePack);

result = sendPack(rtmpPacket);

return result;

}

int sendPack(RTMPPacket *pPacket) {

int result = RTMP_SendPacket(livePack->rtmp,pPacket,1);

RTMPPacket_Free(pPacket);

free(pPacket);

return result;

}

// 发送 sps ，pps 对应的 Rtmp 包

RTMPPacket *createRtmpSteramPack(LivePack *pack) {

// 创建 Rtmp 数据包，对应 RtmpDump 库的 RTMPPacket 结构体

int body_size = 16 + pack->sps_len + pack->pps_len;

RTMPPacket *rtmpPacket = static_cast<RTMPPacket *>(malloc(sizeof(RTMPPacket)));

RTMPPacket_Alloc(rtmpPacket,body_size);

int index = 0;

rtmpPacket->m_body[index++] = 0x17;

//AVC sequence header 设置为0x00

rtmpPacket->m_body[index++] = 0x00;

//CompositionTime

rtmpPacket->m_body[index++] = 0x00;

//AVC sequence header

rtmpPacket->m_body[index++] = 0x01;

// 原始操作

rtmpPacket->m_body[index++] = pack->sps[1]; //profile 如baseline、main、 high

rtmpPacket->m_body[index++] = pack->sps[2]; //profile_compatibility 兼容性

rtmpPacket->m_body[index++] = pack->sps[3]; //profile level

rtmpPacket->m_body[index++] = 0xFF;//已经给你规定好了

rtmpPacket->m_body[index++] = 0xE1; //reserved（111） + lengthSizeMinusOne（5位 sps 个数）总是0xe1

//高八位

rtmpPacket->m_body[index++] = (pack->sps_len >> 8) & 0xFF;

// 低八位

rtmpPacket->m_body[index++] = pack->sps_len & 0xff;

// 拷贝sps的内容

memcpy(&rtmpPacket->m_body[index], pack->sps, pack->sps_len);

index +=pack->sps_len;

// pps

rtmpPacket->m_body[index++] = 0x01; //pps number

//rtmp 协议

//pps length

rtmpPacket->m_body[index++] = (pack->pps_len >> 8) & 0xff;

rtmpPacket->m_body[index++] = pack->pps_len & 0xff;

// 拷贝pps内容

memcpy(&rtmpPacket->m_body[index], pack->pps, pack->pps_len);

//packaet

//视频类型

rtmpPacket->m_packetType = RTMP_PACKET_TYPE_VIDEO;

rtmpPacket->m_nBodySize = body_size;

// 视频 04

rtmpPacket->m_nChannel = 0x04;

rtmpPacket->m_nTimeStamp = 0;

rtmpPacket->m_hasAbsTimestamp = 0;

rtmpPacket->m_headerType = RTMP_PACKET_SIZE_LARGE;

rtmpPacket->m_nInfoField2 = livePack->rtmp->m_stream_id;

return rtmpPacket;

}

RTMPPacket *createRtmpPack(jbyte *array, jint length, jlong tms, LivePack *pack) {

array += 4;

RTMPPacket *packet = (RTMPPacket *) malloc(sizeof(RTMPPacket));

int body_size = length + 9;

RTMPPacket_Alloc(packet, body_size);

if (array[0] == 0x65) {

packet->m_body[0] = 0x17;

LOGI(“发送关键帧 data”);

} else{

packet->m_body[0] = 0x27;

LOGI(“发送非关键帧 data”);

}

// 固定的大小

packet->m_body[1] = 0x01;

packet->m_body[2] = 0x00;

packet->m_body[3] = 0x00;

packet->m_body[4] = 0x00;

//长度

packet->m_body[5] = (length >> 24) & 0xff;

packet->m_body[6] = (length >> 16) & 0xff;

packet->m_body[7] = (length >> 8) & 0xff;

packet->m_body[8] = (length) & 0xff;

//数据

memcpy(&packet->m_body[9], array, length);

packet->m_packetType = RTMP_PACKET_TYPE_VIDEO;

packet->m_nBodySize = body_size;

packet->m_nChannel = 0x04;

packet->m_nTimeStamp = tms;

packet->m_hasAbsTimestamp = 0;

packet->m_headerType = RTMP_PACKET_SIZE_LARGE;

packet->m_nInfoField2 = pack->rtmp->m_stream_id;

return packet;

}

void readSpsPps(jbyte *array, jint length, LivePack *pack) {

for (int i = 0; i < length; i++) {

if (i+4 < length){

// 找到 pps 的下标

if (array[i] == 0x00

&& array[i+1] == 0x00

&& array[i+2] == 0x00

&& array[i+3] == 0x01

&& array[i+4] == 0x68

){

// 保存 sps

livePack->sps_len = i - 4;

livePack->sps = static_cast<int8_t *>(malloc(livePack->sps_len));

memcpy(livePack->sps,array + 4,livePack->sps_len);

// 保存 pps

livePack->pps_len = length -(livePack->sps_len+4) - 4;

livePack->pps = static_cast<int8_t *>(malloc(livePack->pps_len));

memcpy(livePack->pps,array+4+livePack->sps_len+4,livePack->pps_len);

LOGI(“sps:%d pps:%d”, livePack->sps_len, livePack->pps_len);

}

指针的使用

malloc 只管分配内存，并不能对所得的内存进行初始化，所以得到的一片新内存中，其值将是随机的，申请的内存是连续的
返回类型是 void* 类型，void* 表示未确定类型的指针。C/C++ 规定，void* 类型可以强制转换为任何其它类型的指针，malloc 函数返回的是 void * 类型，C++：p = malloc (sizeof(int)); 则程序无法通过编译，报错：“不能将 void* 赋值给 int * 类型变量”。所以必须通过 (int *) 来将强制转换
