【OpenStack精选-详解篇】应用Packstack快速部署Open Stack环境、实例创建及安装报错解决、实例控制台VNC访问不了问题解决、open stack版本查看（保姆级教程）

Packstack工具安装OpenStack的原理是通过使用Puppet和Foreman进行自动化配置和管理。Puppet是一个流行的自动化配置工具，它使用一种声明式的语言来描述系统的配置状态，然后自动将系统配置为所需的状态。Foreman是一个开源的基础架构自动化管理工具，它提供了一个用户友好的Web界面，用于管理和监控系统的配置。

二、Packstack工具安装OpenStack的原理

在Packstack安装过程中，首先会检测系统的配置和环境，确保满足部署OpenStack所需的最低要求。然后，Packstack会根据用户选择的选项和配置文件，使用Puppet来安装和配置OpenStack各个组件，包括计算节点、网络节点、存储节点等。Puppet会根据预先定义的配置模板，自动下载和安装所需的软件包，并进行相应的配置和参数设置。

Packstack还会使用Foreman来监控和管理OpenStack的配置状态。Foreman提供了一个用户友好的Web界面，在这里用户可以查看和管理系统的配置信息，如虚拟机和网络的状态等。通过Foreman，用户可以方便地进行OpenStack的管理和维护工作。

总结起来，Packstack利用Puppet和Foreman实现了对OpenStack的自动化安装和配置。它通过使用预定义的配置模板和参数，自动下载和安装所需的软件包，并进行相应的配置和设置。通过Foreman，用户可以方便地监控和管理OpenStack的配置状态。这样，用户可以快速搭建起一个功能完整的OpenStack私有云环境。

在CentOS7下使用packstack快速部署OpenStack是一个高效的方法，可以帮助我们快速设置一个概念验证（PoC）环境。Packstack是一个命令行工具，使用Python封装了Puppet模块，通过SSH在服务器上部署OpenStack。下面将介绍详细的安装和配置过程。

三、使用PackStack工具安装Open Stack

1、环境准备

以下是我对虚拟机环境的设置

像内存最好是10G往上最好，避免后续不必要的麻烦

操作系统版本	硬件配置	虚拟机IP地址	主机名	OpenStack版本
centos7.9	4vCPUS/10.6G 100G硬盘	192.168.126.5/24	openstack	Stein

环境准备好后，配置虚拟机网络

2、配置网络连接

#以下是我的网络配置环境，根据自己实际情况修改即可
cat /etc/sysconfig/network-scripts/ifcfg-ens160
BOOTPROTO=static
ONBOOT=yes
IPADDR=192.168.126.5
NETMASK=255.255.255.0
GATEWAY=192.168.126.2
DNS1=192.168.126.2
DNS2=223.5.5.5

用连接工具XShell进行连接

3、修改主机名

[root@localhost ~]# hostnamectl set-hostname openstack

[root@localhost ~]# 登出 #Ctrl+D，重新连接主机名生效

连接断开

连接主机...

连接主机成功

Last login: Tue Jun 18 15:06:25 2024 from 192.168.126.1

[root@openstack ~]#

查看主机IP

[root@openstack ~]# hostname -I

192.168.126.5

[root@openstack ~]# ip addr show

4、配置主机映射

#写入hosts文件

[root@openstack ~]# cat >> /etc/hosts << EOF

> 192.168.126.5 openstack

> EOF

#查看

[root@openstack ~]# more /etc/hosts

127.0.0.1 localhost localhost.localdomain localhost4 localhost4.localdomain4

::1 localhost localhost.localdomain localhost6 localhost6.localdomain6

192.168.126.5 openstack

#直接ping主机名测试

[root@openstack ~]# ping -c1 openstack

PING openstack (192.168.126.5) 56(84) bytes of data.

64 bytes from openstack (192.168.126.5): icmp_seq=1 ttl=64 time=0.024 ms

--- openstack ping statistics ---

1 packets transmitted, 1 received, 0% packet loss, time 0ms

rtt min/avg/max/mdev = 0.024/0.024/0.024/0.000 ms

5、设置SHH免密登录

#ssh-keygen命令能够对SSH密钥文件进行生成、管理、转换等工作，支持RSA和DSA两种密钥格式。

#创建一个SSH密钥文件，产生公钥与私钥对

[root@openstack ~]# ssh-keygen

Generating public/private rsa key pair.

Enter file in which to save the key (/root/.ssh/id_rsa): #直接回车，以默认路径保存

Created directory '/root/.ssh'.

Enter passphrase (empty for no passphrase): #直接回车，不额外设置密钥密码

Enter same passphrase again: #直接回车，确认不额外设置密钥密码

Your identification has been saved in /root/.ssh/id_rsa.

Your public key has been saved in /root/.ssh/id_rsa.pub.

The key fingerprint is:

SHA256:8t20um6vL6B2yWC0i8e9cFtMsQFiONMWVl9Fj9IEkwk root@openstack

The key's randomart image is:

+---[RSA 2048]----+

|     o=oo E.+*+ |

|    +oo. o .o+ o |

|     +    + . o .|

|      .    + .   |

|     ...S o .    |

|      +o.+ o .   |

|     +.*oo+ o    |

|    . *o=oo.     |

|     o .o+=*o    |

+----[SHA256]-----+

#将本机的公钥复制到远程机器的authorized_keys文件中

[root@openstack ~]# ssh-copy-id root@192.168.126.5

/usr/bin/ssh-copy-id: INFO: Source of key(s) to be installed: "/root/.ssh/id_rsa.pub"

The authenticity of host '192.168.126.5 (192.168.126.5)' can't be established.

ECDSA key fingerprint is SHA256:3xs/VVcVIUX5Qb6MsY3bwCCOhfS9wLOv+MyIkv5xHSs.

ECDSA key fingerprint is MD5:8f:09:ad:95:04:bf:d3:b3:9e:41:7f:7a:b2:7a:ce:95.

Are you sure you want to continue connecting (yes/no)? yes #输入yes,确认继续连接

/usr/bin/ssh-copy-id: INFO: attempting to log in with the new key(s), to filter out any that are already installed

/usr/bin/ssh-copy-id: INFO: 1 key(s) remain to be installed -- if you are prompted now it is to install the new keys

root@192.168.126.5's password:

Number of key(s) added: 1

Now try logging into the machine, with: "ssh 'root@192.168.126.5'"

and check to make sure that only the key(s) you wanted were added.

6、关闭防火墙、selinux、NetworkManager服务

同时关闭禁用NetworkManager和firewalld，最后重启network服务以更新网络设置

#关闭禁用防火墙

[root@openstack ~]# systemctl stop firewalld

[root@openstack ~]# systemctl disable firewalld

Removed symlink /etc/systemd/system/multi-user.target.wants/firewalld.service.

Removed symlink /etc/systemd/system/dbus-org.fedoraproject.FirewallD1.service.

#临时禁用selinux（这个作用是不用重启系统）

[root@openstack ~]# setenforce 0

#永久禁用selinux

[root@openstack ~]# sed -i 's/SELINUX=.*/SELINUX=disabled/g' /etc/selinux/config

#关闭禁用NetworkManager

[root@openstack ~]# systemctl stop NetworkManager

[root@openstack ~]# systemctl disable NetworkManager

Removed symlink /etc/systemd/system/multi-user.target.wants/NetworkManager.service.

Removed symlink /etc/systemd/system/dbus-org.freedesktop.nm-dispatcher.service.

Removed symlink /etc/systemd/system/network-online.target.wants/NetworkManager-wait-online.service.

#查看NetworkManage状态，确认关闭

[root@openstack ~]# systemctl status NetworkManager

● NetworkManager.service - Network Manager

   Loaded: loaded (/usr/lib/systemd/system/NetworkManager.service; disabled; vendor preset: enabled)

   Active: inactive (dead) since 二 2024-06-18 16:07:13 CST; 21s ago

     Docs: man:NetworkManager(8)

Main PID: 1070 (code=exited, status=0/SUCCESS)

#重启网络

[root@openstack ~]# systemctl restart network

7、获取网络yum源

清空系统默认的yum源

#可以做一个备份(推荐)
mkdir /opt/yum.repo.bak
mv /etc/yum.repos.d/*  /opt/yum.repo.bak

#或者

#直接删除
rm -rf /etc/yum.repos.d/*

#拉取网络yum源

[root@openstack ~]# curl -o /etc/yum.repos.d/CentOS-Base.repo https://mirrors.aliyun.com/repo/Centos-7.repo

[root@openstack ~]# curl -o /etc/yum.repos.d/epel.repo https://mirrors.aliyun.com/repo/epel-7.repo

8、安装常用软件

#这些软件默认是安装的，也可以安装确认一下

#bash-completion，指令自动补全

#yum-utils，这是一个与 yum 集成的实用程序集合，可以通过多种方式扩展其本机功能，从而使其更强大且更易于使用

[root@openstack ~]# yum -y install bash-completion yum-utils

9、安装OpenStack stein的yum库

[root@openstack ~]# yum -y install centos-release-openstack-stein

#安装后做一个做一个yum源备份

[root@openstack ~]# cp /etc/yum.repos.d/CentOS-OpenStack-stein.repo /etc/yum.repos.d/CentOS-OpenStack-stein.repo.bak

#修改yum源文件

[root@openstack ~]# vi /etc/yum.repos.d/CentOS-OpenStack-stein.repo

[centos-openstack-stein]

name=CentOS-7 - OpenStack stein

baseurl=http://mirror.centos.org/$contentdir/$releasever/cloud/$basearch/openstack-stein/ #取消注释，访问该源路径

#mirrorlist=http://mirrorlist.centos.org/?release=$releasever&arch=$basearch&repo=cloud-openstack-stein #将其注释

#清理 YUM 缓存中的所有数据

[root@openstack ~]# yum clean all

#生成软件包的元数据缓存，这可以提升后续使用yum进行软件包安装、更新等操作的速度，因为系统可以直接访问本地的元数据缓存，而不是每次都从远程仓库下载

[root@openstack ~]# yum makecache

10、安装packstack软件包工具

[root@openstack ~]# yum -y install openstack-packstack

四、运行Packstack

1、快速运行Packstack

在终端中执行packstack --allinone命令以快速运行Packstack，安装OpenStack allinone，这将使用默认配置在服务器上部署All-in-One的OpenStack环境。Packstack将自动安装所有必需的组件并配置它们。完成安装后，可以通过浏览器访问OpenStack的控制面板。

#快速运行Packstack

[root@openstack ~]# packstack --allinone

Welcome to the Packstack setup utility

The installation log file is available at: /var/tmp/packstack/20240618-165356-f3rnEs/openstack-setup.log

Installing:

Clean Up                                             [ DONE ]

Discovering ip protocol version                      [ DONE ]

Setting up ssh keys                                  [ DONE ]

Preparing servers                                    [ DONE ]

Pre installing Puppet and discovering hosts' details[ ERROR ]

ERROR : Failed to run remote script, stdout:

stderr: Warning: Permanently added '192.168.126.5' (ECDSA) to the list of known hosts.

+ trap t ERR

+ facter -p

facter: error while loading shared libraries: leatherman_curl.so.1.3.0: cannot open shared object file: No such file or directory

++ t

++ exit 127

Please check log file /var/tmp/packstack/20240618-165356-f3rnEs/openstack-setup.log for more information

Additional information:

* Parameter CONFIG_NEUTRON_L2_AGENT: You have choosen OVN neutron backend. Note that this backend does not support LBaaS, VPNaaS or FWaaS services. Geneve will be used as encapsulation method for tenant networks

#报错1

根据报错内容

facter: error while loading shared libraries: leatherman_curl.so.1.3.0: cannot open shared object file: No such file or directory

#查看是否有该软件包，有改软件包，这是我就搞不明白了

[root@openstack ~]# yum list | grep leatherman

leatherman.x86_64 1.10.0-1.el7 @epel

leatherman-devel.x86_64 1.10.0-1.el7 epel

在网上查看了许多教程，原因可能是 leatherman 版本问题。

#该软件包确实有的，但是版本不一致，这里回退 leatherman版本

#解决

[root@openstack ~]# yum downgrade leatherman -y

###########################这里我又想起来由于我没有开启虚拟机的虚拟化，将虚拟机关机打开虚拟化，如果在安装之前没有开启虚拟化也会成为错误原因#########################

再次运行packstack --allinone命令，又报错咱也是好脾气，遇到问题我不急

#报错2

[root@openstack ~]# packstack --allinone

Applying 192.168.126.5_controller.pp

192.168.126.5_controller.pp: [ ERROR ]

Applying Puppet manifests [ ERROR ]

ERROR : Error appeared during Puppet run: 192.168.126.5_controller.pp

Error: Execution of '/usr/bin/yum -d 0 -e 0 -y install openstack-keystone' returned 1: Error: Package: python2-qpid-proton-0.22.0-1.el7.x86_64 (centos-openstack-stein)

You will find full trace in log /var/tmp/packstack/20240619-081925-vVLNr9/manifests/192.168.126.5_controller.pp.log

Please check log file /var/tmp/packstack/20240619-081925-vVLNr9/openstack-setup.log for more information

Additional information:

* Parameter CONFIG_NEUTRON_L2_AGENT: You have choosen OVN neutron backend. Note that this backend does not support LBaaS, VPNaaS or FWaaS services. Geneve will be used as encapsulation method for tenant networks

* A new answerfile was created in: /root/packstack-answers-20240619-081926.txt

* Time synchronization installation was skipped. Please note that unsynchronized time on server instances might be problem for some OpenStack components.

* File /root/keystonerc_admin has been created on OpenStack client host 192.168.126.5. To use the command line tools you need to source the file.

* To access the OpenStack Dashboard browse to http://192.168.126.5/dashboard .

Please, find your login credentials stored in the keystonerc_admin in your home directory.

根据报错内容

Error: Execution of '/usr/bin/yum -d 0 -e 0 -y install openstack-keystone' returned 1: Error: Package: python2-qpid-proton-0.22.0-1.el7.x86_64 (centos-openstack-stein)

原因：缺失软件包

#解决

#安装依赖软件包

[root@openstack ~]# yum -y install PackageKit-backend

[root@openstack ~]# yum -y install yum-utils

[root@openstack ~]# yum install -y qpid-proton-c-0.22.0-1.el7.x86_64

#安装软件包

[root@openstack ~]# yum -y install openstack-keystone

#成功

①、再次运行packstack --allinone命令，终于成功啦，这一步正常运行时间会久一点，泡杯茶等会

[root@openstack ~]# packstack --allinone

Welcome to the Packstack setup utility

The installation log file is available at: /var/tmp/packstack/20240619-085043-RWK76v/openstack-setup.log

Installing:

Clean Up                                             [ DONE ]

Discovering ip protocol version                      [ DONE ]

Setting up ssh keys                                  [ DONE ]

Preparing servers                                    [ DONE ]

Pre installing Puppet and discovering hosts' details [ DONE ]

Preparing pre-install entries                        [ DONE ]

Setting up CACERT                                    [ DONE ]

Preparing AMQP entries                               [ DONE ]

Preparing MariaDB entries                            [ DONE ]

Fixing Keystone LDAP config parameters to be undef if empty[ DONE ]

Preparing Keystone entries                           [ DONE ]

Preparing Glance entries                             [ DONE ]

Checking if the Cinder server has a cinder-volumes vg[ DONE ]

Preparing Cinder entries                             [ DONE ]

Preparing Nova API entries                           [ DONE ]

Creating ssh keys for Nova migration                 [ DONE ]

Gathering ssh host keys for Nova migration           [ DONE ]

Preparing Nova Compute entries                       [ DONE ]

Preparing Nova Scheduler entries                     [ DONE ]

Preparing Nova VNC Proxy entries                     [ DONE ]

Preparing OpenStack Network-related Nova entries     [ DONE ]

Preparing Nova Common entries                        [ DONE ]

Preparing Neutron LBaaS Agent entries                [ DONE ]

Preparing Neutron API entries                        [ DONE ]

Preparing Neutron L3 entries                         [ DONE ]

Preparing Neutron L2 Agent entries                   [ DONE ]

Preparing Neutron DHCP Agent entries                 [ DONE ]

Preparing Neutron Metering Agent entries             [ DONE ]

Checking if NetworkManager is enabled and running    [ DONE ]

Preparing OpenStack Client entries                   [ DONE ]

Preparing Horizon entries                            [ DONE ]

Preparing Swift builder entries                      [ DONE ]

Preparing Swift proxy entries                        [ DONE ]

Preparing Swift storage entries                      [ DONE ]

Preparing Gnocchi entries                            [ DONE ]

Preparing Redis entries                              [ DONE ]

Preparing Ceilometer entries                         [ DONE ]

Preparing Aodh entries                               [ DONE ]

Preparing Puppet manifests                           [ DONE ]

Copying Puppet modules and manifests                 [ DONE ]

Applying 192.168.126.5_controller.pp

192.168.126.5_controller.pp:                         [ DONE ]

Applying 192.168.126.5_network.pp

192.168.126.5_network.pp:                            [ DONE ]

Applying 192.168.126.5_compute.pp

192.168.126.5_compute.pp:                            [ DONE ]

Applying Puppet manifests                            [ DONE ]

Finalizing                                           [ DONE ]

**** Installation completed successfully ******

#这个说我们安装成功啦！

Additional information:

* Parameter CONFIG_NEUTRON_L2_AGENT: You have choosen OVN neutron backend. Note that this backend does not support LBaaS, VPNaaS or FWaaS services. Geneve will be used as encapsulation method for tenant networks

* A new answerfile was created in: /root/packstack-answers-20240619-085043.txt

* Time synchronization installation was skipped. Please note that unsynchronized time on server instances might be problem for some OpenStack components.

* File /root/keystonerc_admin has been created on OpenStack client host 192.168.126.5. To use the command line tools you need to source the file.

* To access the OpenStack Dashboard browse to http://192.168.126.5/dashboard .

Please, find your login credentials stored in the keystonerc_admin in your home directory.

* The installation log file is available at: /var/tmp/packstack/20240619-085043-RWK76v/openstack-setup.log

* The generated manifests are available at: /var/tmp/packstack/20240619-085043-RWK76v/manifests

②、查看Dashboard web页面的登录账号和密码

http://192.168.126.5/dashboard为OpenStack的登录地址（根据自己主机IP访问）

/root/keystonerc_admin文件是存放登录用户名和密码。

#查看用户名和密码username、password

[root@openstack ~]# cat keystonerc_admin

unset OS_SERVICE_TOKEN

    export OS_USERNAME=admin                                 #Dashboard登录账号

    export OS_PASSWORD='63d66fdb08cf4c5c'   #Dashboard登录密码

    export OS_REGION_NAME=RegionOne

    export OS_AUTH_URL=http://192.168.126.5:5000/v3

    export PS1='[\u@\h \W(keystone_admin)]\$ '



export OS_PROJECT_NAME=admin

export OS_USER_DOMAIN_NAME=Default

export OS_PROJECT_DOMAIN_NAME=Default

export OS_IDENTITY_API_VERSION=3

③、Dashboard web登录界面

④、修改密码

登录的随机密码确实记不住呀，我是不愿意老是复制密码，复制密码这件事我只做一次！！！登录后第一件事我就是修改密码，右上角设置，修改密码

修改完成后，重新登录即可

⑤、修改配置

为了保证后续的步骤能成功进行，需要修改一下keystonerc_admin文件中的OS_PASSWORD变量，换成自己设置的新密码

[root@openstack ~]# vi keystonerc_admin

export OS_PASSWORD='000000'

补充

2、交互式运行Packstack

如果我们要更加灵活地配置OpenStack环境，可以使用交互式模式运行Packstack

#生成配置文件

[root@openstack ~]# packstack --gen-answer-file=answerfile.txt

这将生成一个包含所有配置选项的answerfile.txt文件。然后可以编辑该文件以自定义的OpenStack部署。完成编辑后，指定文件继续安装

[root@openstack ~]# packstack --answer-file=answerfile.txt

3、非交互式运行Packstack

如果我们要在脚本中自动化部署过程，可以使用非交互式模式运行Packstack。首先，创建一个包含所有必需参数的配置文件（例如config.txt）

[root@openstack ~]# packstack --config=config.txt

这将根据配置文件中指定的参数自动部署OpenStack环境。要注意的是，需要在配置文件中指定所有必需的参数，以便正确配置OpenStack组件

五、创建OpenStack实例

网络这些其实是已经创建好了的(我就懒得创建的，用它原有的就行了，当然也可以删除自己去创建，后面我给大家说明一下创建方法) 步骤10已讲解大家可以删除原有的外网自行创建（推荐）

网络

172.24.4.0/24段为已有外网

路由

路由接口

1、创建路由

这边需要新建一个路由，因为已有的路由所属的项目为demo，我们要创建一个所属项目为admin的路由

管理员--->网络--->路由--->新建路由

2、新建内网网络

新建一个内网网络

项目--->网络---->网络--->创建网络

3、新增所属admin的route这个内网接口

项目--->网络--->路由--->点击route--->接口--->增加接口

确认 ping 路由固定IP，如果 ping 不通路由，说明网络配置有误

[root@openstack ~]# ping -c4 172.24.4.98

PING 172.24.4.98 (172.24.4.98) 56(84) bytes of data.

64 bytes from 172.24.4.98: icmp_seq=1 ttl=254 time=6.51 ms

64 bytes from 172.24.4.98: icmp_seq=2 ttl=254 time=0.186 ms

64 bytes from 172.24.4.98: icmp_seq=3 ttl=254 time=0.218 ms

64 bytes from 172.24.4.98: icmp_seq=4 ttl=254 time=0.205 ms

--- 172.24.4.98 ping statistics ---

4 packets transmitted, 4 received, 0% packet loss, time 3001ms

rtt min/avg/max/mdev = 0.186/1.780/6.512/2.732 ms

4、查看网络拓扑

5、安全组

这边安全组我使用默认

6、拉取上传镜像

#拉取镜像
wget  https://download.cirros-cloud.net/0.5.2/cirros-0.5.2-x86_64-disk.img

#生效环境变量

[root@openstack ~(keystone_admin)]# source keystonerc_admin

#上传镜像到OpenStack

openstack image create "cirros_1" --file cirros-0.5.2-x86_64-disk.img --disk-format qcow2 --container-format bare --public

7、创建实例

项目--->计算--->实例--->创建实例

#查看所有实例

[root@openstack ~(keystone_admin)]# virsh list --all

Id 名称状态

----------------------------------------------------

1 instance-00000003 running

8、分配浮动IP

浮动IP讲解

公网用于和外界通信，这里的公网也就是外部网络使用了默认的172.24.4.0/24的网段（宿主机可以连接wifi上网），就比如在华为云中，公网的IP就是真实可上网的地址，需要我们去花钱购买才能使用（这个也就是我们这里的浮动IP）；

而私网用于租户内部之间的通信，可以由我们用户自行分配，且数量不限；

而路由器用于连接公网和私网，如果内部主机想要上网，需要通过路由器来进行转发。

OpenStack中的浮动IP（Floating IP）是一个公共的IP地址，用于将虚拟机（实例）与外部网络连接起来。浮动IP允许外部网络通过互联网访问虚拟机，在虚拟机与外部网络之间建立网络连接。

在OpenStack中，每个项目（tenant）可以分配一定数量的浮动IP地址。浮动IP地址是从云提供商的公共IP地址池中分配的，可以在不同的虚拟机间进行动态分配和释放。

浮动IP的作用是将真实世界的IP地址映射到虚拟机的内部IP地址。这样，虚拟机就可以通过浮动IP地址与外部网络通信，接收来自外部网络的请求和流量。浮动IP解决了虚拟机内部IP地址无法直接从外部网络访问的问题。

使用浮动IP可以实现以下功能：

允许外部网络通过互联网访问虚拟机。
允许虚拟机主动与外部网络通信。
支持负载均衡和高可用性，通过将浮动IP绑定到多个虚拟机实现请求的分发和故障转移。

要使用浮动IP，首先需要创建一个浮动IP池（Floating IP Pool），并从该池中分配浮动IP地址给虚拟机。然后，将浮动IP地址绑定到虚拟机的网络接口上。这样，虚拟机就可以使用浮动IP地址与外部网络进行通信。

总结起来，OpenStack中的浮动IP是一个公共的IP地址，用于将虚拟机与外部网络连接起来。它允许外部网络通过互联网访问虚拟机，并实现负载均衡和高可用性。使用浮动IP需要创建一个浮动IP池，并将浮动IP地址绑定到虚拟机的网络接口上。

绑定浮动IP（必须绑定否则连接虚拟机不上）

#Ping浮动IP，可以ping通，说明能使用

[root@openstack ~]# ping -c4 172.24.4.7

PING 172.24.4.7 (172.24.4.7) 56(84) bytes of data.

64 bytes from 172.24.4.7: icmp_seq=1 ttl=63 time=0.754 ms

64 bytes from 172.24.4.7: icmp_seq=2 ttl=63 time=0.526 ms

64 bytes from 172.24.4.7: icmp_seq=3 ttl=63 time=0.440 ms

64 bytes from 172.24.4.7: icmp_seq=4 ttl=63 time=0.362 ms

9、连接登陆到该实例

这个镜像的用户名和密码

user:cirros

pass:'gocubsgo'

[root@openstack ~]# virsh console instance-00000003

连接到域 instance-00000003

换码符为 ^]

login as 'cirros' user. default password: 'gocubsgo'. use 'sudo' for root.

try login: cirros

Password:

$ ifconfig

eth0      Link encap:Ethernet HWaddr FA:16:3E:72:36:B4

          inet addr:11.12.13.155 Bcast:11.12.13.255 Mask:255.255.255.0

          inet6 addr: fe80::f816:3eff:fe72:36b4/64 Scope:Link

          UP BROADCAST RUNNING MULTICAST MTU:1442 Metric:1

          RX packets:77 errors:0 dropped:0 overruns:0 frame:0

          TX packets:131 errors:0 dropped:0 overruns:0 carrier:0

          collisions:0 txqueuelen:1000

          RX bytes:8364 (8.1 KiB) TX bytes:11626 (11.3 KiB)

lo        Link encap:Local Loopback

          inet addr:127.0.0.1 Mask:255.0.0.0

          inet6 addr: ::1/128 Scope:Host

          UP LOOPBACK RUNNING MTU:65536 Metric:1

          RX packets:0 errors:0 dropped:0 overruns:0 frame:0

          TX packets:0 errors:0 dropped:0 overruns:0 carrier:0

          collisions:0 txqueuelen:1000

          RX bytes:0 (0.0 B) TX bytes:0 (0.0 B)

Ping宿主机

$ ping -c4 192.168.126.5

PING 192.168.126.5 (192.168.126.5): 56 data bytes

64 bytes from 192.168.126.5: seq=0 ttl=63 time=21.242 ms

64 bytes from 192.168.126.5: seq=1 ttl=63 time=0.871 ms

64 bytes from 192.168.126.5: seq=2 ttl=63 time=0.775 ms

64 bytes from 192.168.126.5: seq=3 ttl=63 time=1.417 ms

--- 192.168.126.5 ping statistics ---

4 packets transmitted, 4 packets received, 0% packet loss

round-trip min/avg/max = 0.775/6.076/21.242 ms

#这里面大家也可以去ping一下浮动IP，我就不展示了

SSH方式登录

[root@openstack ~]# ssh root@172.24.4.7

The authenticity of host '172.24.4.7 (172.24.4.7)' can't be established.

ECDSA key fingerprint is SHA256:KigVju46uVM69MctBwJdN/lsZeFBCy2DUG6TJRNjfMs.

ECDSA key fingerprint is MD5:21:8e:46:99:44:5b:4f:87:12:f5:91:ec:98:45:95:d5.

Are you sure you want to continue connecting (yes/no)? yes

Warning: Permanently added '172.24.4.7' (ECDSA) to the list of known hosts.

cirros@172.24.4.7's password:

$ ifconfig

eth0      Link encap:Ethernet HWaddr FA:16:3E:72:36:B4

          inet addr:11.12.13.155 Bcast:11.12.13.255 Mask:255.255.255.0

          inet6 addr: fe80::f816:3eff:fe72:36b4/64 Scope:Link

          UP BROADCAST RUNNING MULTICAST MTU:1442 Metric:1

          RX packets:165 errors:0 dropped:0 overruns:0 frame:0

          TX packets:220 errors:0 dropped:0 overruns:0 carrier:0

          collisions:0 txqueuelen:1000

          RX bytes:20134 (19.6 KiB) TX bytes:20740 (20.2 KiB)

lo        Link encap:Local Loopback

          inet addr:127.0.0.1 Mask:255.0.0.0

          inet6 addr: ::1/128 Scope:Host

          UP LOOPBACK RUNNING MTU:65536 Metric:1

          RX packets:0 errors:0 dropped:0 overruns:0 frame:0

          TX packets:0 errors:0 dropped:0 overruns:0 carrier:0

          collisions:0 txqueuelen:1000

          RX bytes:0 (0.0 B) TX bytes:0 (0.0 B)

10、自己创建外部网络方法

上面给大家说了不使用它原有的外部网络，自己创建外部网络，其实和创建内网差不多

先把之前原有的外部网络删除

项目--->网络---->网络--->创建网络

IP使用宿主机的网段

创建好进行下一步操作

管理员--->网络--->网络--->编辑网络--->勾选外部网络

即创建外部网络完成！

六、无法访问实例控制台问题

无法显示！！！

解决

#修改配置文件

[root@openstack ~]# vi /etc/nova/nova.conf

enabled=True

novncproxy_base_url=http://192.168.126.5:6080/vnc_auto.html

vncserver_proxyclient_address=192.168.126.5

vncserver_listen=0.0.0.0

#查看日志文件/var/log/nova/nova-novncproxy.log

[root@openstack ~]# cat /var/log/nova/nova-novncproxy.log

2024-06-19 09:11:22.440 9690 INFO nova.console.websocketproxy [-] WebSocket server settings:

2024-06-19 09:11:22.440 9690 INFO nova.console.websocketproxy [-]   - Listen on 0.0.0.0:6080

2024-06-19 09:11:22.440 9690 INFO nova.console.websocketproxy [-]   - Flash security policy server

2024-06-19 09:11:22.440 9690 INFO nova.console.websocketproxy [-]   - Web server (no directory listings). Web root: /usr/share/novnc

2024-06-19 09:11:22.440 9690 INFO nova.console.websocketproxy [-]   - No SSL/TLS support (no cert file)

2024-06-19 09:11:22.441 9690 INFO nova.console.websocketproxy [-]   - proxying from 0.0.0.0:6080 to None:None

2024-06-19 11:28:17.938 24871 INFO nova.console.websocketproxy [-] 192.168.126.1 - - [19/Jun/2024 11:28:17] code 400, message Client must support 'binary' or 'base64' protocol

2024-06-19 11:28:56.200 25706 INFO nova.console.websocketproxy [-] 192.168.126.1 - - [19/Jun/2024 11:28:56] code 404, message File not found

2024-06-19 11:28:56.288 25709 INFO nova.console.websocketproxy [-] 192.168.126.1 - - [19/Jun/2024 11:28:56] code 400, message Client must support 'binary' or 'base64' protocol

可以看到出现： Code 400, message Client must support ‘binary’ or ‘base64’

原因：这是因为协议有问题，需编辑 /usr/share/novnc/core/websock.js文件，加入‘binary’ or ‘base64’协议即可

[root@openstack ~]# vi /usr/share/novnc/core/websock.js

#原配置

open(uri, protocols) {

this.attach(new WebSocket(uri, protocols, binary, base64));

#修改配置

    open(uri, protocols) {

        this.attach(new WebSocket(uri,['binary','base64']));

    }

#重启服务

[root@openstack ~]# systemctl restart openstack-nova-novncproxy.service

[root@openstack ~]# systemctl restart openstack-nova-*

再次访问控制台

首先清一下浏览器缓存

清除浏览器数据

成功打开控制台

七、查看OpenStack版本

我们老是说OpenStackT版、M版的等等那到底咋查看呢?

让我们一起探索一下！

#查看OpenStack版本

[root@openstack ~]# openstack --version
openstack 3.18.1

#过滤出安装的nova服务的版本，可以看到nova版本是19.3.2
[root@openstack ~]# rpm -qa | grep nova
openstack-nova-novncproxy-19.3.2-1.el7.noarch
openstack-nova-common-19.3.2-1.el7.noarch
openstack-nova-conductor-19.3.2-1.el7.noarch
openstack-nova-migration-19.3.2-1.el7.noarch
openstack-nova-placement-api-19.3.2-1.el7.noarch
openstack-nova-console-19.3.2-1.el7.noarch
openstack-nova-compute-19.3.2-1.el7.noarch
openstack-nova-api-19.3.2-1.el7.noarch
python2-novaclient-13.0.2-1.el7.noarch
openstack-nova-scheduler-19.3.2-1.el7.noarch
puppet-nova-14.4.0-1.el7.noarch
python2-nova-19.3.2-1.el7.noarch

对照OpenStack官网，点击版本进行查看，看看nova的版本与哪个OpenStack版本对应就好了

OpenStack官网

可以看到与Stein版本一致，也就是S版啦！！！

至此，使用Packstack在CentOS7下快速部署OpenStack是一个简单而高效的方法完成！通过准备系统环境、安装Packstack、选择运行模式并根据实际情况进行配置，可以成功地设置一个概念验证（PoC）环境用于测试和评估OpenStack。还要注意的是，得确保系统资源充足并解决潜在问题以避免部署失败！

最好，大家在遇到问题时要学会看日志分析，去尝试解决问题，我们总是在解决问题中成长学习的，它印象会让我们更深刻，大家一起加油！

SC_CSDN_L

关注

9
点赞
踩
21

收藏

觉得还不错? 一键收藏
3
评论
【OpenStack精选-详解篇】应用Packstack快速部署Open Stack环境、实例创建及安装报错解决、实例控制台VNC访问不了问题解决、open stack版本查看（保姆级教程）

Packstack是一个用于快速部署OpenStack云平台的工具。它基于Puppet和Foreman，能够自动化配置和管理OpenStack的各个组件。Packstack可以简化OpenStack的安装过程，让用户能够快速搭建起一个功能完整的私有云环境。Packstack提供了一个交互式的命令行界面，用户可以通过简单的命令完成OpenStack的安装。它会自动安装和配置OpenStack的各个组件，包括计算节点、网络节点、存储节点等。用户只需要按照提示进行一些基本选项的配置，就可以完成整个安装过程。
复制链接

扫一扫
