前面讲了windows系统下opencv+opencv的编译方法，编译方法和编译好的文件如下：

Windows下联合编译opencv+opencv_contrib微信二维码引擎

OpenCV4.5.2（windows for java）

这次讲下微信二维码引擎的使用方法，为了方便使用，不需要手动添加dll等，对jar、dll、微信配置文件做了集成，重新编译了jar。这个是windows下的，如果要在linux下使用，需要在config下加入对应的so。重新编译的jar如下：

含微信二维码引擎的重编译opencv-452.jar

具体新增如下：
在这里插入图片描述                 在这里插入图片描述
1.把jar添加到项目后，调用Config.load();自动加载dll和微信配置文件。
2.img2mat和mat2img是封装好的图片和Mat转换方法，默认图片格式img为BufferedImage.TYPE_3BYTE_BGR（imgType），mat为CvType.CV_8UC3（matType），通过setType(int imgType, int matType)可进行修改，每调用一次转换方法type值会重置为默认值。

下面以具体例子讲解下使用方法：

package vqb;

import java.awt.Color;
import java.awt.Font;
import java.awt.Graphics2D;
import java.awt.image.BufferedImage;
import java.util.ArrayList;
import java.util.List;

import javax.swing.JFrame;
import javax.swing.JPanel;

import org.opencv.config.Config;
import org.opencv.core.Mat;
import org.opencv.core.Point;
import org.opencv.core.Scalar;
import org.opencv.imgproc.Imgproc;
import org.opencv.utils.Converters;
import org.opencv.videoio.VideoCapture;
import org.opencv.wechat_qrcode.WeChatQRCode;

public class Test {
	private static JFrame frame = new JFrame("camera");
	private static JPanel panel = new JPanel();
	private static int width = 900;
	private static int height = 600;

	static {
		//加载opencv库
		Config.load();
	}

	public static void main(String... args) {
		open();
	}

	public static void open() {
		frame.setSize(width,height);
		frame.setLocationRelativeTo(null);
		frame.setResizable(false);
		frame.setVisible(true);
		frame.setDefaultCloseOperation(JFrame.EXIT_ON_CLOSE);
		frame.setContentPane(panel);
		//openCamera();
		openPic();
	}

	private static void openCamera() {
		VideoCapture camera = new VideoCapture(0);
		if(!camera.isOpened()){
			System.out.println("Camera Error");
			return;
		}
		Mat img = new Mat();
		while(true){
			camera.read(img);
			deCode(img);
			try {
				Thread.sleep(50);
			} catch (InterruptedException e) {
				e.printStackTrace();
			}
			panel.repaint();
		}
	}

	private static void openPic() {
		Mat img = Converters.img2mat(base64);
		System.out.println(img.width());
		deCode(img);
	}

	private static void deCode(Mat img) {
		//微信二维码对象，要返回二维码坐标前2个参数必传；后2个在二维码小或不清晰时必传。
		WeChatQRCode we = new WeChatQRCode(Config.detector_prototxt_path,Config.detector_caffe_model_path,Config.super_resolution_prototxt_path,Config.super_resolution_caffe_model_path);
		List<Mat> points = new ArrayList<Mat>();
		//微信二维码引擎解码，返回的valList中存放的是解码后的数据，points中Mat存放的是二维码4个角的坐标
		List<String> valList = we.detectAndDecode(img, points);
		for(int i = 0; i < valList.size(); i++) {
			//根据坐标画矩形，就是二维码上的那个框
			Imgproc.rectangle(img,new Point(points.get(i).get(0, 0)[0],points.get(i).get(0, 1)[0]),new Point(points.get(i).get(2, 0)[0],points.get(i).get(2, 1)[0]),new Scalar(0, 0, 255),2);
			//opencv的Imgproc.putText方法中文会乱码，如果是英文可以直接使用。
			//Imgproc.putText(img, valList.get(i), new Point(points.get(i).get(0, 0)[0],points.get(i).get(0, 1)[0] - 10), 18, 1, new Scalar(0, 0, 255), 2);
		}
		BufferedImage image = Converters.mat2img(img);
		//因为opencv的Imgproc.putText方法中文会乱码，所以自己写了一个添加文本的方法。
		putText(image, valList, points);
		int w = image.getWidth() > panel.getWidth() ? panel.getWidth() : image.getWidth();
		int h = image.getHeight() > panel.getHeight() ? panel.getHeight() : image.getHeight();
		panel.getGraphics().drawImage(image, (panel.getWidth()-w)/2, (panel.getHeight()-h)/2, w, h, panel);
	}
	//根据坐标为图片添加文字
	private static void putText(BufferedImage img, List<String> textList, List<Mat> points) {
		Graphics2D g = img.createGraphics();
		Font font = new Font("宋体", Font.BOLD, 18);
		g.setColor(Color.red);
		g.setFont(font);
		for(int i = 0; i < textList.size(); i++) {
			g.drawString(textList.get(i), (float)points.get(i).get(0, 0)[0], (float)points.get(i).get(0, 1)[0] - 10);
		}
		g.dispose();
	}

}

电脑上没有摄像头，只测试了二维码图片的扫码，调用摄像头扫码方法虽然没有进行测试，应该没有太大问题。如果发现有什么问题可以留言给我。
