Ubuntu 安装OpenCV3.0.0

 Ubuntu  安装OpenCV3.0.0

为了看看opencv3.0的HDR效果，尝试安装opencv3.0到ubuntu12.04上面，安装了好几次终于成功了。

参考博客：
http://www.samontab.com/web/2014/06/installing-opencv-2-4-9-in-ubuntu-14-04-lts/

http://blog.163.com/huai_jing@126/blog/static/171861983201311103411229

http://www.cnblogs.com/steven-blog/archive/2013/04/27/3046357.html

http://www.cnblogs.com/emouse/archive/2013/02/22/2922940.html

http://blog.sina.com.cn/s/blog_8835a8480100x23h.html


安装过程出现问题解决方法
http://blog.sina.com.cn/s/blog_675e6b570101gpsj.html

卸载方法 OpenCv卸载

http://stackoverflow.com/questions/13134151/how-to-uninstall-opencv-in-ubuntu

You can also uninstall by going to the "build" folder directory of opencv from terminal, and execute the following
make uninstall
cd ..
sudo rm -r build

sudo rm -r /usr/local/include/opencv2
/usr/local/include/opencv
/usr/include/opencv
/usr/include/opencv2
/usr/local/share/opencv
/usr/local/share/OpenCV
/usr/share/opencv
/usr/share/OpenCV
/usr/local/bin/opencv*
/usr/local/lib/libopencv*

install reference
http://www.samontab.com/web/2014/06/installing-opencv-2-4-9-in-ubuntu-14-04-lts/

OpenCV安装
1 系统更新
利用ubuntu自带的更新管理器或者
sudo apt-get update
sudo apt-get upgrade

2 安装必要的组件
sudo apt-get install build-essential libgtk2.0-dev libjpeg-dev libtiff4-dev libjasper-dev libopenexr-dev cmake python-dev python-numpy python-tk libtbb-dev libeigen3-dev yasm libfaac-dev libopencore-amrnb-dev libopencore-amrwb-dev libtheora-dev libvorbis-dev libxvidcore-dev libx264-dev libqt4-dev libqt4-opengl-dev sphinx-common texlive-latex-extra libv4l-dev libdc1394-22-dev libavcodec-dev libavformat-dev libswscale-dev default-jdk ant libvtk5-qt4-dev

3 下载opencv3.0

http://opencv.org/downloads.html

解压到某个文件下，这里选择
/home/yourname/opencv3.0

4  编译opecv3.0
进入解压后的opencv3.0目录

mkdir build

进入build目录

cd build

cmake -D WITH_TBB=ON -D BUILD_NEW_PYTHON_SUPPORT=ON -D WITH_V4L=ON -D INSTALL_C_EXAMPLES=ON -D INSTALL_PYTHON_EXAMPLES=ON -D BUILD_EXAMPLES=ON -D WITH_QT=ON -D WITH_OPENGL=ON ..

5 安装opencv3.0

在build目录
make
sudo make install

6 配置opencv.conf file ，加入环境变量
sudo gedit /etc/ld.so.conf.d/opencv.conf

在opencv.conf里面加入命令
/usr/local/lib

更新库目录
sudo ldconfig

打开文件bash.bashrc
sudo gedit /etc/bash.bashrc
加入下面两行
PKG_CONFIG_PATH=$PKG_CONFIG_PATH:/usr/local/lib/pkgconfig
export PKG_CONFIG_PATH



7 测试你的opencv3.0是否安装成功

编译不通过请注销或者重启电脑试试

测试代码：opencvtest.cpp

#include <opencv2/core/core.hpp>
#include <opencv2/highgui/highgui.hpp>
using namespace cv;

int main()
{
    Mat src = imread("test.jpg",1);
    imshow("src",src);
    waitKey(0);
    return 0;
}

注意：linux下面的目录形式为/.../....

所以“#include <opencv2\core\core.hpp>” 会找不到头文件

编译方式：
1 命令行
g++  opencvtest.cpp -o opencvtest  `pkg-config  --cflags --libs opencv`

2 借助cmake，写CMakeLists.txt

cmake_minimum_required(VERSION 2.8)

project(opencvtest)

find_package( OpenCV REQUIRED )

add_executable( opencvtest opencvtest.cpp )

target_link_libraries( opencvtest ${OpenCV_LIBS} )

之后 执行

cmake .
Make
 运行
./ opencvtest


8 opnecv3.0的HDR效果测试

#include <opencv2/photo.hpp>
#include "opencv2/imgcodecs.hpp"
#include <opencv2/highgui.hpp>
#include <vector>
#include <iostream>
#include <fstream>
#include <string>

using namespace cv;
using namespace std;

void loadExposureSeq(string, vector<Mat>&, vector<float>&);

int main(int, char**argv)

{

    vector<Mat> images;
    vector<float> times;
    string strpath = "./SampleLighthouse";
    loadExposureSeq(strpath, images, times);

    for (int i = 0; i < times.size(); ++i)
    {
        cout << times[i] << " ";
    }
    cout << endl << "here" << endl;

    Mat response;
    Ptr<CalibrateDebevec> calibrate = createCalibrateDebevec();
    calibrate->process(images, response, times);
    Mat hdr;
    Ptr<MergeDebevec> merge_debevec = createMergeDebevec();
    merge_debevec->process(images, hdr, times, response);
    Mat ldr;
    Ptr<TonemapDurand> tonemap = createTonemapDurand(2.2f);
    tonemap->process(hdr, ldr);

    Mat fusion;
    Ptr<MergeMertens> merge_mertens = createMergeMertens();
    merge_mertens->process(images, fusion);

    imwrite("fusion.png", fusion * 255);
    imwrite("ldr.png", ldr * 255);
    imwrite("hdr.hdr", hdr);
    return 0;
}



void loadExposureSeq(string path, vector<Mat>& images, vector<float>& times)
{

    path = path + std::string("/");
    ifstream list_file((path + "ST.txt").c_str());
    string name;
    float val;
    while(list_file >> name >> val) {
        Mat img = imread(path + name);
        images.push_back(img);
        times.push_back(1 / val);
    }
    list_file.close();
}

曝光时间 ST.txt
s1.jpg 40.0
s2.jpg 10.0
s3.jpg 2.0

HDR图片

在普通的显示中无法正常显示，就不给出了

LDR图片


色调映射算法感觉不好，图像的很多细节丢失了。
