Springboot+mybatis构建管理后台系统

新建一个springboot工程

这篇博客教大家如何从零开始使用springboot+mabatis搭建一个博客的后台管理系统；本文采用的开发工具是idea，数据库使用的是mysql
1.使用idea新建springboot工程非常容易，打开idea file->new->project 左侧选择Spring Initialezr

2.点击next,填写maven工程的相关信息

3.点击next 选择web

4.点击next->finish 第一次新建可能要等一会 一点要耐心 新的springboot工程就新建成功了

打开BlogApplication类 右键就可以将项目启动起来了，这样一个新的工程就建好了

开发后台管理登陆功能

1.在springboot中集成mybatis

1.在工程的pom.xml文件中加入

   	   <dependency>
           <groupId>org.mybatis.spring.boot</groupId>
           <artifactId>mybatis-spring-boot-starter</artifactId>
           <version>1.3.2</version>
       </dependency>
       <dependency>
           <groupId>mysql</groupId>
           <artifactId>mysql-connector-java</artifactId>
           <version>8.0.13</version>
           <scope>runtime</scope>
       </dependency>

2.我们在数据库中（blog）中新建一个user表 并新建一条数据

DROP TABLE IF EXISTS `user`;
CREATE TABLE `user` (
  `id` int(11) NOT NULL AUTO_INCREMENT COMMENT '主键',
  `user_name` varchar(32)  DEFAULT NULL COMMENT '用户名',
  `password` varchar(32)  DEFAULT NULL COMMENT '密码',
  `full_name` varchar(32)  DEFAULT NULL COMMENT '姓名',
  `age` int(11) DEFAULT NULL COMMENT '年龄',
  `phone` varchar(16) DEFAULT NULL COMMENT '电话',
  `email` varchar(32) DEFAULT NULL COMMENT '邮箱',
  `motto` varchar(256) DEFAULT NULL COMMENT '座右铭',
  `occupation` varchar(64) DEFAULT NULL COMMENT '职业',
  `hobby` varchar(128) DEFAULT NULL COMMENT '爱好',
  `qq` varchar(16) DEFAULT NULL COMMENT 'qq号',
  `wechat` varchar(16)  DEFAULT NULL COMMENT '微信号',
  `portrait` varchar(256)  DEFAULT NULL COMMENT '头像',
  `wechat_code` varchar(128)  DEFAULT NULL COMMENT '微信二维码',
  PRIMARY KEY (`id`)
) ENGINE=InnoDB AUTO_INCREMENT=1 DEFAULT CHARSET=utf8 COMMENT='后台管理用户表';

-- ----------------------------
-- Records of user
-- ----------------------------
INSERT INTO `user` VALUES ('1', 'admin', '123456', '管理员', '25', null, null, null, null, null, null, null, null, null);

3.编写数据库连接配置文件，springboot中的配置只需要在application.properties文件中加入就可以，下面加入数据库连接配置

spring.datasource.name=blog
spring.datasource.url=jdbc:mysql://localhost:3306/blog?useUnicode=true&characterEncoding=utf-8&useSSL=true&serverTimezone=Hongkong
spring.datasource.username= root
spring.datasource.password=123456
spring.datasource.driver-class-name=com.mysql.cj.jdbc.Driver

但是通常springboot 更习惯将application.properties改名为application.yml文件 这时候配置的写法如下

spring:
    datasource:
        name: blog
        url: jdbc:mysql://localhost:3306/blog?useUnicode=true&characterEncoding=utf-8&useSSL=true&serverTimezone=Hongkong
        username: root
        password: 123456
        driver-class-name: com.mysql.cj.jdbc.Driver

4.新建User实体类，

package com.xiong.blog.model;

public class User {
    private Integer id;

    private String userName;

    private String password;

    private String fullName;

    private Integer age;

    private String phone;

    private String email;

    private String motto;

    private String occupation;

    private String hobby;

    private String qq;

    private String wechat;

    private String portrait;

    private String wechatCode;

    public Integer getId() {
        return id;
    }

    public void setId(Integer id) {
        this.id = id;
    }

    public String getUserName() {
        return userName;
    }

    public void setUserName(String userName) {
        this.userName = userName == null ? null : userName.trim();
    }

    public String getPassword() {
        return password;
    }

    public void setPassword(String password) {
        this.password = password == null ? null : password.trim();
    }

    public String getFullName() {
        return fullName;
    }

    public void setFullName(String fullName) {
        this.fullName = fullName == null ? null : fullName.trim();
    }

    public Integer getAge() {
        return age;
    }

    public void setAge(Integer age) {
        this.age = age;
    }

    public String getPhone() {
        return phone;
    }

    public void setPhone(String phone) {
        this.phone = phone == null ? null : phone.trim();
    }

    public String getEmail() {
        return email;
    }

    public void setEmail(String email) {
        this.email = email == null ? null : email.trim();
    }

    public String getMotto() {
        return motto;
    }

    public void setMotto(String motto) {
        this.motto = motto == null ? null : motto.trim();
    }

    public String getOccupation() {
        return occupation;
    }

    public void setOccupation(String occupation) {
        this.occupation = occupation == null ? null : occupation.trim();
    }

    public String getHobby() {
        return hobby;
    }

    public void setHobby(String hobby) {
        this.hobby = hobby == null ? null : hobby.trim();
    }

    public String getQq() {
        return qq;
    }

    public void setQq(String qq) {
        this.qq = qq == null ? null : qq.trim();
    }

    public String getWechat() {
        return wechat;
    }

    public void setWechat(String wechat) {
        this.wechat = wechat == null ? null : wechat.trim();
    }

    public String getPortrait() {
        return portrait;
    }

    public void setPortrait(String portrait) {
        this.portrait = portrait == null ? null : portrait.trim();
    }

    public String getWechatCode() {
        return wechatCode;
    }

    public void setWechatCode(String wechatCode) {
        this.wechatCode = wechatCode;
    }
}

5.新建mapper接口 UserMapper

package com.xiong.blog.dao;

import com.xiong.blog.model.User;

import java.util.Map;

public interface UserMapper {
    /**
     * 根据用户名密码获取用户
     * @param map
     * @return
     */
    User selectByUserName(Map<String, Object> map);
}

这一步一定要在 BlogApplication类中加入下面配置，否则无法找到接口

6. 新建mybatis mapper.xml文件 ，在resource文件夹下面新建mapping文件夹 然后在里面新建UserMapper.xml

<?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE mapper PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN" "http://mybatis.org/dtd/mybatis-3-mapper.dtd" >
<mapper namespace="com.xiong.blog.dao.UserMapper" >
  <resultMap id="BaseResultMap" type="com.xiong.blog.model.User" >
    <id column="id" property="id" jdbcType="INTEGER" />
    <result column="user_name" property="userName" jdbcType="VARCHAR" />
    <result column="password" property="password" jdbcType="VARCHAR" />
    <result column="full_name" property="fullName" jdbcType="VARCHAR" />
    <result column="age" property="age" jdbcType="INTEGER" />
    <result column="phone" property="phone" jdbcType="VARCHAR" />
    <result column="email" property="email" jdbcType="VARCHAR" />
    <result column="motto" property="motto" jdbcType="VARCHAR" />
    <result column="occupation" property="occupation" jdbcType="VARCHAR" />
    <result column="hobby" property="hobby" jdbcType="VARCHAR" />
    <result column="qq" property="qq" jdbcType="VARCHAR" />
    <result column="wechat" property="wechat" jdbcType="VARCHAR" />
    <result column="portrait" property="portrait" jdbcType="VARCHAR" />
    <result column="wechat_code" property="wechatCode" jdbcType="VARCHAR" />
  </resultMap>
  <sql id="Base_Column_List" >
    id, user_name, password, full_name, age, phone, email, motto, occupation, hobby,
    qq, wechat, portrait,wechat_code
  </sql>

  <select id="selectByUserName" resultMap="BaseResultMap" parameterType="java.util.Map" >
    select
    <include refid="Base_Column_List" />
    from user
    where user_name = #{userName,jdbcType=VARCHAR} and password = #{password,jdbcType=VARCHAR}
  </select>
</mapper>

7.最后还需要在配置文件中加入mybatis mapper文件和model类的路径

mybatis:
    mapper-locations: classpath:mapping/*.xml
    type-aliases-package: com.xiong.blog.model

这样mybatis就集成好了，下面我们来写一个登陆接口

2.编写登陆接口

我们用sping的良好习惯是要编写service层 我们新建UserService 以及他的实现类 UserServiceImpl

package com.xiong.blog.service;

import com.xiong.blog.model.User;

import java.util.Map;

public interface UserService {
    User selectByUserName(Map<String, Object> map);
}

package com.xiong.blog.service.impl;

import com.xiong.blog.dao.UserMapper;
import com.xiong.blog.model.User;
import com.xiong.blog.service.UserService;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Service;

import java.util.Map;

@Service
public class UserServiceImpl implements UserService {
    @Autowired
    private UserMapper userMapper;

    @Override
    public User selectByUserName(Map<String, Object> map) {
        return userMapper.selectByUserName(map);
    }

}

新建LoginController

package com.xiong.blog.controller;

import com.xiong.blog.model.User;
import com.xiong.blog.service.UserService;
import com.xiong.blog.vo.ResultBean;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Controller;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RequestParam;
import org.springframework.web.bind.annotation.ResponseBody;

import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpSession;
import java.util.HashMap;
import java.util.Map;

@Controller
public class LoginController {
    @Autowired
    private UserService userService;

    @RequestMapping("/login")
    @ResponseBody
    public Object login(@RequestParam(value = "user_name", required = false) String userName,
                        @RequestParam(value = "password", required = false) String password) {
        Map<String,Object> map = new HashMap<>();
        map.put("userName",userName);
        map.put("password",password);
        User user = userService.selectByUserName(map);
        return user;
    }
}

最后工程目录下的文件如下：

最后启动工程，然后在浏览器中输入http://localhost:8080/login?user_name=admin&password=123456
浏览器中显示：
接口已经写好了，我们在写工程的时候一般把接口的返回固定成一定的格式，这时候我们新建一个接口返回的vo类

package com.xiong.blog.vo;

import java.io.Serializable;

public class ResultBean implements Serializable {

    public ResultBean(){
    }
    public ResultBean(int code, String msg, Object data) {
        this.code = code;
        this.msg = msg;
        this.data = data;
    }

    private int code;
    private String msg;
    private Object data;

    public int getCode() {
        return code;
    }

    public void setCode(int code) {
        this.code = code;
    }

    public String getMsg() {
        return msg;
    }

    public void setMsg(String msg) {
        this.msg = msg;
    }

    public Object getData() {
        return data;
    }

    public void setData(Object data) {
        this.data = data;
    }
}

同时用户登陆成功后我们把用户信息放到session中 我们改造下接口

 @RequestMapping("/login")
    @ResponseBody
    public Object login(HttpServletRequest request,
                       @RequestParam(value = "user_name", required = false) String userName,
                       @RequestParam(value = "password", required = false) String password) {
        Map<String,Object> map = new HashMap<>();
        map.put("userName",userName);
        map.put("password",password);
        User user = userService.selectByUserName(map);
        if(user == null){
            return new ResultBean(-1,"用户名密码错误",null);
        }else{
            HttpSession session = request.getSession();
            session.setAttribute("user",user);
        }
        return new ResultBean(200,"登陆成功",user);
    }

这样登陆接口就写好了

2.编写登陆页面

springboot中我们通常使用yml模板 讲html文件放在resource下的templates文件夹中 css，js等静态资源放在static文件夹中，
我们在templates文件夹中放入 login.html index.html 页面 使用模板 我们需要在pom.xml中加入配置

<dependency>
     <groupId>org.springframework.boot</groupId>
     <artifactId>spring-boot-starter-thymeleaf</artifactId>
 </dependency>

在LoginController 中加入访问登陆页和首页的代码

@RequestMapping("/")
    public Object index() {
        return "login";
    }
    @RequestMapping("/index")
    public Object indexHtml() {
        return "index.html";
    }

html页面代码

<!doctype html>
<html lang="en">
<head>
    <meta charset="UTF-8">
    <meta name="viewport" content="width=device-width, user-scalable=no, initial-scale=1.0, maximum-scale=1.0, minimum-scale=1.0">
    <meta http-equiv="X-UA-Compatible" content="ie=edge">
    <title>后台管理</title>
    <link rel="stylesheet" href="css/styles.css">
    <link rel="stylesheet" href="css/common.css">
</head>
<body>
<div class="page-wrapper flex-row align-items-center">
    <div class="container">
        <div class="row justify-content-center">
            <div class="col-md-5">
                <div class="card p-4">
                    <div class="card-header text-center text-uppercase h4 font-weight-light">
                        登陆
                    </div>

                    <div class="card-body">
                        <div class="form-group">
                            <label class="form-control-label">用户名</label>
                            <input type="text" id="user_name" class="form-control">
                        </div>

                        <div class="form-group">
                            <label class="form-control-label">密码</label>
                            <input type="password" id="password" class="form-control">
                        </div>

                        <div class="form-group">
                            <p  id="login_tips" class="red"></p>
                        </div>
                    </div>

                    <div class="card-footer">
                        <div class="row">
                            <div class="col-12">
                                <button id="login_btn"  class="btn btn-primary px-5 fullwidth">登陆</button>
                            </div>

                        </div>
                    </div>
                </div>
            </div>
        </div>
    </div>
</div>
<script src="js/jquery.js"></script>
<script src="js/login.js"></script>
</body>
</html>

login.js代码

$(document).ready(function () {

    $('#login_btn').on('click', function (e) {
        e.preventDefault();
        login();
    });

    function login(){
        if($.trim($("#user_name").val())==""||$.trim($("#password").val())==""){
            return;
        }
        $.ajax({
            type:"POST",
            url:"login",
            dataType:"json",
            data:{
                'user_name':$("#user_name").val(),
                'password':$("#password").val()
            },
            success:function(data){
                if(data&&data.code==200){
                    $("#login_tips").hide();
                    window.location.href="index"
                }else{
                    $("#login_tips").html(data.msg);
                    $("#login_tips").show();
                }
            },
            error:function(jqXHR){
                console.log("接口异常"+jqXHR.status);
            }
        });
    }
document.onkeydown = function (e) { // 回车提交表单
// 兼容FF和IE和Opera
    var theEvent = window.event || e;
    var code = theEvent.keyCode || theEvent.which || theEvent.charCode;
    if (code == 13) {
        login();
    }
}
});

重新运行工程 浏览器中输入http://localhost:8080/ 即可打开登陆页面

输入用户名 admin 密码123456 即可进入index.html页面

登陆功能就已经完成了 后面还有很多功能由于篇幅问题 就不在这里介绍了 有兴趣的直接取github上面下载源码 ，后续还会持续更新SpingCloud的相关知识喜欢的可以关注微信公众号码农冲天梯 获取更多java文章

源码地址.
