5.8G各种类型的天线测试数据对比 增益和驻波比

天线1

天线2

天线3

天线4

天线5/6

天线1			天线2			天线3			天线4
Freq	Effi	Gain	Freq	Effi	Gain	Freq	Effi	Gain	Freq	Effi	Gain
(MHz)	(%)	(dBi)	(MHz)	(%)	(dBi)	(MHz)	(%)	(dBi)	(MHz)	(%)	(dBi)
5150	77.4	3.65	5150	44.06	-0.49	5150	37.73	-2.39	5150	58.68	0.4
5160	73.87	3.37	5160	40.65	-0.75	5160	42.07	-1.87	5160	63.61	0.68
5170	78.14	3.51	5170	43.06	-0.49	5170	39.22	-2.24	5170	61.65	0.44
5180	73.81	3.18	5180	49.29	0.19	5180	44.1	-1.69	5180	67.41	0.83
5190	78.25	3.46	5190	49.52	0.25	5190	41.1	-2	5190	65.57	0.7
5200	76.78	3.46	5200	53.99	0.61	5200	43.67	-1.62	5200	69.4	1.04
5210	76.65	3.54	5210	49.53	0.24	5210	47.13	-1.29	5210	73.24	1.44
5220	74.63	3.52	5220	52.59	0.46	5220	49.63	-0.99	5220	76.49	1.73
5230	76.41	3.55	5230	51.65	0.34	5230	51.36	-0.75	5230	78.6	1.89
5240	78.31	3.78	5240	55.4	0.59	5240	44.94	-1.23	5240	74.27	1.64
5250	77.93	3.59	5250	57.75	0.78	5250	52.69	-0.57	5250	81.25	2
5260	77.05	3.88	5260	55.27	0.6	5260	52.21	-0.62	5260	81.11	1.96
5270	73.49	4.02	5270	55.91	0.64	5270	53.05	-0.51	5270	81.35	1.97
5280	76.29	4.44	5280	53.67	0.42	5280	52.56	-0.54	5280	82.03	2.04
5290	72.47	4.5	5290	56.72	0.57	5290	54.4	-0.41	5290	83.23	2.12
5300	72.96	4.75	5300	56.13	0.39	5300	58.8	-0.08	5300	87.33	2.28
5310	75.98	5.04	5310	67.27	1.08	5310	58.47	-0.09	5310	87.42	2.4
5320	73.13	4.98	5320	62.22	0.82	5320	66.05	0.43	5320	91.25	2.53
5330	76.1	5.14	5330	59.35	0.72	5330	61.17	0.11	5330	88.74	2.35
5340	76.27	5.17	5340	63.06	1.04	5340	68.36	0.62	5340	91.76	2.59
5350	77.65	5.19	5350	65.47	1.25	5350	66.14	0.42	5350	90.98	2.51
5360	77.97	5.15	5360	69.21	1.47	5360	73.89	0.9	5360	90.08	2.67
5370	78.04	4.93	5370	63.92	1.24	5370	76.69	1.22	5370	91.61	2.78
5380	79.16	4.78	5380	67.58	1.51	5380	77.14	1.29	5380	92.09	2.85
5390	76.24	4.34	5390	63.18	1.24	5390	81.78	1.64	5390	91.62	2.89
5400	81.39	4.5	5400	64.99	1.42	5400	74.01	1.28	5400	91.8	2.75
5410	82.26	4.63	5410	67.6	1.56	5410	79.27	1.74	5410	91.37	2.92
5420	81.14	4.53	5420	65.11	1.34	5420	78.9	1.84	5420	91.98	2.78
5430	75.26	4.33	5430	61.93	1.09	5430	86.78	2.41	5430	93.34	2.87
5440	73.17	4.14	5440	53.59	0.28	5440	76.8	1.91	5440	89.34	2.49
5450	79.02	4.56	5450	60.62	0.72	5450	76.41	1.98	5450	92.49	2.69
5460	76.57	4.34	5460	56.28	0.25	5460	77.26	1.92	5460	89.77	2.62
5470	82.78	4.74	5470	63.15	0.51	5470	77.84	1.89	5470	92.78	2.82
5480	78.99	4.48	5480	59.86	0.2	5480	79.7	1.91	5480	90.46	2.72
5490	78.69	4.6	5490	58.82	0.06	5490	74.29	1.56	5490	90.19	2.55
5500	76.26	4.44	5500	55.58	-0.25	5500	75.16	1.63	5500	89.72	2.59
5510	77.33	4.59	5510	54.43	-0.33	5510	66.35	1.12	5510	84.57	2.28
5520	88.78	5.2	5520	69.61	0.66	5520	71.14	1.42	5520	91.09	2.64
5530	84.16	4.85	5530	65.04	0.35	5530	70.25	1.24	5530	87.7	2.46
5540	85.78	4.94	5540	68.04	0.56	5540	69.99	1.17	5540	87.67	2.41
5550	83.01	4.77	5550	65.39	0.42	5550	71.65	1.22	5550	88.51	2.55
5560	88.25	5.09	5560	71.16	0.75	5560	68.41	0.95	5560	86.5	2.49
5570	89.72	5.21	5570	74.13	0.9	5570	68.59	0.88	5570	86.41	2.49
5580	94.14	5.4	5580	78.01	1.12	5580	65.39	0.63	5580	83.02	2.32
5590	95.37	5.49	5590	90.36	1.68	5590	72.95	1.1	5590	90.49	2.66
5600	90.62	5.13	5600	82.72	1.33	5600	72.85	1.12	5600	89.65	2.57
5610	91.73	5.18	5610	85.25	1.47	5610	71.41	1.01	5610	85.44	2.33
5620	89.98	5.05	5620	83.33	1.37	5620	71.66	0.95	5620	84.2	2.24
5630	91.68	5.14	5630	89.23	1.69	5630	70.26	0.69	5630	79.75	2.03
5640	91.27	5.22	5640	86.25	1.77	5640	75.55	0.96	5640	84.6	2.31
5650	92.77	5.35	5650	89.32	1.85	5650	75.47	0.92	5650	82.35	2.26
5660	93.61	5.43	5660	83.62	2.04	5660	81.98	1.37	5660	89.49	2.64
5670	89.32	5.3	5670	86.63	1.73	5670	78.62	1.37	5670	84.17	2.46
5680	89.85	5.31	5680	90.9	1.88	5680	79.06	1.49	5680	80.75	2.27
5690	88.86	5.24	5690	91.06	1.89	5690	79.47	1.54	5690	77.57	2.03
5700	87.02	5.19	5700	93.81	2.03	5700	81.63	1.62	5700	77.2	1.97
5710	85.07	5.04	5710	91.43	1.98	5710	85.3	1.71	5710	84.88	2.39
5720	84.86	4.88	5720	91.01	1.97	5720	82.85	1.53	5720	78	2.06
5730	84.44	4.72	5730	90.25	2.2	5730	86	1.78	5730	81.16	2.3
5740	82.39	4.53	5740	91.45	1.94	5740	81.56	1.69	5740	71.47	1.83
5750	78.95	4.25	5750	90.78	1.89	5750	80.78	1.79	5750	69.59	1.75
5760	80.93	4.35	5760	91.39	1.89	5760	82.96	1.94	5760	72.53	1.87
5770	81.05	4.41	5770	91.75	1.9	5770	84.67	1.94	5770	74.33	1.97
5780	82.61	4.38	5780	91.62	1.9	5780	86.04	2.07	5780	76.19	2.13
5790	79.05	4.14	5790	86.71	1.71	5790	82.58	1.87	5790	63.65	1.34
5800	76.41	3.78	5800	86.64	1.69	5800	82.84	1.88	5800	66.02	1.63
5810	76.46	3.95	5810	86.6	1.63	5810	83.16	1.82	5810	64.43	1.63
5820	76.96	3.93	5820	88.68	1.7	5820	84.19	1.84	5820	69.95	2
5830	80.67	4.16	5830	88.95	1.68	5830	83.96	1.92	5830	69.87	1.95
5840	82.58	4.22	5840	89.93	1.75	5840	85.02	1.94	5840	70.6	2.09
5850	80.57	4.09	5850	86.8	1.62	5850	82.76	1.79	5850	66.14	1.82



八木天线-BGS				八木天线-客供
Freq	Effi	Gain		Freq	Effi	Gain
(MHz)	(%)	(dBd)		(MHz)	(%)	(dBd)
840	66.37	7.93		840	62.23	5.79
850	62.37	7.58		850	59.02	5.19
860	65.16	7.57		860	62.66	5.19
870	62.81	7.61		870	61.09	5.13
880	62.66	7.71		880	61.52	4.84
890	65.31	8.36		890	63.97	4.98
900	61.38	8.41		900	59.43	4.51
910	63.1	8.86		910	60.26	4.48
920	60.81	8.41		920	54.33	3.87
930	62.09	8.95		930	50.47	4.48

 天线1



天线2

天线3

天线4

天线5

天线6
