爬虫框架Scrapy的学习记录

本次实验以爬取美剧天堂最近更新页面的美剧名字为目的 https://www.meijutt.com/new100.html

1、环境

• Centos7 x64
• python2或者python3(本次实验用python3版本)
• virtualenvwrapper 虚拟环境

2、安装Scrapy

mkvirtualenv learnScrapypython3 --python=python3 #创建一个python3版本的虚拟环境
cd ~/.virtualenvs/learnScrapypython3/
pip install scrapy
pip list

安装Scrapy后会自动安装如下模块：

(learnScrapypython3) [root@vps movie]# pip list
Package Version

---

asn1crypto 0.24.0
attrs 18.2.0
Automat 0.7.0
cffi 1.11.5
constantly 15.1.0
cryptography 2.4.2
cssselect 1.0.3
hyperlink 18.0.0
idna 2.8
incremental 17.5.0
lxml 4.2.5
parsel 1.5.1
pip 18.1
pyasn1 0.4.4
pyasn1-modules 0.2.2
pycparser 2.19
PyDispatcher 2.0.5
PyHamcrest 1.9.0
pyOpenSSL 18.0.0
queuelib 1.5.0
Scrapy 1.5.1
service-identity 18.1.0
setuptools 40.6.3
six 1.12.0
Twisted 18.9.0
w3lib 1.19.0
wheel 0.32.3
zope.interface 4.6.0

3、创建项目

scrapy startproject movie
cd movie
scrapy genspider meiju meijutt.com

此时整个项目目录结构如下：

/root/.virtualenvs/learnScrapypython3
				├── bin
				├── include
				├── lib
				└── movie
					├── movie
					│   ├── __init__.py
					│   ├── items.py
					│   ├── middlewares.py
					│   ├── pipelines.py
					│   ├── __pycache__
					│   ├── settings.py
					│   └── spiders
					│       ├── __init__.py
					│       ├── meiju.py
					│       └── __pycache__
					└── scrapy.cfg

因为之前有学过Django，可以看出上面这个目录结构和django的文件目录结构非常相似。
目录文件说明：

下文用./ 代替/root/.virtualenvs/learnScrapypython3/

• ./bin ./include ./lib是创建虚拟环境时生成的，暂时不用管
• ./scrapy.cfg 项目的配置信息，主要为Scrapy命令行工具提供一个基础的配置信息。目前只记录爬虫setting文件的路径和爬虫程序的名字
• ./movie是存放整个爬虫文件的地方
• ./movie/items.py 设置数据存储模板，用于结构化数据，类似于Django的model.py文件
• ./movie/pipelines.py 数据处理行为，本次实验：把爬取的信息存到一个文件里
• ./movie/setting.py 配置文件，如：递归的层数、并发数，延迟下载等
• ./movie/spiders/ 爬虫目录，如：创建文件，编写爬虫规则
• ./movie/middlewares.py 中间件，处理xxx与xxx请求和相应（爬虫、调度、下载器、引擎）

4、修改爬虫程序的各个文件

• ./movie/items.py：

# -*- coding: utf-8 -*-

# Define here the models for your scraped items
#
# See documentation in:
# https://doc.scrapy.org/en/latest/topics/items.html

import scrapy


class MovieItem(scrapy.Item):
    # define the fields for your item here like:
    # name = scrapy.Field()
    # pass
    name = scrapy.Field()

• 爬虫文件./movie/spiders/meiju.py：

# -*- coding: utf-8 -*-
import scrapy
from movie.items import MovieItem


class MeijuSpider(scrapy.Spider):
    name = 'meiju'
    allowed_domains = ['meijutt.com']
    start_urls = ['http://www.meijutt.com/new100.html']

    def parse(self, response):
        movies = response.xpath('/html/body/div[2]/div[4]/div[1]/ul/li')
        for each_movie in movies:
            item = MovieItem()
            item['name'] = each_movie.xpath('./h5/a/@title').extract()[0]
            yield item

• 爬虫设置文件./movie/setting.py增加如下内容：

ITEM_PIPELINES = {'movie.pipelines.MoviePipeline':100}

• 数据处理脚本 ./movie/pipelines.py:

# -*- coding: utf-8 -*-

# Define your item pipelines here
#
# Don't forget to add your pipeline to the ITEM_PIPELINES setting
# See: https://doc.scrapy.org/en/latest/topics/item-pipeline.html


class MoviePipeline(object):
    def process_item(self, item, spider):
        with open("my_meiju.txt",'a',encoding='utf-8') as fp:
            fp.write(str(item['name'])+ '\n')
        return item

5、执行爬虫

在/root/.virtualenvs/learnScrapypython3/movie目录下执行如下命令开启爬虫程序（其实只要是在./movie项目下的任意目录中都可以成功执行）

scrapy crawl meiju --nolog

为方便查看错误也可执行下面的命令

scrapy crawl meiju

如果没错误，会在当前目录下产生一个名为my_meiju.txt的文件，里面是 https://www.meijutt.com/new100.html 的美剧的名字
截图如下：

6、实例二：爬取校花网图片

网站：http://www.xiaohuar.com/

• 创建爬虫程序

scrapy startproject xhwpic
cd xhwpic
scrapy genspider xiaohuar xiaohuar.com

• vim ./xhwpic/items.py

# -*- coding: utf-8 -*-

# Define here the models for your scraped items
#
# See documentation in:
# https://doc.scrapy.org/en/latest/topics/items.html

import scrapy


class XhwpicItem(scrapy.Item):
    # define the fields for your item here like:
    # name = scrapy.Field()
    name = scrapy.Field()
    addr = scrapy.Field()

• vim ./xhwpic/pipelines.py

# -*- coding: utf-8 -*-

import requests
import os

# Define your item pipelines here
#
# Don't forget to add your pipeline to the ITEM_PIPELINES setting
# See: https://doc.scrapy.org/en/latest/topics/item-pipeline.html


class XhwpicPipeline(object):
    def process_item(self, item, spider):
        headers = {'User-Agent': 'Mozilla/5.0 (Windows NT 6.1; WOW64; rv:52.0) Gecko/20100101 Firefox/52.0'}

        res = requests.get(url=item['addr'],headers=headers,stream=True)
        if not os.path.exists('./mypic'):
            os.makedirs('./mypic')
        filename = os.path.join('./mypic',item['name']+'.jpg')
        with open(filename,'wb') as fp:
            fp.write(res.content)

• vim ./xhwpic/setting.py增加一行：

ITEM_PIPELINES = {'xhwpic.pipelines.XhwpicPipeline':100}

• vim ./xhwpic/spiders/xiaohuar.py

# -*- coding: utf-8 -*-
import scrapy
import os

from xhwpic.items import XhwpicItem

class XiaohuarSpider(scrapy.Spider):
    name = 'xiaohuar'
    allowed_domains = ['xiaohuar.com']
    start_urls = ['http://www.xiaohuar.com']
    url_set = set()
    def parse(self, response):
        #if response.url.startswith("http://www.xiaohuar.com/list-"):
        if response.url.startswith("http://www.xiaohuar.com"):
            allPics = response.xpath('//div[@class="img"]/a')
            for pic in allPics:
                item = XhwpicItem()
                name = pic.xpath('./img/@alt').extract()[0]
                addr = pic.xpath('./img/@src').extract()[0]
                addr = 'http://www.xiaohuar.com'+addr
                item['name'] = name
                item['addr'] = addr
                yield item

        urls = response.xpath("//a/@href").extract()
        for url in urls:
            #if url.startswith("http://www.xiaohuar.com/list-"):
            if url.startswith("http://www.xiaohuar.com"):
                if url in XiaohuarSpider.url_set:
                    pass
                else:
                    XiaohuarSpider.url_set.add(url)
                    yield self.make_requests_from_url(url)
            else:
                pass

• 执行爬虫

scrapy crawl xiaohuar

会在本地./mypic目录中出现xxx校花xxx.jpg等图片，大概有940张左右

7、参考教程

1. Scrapy简单入门及实例讲解
2. Scrapy入门教程
