QT学习---网络编程

为了方便调试，网上找来客户端例程，修改成上位机控制端。





1、pro文件

从这里，我们可以看到，必须要在.pro文件中添加QT += network才可以进行网络编程，否则是访问不到<QTcpSocket>头文件的。
客户端读写相对简单，我们看一下代码头文件：
#-------------------------------------------------
#
# Project created by QtCreator 2019-08-25T14:10:09
#
#-------------------------------------------------

QT       += core gui
QT += network
greaterThan(QT_MAJOR_VERSION, 4): QT += widgets

TARGET = myFrist
TEMPLATE = app

# The following define makes your compiler emit warnings if you use
# any feature of Qt which has been marked as deprecated (the exact warnings
# depend on your compiler). Please consult the documentation of the
# deprecated API in order to know how to port your code away from it.
DEFINES += QT_DEPRECATED_WARNINGS

# You can also make your code fail to compile if you use deprecated APIs.
# In order to do so, uncomment the following line.
# You can also select to disable deprecated APIs only up to a certain version of Qt.
#DEFINES += QT_DISABLE_DEPRECATED_BEFORE=0x060000    # disables all the APIs deprecated before Qt 6.0.0

CONFIG += c++11

SOURCES += \
        clientwidget.cpp \
        main.cpp \
        mainwindow.cpp

HEADERS += \
        clientwidget.h \
        mainwindow.h

FORMS += \
        clientwidget.ui \
        mainwindow.ui

# Default rules for deployment.
qnx: target.path = /tmp/$${TARGET}/bin
else: unix:!android: target.path = /opt/$${TARGET}/bin
!isEmpty(target.path): INSTALLS += target

2、client.cpp

#include "clientwidget.h"
#include "ui_clientwidget.h"
#include<QHostAddress>
#include <QDebug>
#include <stdio.h>
#include <stdlib.h>
#include <string.h>

ClientWidget::ClientWidget(QWidget *parent) :
    QWidget(parent),
    ui(new Ui::ClientWidget)
{
    ui->setupUi(this);
    //初始化套接字
    //tcpSocket = NULL;
    //分配空间，指定父对象
    tcpSocket = new QTcpSocket(this);
    //建立连接的信号槽
    connect(tcpSocket,&QTcpSocket::connected,
            [=]()
            {
                 ui->textEditRead->setText("恭喜，成功连接服务器！");
                 ui->textEditguid->setText("成功连接服务器！");

            }
            );
    //连接建立后收到服务器数据的信号槽
    connect(tcpSocket,&QTcpSocket::readyRead,
            [=]()
           {
         //获取对方发送的内容
            qint16 n =5;
        QByteArray array = tcpSocket->readAll();
       quint8 buf[64] = {0};
//        buf[0]  = array[1];
       QString str1 = "Welcome";
         // qint64 read(char *data, qint64 maxlen);
        if(array[7] == (char)3)
        {
            ui->textEditRead->append("参数设置为:");

 //           str1.sprintf( "year:%d\tmoth:%d\tday:%d", ((quint8)array[20]+(array[19]<<8)),
//                    array[22]+(array[21]<<8), array[24]+(array[23]<<8));
            str1.sprintf( "年:%d\t月:%d\t日:%d", ((quint8)array[20]+(array[19]<<8)),
                    array[22]+(array[21]<<8), array[24]+(array[23]<<8));
            ui->textEditRead->append(str1);
//            str1.sprintf( "V1:%d\tV2:%d\tspeed3:%d",array[10]+(array[9]<<8),
//                   (quint8)array[12]+(array[11]<<8),  array[14]+(array[13]<<8));
            str1.sprintf( "消毒桶:%d\t饮水桶:%d\t流速:%d",array[10]+(array[9]<<8),
                    (quint8)array[12]+(array[11]<<8),  array[14]+(array[13]<<8));
            ui->textEditRead->append(str1);
//            str1.sprintf( "dree:%d\tweigt:%d",array[16]+(array[15]<<8),
//                    array[18]+(array[17]<<8));
            str1.sprintf( "溶解度:%d\t药重:%d",array[16]+(array[15]<<8),
                    array[18]+(array[17]<<8));
            ui->textEditRead->append(str1);
            //sprintf(buf, "year:%d-moth:%d-day:%d", array[7], array[7], array[7]);

        }else
        {//显示到编辑框
        ui->textEditRead->append("Recv:");
        ui->textEditRead->append(array);//append，添加内容
        }


            }
            );
    //设置窗口标题
    setWindowTitle("TCP客户端");
}

ClientWidget::~ClientWidget()
{
    delete ui;
}

void ClientWidget::on_buttonConnect_clicked()
{
    //获取服务器IP和端口
    QString ip = ui->lineEditIP->text();
    quint16 port = ui->lineEditPort->text().toUShort();
    //主动连接服务器
    tcpSocket->connectToHost(QHostAddress(ip),port);
}

void ClientWidget::on_buttonSend_clicked()
{
    //获取编辑框内容
     QString str = ui->textEditWrite->toPlainText();
     //发送数据
     tcpSocket->write( str.toUtf8().data() );

}

void ClientWidget::on_buttonClose_clicked()
{ //主动断开连接
    tcpSocket->disconnectFromHost();
    ui->textEditguid->setText("已断开连接！");
}

QByteArray InnitialQByteArry(qint8 in[],int len)//输入int数组和数组长度，将数组中的值存入QByteArry中
{
    QByteArray byteArry;
    byteArry.resize(len);
    for (int i=0;i<len;i++)
    {
        byteArry[i]=in[i];
    }
    return byteArry;
}



void ClientWidget::on_buttonSet_clicked()
{

     /*

    lineEditset1
    lineEditset1
    lineEditset1
    lineEditset1
    */

        qint16 num ,n =13;
        //发送数据
        //tcpSocket->write( str.toUtf8().data() );
        qint8 buf[43] = {0x00,0x00,0x00,0x00,0x00,0x06,0x01,0x10,0x00,0x00,0x00,0x10,0x20};
        num = ui->lineEditset1->text().toShort();
        buf[n+0] = num>>8;
        buf[n+1] =(qint8) num;
        num = ui->lineEditset2->text().toShort();
        buf[n+2] = num>>8;
        buf[n+3] =(qint8) num;
        num = ui->lineEditset3->text().toShort();
        buf[n+4] = num>>8;
        buf[n+5] =(qint8) num;
        num = ui->lineEditset4->text().toShort();
        buf[n+6] = num>>8;
        buf[n+7] =(qint8) num;
        num = ui->lineEditset5->text().toShort();
        buf[n+8] = num>>8;
        buf[n+9] =(qint8) num;
        num = ui->lineEditset6->text().toShort();
        buf[n+10] = num>>8;
        buf[n+11] =(qint8) num;
        num = ui->lineEditset7->text().toShort();
        buf[n+12] = num>>8;
        buf[n+13] =(qint8) num;
        num = ui->lineEditset7_2->text().toShort();
        buf[n+14] = num>>8;
        buf[n+15] =(qint8) num;
        num = ui->lineEditset8->text().toShort();
        buf[n+16] = num>>8;
        buf[n+17] =(qint8) num;
        num = ui->lineEditset8_2->text().toShort();
        buf[n+18] = num>>8;
        buf[n+19] =(qint8) num;
        num = ui->lineEditset9->text().toShort();
        buf[n+20] = num>>8;
        buf[n+21] =(qint8) num;
        num = ui->lineEditset9_2->text().toShort();
        buf[n+22] = num>>8;
        buf[n+23] =(qint8) num;
        num = ui->lineEditset10->text().toShort();
        buf[n+24] = num>>8;
        buf[n+25] =(qint8) num;
        num = ui->lineEditset10_2->text().toShort();
        buf[n+26] = num>>8;
        buf[n+27] =(qint8) num;
        //lineEditset7_2


        num = 0;

        if(ui->checkBox_1->isChecked() ){
            qDebug("checkBox_1");
            num  |= 1;
        }
        if(ui->checkBox_2->isChecked() ){
            qDebug("checkBox_2");
            num  |= 1<<1;
        }
        if(ui->checkBox_3->isChecked() ){
            qDebug("checkBox_3");
            num  |= 1<<2;

        }
        if(ui->checkBox_4->isChecked() ){
            qDebug("checkBox_4");
            num  |= 1<<3;

        }
        if(ui->checkBox_5->isChecked() ){
            qDebug("checkBox_5");
            num  |= 1<<4;

        }
        if(ui->checkBox_6->isChecked() ){
            qDebug("checkBox_6");
            num  |= 1<<5;

        }
//         qDebug()<<"num:";
//        qDebug()<<num;
        buf[n+28] = num>>8;
        buf[n+29] =(qint8) num;
        int siz =sizeof(buf)/sizeof(buf[0]);
       QByteArray sendM=InnitialQByteArry(buf,siz);
       tcpSocket->write( sendM);
}

void ClientWidget::on_buttonRead_clicked()
{

     //   qint16 addr = ui->lineEditAddr->text().toShort();
     ///   qint16 num = ui->lineEditNum->text().toShort();
        //发送数据
        //tcpSocket->write( str.toUtf8().data() );
        qint8 buf[12] = {0x00,0x00,0x00,0x00,0x00,0x06,0x01,0x03,0x00,0x00,0x00,0x20};
     //   buf[8] = addr>>8;
     //   buf[9] =(qint8) addr;
     //   buf[10] = num>>8;
     //   buf[11] =(qint8) num;
         int siz =sizeof(buf)/sizeof(buf[0]);
        QByteArray sendM=InnitialQByteArry(buf,siz);
        tcpSocket->write( sendM);
       ui->textEditRead->setText("读取设置内容为：");
}

3、UI文件

<?xml version="1.0" encoding="UTF-8"?>
<ui version="4.0">
 <class>ClientWidget</class>
 <widget class="QWidget" name="ClientWidget">
  <property name="geometry">
   <rect>
    <x>0</x>
    <y>0</y>
    <width>946</width>
    <height>641</height>
   </rect>
  </property>
  <property name="minimumSize">
   <size>
    <width>0</width>
    <height>300</height>
   </size>
  </property>
  <property name="windowTitle">
   <string>Form</string>
  </property>
  <layout class="QGridLayout" name="gridLayout">
   <item row="0" column="3">
    <widget class="QGroupBox" name="groupBox_6">
     <property name="minimumSize">
      <size>
       <width>450</width>
       <height>580</height>
      </size>
     </property>
     <property name="maximumSize">
      <size>
       <width>450</width>
       <height>560</height>
      </size>
     </property>
     <property name="title">
      <string>数据读写</string>
     </property>
     <widget class="QGroupBox" name="groupBox_5">
      <property name="enabled">
       <bool>true</bool>
      </property>
      <property name="geometry">
       <rect>
        <x>20</x>
        <y>30</y>
        <width>400</width>
        <height>500</height>
       </rect>
      </property>
      <property name="sizePolicy">
       <sizepolicy hsizetype="Preferred" vsizetype="Preferred">
        <horstretch>0</horstretch>
        <verstretch>0</verstretch>
       </sizepolicy>
      </property>
      <property name="minimumSize">
       <size>
        <width>400</width>
        <height>500</height>
       </size>
      </property>
      <property name="maximumSize">
       <size>
        <width>400</width>
        <height>500</height>
       </size>
      </property>
      <property name="sizeIncrement">
       <size>
        <width>2</width>
        <height>0</height>
       </size>
      </property>
      <property name="font">
       <font>
        <family>微软雅黑</family>
        <weight>50</weight>
        <bold>false</bold>
       </font>
      </property>
      <property name="title">
       <string>数据设置</string>
      </property>
      <widget class="QLabel" name="label_8">
       <property name="geometry">
        <rect>
         <x>30</x>
         <y>30</y>
         <width>100</width>
         <height>30</height>
        </rect>
       </property>
       <property name="minimumSize">
        <size>
         <width>100</width>
         <height>20</height>
        </size>
       </property>
       <property name="maximumSize">
        <size>
         <width>100</width>
         <height>30</height>
        </size>
       </property>
       <property name="font">
        <font>
         <family>微软雅黑</family>
         <pointsize>10</pointsize>
         <weight>50</weight>
         <bold>false</bold>
        </font>
       </property>
       <property name="text">
        <string>消毒桶体积：</string>
       </property>
      </widget>
      <widget class="QLineEdit" name="lineEditset1">
       <property name="geometry">
        <rect>
         <x>130</x>
         <y>30</y>
         <width>71</width>
         <height>21</height>
        </rect>
       </property>
       <property name="text">
        <string>45</string>
       </property>
      </widget>
      <widget class="QLabel" name="label_9">
       <property name="geometry">
        <rect>
         <x>210</x>
         <y>60</y>
         <width>100</width>
         <height>30</height>
        </rect>
       </property>
       <property name="minimumSize">
        <size>
         <width>100</width>
         <height>20</height>
        </size>
       </property>
       <property name="maximumSize">
        <size>
         <width>100</width>
         <height>30</height>
        </size>
       </property>
       <property name="font">
        <font>
         <family>微软雅黑</family>
         <pointsize>10</pointsize>
         <weight>50</weight>
         <bold>false</bold>
        </font>
       </property>
       <property name="text">
        <string>药物重量：</string>
       </property>
      </widget>
      <widget class="QLineEdit" name="lineEditset2">
       <property name="geometry">
        <rect>
         <x>130</x>
         <y>70</y>
         <width>71</width>
         <height>21</height>
        </rect>
       </property>
       <property name="text">
        <string>1000</string>
       </property>
      </widget>
      <widget class="QPushButton" name="buttonSet">
       <property name="geometry">
        <rect>
         <x>260</x>
         <y>390</y>
         <width>93</width>
         <height>71</height>
        </rect>
       </property>
       <property name="text">
        <string>参数设置</string>
       </property>
      </widget>
      <widget class="QLabel" name="label_10">
       <property name="geometry">
        <rect>
         <x>30</x>
         <y>90</y>
         <width>100</width>
         <height>30</height>
        </rect>
       </property>
       <property name="minimumSize">
        <size>
         <width>100</width>
         <height>20</height>
        </size>
       </property>
       <property name="maximumSize">
        <size>
         <width>100</width>
         <height>30</height>
        </size>
       </property>
       <property name="font">
        <font>
         <family>微软雅黑</family>
         <pointsize>10</pointsize>
         <weight>50</weight>
         <bold>false</bold>
        </font>
       </property>
       <property name="text">
        <string>水泵流量：</string>
       </property>
      </widget>
      <widget class="QLabel" name="label_11">
       <property name="geometry">
        <rect>
         <x>30</x>
         <y>60</y>
         <width>100</width>
         <height>30</height>
        </rect>
       </property>
       <property name="minimumSize">
        <size>
         <width>100</width>
         <height>20</height>
        </size>
       </property>
       <property name="maximumSize">
        <size>
         <width>100</width>
         <height>30</height>
        </size>
       </property>
       <property name="font">
        <font>
         <family>微软雅黑</family>
         <pointsize>10</pointsize>
         <weight>50</weight>
         <bold>false</bold>
        </font>
       </property>
       <property name="text">
        <string>饮水桶体积：</string>
       </property>
      </widget>
      <widget class="QLabel" name="label_12">
       <property name="geometry">
        <rect>
         <x>220</x>
         <y>30</y>
         <width>100</width>
         <height>30</height>
        </rect>
       </property>
       <property name="minimumSize">
        <size>
         <width>100</width>
         <height>20</height>
        </size>
       </property>
       <property name="maximumSize">
        <size>
         <width>100</width>
         <height>30</height>
        </size>
       </property>
       <property name="font">
        <font>
         <family>微软雅黑</family>
         <pointsize>10</pointsize>
         <weight>50</weight>
         <bold>false</bold>
        </font>
       </property>
       <property name="text">
        <string>稀释度：</string>
       </property>
      </widget>
      <widget class="QLineEdit" name="lineEditset3">
       <property name="geometry">
        <rect>
         <x>130</x>
         <y>100</y>
         <width>71</width>
         <height>21</height>
        </rect>
       </property>
       <property name="text">
        <string>5</string>
       </property>
      </widget>
      <widget class="QLineEdit" name="lineEditset4">
       <property name="geometry">
        <rect>
         <x>300</x>
         <y>30</y>
         <width>71</width>
         <height>21</height>
        </rect>
       </property>
       <property name="text">
        <string>2</string>
       </property>
      </widget>
      <widget class="QLineEdit" name="lineEditset5">
       <property name="geometry">
        <rect>
         <x>300</x>
         <y>70</y>
         <width>71</width>
         <height>21</height>
        </rect>
       </property>
       <property name="text">
        <string>10000</string>
       </property>
      </widget>
      <widget class="QLabel" name="label_13">
       <property name="geometry">
        <rect>
         <x>30</x>
         <y>140</y>
         <width>100</width>
         <height>30</height>
        </rect>
       </property>
       <property name="minimumSize">
        <size>
         <width>100</width>
         <height>20</height>
        </size>
       </property>
       <property name="maximumSize">
        <size>
         <width>100</width>
         <height>30</height>
        </size>
       </property>
       <property name="font">
        <font>
         <family>微软雅黑</family>
         <pointsize>10</pointsize>
         <weight>50</weight>
         <bold>false</bold>
        </font>
       </property>
       <property name="text">
        <string>加药年月日：</string>
       </property>
      </widget>
      <widget class="QLineEdit" name="lineEditset6">
       <property name="geometry">
        <rect>
         <x>130</x>
         <y>150</y>
         <width>51</width>
         <height>21</height>
        </rect>
       </property>
       <property name="text">
        <string>2019</string>
       </property>
      </widget>
      <widget class="QLineEdit" name="lineEditset7">
       <property name="geometry">
        <rect>
         <x>190</x>
         <y>150</y>
         <width>51</width>
         <height>21</height>
        </rect>
       </property>
       <property name="text">
        <string>8</string>
       </property>
      </widget>
      <widget class="QLabel" name="label_14">
       <property name="geometry">
        <rect>
         <x>30</x>
         <y>210</y>
         <width>100</width>
         <height>30</height>
        </rect>
       </property>
       <property name="minimumSize">
        <size>
         <width>100</width>
         <height>20</height>
        </size>
       </property>
       <property name="maximumSize">
        <size>
         <width>100</width>
         <height>30</height>
        </size>
       </property>
       <property name="font">
        <font>
         <family>微软雅黑</family>
         <pointsize>10</pointsize>
         <weight>50</weight>
         <bold>false</bold>
        </font>
       </property>
       <property name="text">
        <string>限制时间1止：</string>
       </property>
      </widget>
      <widget class="QLineEdit" name="lineEditset9">
       <property name="geometry">
        <rect>
         <x>140</x>
         <y>220</y>
         <width>51</width>
         <height>21</height>
        </rect>
       </property>
       <property name="text">
        <string>12</string>
       </property>
      </widget>
      <widget class="QLineEdit" name="lineEditset8">
       <property name="geometry">
        <rect>
         <x>140</x>
         <y>190</y>
         <width>51</width>
         <height>21</height>
        </rect>
       </property>
       <property name="text">
        <string>9</string>
       </property>
      </widget>
      <widget class="QLabel" name="label_15">
       <property name="geometry">
        <rect>
         <x>30</x>
         <y>180</y>
         <width>100</width>
         <height>30</height>
        </rect>
       </property>
       <property name="minimumSize">
        <size>
         <width>100</width>
         <height>20</height>
        </size>
       </property>
       <property name="maximumSize">
        <size>
         <width>100</width>
         <height>30</height>
        </size>
       </property>
       <property name="font">
        <font>
         <family>微软雅黑</family>
         <pointsize>10</pointsize>
         <weight>50</weight>
         <bold>false</bold>
        </font>
       </property>
       <property name="text">
        <string>限制时间1起：</string>
       </property>
      </widget>
      <widget class="QLineEdit" name="lineEditset10">
       <property name="geometry">
        <rect>
         <x>140</x>
         <y>250</y>
         <width>51</width>
         <height>21</height>
        </rect>
       </property>
       <property name="text">
        <string>14</string>
       </property>
      </widget>
      <widget class="QLabel" name="label_16">
       <property name="geometry">
        <rect>
         <x>30</x>
         <y>240</y>
         <width>100</width>
         <height>30</height>
        </rect>
       </property>
       <property name="minimumSize">
        <size>
         <width>100</width>
         <height>20</height>
        </size>
       </property>
       <property name="maximumSize">
        <size>
         <width>100</width>
         <height>30</height>
        </size>
       </property>
       <property name="font">
        <font>
         <family>微软雅黑</family>
         <pointsize>10</pointsize>
         <weight>50</weight>
         <bold>false</bold>
        </font>
       </property>
       <property name="text">
        <string>限制时间2起：</string>
       </property>
      </widget>
      <widget class="QLineEdit" name="lineEditset7_2">
       <property name="geometry">
        <rect>
         <x>250</x>
         <y>150</y>
         <width>51</width>
         <height>21</height>
        </rect>
       </property>
       <property name="text">
        <string>26</string>
       </property>
      </widget>
      <widget class="QLineEdit" name="lineEditset8_2">
       <property name="geometry">
        <rect>
         <x>200</x>
         <y>190</y>
         <width>51</width>
         <height>21</height>
        </rect>
       </property>
       <property name="text">
        <string>00</string>
       </property>
      </widget>
      <widget class="QLineEdit" name="lineEditset9_2">
       <property name="geometry">
        <rect>
         <x>200</x>
         <y>220</y>
         <width>51</width>
         <height>21</height>
        </rect>
       </property>
       <property name="text">
        <string>30</string>
       </property>
      </widget>
      <widget class="QLineEdit" name="lineEditset10_2">
       <property name="geometry">
        <rect>
         <x>200</x>
         <y>250</y>
         <width>51</width>
         <height>21</height>
        </rect>
       </property>
       <property name="text">
        <string>30</string>
       </property>
      </widget>
      <widget class="QCheckBox" name="checkBox_1">
       <property name="geometry">
        <rect>
         <x>30</x>
         <y>320</y>
         <width>91</width>
         <height>19</height>
        </rect>
       </property>
       <property name="font">
        <font>
         <family>微软雅黑</family>
         <pointsize>10</pointsize>
         <weight>50</weight>
         <bold>false</bold>
        </font>
       </property>
       <property name="text">
        <string>1单元</string>
       </property>
      </widget>
      <widget class="QCheckBox" name="checkBox_2">
       <property name="geometry">
        <rect>
         <x>30</x>
         <y>350</y>
         <width>91</width>
         <height>19</height>
        </rect>
       </property>
       <property name="font">
        <font>
         <family>微软雅黑</family>
         <pointsize>10</pointsize>
         <weight>50</weight>
         <bold>false</bold>
        </font>
       </property>
       <property name="text">
        <string>2单元</string>
       </property>
      </widget>
      <widget class="QCheckBox" name="checkBox_3">
       <property name="geometry">
        <rect>
         <x>30</x>
         <y>380</y>
         <width>91</width>
         <height>19</height>
        </rect>
       </property>
       <property name="font">
        <font>
         <family>微软雅黑</family>
         <pointsize>10</pointsize>
         <weight>50</weight>
         <bold>false</bold>
        </font>
       </property>
       <property name="text">
        <string>3单元</string>
       </property>
      </widget>
      <widget class="QCheckBox" name="checkBox_4">
       <property name="geometry">
        <rect>
         <x>30</x>
         <y>410</y>
         <width>91</width>
         <height>19</height>
        </rect>
       </property>
       <property name="font">
        <font>
         <family>微软雅黑</family>
         <pointsize>10</pointsize>
         <weight>50</weight>
         <bold>false</bold>
        </font>
       </property>
       <property name="text">
        <string>4单元</string>
       </property>
      </widget>
      <widget class="QCheckBox" name="checkBox_5">
       <property name="geometry">
        <rect>
         <x>30</x>
         <y>440</y>
         <width>91</width>
         <height>19</height>
        </rect>
       </property>
       <property name="font">
        <font>
         <family>微软雅黑</family>
         <pointsize>10</pointsize>
         <weight>50</weight>
         <bold>false</bold>
        </font>
       </property>
       <property name="text">
        <string>5单元</string>
       </property>
      </widget>
      <widget class="QCheckBox" name="checkBox_6">
       <property name="geometry">
        <rect>
         <x>30</x>
         <y>470</y>
         <width>91</width>
         <height>19</height>
        </rect>
       </property>
       <property name="font">
        <font>
         <family>微软雅黑</family>
         <pointsize>10</pointsize>
         <weight>50</weight>
         <bold>false</bold>
        </font>
       </property>
       <property name="text">
        <string>6单元</string>
       </property>
      </widget>
      <widget class="QLabel" name="label_17">
       <property name="geometry">
        <rect>
         <x>20</x>
         <y>280</y>
         <width>120</width>
         <height>30</height>
        </rect>
       </property>
       <property name="minimumSize">
        <size>
         <width>120</width>
         <height>20</height>
        </size>
       </property>
       <property name="maximumSize">
        <size>
         <width>100</width>
         <height>30</height>
        </size>
       </property>
       <property name="font">
        <font>
         <family>微软雅黑</family>
         <pointsize>10</pointsize>
         <weight>50</weight>
         <bold>false</bold>
        </font>
       </property>
       <property name="text">
        <string>喂药单元选择：</string>
       </property>
      </widget>
     </widget>
    </widget>
   </item>
   <item row="0" column="2">
    <widget class="QGroupBox" name="groupBox_7">
     <property name="minimumSize">
      <size>
       <width>300</width>
       <height>560</height>
      </size>
     </property>
     <property name="title">
      <string>连接</string>
     </property>
     <widget class="QGroupBox" name="groupBox_4">
      <property name="geometry">
       <rect>
        <x>20</x>
        <y>250</y>
        <width>430</width>
        <height>300</height>
       </rect>
      </property>
      <property name="minimumSize">
       <size>
        <width>430</width>
        <height>300</height>
       </size>
      </property>
      <property name="maximumSize">
       <size>
        <width>430</width>
        <height>300</height>
       </size>
      </property>
      <property name="title">
       <string>数据显示</string>
      </property>
      <widget class="QTextEdit" name="textEditRead">
       <property name="geometry">
        <rect>
         <x>20</x>
         <y>20</y>
         <width>331</width>
         <height>200</height>
        </rect>
       </property>
       <property name="maximumSize">
        <size>
         <width>16777215</width>
         <height>200</height>
        </size>
       </property>
       <property name="readOnly">
        <bool>true</bool>
       </property>
      </widget>
      <widget class="QTextEdit" name="textEditWrite">
       <property name="geometry">
        <rect>
         <x>20</x>
         <y>230</y>
         <width>331</width>
         <height>51</height>
        </rect>
       </property>
       <property name="maximumSize">
        <size>
         <width>16777215</width>
         <height>100</height>
        </size>
       </property>
      </widget>
      <widget class="QPushButton" name="buttonSend">
       <property name="geometry">
        <rect>
         <x>360</x>
         <y>230</y>
         <width>71</width>
         <height>51</height>
        </rect>
       </property>
       <property name="text">
        <string>发送数据</string>
       </property>
      </widget>
      <widget class="QPushButton" name="buttonRead">
       <property name="geometry">
        <rect>
         <x>360</x>
         <y>20</y>
         <width>71</width>
         <height>51</height>
        </rect>
       </property>
       <property name="text">
        <string>读取参数</string>
       </property>
      </widget>
     </widget>
     <widget class="QGroupBox" name="groupBox">
      <property name="geometry">
       <rect>
        <x>20</x>
        <y>20</y>
        <width>421</width>
        <height>200</height>
       </rect>
      </property>
      <property name="minimumSize">
       <size>
        <width>400</width>
        <height>200</height>
       </size>
      </property>
      <property name="maximumSize">
       <size>
        <width>16777215</width>
        <height>200</height>
       </size>
      </property>
      <property name="title">
       <string>连接</string>
      </property>
      <widget class="QPushButton" name="buttonConnect">
       <property name="geometry">
        <rect>
         <x>210</x>
         <y>40</y>
         <width>93</width>
         <height>28</height>
        </rect>
       </property>
       <property name="text">
        <string>连接服务器</string>
       </property>
      </widget>
      <widget class="QLabel" name="label">
       <property name="geometry">
        <rect>
         <x>20</x>
         <y>30</y>
         <width>100</width>
         <height>30</height>
        </rect>
       </property>
       <property name="minimumSize">
        <size>
         <width>100</width>
         <height>20</height>
        </size>
       </property>
       <property name="maximumSize">
        <size>
         <width>100</width>
         <height>30</height>
        </size>
       </property>
       <property name="text">
        <string>服务器端口：</string>
       </property>
      </widget>
      <widget class="QLineEdit" name="lineEditPort">
       <property name="geometry">
        <rect>
         <x>120</x>
         <y>40</y>
         <width>71</width>
         <height>21</height>
        </rect>
       </property>
       <property name="text">
        <string>502</string>
       </property>
      </widget>
      <widget class="QLabel" name="label_2">
       <property name="geometry">
        <rect>
         <x>20</x>
         <y>80</y>
         <width>93</width>
         <height>21</height>
        </rect>
       </property>
       <property name="text">
        <string>服务器IP：</string>
       </property>
      </widget>
      <widget class="QLineEdit" name="lineEditIP">
       <property name="geometry">
        <rect>
         <x>110</x>
         <y>80</y>
         <width>254</width>
         <height>31</height>
        </rect>
       </property>
       <property name="text">
        <string>192.168.0.200</string>
       </property>
      </widget>
      <widget class="QLabel" name="label_3">
       <property name="geometry">
        <rect>
         <x>20</x>
         <y>120</y>
         <width>100</width>
         <height>30</height>
        </rect>
       </property>
       <property name="minimumSize">
        <size>
         <width>100</width>
         <height>20</height>
        </size>
       </property>
       <property name="maximumSize">
        <size>
         <width>100</width>
         <height>30</height>
        </size>
       </property>
       <property name="text">
        <string>连接状态：</string>
       </property>
      </widget>
      <widget class="QTextEdit" name="textEditguid">
       <property name="geometry">
        <rect>
         <x>110</x>
         <y>120</y>
         <width>201</width>
         <height>31</height>
        </rect>
       </property>
       <property name="html">
        <string>&lt;!DOCTYPE HTML PUBLIC &quot;-//W3C//DTD HTML 4.0//EN&quot; &quot;http://www.w3.org/TR/REC-html40/strict.dtd&quot;&gt;
&lt;html&gt;&lt;head&gt;&lt;meta name=&quot;qrichtext&quot; content=&quot;1&quot; /&gt;&lt;style type=&quot;text/css&quot;&gt;
p, li { white-space: pre-wrap; }
&lt;/style&gt;&lt;/head&gt;&lt;body style=&quot; font-family:'SimSun'; font-size:9pt; font-weight:400; font-style:normal;&quot;&gt;
&lt;p style=&quot; margin-top:0px; margin-bottom:0px; margin-left:0px; margin-right:0px; -qt-block-indent:0; text-indent:0px;&quot;&gt;未连接&lt;/p&gt;&lt;/body&gt;&lt;/html&gt;</string>
       </property>
      </widget>
      <widget class="QPushButton" name="buttonClose">
       <property name="geometry">
        <rect>
         <x>310</x>
         <y>40</y>
         <width>93</width>
         <height>28</height>
        </rect>
       </property>
       <property name="text">
        <string>关闭连接</string>
       </property>
      </widget>
     </widget>
    </widget>
   </item>
  </layout>
 </widget>
 <resources/>
 <connections/>
</ui>
