HarmonyOS自API12版本后，推出了全新的状态管理V2。V2是V1的增强版本，为我们带来了更多功能和灵活性。对于新开发的应用，建议直接使用V2版本范式来进行开发。对于已经使用V1的应用，如果V1的功能和性能已能满足需求，则不必立即切换到V2。如果开发者在开发过程中受限于V1不能深度观察等特性，则建议开发者尽早规划向V2的迁移，以便未来实现平滑过渡和改进。

目前，华为开发者联盟官网给出的案例，大多都是应用V1版来编码实现，如《基于Canvas实现画布的功能》这个案例，gitee地址为：HarmonyOS_Samples/CustomCanvas。效果图预览如下：

现在，我们尝试将这个案例的状态管理升级到V2版。整个升级只涉及画布主页面和自定义底部设置面板子组件。

1. 画布主页面

V1版本全部代码如下：

import { display } from '@kit.ArkUI';
import DrawInvoker from '../viewmodel/DrawInvoker';
import DrawPath from '../viewmodel/IDraw';
import { IBrush } from '../viewmodel/IBrush';
import NormalBrush from '../viewmodel/IBrush';
import Paint from '../viewmodel/Paint';
import { CommonConstants } from '../common/CommonConstants';
import { myPaintSheet } from '../view/myPaintSheet';

@Entry
@Component
struct DrawCanvas {
  @State @Watch('createDraw') isDrawing: boolean = false;
  @State unDoDraw: boolean = false;
  @State redoDraw: boolean = false;
  @State isPaint: boolean = true;
  @State isShow: boolean = false;
  @State isMarker: boolean = false;
  @State scaleValueX: number = 1;
  @State scaleValueY: number = 1;
  @State pinchValueX: number = 1;
  @State pinchValueY: number = 1;
  @State strokeWidth: number = 3;
  @State alpha: number = 1;
  @State color: string = '#000000';
  @State thicknessesValue: number = 3;
  @State index: number = -1;
  @State clean: boolean = false;
  @State percent: string = '100';
  @Provide mPaint: Paint = new Paint(0, '', 1);
  @Provide mBrush: IBrush = new NormalBrush();
  private setting: RenderingContextSettings = new RenderingContextSettings(true);
  private context: CanvasRenderingContext2D = new CanvasRenderingContext2D(this.setting);
  private drawInvoker: DrawInvoker = new DrawInvoker();
  private path2Db: Path2D = new Path2D();
  private mPath: DrawPath = new DrawPath(this.mPaint, this.path2Db);
  private arr: number[] = [];

  aboutToAppear(): void {
    this.mPaint = new Paint(CommonConstants.ZERO, CommonConstants.COLOR_STRING, CommonConstants.ONE);
    this.mPaint.setStrokeWidth(CommonConstants.THREE);
    this.mPaint.setColor(CommonConstants.BLACK);
    this.mPaint.setGlobalAlpha(CommonConstants.ONE);
    this.mBrush = new NormalBrush();
    display.on('foldStatusChange', (data: display.FoldStatus) => {
      if (data === 2) {
        this.scaleValueX = 0.5;
        this.pinchValueX = 0.5;
        this.scaleValueY = 1;
        this.pinchValueY = 1;
        this.context.clearRect(0, 0, this.context.width, this.context.height);
        this.drawInvoker.execute(this.context);
      } else if (data === 1) {
        this.scaleValueX = 1;
        this.scaleValueY = 1;
        this.pinchValueX = 1;
        this.pinchValueY = 1;
        this.context.clearRect(0, 0, this.context.width, this.context.height);
        this.drawInvoker.execute(this.context);
      }
    })
  }

  createDraw() {
    if (this.isDrawing) {
      this.context.fillStyle = Color.White;
      this.context.fillRect(CommonConstants.ZERO, CommonConstants.ZERO, this.context.width, this.context.height);
      this.drawInvoker.execute(this.context);
      this.isDrawing = false;
    }
  }

  /**
   * Add a sketch path.
   */
  add(path: DrawPath): void {
    this.drawInvoker.add(path);
  }

  /**
   * Toggle weight, color, transparency.
   */
  ToggleThicknessColor(): void {
    this.mPaint = new Paint(CommonConstants.ZERO, CommonConstants.COLOR_STRING, CommonConstants.ONE);
    this.mPaint.setStrokeWidth(this.strokeWidth);
    this.mPaint.setColor(this.color);
    this.mPaint.setGlobalAlpha(this.alpha);
    this.mBrush = new NormalBrush();
  }

  /**
   * Undo operation.
   */
  drawOperateUndo(): void {
    this.drawInvoker.undo();
    this.isDrawing = true;
    if (!this.drawInvoker.canUndo()) {
      this.unDoDraw = false;
    }
    this.redoDraw = true;
  }

  /**
   * Redo operation.
   */
  drawOperateRedo(): void {
    this.drawInvoker.redo();
    this.isDrawing = true;
    if (!this.drawInvoker.canRedo()) {
      this.redoDraw = false;
    }
    this.unDoDraw = true;
  }

  /**
   * Clear operation.
   */
  clear(): void {
    this.drawInvoker.clear();
    this.isDrawing = true;
    this.redoDraw = false;
    this.unDoDraw = false;
  }

  @Builder
  myPaintSheet() {
    Column() {
      myPaintSheet({
        isMarker: this.isMarker,
        alpha: this.alpha,
        percent: this.percent,
        color: this.color,
        thicknessesValue: this.thicknessesValue,
        strokeWidth: this.strokeWidth
      })
    }
  }

  build() {
    Stack({ alignContent: Alignment.Bottom }) {
      Canvas(this.context)
        .width(CommonConstants.CANVAS_WIDTH)
        .height(CommonConstants.CANVAS_WIDTH)
        .backgroundColor($r('sys.color.white'))
        .onTouch((event: TouchEvent) => {
          this.clean = false;
          if (this.index === 1 || event.touches.length > 1) {
            return;
          }
          this.arr.push(event.touches[0].x + event.touches[0].y);
          if (event.touches.length === 1 && event.touches[0].id === 0 && event.type === TouchType.Down) {
            this.mPath = new DrawPath(this.mPaint, this.path2Db);
            this.mPath.paint = this.mPaint;
            this.mPath.path = new Path2D();
            this.mBrush.down(this.mPath.path, event.touches[0].x, event.touches[0].y);
          }
          if (event.touches.length === 1 && event.touches[0].id === 0 && event.type === TouchType.Move) {
            this.mBrush.move(this.mPath.path, event.touches[0].x, event.touches[0].y);
            this.context.clearRect(0, 0, this.context.width, this.context.height);
            this.drawInvoker.execute(this.context);
            if (this.arr.length > 4) {
              this.mPath.draw(this.context);
            }
          }
          if (event.touches.length === 1 && event.touches[0].id === 0 && event.type === TouchType.Up) {
            this.add(this.mPath);
            this.arr = [];
            this.redoDraw = false;
            this.unDoDraw = true;
            this.isDrawing = true;
            this.context.clearRect(0, 0, this.context.width, this.context.height);
            this.drawInvoker.execute(this.context);
          }
        })
        .scale({
          x: this.scaleValueX,
          y: this.scaleValueY,
          z: CommonConstants.ONE
        })
        .gesture(
          PinchGesture()
            .onActionStart(() => {
              this.index = 1;
            })
            .onActionUpdate((event: GestureEvent) => {
              this.context.clearRect(0, 0, this.context.width, this.context.height);
              this.drawInvoker.execute(this.context);
              if (event) {
                this.scaleValueX = this.pinchValueX * event.scale;
                this.scaleValueY = this.pinchValueY * event.scale;
              }
            })
            .onActionEnd(() => {
              this.pinchValueX = this.scaleValueX;
              this.pinchValueY = this.scaleValueY;
              this.context.clearRect(0, 0, this.context.width, this.context.height);
              this.drawInvoker.execute(this.context);
            })
        )
      Column()
        .width(CommonConstants.ONE_HUNDRED_PERCENT)
        .height(CommonConstants.ONE_HUNDRED_PERCENT)
        .backgroundColor(Color.Transparent)
        .zIndex(this.index)
        .gesture(
          PinchGesture()
            .onActionStart(() => {
              this.index = 1;
            })
            .onActionUpdate((event: GestureEvent) => {
              this.context.clearRect(0, 0, this.context.width, this.context.height);
              this.drawInvoker.execute(this.context);
              if (event) {
                this.scaleValueX = this.pinchValueX * event.scale;
                this.scaleValueY = this.pinchValueY * event.scale;
              }
            })
            .onActionEnd(() => {
              this.context.clearRect(0, 0, this.context.width, this.context.height);
              this.drawInvoker.execute(this.context);
              this.pinchValueX = this.scaleValueX;
              this.pinchValueY = this.scaleValueY;
            })
        )
      Row() {
        Stack() {
          Column() {
            Image(this.isPaint && this.index === CommonConstants.NEGATIVE_ONE ? $r('app.media.paintbrush_active') :
            $r('app.media.paintbrush'))
              .width($r('app.float.image_width'))
              .height($r('app.float.image_width'))
              .margin({ bottom: $r('app.float.bottom') })
            Text($r('app.string.paint'))
              .fontSize($r('app.float.font_size_m'))
              .fontColor(this.isPaint && this.index === CommonConstants.NEGATIVE_ONE ? $r('app.color.theme_color') :
              $r('sys.color.mask_secondary'))
          }
          .width(CommonConstants.ONE_HUNDRED_PERCENT)
          .height(CommonConstants.ONE_HUNDRED_PERCENT)

          Button({ type: ButtonType.Normal })
            .backgroundColor(Color.Transparent)
            .width(CommonConstants.ONE_HUNDRED_PERCENT)
            .height(CommonConstants.ONE_HUNDRED_PERCENT)
            .onClick(() => {
              this.ToggleThicknessColor();
              this.isPaint = true;
              this.isShow = !this.isShow;
              this.index = -1;
              this.arr = [];
            })
        }
        .bindSheet($$this.isShow, this.myPaintSheet(), {
          height: $r('app.float.height'),
          backgroundColor: Color.White,
          title: {
            title: $r('app.string.paint')
          },
          detents: CommonConstants.DETENTS
        })
        .width($r('app.float.paint_width'))
        .height($r('app.float.paint_height'))

        Stack() {
          Column() {
            Image(this.isPaint || this.index === CommonConstants.ONE ? $r('app.media.rubbers') :
            $r('app.media.rubbers_active'))
              .width($r('app.float.image_width'))
              .height($r('app.float.image_width'))
              .margin({ bottom: $r('app.float.bottom') })
            Text($r('app.string.rubber'))
              .fontSize($r('app.float.font_size_m'))
              .fontColor(this.isPaint || this.index === CommonConstants.ONE ? $r('sys.color.mask_secondary') :
              $r('app.color.theme_color'))

          }
          .width(CommonConstants.ONE_HUNDRED_PERCENT)
          .height(CommonConstants.ONE_HUNDRED_PERCENT)

          Button({ type: ButtonType.Normal })
            .backgroundColor(Color.Transparent)
            .width(CommonConstants.ONE_HUNDRED_PERCENT)
            .height(CommonConstants.ONE_HUNDRED_PERCENT)
            .onClick(() => {
              this.mPaint = new Paint(CommonConstants.ZERO, CommonConstants.COLOR_STRING, CommonConstants.ONE);
              this.mPaint.setStrokeWidth(CommonConstants.TEN);
              this.mPaint.setColor(CommonConstants.WHITE);
              this.mPaint.setGlobalAlpha(CommonConstants.ONE);
              this.isPaint = false;
            })
        }
        .width($r('app.float.paint_width'))
        .height($r('app.float.paint_height'))

        Stack() {
          Column() {
            Image(this.unDoDraw ? $r('app.media.recall_active') : $r('app.media.recall'))
              .width($r('app.float.image_width'))
              .height($r('app.float.image_width'))
              .margin({ bottom: $r('app.float.bottom') })
            Text($r('app.string.redo'))
              .fontSize($r('app.float.font_size_m'))
              .fontColor(this.unDoDraw ? $r('app.color.theme_color') : $r('sys.color.mask_secondary'))
          }
          .width(CommonConstants.ONE_HUNDRED_PERCENT)
          .height(CommonConstants.ONE_HUNDRED_PERCENT)

          Button({ type: ButtonType.Normal })
            .backgroundColor(Color.Transparent)
            .enabled(this.unDoDraw)
            .width(CommonConstants.ONE_HUNDRED_PERCENT)
            .height(CommonConstants.ONE_HUNDRED_PERCENT)
            .onClick(async () => {
              this.drawOperateUndo();
              this.context.clearRect(0, 0, this.context.width, this.context.height);
              this.drawInvoker.execute(this.context);
            })
        }
        .width($r('app.float.paint_width'))
        .height($r('app.float.paint_height'))

        Stack() {
          Column() {
            Image(this.redoDraw ? $r('app.media.redo_active') : $r('app.media.redo'))
              .width($r('app.float.image_width'))
              .height($r('app.float.image_width'))
              .margin({ bottom: $r('app.float.bottom') })
            Text($r('app.string.undo'))
              .fontSize($r('app.float.font_size_m'))
              .fontColor(this.redoDraw ? $r('app.color.theme_color') : $r('sys.color.mask_secondary'))
          }
          .width(CommonConstants.ONE_HUNDRED_PERCENT)
          .height(CommonConstants.ONE_HUNDRED_PERCENT)

          Button({ type: ButtonType.Normal })
            .backgroundColor(Color.Transparent)
            .enabled(this.redoDraw)
            .width(CommonConstants.ONE_HUNDRED_PERCENT)
            .height(CommonConstants.ONE_HUNDRED_PERCENT)
            .onClick(async () => {
              this.drawOperateRedo();
              this.context.clearRect(0, 0, this.context.width, this.context.height);
              this.drawInvoker.execute(this.context);
            })
        }
        .width($r('app.float.paint_width'))
        .height($r('app.float.paint_height'))

        Stack() {
          Column() {
            Image(this.clean ? $r('app.media.clear_active') : $r('app.media.clear'))
              .width($r('app.float.image_width'))
              .height($r('app.float.image_width'))
              .margin({ bottom: $r('app.float.bottom') })
            Text($r('app.string.clear'))
              .fontSize($r('app.float.font_size_m'))
              .fontColor(this.clean ? $r('app.color.theme_color') : $r('sys.color.mask_secondary'))
          }
          .width(CommonConstants.ONE_HUNDRED_PERCENT)
          .height(CommonConstants.ONE_HUNDRED_PERCENT)

          Button({ type: ButtonType.Normal })
            .backgroundColor(Color.Transparent)
            .width(CommonConstants.ONE_HUNDRED_PERCENT)
            .height(CommonConstants.ONE_HUNDRED_PERCENT)
            .onClick(async () => {
              this.clear();
              this.context.clearRect(0, 0, this.context.width, this.context.height);
              this.drawInvoker.execute(this.context);
              this.clean = true;
            })
        }
        .width($r('app.float.paint_width'))
        .height($r('app.float.paint_height'))
      }
      .justifyContent(FlexAlign.SpaceBetween)
      .alignItems(VerticalAlign.Center)
      .zIndex(CommonConstants.TEN)
    }
    .backgroundColor($r('sys.color.comp_background_focus'))
    .width(CommonConstants.ONE_HUNDRED_PERCENT)
    .height(CommonConstants.ONE_HUNDRED_PERCENT)
  }
}

1.1. 自定义组件@Component装饰器迁移

V1版

@Entry
@Component
struct DrawCanvas {
  // ...
}

V2版

直接将@Component修改为@ComponentV2即可。

@Entry
@ComponentV2
struct DrawCanvas {
  // ...
}

1.2. @State迁移

V1版

@State @Watch('createDraw') isDrawing: boolean = false;
@State unDoDraw: boolean = false;
@State redoDraw: boolean = false;
@State isPaint: boolean = true;
@State isShow: boolean = false;
@State isMarker: boolean = false;
@State scaleValueX: number = 1;
@State scaleValueY: number = 1;
@State pinchValueX: number = 1;
@State pinchValueY: number = 1;
@State strokeWidth: number = 3;
@State alpha: number = 1;
@State color: string = '#000000';
@State thicknessesValue: number = 3;
@State index: number = -1;
@State clean: boolean = false;
@State percent: string = '100';

V2版

直接将@State修改为@Local即可。

@Local @Watch('createDraw') isDrawing: boolean = false;
@Local unDoDraw: boolean = false;
@Local redoDraw: boolean = false;
@Local isPaint: boolean = true;
@Local isShow: boolean = false;
@Local isMarker: boolean = false;
@Local scaleValueX: number = 1;
@Local scaleValueY: number = 1;
@Local pinchValueX: number = 1;
@Local pinchValueY: number = 1;
@Local strokeWidth: number = 3;
@Local alpha: number = 1;
@Local color: string = '#000000';
@Local thicknessesValue: number = 3;
@Local index: number = -1;
@Local clean: boolean = false;
@Local percent: string = '100';

1.3. @Watch迁移

V1版

@State @Watch('createDraw') isDrawing: boolean = false;

createDraw() {
  if (this.isDrawing) {
    this.context.fillStyle = Color.White;
    this.context.fillRect(CommonConstants.ZERO, CommonConstants.ZERO, this.context.width, this.context.height);
    this.drawInvoker.execute(this.context);
    this.isDrawing = false;
  }
}

V2版

V2版采用@Monitor来代替@Watch。

@State isDrawing: boolean = false;

@Monitor('isDrawing')
createDraw() {
  if (this.isDrawing) {
    this.context.fillStyle = Color.White
    this.context.fillRect(CommonConstants.ZERO, CommonConstants.ZERO, this.context.width, this.context.height)
    this.drawInvoker.execute(this.context)
    this.isDrawing = false
  }
}

1.4. @Provide迁移

V1版

@Provide mPaint: Paint = new Paint(0, '', 1);
@Provide mBrush: IBrush = new NormalBrush();

V2版

V2版采用@Provider来代替@Provide。注意@Provider可以不用定义别名(alias)，通过变量名来供@Consumer消费，但小括号必须保留。

@Provider() mPaint: Paint = new Paint(0, '', 1);
@Provider() mBrush: IBrush = new NormalBrush();

1.5. 子组件传参迁移

V1版

@Builder
myPaintSheet() {
  Column() {
    myPaintSheet({
      isMarker: this.isMarker,
      alpha: this.alpha,
      percent: this.percent,
      color: this.color,
      thicknessesValue: this.thicknessesValue,
      strokeWidth: this.strokeWidth
    })
  }
}

V2版

myPaintSheet是子组件，给它传递的全部参数，都会在子组件中修改，并同步给父组件。在V1中，在子组件里，只需要使用@Link装饰器即可，在V2版里，我们得需要自己来实现@Link的功能，这里可以采用双叹号(!!)语法来实现迁移，子组件需要应用@Event，$变量名来配合。

@Builder
myPaintSheet() {
  Column() {
    myPaintSheet({
      isMarker: this.isMarker!!,
      alpha: this.alpha!!,
      percent: this.percent!!,
      color: this.color!!,
      thicknessesValue: this.thicknessesValue!!,
      strokeWidth: this.strokeWidth!!
    })
  }
}

2. 自定义底部设置面板组件

V1版全部代码如下：

import { CommonConstants } from '../common/CommonConstants';
import { IBrush } from '../viewmodel/IBrush';
import NormalBrush from '../viewmodel/IBrush';
import Paint from '../viewmodel/Paint';

@Component
export struct myPaintSheet {
  @Link isMarker: boolean;
  @Link alpha: number;
  @Link percent: string;
  @Link color: string;
  @Link thicknessesValue: number;
  @Link strokeWidth: number;
  @Consume mPaint: Paint;
  @Consume mBrush: IBrush;

  ToggleThicknessColor() {
    this.mPaint = new Paint(CommonConstants.ZERO, CommonConstants.COLOR_STRING, CommonConstants.ONE);
    this.mPaint.setStrokeWidth(this.strokeWidth);
    this.mPaint.setColor(this.color);
    this.mPaint.setGlobalAlpha(this.alpha);
    this.mBrush = new NormalBrush();
  }

  build() {
    Column() {
      Column() {
        Text($r('app.string.brash'))
          .textAlign(TextAlign.Start)
          .fontSize($r('app.float.font_size'))
          .fontColor($r('sys.color.mask_secondary'))
          .margin({ bottom: $r('app.float.margin_bottom') })
        Row() {
          Column() {
            Stack() {
              Text()
                .width($r('app.float.back_width'))
                .height($r('app.float.back_width'))
                .backgroundColor(this.isMarker ? $r('app.color.paint_color') : $r('app.color.theme_color'))
                .borderRadius($r('app.float.border_radius'))
              Image(this.isMarker ? $r('app.media.Ballpoint') : $r('app.media.Ballpoint_active'))
                .width($r('app.float.image_width'))
                .height($r('app.float.image_width'))
              Button({ type: ButtonType.Normal })
                .width($r('app.float.back_width'))
                .height($r('app.float.back_width'))
                .borderRadius($r('app.float.border_radius'))
                .backgroundColor(Color.Transparent)
                .onClick(() => {
                  this.isMarker = false;
                  this.alpha = 1;
                  this.percent = '100';
                  this.ToggleThicknessColor();
                })
            }

            Text($r('app.string.ballpoint'))
              .fontSize($r('app.float.font_size'))
              .fontColor(this.isMarker ? $r('sys.color.mask_secondary') : $r('app.color.theme_color'))
              .margin({ top: $r('app.float.margin_top') })
          }
          .width($r('app.float.brash_width'))
          .height($r('app.float.brash_height'))

          Column() {
            Stack() {
              Text()
                .width($r('app.float.back_width'))
                .height($r('app.float.back_width'))
                .backgroundColor(this.isMarker ? $r('app.color.theme_color') : $r('app.color.paint_color'))
                .borderRadius($r('app.float.border_radius'))
              Image(this.isMarker ? $r('app.media.marker_active') : $r('app.media.marker'))
                .width($r('app.float.image_width'))
                .height($r('app.float.image_width'))
              Button({ type: ButtonType.Normal })
                .width($r('app.float.back_width'))
                .height($r('app.float.back_width'))
                .borderRadius($r('app.float.border_radius'))
                .backgroundColor(Color.Transparent)
                .onClick(() => {
                  this.isMarker = true;
                  this.alpha = 0.5;
                  this.percent = '50';
                  this.ToggleThicknessColor();
                })
            }

            Text($r('app.string.marker'))
              .fontSize($r('app.float.font_size'))
              .fontColor(this.isMarker ? $r('app.color.theme_color') : $r('sys.color.mask_secondary'))
              .margin({ top: $r('app.float.margin_top') })
          }
          .width($r('app.float.brash_width'))
          .height($r('app.float.brash_height'))

          Column() {
            Stack() {
              Text()
                .width($r('app.float.back_width'))
                .height($r('app.float.back_width'))
                .backgroundColor($r('app.color.paint_color'))
                .borderRadius($r('app.float.border_radius'))
              Image($r('app.media.pencils'))
                .width($r('app.float.image_width'))
                .height($r('app.float.image_width'))
            }

            Text($r('app.string.pencil'))
              .fontSize($r('app.float.font_size'))
              .fontColor($r('sys.color.mask_secondary'))
              .margin({ top: $r('app.float.margin_top') })
          }
          .width($r('app.float.brash_width'))
          .height($r('app.float.brash_height'))

          Column() {
            Stack() {
              Text()
                .width($r('app.float.back_width'))
                .height($r('app.float.back_width'))
                .backgroundColor($r('app.color.paint_color'))
                .borderRadius($r('app.float.border_radius'))
              Image($r('app.media.fountain'))
                .width($r('app.float.image_width'))
                .height($r('app.float.image_width'))
            }

            Text($r('app.string.fountain_pen'))
              .fontSize($r('app.float.font_size'))
              .fontColor($r('sys.color.mask_secondary'))
              .margin({ top: $r('app.float.margin_top') })
          }
          .width($r('app.float.brash_width'))
          .height($r('app.float.brash_height'))

          Column() {
            Stack() {
              Text()
                .width($r('app.float.back_width'))
                .height($r('app.float.back_width'))
                .backgroundColor($r('app.color.paint_color'))
                .borderRadius($r('app.float.border_radius'))
              Image($r('app.media.laser'))
                .width($r('app.float.image_width'))
                .height($r('app.float.image_width'))
            }

            Text($r('app.string.laser_pointer'))
              .fontSize($r('app.float.font_size'))
              .fontColor($r('sys.color.mask_secondary'))
              .margin({ top: $r('app.float.margin_top') })
          }
          .width($r('app.float.brash_width'))
          .height($r('app.float.brash_height'))
        }
        .padding({
          left: $r('app.float.margin_top'),
          right: $r('app.float.margin_top')
        })
        .width(CommonConstants.ONE_HUNDRED_PERCENT)
        .justifyContent(FlexAlign.SpaceBetween)
      }
      .padding({
        left: $r('app.float.padding_left'),
        right: $r('app.float.padding_left'),
        top: $r('app.float.margin_bottom')
      })
      .alignItems(HorizontalAlign.Start)
      .width(CommonConstants.ONE_HUNDRED_PERCENT)
      .margin({ bottom: $r('app.float.title_bottom') })

      Column() {
        Text($r('app.string.color'))
          .textAlign(TextAlign.Start)
          .fontSize($r('app.float.font_size'))
          .fontColor($r('sys.color.mask_secondary'))
          .margin({ bottom: $r('app.float.margin_bottom') })
        Row() {
          ForEach(CommonConstants.COLOR_ARR, (item: string) => {
            Text()
              .width($r('app.float.image_width'))
              .height($r('app.float.image_width'))
              .borderRadius($r('app.float.border_radius_m'))
              .backgroundColor(item)
              .onClick(() => {
                this.color = item;
                this.ToggleThicknessColor();
              })
          }, (item: string) => JSON.stringify(item))
        }
        .padding({
          left: $r('app.float.margin_top'),
          right: $r('app.float.margin_top')
        })
        .justifyContent(FlexAlign.SpaceBetween)
        .width(CommonConstants.ONE_HUNDRED_PERCENT)
      }
      .padding({
        left: $r('app.float.padding_left'),
        right: $r('app.float.padding_left')
      })
      .alignItems(HorizontalAlign.Start)
      .width(CommonConstants.ONE_HUNDRED_PERCENT)
      .margin({ bottom: $r('app.float.margin_bottom') })

      Column() {
        Text($r('app.string.opacity'))
          .textAlign(TextAlign.Start)
          .fontSize($r('app.float.font_size'))
          .fontColor($r('sys.color.mask_secondary'))
          .margin({ bottom: $r('app.float.margin_top') })
        Row() {
          Stack() {
            Slider({
              style: SliderStyle.InSet,
              value: this.alpha * CommonConstants.ONE_HUNDRED
            })
              .height($r('app.float.brash_width'))
              .width($r('app.float.slider_width'))
              .selectedColor(Color.Transparent)
              .minResponsiveDistance(CommonConstants.ONE)
              .trackColor(new LinearGradient([
                { color: $r('app.color.linear_start'), offset: CommonConstants.ZERO },
                { color: $r('app.color.linear_end'), offset: CommonConstants.ONE }
              ]))
              .onChange((value: number) => {
                if (this.isMarker) {
                  this.alpha = value / 100;
                  this.percent = value.toFixed(0);
                  this.ToggleThicknessColor();
                }
              })
            if (!this.isMarker) {
              Row()
                .backgroundColor(Color.Transparent)
                .width($r('app.float.slider_width'))
                .height($r('app.float.brash_width'))
            }
          }

          Text(this.percent + CommonConstants.SIGN)
            .width($r('app.float.number'))
            .height($r('app.float.image_width'))
            .fontSize($r('app.float.font_size_l'))
            .borderRadius($r('app.float.border_radius_m'))
            .textAlign(TextAlign.Center)
            .backgroundColor($r('app.color.number_color'))
        }
        .padding({
          left: $r('app.float.margin_top'),
          right: $r('app.float.margin_top')
        })
        .justifyContent(FlexAlign.SpaceBetween)
        .width(CommonConstants.ONE_HUNDRED_PERCENT)
      }
      .padding({
        left: $r('app.float.padding_left'),
        right: $r('app.float.padding_left')
      })
      .alignItems(HorizontalAlign.Start)
      .width(CommonConstants.ONE_HUNDRED_PERCENT)
      .margin({ bottom: $r('app.float.margin_bottom') })

      Column() {
        Text($r('app.string.thicknesses'))
          .textAlign(TextAlign.Start)
          .fontSize($r('app.float.font_size'))
          .fontColor($r('sys.color.mask_secondary'))
          .margin({ bottom: $r('app.float.margin_bottom') })
        Row() {
          Image($r('app.media.minuses'))
            .width($r('app.float.image_width'))
            .height($r('app.float.image_width'))
            .onClick(() => {
              this.thicknessesValue -= 1;
              this.strokeWidth = this.thicknessesValue;
              this.ToggleThicknessColor();
            })
          Slider({
            value: this.thicknessesValue,
            min: CommonConstants.THREE,
            max: CommonConstants.TWENTY_ONE
          })
            .width($r('app.float.slider_width'))
            .minResponsiveDistance(CommonConstants.ONE)
            .onChange((value: number, _mode: SliderChangeMode) => {
              this.thicknessesValue = value;
              this.strokeWidth = value;
              this.ToggleThicknessColor();
            })
          Image($r('app.media.add'))
            .width($r('app.float.image_width'))
            .height($r('app.float.image_width'))
            .onClick(() => {
              this.thicknessesValue += 1;
              this.strokeWidth = this.thicknessesValue;
              this.ToggleThicknessColor();
            })
        }
        .padding({
          left: $r('app.float.margin_bottom'),
          right: $r('app.float.margin_bottom')
        })
        .justifyContent(FlexAlign.SpaceBetween)
        .width(CommonConstants.ONE_HUNDRED_PERCENT)
      }
      .padding({
        left: $r('app.float.padding_left'),
        right: $r('app.float.padding_left')
      })
      .alignItems(HorizontalAlign.Start)
      .width(CommonConstants.ONE_HUNDRED_PERCENT)
    }
    .width(CommonConstants.ONE_HUNDRED_PERCENT)
    .height(CommonConstants.ONE_HUNDRED_PERCENT)
  }
}

2.1. 自定义组件@Component装饰器迁移

V1版

@Component
export struct myPaintSheet {
  // ...
}

V2版

直接将@Component修改为@ComponentV2即可。

@ComponentV2
export struct myPaintSheet {
  // ...
}

2.2. @Link升级

V1版

@Link isMarker: boolean;
@Link alpha: number;
@Link percent: string;
@Link color: string;
@Link thicknessesValue: number;
@Link strokeWidth: number;

V2版

@Link迁移至V2版，需要应用@Param装饰器和@Event两个装饰器来实现。上节使用双叹号语法(!!)实现子组件传递信息给父组件，因此这里的@Event装饰的变量名的签名需要加上$符号。

@Param isMarker: boolean = false
@Event $isMarker: (val: boolean) => void = (val: boolean) => {}

@Param alpha: number = 1
@Event $alpha: (val: number) => void = (val: number) => {}

@Param percent: string = '100'
@Event $percent: (val: string) => void = (val: string) => {}

@Param color: string = '#000000'
@Event $color: (val: string) => void = (val: string) => {}

@Param thicknessesValue: number = 3
@Event $thicknessesValue: (val: number) => void = (val: number) => {}

@Param strokeWidth: number = 3
@Event $strokeWidth: (val: number) => void = (val: number) => {}

3. 遗留问题

理论上，到这里我们的迁移就结束了，但是问题来了，在去修改画笔颜色并重新画笔属性的时候，会发现修改的颜色不能同步，V1代码如下：

ToggleThicknessColor() {
  this.mPaint = new Paint(CommonConstants.ZERO, CommonConstants.COLOR_STRING, CommonConstants.ONE);
  this.mPaint.setStrokeWidth(this.strokeWidth);
  this.mPaint.setColor(this.color);
  this.mPaint.setGlobalAlpha(this.alpha);
  this.mBrush = new NormalBrush();
}

.onClick(() => {
  this.color = item;
  this.ToggleThicknessColor();
})

这是为什么呢？这个问题直接原因是：使用@Event修改父组件的值是立刻生效的，但从父组件将变化同步回子组件的过程是异步的，即在调用完@Event的方法后，子组件内的值不会立刻变化。这是因为@Event将子组件值实际的变化能力交由父组件处理，在父组件实际决定如何处理后，将最终值在渲染之前同步回子组件。看下面这个例子：

@ComponentV2
struct Child {
  @Param index: number = 0;
  @Event changeIndex: (val: number) => void;

  build() {
    Column() {
      Text(`Child index: ${this.index}`)
        .onClick(() => {
          this.changeIndex(20);
          console.log(`after changeIndex ${this.index}`);
        })
    }
  }
}
@Entry
@ComponentV2
struct Index {
  @Local index: number = 0;

  build() {
      Column() {
        Child({
          index: this.index,
          changeIndex: (val: number) => {
            this.index = val;
            console.log(`in changeIndex ${this.index}`);
          }
        })
      }
  }
}

在上面的示例中，点击文字触发@Event函数事件改变子组件的值，打印出的日志为：

in changeIndex 20
after changeIndex 0

那上面的问题找到了，但是要如何解决呢？我的思路是，让this.ToggleThicknessColor();语句延迟执行，简单处理如下：

ToggleThicknessColor() {
  this.mPaint = new Paint(CommonConstants.ZERO, CommonConstants.COLOR_STRING, CommonConstants.ONE);
  this.mPaint.setStrokeWidth(this.strokeWidth);
  this.mPaint.setColor(this.color);
  this.mPaint.setGlobalAlpha(this.alpha);
  this.mBrush = new NormalBrush();
}

.onClick(() => {
  this.color = item;
  setTimeout(() => {
    this.ToggleThicknessColor()
  }, 100)
})

这里延迟时间设置要多于10秒。
