MQTTnet 2.8使用

MQTTdemo里包含了客户端和服务端

下载地址https://download.csdn.net/download/g313105910/18161022

通过订阅主题实现消息传递

通过 builder.WithTcpServer("127.0.0.1", 5550);设置绑定IP和端口

主要代码

using MQTTnet;
using MQTTnet.Client;
using MQTTnet.Protocol;
using System;
using System.Collections.Generic;
using System.ComponentModel;
using System.Configuration;
using System.Data;
using System.Drawing;
using System.Linq;
using System.Text;
using System.Threading.Tasks;
using System.Windows.Forms;

namespace MQTTdemo
{
    public partial class FrmMain : Form
    {
        private MqttClient mqttClient = null;
        public FrmMain()
        {
            InitializeComponent();
        }
        /// <summary>
        /// 客户端配置信息
        /// </summary>
        private IMqttClientOptions Options
        {
            get
            {
                MqttClientOptionsBuilder builder = new MqttClientOptionsBuilder();

                builder.WithTcpServer(ConfigurationManager.AppSettings["ServerAddress"]);
                builder.WithCleanSession(false);
                builder.WithCredentials(ConfigurationManager.AppSettings["UserName"], ConfigurationManager.AppSettings["UserPwd"]);
                var id = Guid.NewGuid().ToString();
                builder.WithClientId(id);
                builder.WithTcpServer("127.0.0.1", 5550);
                return builder.Build();
            }
        }
        /// <summary>
        /// 连接到服务端
        /// </summary>
        /// <returns></returns>
        private void ConnectMqttServer()
        {
            MqttFactory factory = new MqttFactory();
            if (mqttClient == null)
            {
                mqttClient = (MqttClient)factory.CreateMqttClient();
                mqttClient.ApplicationMessageReceived += MqttClient_ApplicationMessageReceived;
                mqttClient.Connected += MqttClient_Connected;
                mqttClient.Disconnected += (s, e) =>
                {
                    if (!IsClose)
                    {
                        Invoke((new Action(() =>
                        {
                            if (txtReceiveMessage != null)
                            {
                                txtReceiveMessage.AppendText("已断开MQTT连接！" + Environment.NewLine);
                            }
                        })));
                        Invoke((new Action(() =>
                        {
                            txtReceiveMessage.AppendText("尝试重连！" + Environment.NewLine);
                        })));
                    }
                };
            }
            ConnectToServer();
        }

        private async void ConnectToServer()
        {
            try
            {
                var res = await mqttClient.ConnectAsync(Options);
            }
            catch (Exception ex)
            {
                Invoke((new Action(() =>
                {
                    txtReceiveMessage.AppendText($"连接到MQTT服务器失败！" + Environment.NewLine + ex.Message + Environment.NewLine);
                })));
            }
        }
        public bool IsClose { get; set; } = false;
        private void MqttClient_Connected(object sender, EventArgs e)
        {
            Invoke((new Action(() =>
            {
                txtReceiveMessage.AppendText("已连接到MQTT服务器！" + Environment.NewLine);
            })));
        }
        private void MqttClient_ApplicationMessageReceived(object sender, MqttApplicationMessageReceivedEventArgs e)
        {
            Invoke((new Action(() =>
            {
                txtReceiveMessage.AppendText($">> {Encoding.UTF8.GetString(e.ApplicationMessage.Payload)}{Environment.NewLine}");
            })));
        }

        private void BtnSubscribe_ClickAsync(object sender, EventArgs e)
        {
            string topic = txtSubTopic.Text.Trim();

            if (string.IsNullOrEmpty(topic))
            {
                MessageBox.Show("订阅主题不能为空！");
                return;
            }

            if (!mqttClient.IsConnected)
            {
                MessageBox.Show("MQTT客户端尚未连接！");
                return;
            }
            mqttClient.SubscribeAsync(new List<TopicFilter> {
                new TopicFilter(topic, MqttQualityOfServiceLevel.ExactlyOnce)
            });

            txtReceiveMessage.AppendText($"已订阅[{topic}]主题" + Environment.NewLine);
        }

        private async void BtnPublish_Click(object sender, EventArgs e)
        {
            string topic = txtPubTopic.Text.Trim();

            if (string.IsNullOrEmpty(topic))
            {
                MessageBox.Show("发布主题不能为空！");
                return;
            }

            string inputString = txtSendMessage.Text.Trim();
            MqttApplicationMessageBuilder builder = new MqttApplicationMessageBuilder();
            builder.WithPayload(Encoding.UTF8.GetBytes(inputString));
            builder.WithTopic(topic);
            builder.WithRetainFlag();
            builder.WithExactlyOnceQoS();
            await mqttClient.PublishAsync(builder.Build());
        }

        private void btnDescribe_Click(object sender, EventArgs e)
        {
            string topic = txtSubTopic.Text.Trim();

            if (string.IsNullOrEmpty(topic))
            {
                MessageBox.Show("退订主题不能为空！");
                return;
            }
            if (!mqttClient.IsConnected)
            {
                MessageBox.Show("MQTT客户端尚未连接！");
                return;
            }
            mqttClient.UnsubscribeAsync(topic);
            txtReceiveMessage.AppendText($"已退订[{topic}]主题" + Environment.NewLine);
        }

        private void FrmMain_Load(object sender, EventArgs e)
        {
            Task.Run(async () => { ConnectMqttServer(); });
        }

        private async void FrmMain_FormClosing(object sender, FormClosingEventArgs e)
        {
            IsClose = true;
            await mqttClient.DisconnectAsync();
            mqttClient.Dispose();
        }

        private void button1_Click(object sender, EventArgs e)
        {
            ConnectToServer();
        }
    }
}

MqttClient和MqttServer通过另一种方式实现了参数配置

端口设置

var options = new MqttServerOptions();
options.DefaultEndpointOptions.Port = 5550;

主要代码

using MQTTnet;
using MqttServer.General;
using System;
using System.Collections.ObjectModel;
using System.Text;
using System.Windows;
using MQTTnet.Protocol;
using MQTTnet.Server;

namespace MqttServer
{
    /// <summary>
    /// MainWindow.xaml 的交互逻辑
    /// </summary>
    public partial class MainWindow : Window
    {
        public MainWindow()
        {
            InitializeComponent();
            ClientInsTances = new ObservableCollection<ClientInstance>();
        }

        IMqttServer mqttServer;  //MQTT服务端实例

        string message;

        /// <summary>
        /// 消息   用于界面显示
        /// </summary>
        public string Message
        {
            get { return message; }
            set { message = value;  }
        }


        ObservableCollection<ClientInstance> clientInstances; //客户端登录缓存信息

        /// <summary>
        /// 客户端实例
        /// </summary>
        public ObservableCollection<ClientInstance> ClientInsTances
        {
            get { return clientInstances; }
            set { clientInstances = value;}
        }

        //开启MQTT服务
        public void OpenMqttServer()
        {
            mqttServer = new MqttFactory().CreateMqttServer();
            var options = new MqttServerOptions();
            options.DefaultEndpointOptions.Port = 5550;
            //拦截登陆
            options.ConnectionValidator = c =>
            {
                try
                {
                    Message += string.Format("用户尝试登陆:用户ID：{0}\t用户信息：{1}\t用户密码：{2}", c.ClientId, c.Username, c.Password) + "\r\n";
                    if (string.IsNullOrWhiteSpace(c.Username))
                    {
                        Message += string.Format("用户：{0}登陆失败，用户信息为空", c.ClientId) + "\r\n";

                        c.ReturnCode = MQTTnet.Protocol.MqttConnectReturnCode.ConnectionRefusedBadUsernameOrPassword;
                        return;
                    }
                    //解析用户名和密码，这个地方须要改为查找咱们本身建立的用户名和密码。
                    if (c.Username == "admin" && c.Password == "123456")
                    {
                        c.ReturnCode = MqttConnectReturnCode.ConnectionAccepted;
                        Message += c.ClientId + " 登陆成功" + "\r\n";
                        ClientInsTances.Add(new ClientInstance()
                        {
                            ClientID = c.ClientId,
                            UserName = c.Username,
                            PassWord = c.Password
                        });
                        return;
                    }
                    else
                    {
                        c.ReturnCode = MqttConnectReturnCode.ConnectionRefusedBadUsernameOrPassword;
                        Message += "用户名密码错误登录失败" + "\r\n";
                        return;
                    }
                }
                catch (Exception ex)
                {
                    Console.WriteLine("登陆失败:" + ex.Message);
                    c.ReturnCode = MqttConnectReturnCode.ConnectionRefusedIdentifierRejected;
                    return;
                }
            };
            //拦截订阅
            options.SubscriptionInterceptor = context =>
            {
                try
                {
                    Message += "用户" + context.ClientId + "订阅" + "\r\n";
                }
                catch (Exception ex)
                {
                    Console.WriteLine("订阅失败:" + ex.Message);
                    context.AcceptSubscription = false;
                }
            };
            //拦截消息
            options.ApplicationMessageInterceptor = context =>
            {
                try
                {
                    //通常不须要处理消息拦截
                    // Console.WriteLine(Encoding.UTF8.GetString(context.ApplicationMessage.Payload));
                }
                catch (Exception ex)
                {
                    Console.WriteLine("消息拦截:" + ex.Message);
                }
            };
            mqttServer.ClientDisconnected += ClientDisconnected;
            mqttServer.ClientConnected += MqttServer_ClientConnected;
            mqttServer.Started += MqttServer_Started;

            //mqttServer.ApplicationMessageReceived += MqttServer_ApplicationMessageReceived;
            //mqttServer.ClientConnected += MqttServer_ClientConnected;
            //mqttServer.ClientDisconnected += MqttServer_ClientDisconnected;
            //mqttServer.StartAsync(Options);

            mqttServer.StartAsync(options);
            Message += "Mqtt服务启动成功！";
            Application.Current.Dispatcher.Invoke(() =>
            {
                TbInfo.Text = Message;
            });
        }


        private void MqttServer_Started(object sender, EventArgs e)
        {
            Message += "消息服务启动成功：任意键退出" + "\r\n";
            Application.Current.Dispatcher.Invoke(() =>
            {
                TbInfo.Text = Message;
            });
        }

        private void MqttServer_ClientConnected(object sender, MqttClientConnectedEventArgs e)
        {
            //客户端连接
            Message += e.ClientId + "链接" + "\r\n";
            Application.Current.Dispatcher.Invoke(() =>
            {
                TbInfo.Text = Message;
            });
        }

        private void ClientDisconnected(object sender, MqttClientDisconnectedEventArgs e)
        {
            //客户端断开
            Message += e.ClientId + "断开" + "\r\n";
            Application.Current.Dispatcher.Invoke(() =>
            {
                TbInfo.Text = Message;
            });
        }

        /// <summary>
        /// 客户端推送信息    -  用于测试服务推送
        /// </summary>
        /// <param name="clientID"></param>
        /// <param name="message"></param>
        public void SendMessage(string clientID, string message)
        {
            mqttServer.PublishAsync(new MqttApplicationMessage
            {
                Topic = clientID,
                QualityOfServiceLevel = MqttQualityOfServiceLevel.ExactlyOnce,
                Retain = false,
                Payload = Encoding.UTF8.GetBytes(message),
            });
        }

        private void Strat_Click(object sender, RoutedEventArgs e)
        {
            OpenMqttServer();
        }

        private void Test_Click(object sender, RoutedEventArgs e)
        {
            foreach(var item in clientInstances)
            {
                try
                {
                    SendMessage(item.ClientID, "测试!");
                }
                catch(Exception ex)
                {
                    Application.Current.Dispatcher.Invoke(() =>
                    {
                        TbInfo.Text = ex.Message + "\r\n";
                    });
                }
            }
        }
    }
}
