在nrf52840上,P0.22口可以被配置为PWM输出。要启用高分辨率模式,您需要使用EasyDMA来传输数据。下面给出了一些基本的代码示例,可以指导您如何配置P0.22口为PWM高分辨率模式。
首先,您需要在nrfx_pwm.h头文件中定义一个nrfx_pwm_config_t结构体来配置PWM通道。以下是一个示例:
```c
nrfx_pwm_config_t const config =
{
.output_pins =
{
NRF_GPIO_PIN_MAP(0, 22), // P0.22口
NRF_PWM_PIN_NOT_USED,
NRF_PWM_PIN_NOT_USED,
NRF_PWM_PIN_NOT_USED,
},
.irq_priority = APP_IRQ_PRIORITY_LOWEST,
.base_clock = NRF_PWM_CLK_16MHz,
.count_mode = NRF_PWM_MODE_UP,
.top_value = 1000,
.load_mode = NRF_PWM_LOAD_COMMON,
.step_mode = NRF_PWM_STEP_AUTO
};
```
接下来,您可以使用以下函数来初始化PWM通道:
```c
nrfx_pwm_init(&m_pwm0, &config, NULL);
```
然后,您需要创建一个数组来存储PWM数据,并使用以下代码来将数据传输到PWM通道中:
```c
uint16_t const seq_values[] = {100, 200, 300, 400, 500, 600, 700, 800, 900, 1000};
nrf_pwm_values_individual_t seq_values_individual[] =
{
{0, seq_values[0]},
{0, seq_values[1]},
{0, seq_values[2]},
{0, seq_values[3]},
{0, seq_values[4]},
{0, seq_values[5]},
{0, seq_values[6]},
{0, seq_values[7]},
{0, seq_values[8]},
{0, seq_values[9]}
};
nrfx_pwm_simple_playback(&m_pwm0, &seq, 1, NRFX_PWM_FLAG_LOOP);
```
在这个例子中,我们将PWM输出设置为循环模式,并在10个步骤中输出不同的PWM值。
最后,您可以使用以下代码停止PWM输出:
```c
nrfx_pwm_stop(&m_pwm0, true);
```
希望这能帮助到您。
