android实现自定义顶部标题栏

标题布局

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="52dp"
    android:background="#ed4255">

    <TextView
        android:id="@+id/title"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        android:ellipsize="marquee"
        android:gravity="center_horizontal|center"
        android:text="标题"
        android:textColor="#ffffffff"
        android:textSize="20dp" />

    <TextView
        android:id="@+id/backward"
        android:layout_width="60dp"
        android:layout_height="match_parent"
        android:drawablePadding="6dp"
        android:ellipsize="end"
        android:gravity="center"
        android:paddingLeft="5dp"
        android:text="返回"
        android:textColor="#ffffffff"
        android:textSize="18dp" />

    <TextView
        android:id="@+id/forward"
        android:layout_width="60dp"
        android:layout_height="match_parent"
        android:layout_alignParentRight="true"
        android:drawablePadding="6dp"
        android:ellipsize="end"
        android:gravity="center"
        android:paddingLeft="5dp"
        android:text="提交"
        android:textColor="#ffffffff"
        android:textSize="18dp" />

</RelativeLayout>

MainActivity引用布局并添加自己内容

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:orientation="vertical"
    tools:context="com.bw.titleactivitydemo.MainActivity">

    <include layout="@layout/activity_title" />

    <TextView
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        android:padding="20dp"
        android:text="Hollo Word !"/>
</LinearLayout>

TitleActivity设置

package com.bw.titleactivitydemo;

import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;
import android.view.View;
import android.view.View.OnClickListener;
import android.widget.TextView;
import android.widget.Toast;

/*
* 自定义TitleActivity
* */
public abstract class TitleActivity extends AppCompatActivity implements OnClickListener {

    /**
     * 标题栏
     */
    private TextView mTitle;
    /**
     * < 返回
     */
    private TextView mBackward;
    /**
     * 提交
     */
    private TextView mForward;

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(getLayoutId());
        initView();

    }

    public abstract int getLayoutId();
    //初始化组件
    private void initView() {
        mTitle = (TextView) findViewById(R.id.title);
        mBackward = (TextView) findViewById(R.id.backward);
        mBackward.setOnClickListener(this);
        mForward = (TextView) findViewById(R.id.forward);
        mForward.setOnClickListener(this);
    }


    //返回按钮和提交按钮的点击判断监听事件
    @Override
    public void onClick(View v) {
        switch (v.getId()) {
            default:
                break;
            case R.id.backward:
                Toast.makeText(this, "点击返回，可在此处调用finish()", Toast.LENGTH_SHORT).show();
                break;
            case R.id.forward:
                Toast.makeText(this, "我是提交按钮", Toast.LENGTH_SHORT).show();
                break;
        }
    }
}

MainActivity继承TitleActivity

package com.bw.titleactivitydemo;

import android.os.Bundle;

public class MainActivity extends TitleActivity {
    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
    }
    @Override
    public int getLayoutId() {
        return (R.layout.activity_main);
    }
}
