Hi各位,我是树林子,一个工作两年的程序员。
最近接收到一个开发任务,给照片添加水印功能,最开始是一条对角线的水印,做完后被否掉了,要求平铺,查来查去走了不少坑,所以决定写一篇对小白超级友好,巨详细的文章。
第一种原图:
第一种效果图:
如果以上是你想找的,话不多说,抓紧往下看!!!!!!
调用:
//1、水印文字
String logoText = "这只是一个水印 SMALLGROVE";
//2、获取原始图片路径(我这里只写了本地图片路径,还有一种是从服务器的归档文件中获取)
String srcImgPath = "d:/srcImg.png";
//3、目标图片路径(加完水印之后的图片,要存放的路径,随便起的名字)
String targetPath = "d:/targetImg.png";
//4、给图片添加水印文字(logoText水印内容,srcImgPath原图片路径,targerPath目标图片路径)
markImageByText(logoText, srcImgPath, targetPath);
水印处理的方法:
/**
* 给图片添加水印文字、可设置水印文字的大小、旋转角度、透明度
* @param logoText 水印内容
* @param srcImgPath 原图片路径
* @param targetImgPath 目标图片路径
*/
public void markImageByText(String logoText, String srcImgPath,
String targetImgPath) throws IOException {
debugLog("图片开始添加水印文字");
// 1、读取源图片,Image获取图片宽度、高度
Image scrImg = ImageIO.read(new File(srcImgPath));
BufferedImage buffImg = new BufferedImage(scrImg.getWidth(null), scrImg.getHeight(null), BufferedImage.TYPE_INT_RGB);
// 2、得到画笔对象
Graphics2D graphics = buffImg.createGraphics();
// 3、设置对线段的锯齿状边缘处理
graphics.setRenderingHint(RenderingHints.KEY_INTERPOLATION, RenderingHints.VALUE_INTERPOLATION_BILINEAR);
graphics.drawImage(scrImg.getScaledInstance(scrImg.getWidth(null), scrImg.getHeight(null), Image.SCALE_SMOOTH), 0, 0, null);
// 4、设置水印倾斜度,这里是在图片的对角线上
// 对角线长度lengthOfDiagonal
double lengthOfDiagonal = Math.sqrt(Math.pow(buffImg.getWidth(),2) + Math.pow(buffImg.getHeight(),2));
double v = (Math.pow(buffImg.getWidth(), 2) + Math.pow(lengthOfDiagonal, 2) - Math.pow(buffImg.getHeight(), 2)) / (2 * buffImg.getWidth() * lengthOfDiagonal);
//get到了一个弧度数
double acos = Math.acos(v);
double myDegree = Math.toDegrees(acos);
//这里的负号决定对角线-Math.toRadians(myDegree)
graphics.rotate(-Math.toRadians(myDegree),
(double) buffImg.getWidth() / 2,
(double) buffImg.getHeight() / 2);
// 5、设置水印文字颜色
graphics.setColor(Color.RED);
// 6、获取源图片的宽度和高度
int width = scrImg.getWidth(null);
int heigth = scrImg.getHeight(null);
// 7、设置水印文字大小(根据原图的宽、高度,我这里是哪个长就取哪个,再除上水印字符串长度,记为size)
int size = 0;
if (width >= heigth) {
size = width / logoText.length();
} else {
size = heigth / logoText.length();
}
//Font是JAVA中的字体类,PLAIN:普通样式常量;BOLD:粗体样式常量;ITALIC:斜体样式常量
//如下初始化对象:Font font = new Font("宋体" , Font.BOLD , 23);该字体表示23磅粗体的宋体字
graphics.setFont(new Font("宋体", Font.PLAIN, size));
//8、设置透明度
graphics.setComposite(AlphaComposite.getInstance(AlphaComposite.SRC_ATOP,
0.3f));
//9、设置文字位置
FontDesignMetrics metrics = FontDesignMetrics.getMetrics(graphics.getFont());
//获取文字宽度
int strWidth = metrics.stringWidth(logoText);
int strHeight = metrics.getHeight();
//文字在画布上的坐标
int left = (width - strWidth) / 2;
//有条基线,加上ascent,相当于画布要向上移动(或是文字向下移),才能保证文字是居中的
int top = (heigth - strHeight) / 2 + metrics.getAscent();
//10、水印文字开始动工了,文字内容,x,y坐标
graphics.drawString(logoText, left, top);
//11、释放资源
graphics.dispose();
//12、生成图片
try {
OutputStream os = null;
os = new FileOutputStream(targetImgPath);
ImageIO.write(buffImg, "png", os);
} catch (FileNotFoundException e) {
e.printStackTrace();
}
debugLog("图片完成添加水印文字");
}
第二种原图:
第二种效果图:
/**
* 给图片添加水印文字、可设置水印文字的大小、旋转角度、透明度
*
* @param logoText 水印内容
* @param srcImgPath 原图片路径
* @param targerPath 目标图片路径
*/
public void markImageByText(String logoText, String srcImgPath,
String targerPath) throws IOException {
debugLog("图片开始添加水印文字");
// 1、读取源图片,Image获取图片宽度、高度
Image scrImg = ImageIO.read(new File(srcImgPath));
BufferedImage buffImg = new BufferedImage(scrImg.getWidth(null), scrImg.getHeight(null), BufferedImage.TYPE_INT_RGB);
// 2、得到画笔对象
Graphics2D graphics = buffImg.createGraphics();
// 3、设置对线段的锯齿状边缘处理
graphics.setRenderingHint(RenderingHints.KEY_INTERPOLATION, RenderingHints.VALUE_INTERPOLATION_BILINEAR);
graphics.drawImage(scrImg.getScaledInstance(scrImg.getWidth(null), scrImg.getHeight(null), Image.SCALE_SMOOTH), 0, 0, null);
// 4、设置水印倾斜度,这里是在图片的对角线上
// 对角线长度lengthOfDiagonal
double lengthOfDiagonal = Math.sqrt(Math.pow(buffImg.getWidth(), 2) + Math.pow(buffImg.getHeight(), 2));
double v = (Math.pow(buffImg.getWidth(), 2) + Math.pow(lengthOfDiagonal, 2) - Math.pow(buffImg.getHeight(), 2)) / (2 * buffImg.getWidth() * lengthOfDiagonal);
//get到了一个弧度数
double acos = Math.acos(v);
double myDegree = Math.toDegrees(acos);
//这里的负号决定对角线-Math.toRadians(myDegree)
graphics.rotate(-Math.toRadians(myDegree),
(double) buffImg.getWidth() / 2,
(double) buffImg.getHeight() / 2);
// 5、设置水印文字颜色
graphics.setColor(Color.DARK_GRAY);
// 6、获取源图片的宽度和高度
int width = scrImg.getWidth(null);
int heigth = scrImg.getHeight(null);
graphics.setFont(new Font("微软雅黑", Font.BOLD, 50));
//8、设置透明度
graphics.setComposite(AlphaComposite.getInstance(AlphaComposite.SRC_ATOP,
0.2f));
//9、设置文字位置
FontDesignMetrics metrics = FontDesignMetrics.getMetrics(graphics.getFont());
//获取文字宽度
int strWidth = metrics.stringWidth(logoText);
int xNum = width / strWidth + 1;
int yNum = heigth / 50 + 1;
int split = 50;
for (int i = 1; i <= 2 * yNum; i++) {
int y = -heigth + 50 * i + 5 * split * i;
for (int j = 0; j < xNum; j++) {
int x = strWidth * j + 3 * split * j;
graphics.drawString(logoText, x, y);
}
}
//11、释放资源
graphics.dispose();
//12、生成图片
try {
OutputStream os = null;
os = new FileOutputStream(targerPath);
ImageIO.write(buffImg, "jpg", os);
} catch (
FileNotFoundException e) {
e.printStackTrace();
}
debugLog("图片完成添加水印文字");
}
平时会更一些日常工作中遇到的问题,以此来记录自己的成长。
下期见面!Bye!
