HDLBits-Verilog:K-map implemented with a multiplexer

For the following Karnaugh map, give the circuit implementation using one 4-to-1 multiplexer and as many 2-to-1 multiplexers as required, but using as few as possible. You are not allowed to use any other logic gate and you must use a and b as the multiplexer selector inputs, as shown on the 4-to-1 multiplexer below.

You are implementing just the portion labelled top_module, such that the entire circuit (including the 4-to-1 mux) implements the K-map.



module top_module (//我的answer横着拆
    input c,
    input d,
    output reg [3:0] mux_in
);
​
    wire [1:0] cd;//注意这里一定不要忘记声明长度!
    assign cd={c,d};
    always@(*) begin
        case(cd)
            2'b00:mux_in=4'b0100;
            2'b01:mux_in=4'b0001;
            2'b10:mux_in=4'b0101;
            2'b11:mux_in=4'b1001;
        endcase
    end

endmodule
module top_module (//refer answer竖着拆
    input c,
    input d,
    output [3:0] mux_in
);

    // After splitting the truth table into four columns,
    // the rest of this question involves implementing logic functions
    // using only multiplexers (no other gates).
    // I will use the conditional operator for each 2-to-1 mux: (s ? a : b)
    assign mux_in[0] = c ? 1 : d;          // 1 mux:   c|d
    assign mux_in[1] = 0;                  // No muxes:  0
    assign mux_in[2] = d ? 0 : 1;          // 1 mux:    ~d
    assign mux_in[3] = c ? d : 0;          // 1 mux:   c&d

endmodule
