简介
- 是什么 -
Pannellum
是一个可以利用全景图片来生成VR场景展示的插件。 - 特点 - 可以加载一张全景图片,也可以加载多张图片合成一个场景;可以设定
hotSpots
来进行标记场景中的特定事物,也可以来进行场景之间的切换来展示较大视图的不同部分; - 使用场景 - VR看房
下载
pannellum下载地址: https://pannellum.org/download/
基本demo配置
这里是基本前提配置,后面demo省略这里,只展示js部分
<!DOCTYPE HTML>
<html>
<head>
<meta charset="utf-8">
<meta name="viewport" content="width=device-width, initial-scale=1.0">
<title>Compass</title>
<link rel="stylesheet" href="./pannellum/pannellum.css" />
<style>
#panorama {
width: 600px;
height: 400px;
}
</style>
</head>
<body>
<div id="panorama"></div>
</body>
<script src="./pannellum/pannellum.js"></script>
<script src="./index.js"></script>
</html>
加载全景图
只配置全景图来进行场景展示
// pannellum为暴露的全局方法
// viewer方法来生成场景视图 - pannellum.viewer(containerId, option);
// containerId - 容器ID
// option - 视图生成初始配置项
pannellum.viewer('panorama', {
panorama: "https://pannellum.org/images/bloomberg.jpg"
});
效果图
自动加载
// autoLoad: 是否自动加载 true-自动加载全景图; false-不自动加载; 默认为false
pannellum.viewer('panorama', {
autoLoad: true,
panorama: "https://pannellum.org/images/bloomberg.jpg",
});
效果图
自动旋转
// autoRotate: 加载后的自动旋转速度,number类型,单位为deg/s; 正数-逆时针; 负数-顺时针; 默认为-
// autoRotateInactivityDelay: 用户活动停止后开始自动旋转全景图,毫秒为单位。
pannellum.viewer('panorama', {
autoLoad: true,
panorama: "https://pannellum.org/images/bloomberg.jpg",
autoRotate: 10,
autoRotateInactivityDelay: 1000,
});
效果图
热点配置
// hotSpots: 热点设置-也可称为标记
// hotSpots-pitch: 垂直位置, 单位deg
// hotSpots-yaw: 水平位置, 单位deg
// hotSpots-type: 类型, 可取值 - info, scene
// hotSpots-text: 悬浮提示内容
// hotSpots-URL: 链接url
// hotSpots-sceneId: 指定要链接到`scene`热点的场景ID
pannellum.viewer('panorama', {
autoLoad: true,
panorama: "https://pannellum.org/images/bloomberg.jpg",
previewTitle: '我在右下角展示呢',
hotSpots: [
{
pitch: 14.1,
yaw: 1.5,
type: "info",
text: "外部链接",
URL: "https://artbma.org/"
},
{
pitch: -9.4,
yaw: 222.6,
type: "scene",
text: "场景",
sceneId: "切入场景id"
},
{
pitch: -0.9,
yaw: 144.4,
type: "info",
text: "信息"
}
]
});
效果图
时间旅行
// 时间旅行
// sceneFadeDuration: 场景转换的时候,淡入淡出的时间设置,单位`ms`
// scenes: 多个场景配置,first, second-为场景ID
// scene-title: 标题
// scene-hfov: 水平视野, 单位deg, 默认100
// scene-pitch: 垂直位置, 单位deg, 默认100
// scene-yaw: 水平位置, 单位deg, 默认100
// scene-type: 场景图类型, 默认为equirectangular
pannellum.viewer('panorama', {
default: {
firstScene: "first",
author: "作者在这里",
sceneFadeDuration: 1000
},
scenes: {
first: {
title: "场景一",
hfov: 110,
pitch: -3,
yaw: 117,
type: "equirectangular",
panorama: "https://pannellum.org/images/from-tree.jpg",
hotSpots: [
{
pitch: -2.1,
yaw: 132.9,
type: "scene",
text: "切入场景二",
sceneId: "second"
}
]
},
second: {
title: "场景二",
hfov: 110,
yaw: 5,
type: "equirectangular",
panorama: "https://pannellum.org/images/bma-0.jpg",
hotSpots: [
{
pitch: -0.6,
yaw: 37.1,
type: "scene",
text: "切入场景一",
sceneId: "first",
targetYaw: -23,
targetPitch: 2
}
]
}
}
});
效果图
