MongoDB分片集群搭建

分片集群搭建过程

配置并启动config节点集群

config部分的yml

version: '3'
services:
  # config server配置
  mongo_config_server_node_1:
    image: mongo:latest
    container_name: mongo_config_server_node_1
    ports:
      - 27010:27017
    volumes:
      - ./config_server/node_1/data:/data/db
      - ./config_server/node_1/log:/var/log/mongodb
      - ./config_server/node_1/mongo-entrypoint/:/docker-entrypoint-initdb.d/
      - ./config_server/node_1/mongod.conf:/etc/mongod.conf
    entrypoint: ["mongod","--config","/etc/mongod.conf"]
  mongo_config_server_node_2:
    image: mongo:latest
    container_name: mongo_config_server_node_2
    ports:
      - 27011:27017
    volumes:
      - ./config_server/node_2/data:/data/db
      - ./config_server/node_2/log:/var/log/mongodb
      - ./config_server/node_2/mongo-entrypoint/:/docker-entrypoint-initdb.d/
      - ./config_server/node_2/mongod.conf:/etc/mongod.conf
    entrypoint: ["mongod","--config","/etc/mongod.conf"]
  mongo_config_server_node_3:
    image: mongo:latest
    container_name: mongo_config_server_node_3
    ports:
      - 27012:27017
    volumes:
      - ./config_server/node_3/data:/data/db
      - ./config_server/node_3/log:/var/log/mongodb
      - ./config_server/node_3/mongo-entrypoint/:/docker-entrypoint-initdb.d/
      - ./config_server/node_3/mongod.conf:/etc/mongod.conf
    entrypoint: ["mongod","--config","/etc/mongod.conf"]

创建config_server/node_1，config_server/node_2，config_server/node_3三个目录并且添加上相同配置文件mongod.conf

# 数据库文件位置
# 以追加方式写入日志
logappend=true
# 绑定ip
bind_ip=0.0.0.0
# 绑定端口
port = 27017
# 表示是一个配置服务器
configsvr=true
#配置服务器副本集名称
replSet=config-server

# 是否以守护进程方式运行
# fork = true
# 数据库文件位置
# dbpath=config/config1
# 日志文件位置
# logpath=config/logs/config1.log

使用docker-compose up启动容器，随后进入到其中一个容器当中，使用mongo shell添加节点集群的配置，注意要use admin

// 进入mongo
mongo
// 使用admin
use admin
// 初始化配置信息
var cfg = {

	"_id": "config-server",
	"members": [{

		"_id": 1,
		"host": "mongo_config_server_node_1:27017"
	}, {

		"_id": 2,
		"host": "mongo_config_server_node_2:27017"
	}, {

		"_id": 3,
		"host": "mongo_config_server_node_3:27017"
	}]
}
// 执行初始化
rs.initiate(cfg)

配置shard集群

需要搭建起mongo_shard_1和mongo_shard_2两个ReplicaSet集群，具体的步骤如下，创建shard_1/node_1,shard_1/node_2，shard_1/node_3三个目录，并分别在目录下面创建mongod.conf文件。

# 绑定ip
bind_ip=0.0.0.0
# 绑定端口
port=27017
# 日志是否总是在后面附加
logappend=true
# replSet名称，要相同才能进入同一个replSet
replSet=shard_1
# 开启日志，似乎默认就是开启的
journal=true
# 开启权限验证
# auth=true

# 数据存储的路径(在docker中的话不需要添加，使用映射即可)
# dbpath=/opt/shell-script/mongo_cluster/node_1/data
# 日志的存储路径(在docker中的话不需要添加，使用映射即可)
# logpath=/opt/shell-script/mongo_cluster/node_1/log/server.log
# 是否后台启动(在docker中的话不需要添加，因为会停止)
# fork=true

在之前的docker-compose文件后面继续追加shard1的相关配置。
docker-compose.yml

version: '3'
services:
  # config server
  mongo_config_server_node_1:
    image: mongo:latest
    container_name: mongo_config_server_node_1
    ports:
      - 27010:27017
    volumes:
      - ./config_server/node_1/data:/data/db
      - ./config_server/node_1/log:/var/log/mongodb
      - ./config_server/node_1/mongo-entrypoint/:/docker-entrypoint-initdb.d/
      - ./config_server/node_1/mongod.conf:/etc/mongod.conf
    entrypoint: ["mongod","--config","/etc/mongod.conf"]
  mongo_config_server_node_2:
    image: mongo:latest
    container_name: mongo_config_server_node_2
    ports:
      - 27011:27017
    volumes:
      - ./config_server/node_2/data:/data/db
      - ./config_
