Maven

<dependency>
    <groupId>org.apache.pdfbox</groupId>
    <artifactId>pdfbox</artifactId>
    <version>2.0.21</version>
</dependency>

PdfUtil

import org.apache.commons.collections4.CollectionUtils;
import org.apache.pdfbox.cos.COSDictionary;
import org.apache.pdfbox.cos.COSName;
import org.apache.pdfbox.multipdf.LayerUtility;
import org.apache.pdfbox.pdmodel.PDDocument;
import org.apache.pdfbox.pdmodel.PDPage;
import org.apache.pdfbox.pdmodel.common.PDRectangle;
import org.apache.pdfbox.pdmodel.graphics.form.PDFormXObject;

import java.awt.geom.AffineTransform;
import java.io.File;
import java.io.IOException;
import java.nio.charset.Charset;
import java.nio.file.Files;
import java.nio.file.Paths;
import java.util.Arrays;
import java.util.List;
import java.util.stream.Collectors;

/**
 * @Author: liaoy
 * @Date: 2024-02-28-10:49
 * @Description:
 */
public class PdfUtil {

    private static final float wight = 610.f;
    private static final float height = 394.f;
    private static final float padding = 10;

    public static void mergeInvoice(List<String> files, String dest) throws IOException {
        if (CollectionUtils.isNotEmpty(files)) {
            PDDocument pdDocument = new PDDocument();
            int heightCount = (int) Math.ceil(files.size() / 2.0);
            if (heightCount < 2) {
                heightCount = 2;
            }
            float v = height * heightCount + padding * (heightCount - 1);
            PDRectangle outPdfFrame = new PDRectangle(wight * 2 + padding, v);
            COSDictionary dict = new COSDictionary();
            dict.setItem(COSName.TYPE, COSName.PAGE);
            dict.setItem(COSName.MEDIA_BOX, outPdfFrame);
            dict.setItem(COSName.CROP_BOX, outPdfFrame);
            dict.setItem(COSName.ART_BOX, outPdfFrame);
            PDPage page = new PDPage(dict);
            pdDocument.addPage(page);
            LayerUtility layerUtility = new LayerUtility(pdDocument);

            for (int i = 0; i < files.size(); i++) {
                PDFormXObject formPdf = layerUtility.importPageAsForm(PDDocument.load(Files.newInputStream(Paths.get(files.get(i)))), 0);
                double tx;
                if (i % 2 == 0) {
                    tx = 0.0;
                } else {
                    tx = wight + padding;
                }
                int h = i / 2 + 1;
                double ty = (heightCount - h) * height + (heightCount - h - 1) * padding;

                AffineTransform form = AffineTransform.getTranslateInstance(tx, ty);
                layerUtility.appendFormAsLayer(page, formPdf, form, String.valueOf(i));
            }
            pdDocument.save(dest);
            pdDocument.close();
        }
    }
}

代码比较糙，可以自己修改，这里提供个思路。

想随意拼接需要涉及到AffineTransform仿射变换，可以学习学习。
