celery源码分析
本文环境python3.5.2,celery4.0.2,django1.10.x系列
celery的worker启动
在上文中分析到了Hub类的初始化,接下来继续分析Pool类的初始化,
class Pool(bootsteps.StartStopStep):
"""Bootstep managing the worker pool.
Describes how to initialize the worker pool, and starts and stops
the pool during worker start-up/shutdown.
Adds attributes:
* autoscale
* pool
* max_concurrency
* min_concurrency
"""
requires = (Hub,)
...
def create(self, w):
semaphore = None
max_restarts = None
if w.app.conf.worker_pool in GREEN_POOLS: # pragma: no cover 判断worker_pool是在'eventlet', 'gevent'中默认的是prefork
warnings.warn(UserWarning(W_POOL_SETTING))
threaded = not w.use_eventloop or IS_WINDOWS # user_eventloop是否为True和是否是windows如果是则使用线程
procs = w.min_concurrency # 最小缓冲池个数,默认为4
w.process_task = w._process_task # 将worker的_process_task绑定到process_task
if not threaded: # 不使用线程的话
semaphore = w.semaphore = LaxBoundedSemaphore(procs) # 通过LaxBoundedSemaphore实现原子操作,利用队列实现
w._quick_acquire = w.semaphore.acquire # 将相关的操作方法赋值给worker
w._quick_release = w.semaphore.release
max_restarts = 100 # 最大重启次数
if w.pool_putlocks and w.pool_cls.uses_semaphore: # 通过查看类配置是否更新process_task方法
w.process_task = w._process_task_sem # 默认配置更新process_task
allow_restart = w.pool_restarts # 是否允许重启
pool = w.pool = self.instantiate( #
w.pool_cls, w.min_concurrency, # w.pool_cls默认是prefork.TaskPool
initargs=(w.app, w.hostname),
maxtasksperchild=w.max_tasks_per_child,
max_memory_per_child=w.max_memory_per_child,
timeout=w.time_limit,
soft_timeout=w.soft_time_limit,
putlocks=w.pool_putlocks and threaded,
lost_worker_timeout=w.worker_lost_wait,
threads=threaded,
max_restarts=max_restarts,
allow_restart=allow_restart,
forking_enable=True,
semaphore=semaphore,
sched_strategy=self.optimization,
app=w.app,
)
_set_task_join_will_block(pool.task_join_will_block)
return pool
此时调用s.include方法会调用到Pool的create方法,该方法就是实力化了一个连接池。
Beat类分析,此时继续执行会执行到beat类,
class Beat(bootsteps.StartStopStep):
"""Step used to embed a beat process.
Enabled when the ``beat`` argument is set.
"""
label = 'Beat'
conditional = True
def __init__(self, w, beat=False, **kwargs):
self.enabled = w.beat = beat
w.beat = None
super(Beat, self).__init__(w, beat=beat, **kwargs)
def create(self, w):
from celery.beat import EmbeddedService
if w.pool_cls.__module__.endswith(('gevent', 'eventlet')): # 检查pool_cls是否是'gevent', 'eventlet'
raise ImproperlyConfigured(ERR_B_GREEN) # 如果是则不能使用定时任务
b = w.beat = EmbeddedService(w.app,
schedule_filename=w.schedule_filename,
scheduler_cls=w.scheduler) # 根据线程或者进程来开启定时任务
return b
此时beat类会根据传入的参数来确定是开启线程或者进程来执行定时任务。
Consumer类的加载过程如下,
class Consumer(bootsteps.StartStopStep):
"""Bootstep starting the Consumer blueprint."""
last = True
def create(self, w):
if w.max_concurrency: # 是否设置最大进程数
prefetch_count = max(w.min_concurrency, 1) * w.prefetch_multiplier # 最大进程数乘以CPU数
else:
prefetch_count = w.concurrency * w.prefetch_multiplier # 获取最终设置运行进程数
c = w.consumer = self.instantiate(
w.consumer_cls, w.process_task, # 初始化consumer类
hostname=w.hostname,
task_events=w.task_events,
init_callback=w.ready_callback,
initial_prefetch_count=prefetch_count,
pool=w.pool,
timer=w.timer,
app=w.app,
controller=w,
hub=w.hub,
worker_options=w.options,
disable_rate_limits=w.disable_rate_limits,
prefetch_multiplier=w.prefetch_multiplier,
)
return c
此时加载Consumer类,此时会加载位于celery/worker/consumer.py中的Consumer类,该类的加载过程如worker类似,
@python_2_unicode_compatible
class Consumer(object):
"""Consumer blueprint."""
Strategies = dict
#: Optional callback called the first time the worker
#: is ready to receive tasks.
init_callback = None
#: The current worker pool instance.
pool = None
#: A timer used for high-priority internal tasks, such
#: as sending heartbeats.
timer = None
restart_count = -1 # first start is the same as a restart
class Blueprint(bootsteps.Blueprint):
"""Consumer blueprint."""
name = 'Consumer'
default_steps = [
'celery.worker.consumer.connection:Connection',
'celery.worker.consumer.mingle:Mingle',
'celery.worker.consumer.events:Events',
'celery.worker.consumer.gossip:Gossip',
'celery.worker.consumer.heart:Heart',
'celery.worker.consumer.control:Control',
'celery.worker.consumer.tasks:Tasks',
'celery.worker.consumer.consumer:Evloop',
'celery.worker.consumer.agent:Agent',
]
def shutdown(self, parent):
self.send_all(parent, 'shutdown')
def __init__(self, on_task_request,
init_callback=noop, hostname=None,
pool=None, app=None,
timer=None, controller=None, hub=None, amqheartbeat=None,
worker_options=None, disable_rate_limits=False,
initial_prefetch_count=2, prefetch_multiplier=1, **kwargs):
self.app = app # 设置app
self.controller = controller # 设置worker的类
self.init_callback = init_callback # 设置初始化完成的回调函数
self.hostname = hostname or gethostname() # 获取运行的hostname
self.pid = os.getpid() # 获取进程的pid
self.pool = pool # 设置连接池
self.timer = timer # 设置timer
self.strategies = self.Strategies()
self.conninfo = self.app.connection_for_read() # 连接信息
self.connection_errors = self.conninfo.connection_errors
self.channel_errors = self.conninfo.channel_errors
self._restart_state = restart_state(maxR=5, maxT=1) # 重置状态
self._does_info = logger.isEnabledFor(logging.INFO)
self._limit_order = 0
self.on_task_request = on_task_request
self.on_task_message = set()
self.amqheartbeat_rate = self.app.conf.broker_heartbeat_checkrate # 心跳速率
self.disable_rate_limits = disable_rate_limits
self.initial_prefetch_count = initial_prefetch_count
self.prefetch_multiplier = prefetch_multiplier
# this contains a tokenbucket for each task type by name, used for
# rate limits, or None if rate limits are disabled for that task.
self.task_buckets = defaultdict(lambda: None)
self.reset_rate_limits()
self.hub = hub # 设置hub
if self.hub or getattr(self.pool, 'is_green', False):
self.amqheartbeat = amqheartbeat
if self.amqheartbeat is None:
self.amqheartbeat = self.app.conf.broker_heartbeat
else:
self.amqheartbeat = 0
if not hasattr(self, 'loop'): # 设置loop
self.loop = loops.asynloop if hub else loops.synloop
if _detect_environment() == 'gevent': # 判断是否是gevent
# there's a gevent bug that causes timeouts to not be reset,
# so if the connection timeout is exceeded once, it can NEVER
# connect again.
self.app.conf.broker_connection_timeout = None
self._pending_operations = []
self.steps = []
self.blueprint = self.Blueprint(
steps=self.app.steps['consumer'],
on_close=self.on_close,
) # 初始化blueprint类
self.blueprint.apply(self, **dict(worker_options or {}, **kwargs)) # 调用该类的apply方法
当该类初始化完成后,就会调用blueprint.apply方法,此时执行的操作就是加载blueprint类中的default_steps,在此就不一一分析该类的初始化和加载过程。
当所有的类初始化完成后,此时就是一个worker就初始化完成,此时初始化完成后就执行到了celery/bin/worker.py中的256行,
worker.start()
此时调用的方法就是celery/apps/worker.py中的,
def start(self):
try:
self.blueprint.start(self) # 此时调用blueprint的start方法
except WorkerTerminate:
self.terminate()
except Exception as exc:
logger.critical('Unrecoverable error: %r', exc, exc_info=True)
self.stop(exitcode=EX_FAILURE)
except SystemExit as exc:
self.stop(exitcode=exc.code)
except KeyboardInterrupt:
self.stop(exitcode=EX_FAILURE)
此时查看blueprint的start方法,
def start(self, parent):
self.state = RUN # 设置当前运行状态
if self.on_start: # 如果初始化是传入了该方法就执行该方法
self.on_start()
for i, step in enumerate(s for s in parent.steps if s is not None): # 依次遍历step并调用step的start方法
self._debug('Starting %s', step.alias)
self.started = i + 1
step.start(parent)
logger.debug('^-- substep ok')
此时,parent.steps就是在step.include中添加到该数组中,parent.steps目前值为[Hub,Pool,Beat,Consumer],此时调用了worker的on_start方法,
def on_start(self):
app = self.app # 设置app
WorkController.on_start(self) # 调用父类的on_start
# this signal can be used to, for example, change queues after
# the -Q option has been applied.
signals.celeryd_after_setup.send(
sender=self.hostname, instance=self, conf=app.conf,
)
if self.purge:
self.purge_messages()
if not self.quiet:
self.emit_banner() # 打印启动信息
self.set_process_status('-active-')
self.install_platform_tweaks(self) # 注册相应的信号处理handler
if not self._custom_logging and self.redirect_stdouts:
app.log.redirect_stdouts(self.redirect_stdouts_level)
父类的on_start就是创建pid文件,
def on_start(self):
if self.pidfile:
self.pidlock = create_pidlock(self.pidfile) # 创建pid文件
其中注册相关的信号处理handler的函数如下,
def install_platform_tweaks(self, worker):
"""Install platform specific tweaks and workarounds."""
if self.app.IS_macOS:
self.macOS_proxy_detection_workaround()
# Install signal handler so SIGHUP restarts the worker.
if not self._isatty:
# only install HUP handler if detached from terminal,
# so closing the terminal window doesn't restart the worker
# into the background.
if self.app.IS_macOS:
# macOS can't exec from a process using threads.
# See https://github.com/celery/celery/issues#issue/152
install_HUP_not_supported_handler(worker)
else:
install_worker_restart_handler(worker) # 注册重启的信号 SIGHUP
install_worker_term_handler(worker)
install_worker_term_hard_handler(worker)
install_worker_int_handler(worker)
install_cry_handler() # SIGUSR1 信号处理函数
install_rdb_handler() # SIGUSR2 信号处理函数
就单独分析一下重启的函数,
def _reload_current_worker():
platforms.close_open_fds([
sys.stdin, sys.stdout, sys.stderr,
]) # 关闭已经打开的文件描述符
os.execv(sys.executable, [sys.executable] + sys.argv) # 重新加载该程序
def install_worker_restart_handler(worker, sig=’SIGHUP’):
def restart_worker_sig_handler(*args):
"""Signal handler restarting the current python program."""
set_in_sighandler(True)
safe_say('Restarting celery worker ({0})'.format(' '.join(sys.argv)))
import atexit
atexit.register(_reload_current_worker) # 注册程序退出时执行的函数
from celery.worker import state
state.should_stop = EX_OK # 设置状态
platforms.signals[sig] = restart_worker_sig_handler
其中的platforms.signals类设置了setitem方法,
def __setitem__(self, name, handler):
"""Install signal handler.
Does nothing if the current platform has no support for signals,
or the specified signal in particular.
"""
try:
_signal.signal(self.signum(name), handler)
except (AttributeError, ValueError):
pass
此时就将相应的handler设置到了运行程序中,_signal就是导入的signal库。
此时就继续执行Blueprint中的start方法中,依次遍历parent.steps的方法中,依次调用step的start方法,依次遍历Hub,Pool,Beat,Consumer,
由于Hub重写了start方法,该方法什么都不执行,
def start(self, w):
pass
继续调用Pool方法,此时会调用到StartStopStep,此时的obj就是调用create方法返回的对象,此时obj为pool实例,
def start(self, parent):
if self.obj:
return self.obj.start()
此时就继续调用pool实例的start方法,调用BasePool,
def start(self):
self._does_debug = logger.isEnabledFor(logging.DEBUG)
self.on_start()
self._state = self.RUN
调用的就是父类prefork的on_start,
def on_start(self):
forking_enable(self.forking_enable)
Pool = (self.BlockingPool if self.options.get('threads', True)
else self.Pool) # 是否是阻塞,如果传入的选项有threads则使用阻塞
P = self._pool = Pool(processes=self.limit,
initializer=process_initializer,
on_process_exit=process_destructor,
enable_timeouts=True,
synack=False,
**self.options) # AsynPool实例化
# Create proxy methods
self.on_apply = P.apply_async # 将pool中的方法设置到Pool类上
self.maintain_pool = P.maintain_pool
self.terminate_job = P.terminate_job
self.grow = P.grow
self.shrink = P.shrink
self.flush = getattr(P, 'flush', None) # FIXME add to billiard
继续调用Beat方法,Beat同上相同由于默认使用的是进程启动,所有此时的start方法就是调用启动进程,
def start(self):
'''
Start child process
'''
assert self._popen is None, 'cannot start a process twice'
assert self._parent_pid == os.getpid(), \
'can only start a process object created by current process'
_cleanup()
self._popen = self._Popen(self)
self._sentinel = self._popen.sentinel
_children.add(self)
继续调用Consumer的start方法,
def start(self):
blueprint = self.blueprint
while blueprint.state != CLOSE: # 判断当前状态是否是关闭
maybe_shutdown() # 通过标志判断是否应该关闭
if self.restart_count: # 如果设置了重启次数
try:
self._restart_state.step() # 重置
except RestartFreqExceeded as exc:
crit('Frequent restarts detected: %r', exc, exc_info=1)
sleep(1)
self.restart_count += 1 # 次数加1
try:
blueprint.start(self) # 调用开始方法
except self.connection_errors as exc:
# If we're not retrying connections, no need to catch
# connection errors
if not self.app.conf.broker_connection_retry:
raise
if isinstance(exc, OSError) and exc.errno == errno.EMFILE:
raise # Too many open files
maybe_shutdown()
if blueprint.state != CLOSE: # 如果状态不是关闭状态
if self.connection:
self.on_connection_error_after_connected(exc)
else:
self.on_connection_error_before_connected(exc)
self.on_close()
blueprint.restart(self) # 调用重启方法
此时又进入到了blueprint的start方法,此时该blueprint的steps值是由Consumer在初始化的时候传入的,所有依次遍历step,然后start的方法,是根据该传入的steps来执行的,传入的steps是Agent,Connection,Evloop,Control,Events,Gossip,Heart,Mingle,Tasks类的实例,然后根据调用最后添加到parent.steps中的实例就是[Connection,Events,Heart,Mingle,Tasks,Control,Gossip,Evloop],此时就依次调用这些实例的start方法,
首先分析仪一下Connection的start方法,
def start(self, c):
c.connection = c.connect()
info('Connected to %s', c.connection.as_uri())
就是调用了consumer的connect()函数,
def connect(self):
"""Establish the broker connection.
Retries establishing the connection if the
:setting:`broker_connection_retry` setting is enabled
"""
conn = self.app.connection_for_read(heartbeat=self.amqheartbeat) # 心跳
# Callback called for each retry while the connection
# can't be established.
def _error_handler(exc, interval, next_step=CONNECTION_RETRY_STEP):
if getattr(conn, 'alt', None) and interval == 0:
next_step = CONNECTION_FAILOVER
error(CONNECTION_ERROR, conn.as_uri(), exc,
next_step.format(when=humanize_seconds(interval, 'in', ' ')))
# remember that the connection is lazy, it won't establish
# until needed.
if not self.app.conf.broker_connection_retry: # 如果retry禁止
# retry disabled, just call connect directly.
conn.connect() # 直接连接
return conn # 返回conn
conn = conn.ensure_connection(
_error_handler, self.app.conf.broker_connection_max_retries,
callback=maybe_shutdown,
) # 确保连接上
if self.hub:
conn.transport.register_with_event_loop(conn.connection, self.hub) # 使用异步调用
return conn # 返回conn
此时就建立了连接。
继续分析Task的start方法,
def start(self, c):
"""Start task consumer."""
c.update_strategies() # 更新已知的任务
# - RabbitMQ 3.3 completely redefines how basic_qos works..
# This will detect if the new qos smenatics is in effect,
# and if so make sure the 'apply_global' flag is set on qos updates.
qos_global = not c.connection.qos_semantics_matches_spec
# set initial prefetch count
c.connection.default_channel.basic_qos(
0, c.initial_prefetch_count, qos_global,
) # 设置计数
c.task_consumer = c.app.amqp.TaskConsumer(
c.connection, on_decode_error=c.on_decode_error,
) # 开始消费
def set_prefetch_count(prefetch_count):
return c.task_consumer.qos(
prefetch_count=prefetch_count,
apply_global=qos_global,
)
c.qos = QoS(set_prefetch_count, c.initial_prefetch_count) # 设置计数
此时就开启了对应的任务消费,开启消费后我们继续分析一下loop的开启,
def start(self, c):
self.patch_all(c)
c.loop(*c.loop_args())
此时就是调用了consumer中的loop函数,该loop函数就是位于celery/worker/loops.py中的asyncloop函数,
def asynloop(obj, connection, consumer, blueprint, hub, qos,
heartbeat, clock, hbrate=2.0):
"""Non-blocking event loop.""" # 其中obj就是consumer实例
RUN = bootsteps.RUN # 获取运行状态
update_qos = qos.update
errors = connection.connection_errors
on_task_received = obj.create_task_handler() # 创建任务处理头
_enable_amqheartbeats(hub.timer, connection, rate=hbrate) # 定时发送心跳包
consumer.on_message = on_task_received # 设置消费的on_message为on_task_received
consumer.consume() # 开始消费
obj.on_ready() # 调用回调函数
obj.controller.register_with_event_loop(hub) # 向所有生成的blueprint中的实例注册hub
obj.register_with_event_loop(hub)
# did_start_ok will verify that pool processes were able to start,
# but this will only work the first time we start, as
# maxtasksperchild will mess up metrics.
if not obj.restart_count and not obj.pool.did_start_ok():
raise WorkerLostError('Could not start worker processes')
# consumer.consume() may have prefetched up to our
# limit - drain an event so we're in a clean state
# prior to starting our event loop.
if connection.transport.driver_type == 'amqp':
hub.call_soon(_quick_drain, connection)
# FIXME: Use loop.run_forever
# Tried and works, but no time to test properly before release.
hub.propagate_errors = errors
loop = hub.create_loop() # 创建loop,本质是一个生成器
try:
while blueprint.state == RUN and obj.connection: # 检查是否在运行并且连接是否有
# shutdown if signal handlers told us to.
should_stop, should_terminate = (
state.should_stop, state.should_terminate,
)
# False == EX_OK, so must use is not False
if should_stop is not None and should_stop is not False:
raise WorkerShutdown(should_stop)
elif should_terminate is not None and should_stop is not False:
raise WorkerTerminate(should_terminate)
# We only update QoS when there's no more messages to read.
# This groups together qos calls, and makes sure that remote
# control commands will be prioritized over task messages.
if qos.prev != qos.value:
update_qos()
try:
next(loop) # 循环下一个
except StopIteration:
loop = hub.create_loop()
finally:
try:
hub.reset()
except Exception as exc: # pylint: disable=broad-except
logger.exception(
'Error cleaning up after event loop: %r', exc)
至此,异步Loop就开启了,然后就开始了服务端的事件等待处理,至此,worker流程就启动完毕。
本文总结
本文主要讲述了继续分析了worker的启动流程,celery默认启动的就是已进程的方式启动定时任务,然后异步IO处理消费端的事件,这其中也设计到celery对worker任务之间的一些任务消费的情况,但是没有做一一分析,至此worker的启动流程概述已分析完毕。
