DCS (Display Command Set)

DCS is a MIPI Alliance specification for the command set used by DSI and DBI-2 standards.

• The Display Command Set is used to store image data, configure the display module behavior andretrieve display module data including identification information by accessing the frame memory andthe display module registers.

•All commands consist of a single 8-bit byte, in some cases accompanied by parameters thatsupply necessary information for the correct execution ofthe command.

1）UCS(User Command Set): 00h ~AFh

2）MCS(Manufacturer Command Set) : other codes
