cs61b实验记录(四)HW2,lab9
HW 2
Percolation
:
先不解决backwash问题
import edu.princeton.cs.algs4.WeightedQuickUnionUF;
public class Percolation {
private boolean[][]grid;
private int N;
private WeightedQuickUnionUF UF;
private int numberOfOpenSites;
public Percolation(int N){
if (N<=0)
throw new IllegalArgumentException("N must > 0");
this.N=N;
this.numberOfOpenSites=0;
UF=new WeightedQuickUnionUF(N*N+2);
grid=new boolean[N][N];
}
public void open(int row,int col){
int next[][]=new int[][]{
{0,1},
{1,0},
{0,-1},
{-1,0}
};
if (row<0||row>=N||col<0||col>=N)
throw new IllegalArgumentException("row and col must between 0 and N-1");
if (isOpen(row,col))return;
grid[row][col]=true;
numberOfOpenSites++;
//连接周围的open的点
for (int i=0;i<=3;i++){
int mx=row+next[i][0];
int my=col+next[i][1];
if (my<0||my>=N)
continue;
if (mx==-1){
UF.union(xyTo1D(row, col),N*N);
continue;
}
else if (mx==N){
UF.union(xyTo1D(row, col),N*N+1);
continue;
}
if (isOpen(mx,my)&&UF.connected(xyTo1D(row,col),xyTo1D(mx,my))==false)
UF.union(xyTo1D(row, col),xyTo1D(mx,my));
}
}
private int xyTo1D(int mx,int my){
return mx*N+my;
}
// is the site (row, col) open?
public boolean isOpen(int row, int col){
if (row<0||row>=N||col<0||col>=N)
throw new IllegalArgumentException("row and col must between 0 and N-1");
return grid[row][col];
}
// is the site (row, col) full?
public boolean isFull(int row, int col){
if (row<0||row>=N||col<0||col>=N)
throw new IllegalArgumentException("row and col must between 0 and N-1");
return UF.connected(xyTo1D(row, col), N * N);
}
// number of open sites
public int numberOfOpenSites(){
return numberOfOpenSites;
}
// does the system percolate?
public boolean percolates(){
return UF.connected(N*N,N*N+1);
}
}
引起backwash的根本原因是:在最底部的一排的下面还有一个额外的辅助点,在isFull方法中由于这个辅助点的存在导致了backwash。
按照我们的本意,这个辅助点应该只在percolate方法中使用,和最顶部的辅助点一起判断地图是否从上到下连通。isFull方法只需要判断某个点是否与最顶部的辅助点相连,不需要使用最底部的辅助点。然而在isFull方法中这个辅助点也被使用了,这与我们的本意相违背。
所以percolate需要底部的辅助点,isFull方法不需要底部的辅助点,即这两个方法对UnionFind的需求不一致,所以我们可以创造两个UnionFind对象,分别适用于两个不同的方法。
import edu.princeton.cs.algs4.WeightedQuickUnionUF;
public class Percolation {
private boolean[][]grid;
private int N;
private WeightedQuickUnionUF UF;
//用来避免backwash的UF
private WeightedQuickUnionUF UFwithoutBackWash;
private int numberOfOpenSites;
public Percolation(int N){
if (N<=0)
throw new IllegalArgumentException("N must > 0");
this.N=N;
this.numberOfOpenSites=0;
UF=new WeightedQuickUnionUF(N*N+2);
UFwithoutBackWash=new WeightedQuickUnionUF(N*N+2);
grid=new boolean[N][N];
}
public void open(int row,int col){
int next[][]=new int[][]{
{0,1},
{1,0},
{0,-1},
{-1,0}
};
if (row<0||row>=N||col<0||col>=N)
throw new IllegalArgumentException("row and col must between 0 and N-1");
if (isOpen(row,col))return;
grid[row][col]=true;
numberOfOpenSites++;
//连接周围的open的点
for (int i=0;i<=3;i++){
int mx=row+next[i][0];
int my=col+next[i][1];
if (my<0||my>=N)
continue;
if (mx==-1){
//两个UnionFind都需要使用最顶部的辅助点
UFwithoutBackWash.union(xyTo1D(row, col),N*N);
UF.union(xyTo1D(row, col),N*N);
continue;
}
else if (mx==N){
//只有一个UnionFind需要使用最底部的辅助点
UF.union(xyTo1D(row, col),N*N+1);
continue;
}
//判断两个点之间有没有连接不需要底部的辅助点
if (isOpen(mx,my)&&UFwithoutBackWash.connected(xyTo1D(row,col),xyTo1D(mx,my))==false){
UF.union(xyTo1D(row, col),xyTo1D(mx,my));
UFwithoutBackWash.union(xyTo1D(row, col),xyTo1D(mx,my));
}
}
}
private int xyTo1D(int mx,int my){
return mx*N+my;
}
// is the site (row, col) open?
public boolean isOpen(int row, int col){
if (row<0||row>=N||col<0||col>=N)
throw new IllegalArgumentException("row and col must between 0 and N-1");
return grid[row][col];
}
// is the site (row, col) full?
public boolean isFull(int row, int col){
if (row<0||row>=N||col<0||col>=N)
throw new IllegalArgumentException("row and col must between 0 and N-1");
//在isFull中使用UFwithoutBackWash
return UFwithoutBackWash.connected(xyTo1D(row, col), N * N);
}
// number of open sites
public int numberOfOpenSites(){
return numberOfOpenSites;
}
// does the system percolate?
public boolean percolates(){
//
return UF.connected(N*N,N*N+1);
}
// use for unit testing (not required)
}
PercolationStats
:
import edu.princeton.cs.algs4.StdRandom;
import edu.princeton.cs.algs4.StdStats;
public class PercolationStats {
private int T;
private double[]x;
// perform T independent experiments on an N-by-N grid
public PercolationStats(int N, int T, PercolationFactory pf){
if (N<=0||T<=0)
throw new IllegalArgumentException("N and T must > 0");
this.T=T;
x=new double[T];
for (int i=0;i<T;i++){
Percolation test=pf.make(N);
while (!test.percolates()){
int randomRow= StdRandom.uniform(N);
int randomCol = StdRandom.uniform(N);
test.open(randomRow,randomCol);
}
x[i]=(double) test.numberOfOpenSites()/(N*N);
}
}
// sample mean of percolation threshold
public double mean(){
return StdStats.mean(x);
}
// sample standard deviation of percolation threshold
public double stddev(){
return StdStats.stddev(x);
}
// low endpoint of 95% confidence interval
public double confidenceLow(){
return mean()-1.96*stddev()/Math.sqrt(T);
}
// high endpoint of 95% confidence interval
public double confidenceHigh(){
return mean() + 1.96 * stddev() / Math.sqrt(T);
}
}
Autograder分数:
lab 9
BSTmap
:
package lab9;
import java.util.Iterator;
import java.util.Set;
import java.util.TreeSet;
/**
* Implementation of interface Map61B with BST as core data structure.
*
* @author Your name here
*/
public class BSTMap<K extends Comparable<K>, V> implements Map61B<K, V> {
private class Node {
/* (K, V) pair stored in this Node. */
private K key;
private V value;
/* Children of this Node. */
private Node left;
private Node right;
private Node(K k, V v) {
key = k;
value = v;
}
}
private class Entry{
private K key;
private V value;
public Entry(K k,V v){
key=k;
value=v;
}
}
private Node root; /* Root node of the tree. */
private int size; /* The number of key-value pairs in the tree */
/* Creates an empty BSTMap. */
public BSTMap() {
this.clear();
}
/* Removes all of the mappings from this map. */
@Override
public void clear() {
root = null;
size = 0;
}
/** Returns the value mapped to by KEY in the subtree rooted in P.
* or null if this map contains no mapping for the key.
*/
private V getHelper(K key, Node p) {
if(p==null)return null;
if (key.compareTo(p.key)<0)return getHelper(key,p.left);
else if (key.compareTo(p.key)>0)return getHelper(key, p.right);
return p.value;
}
/** Returns the value to which the specified key is mapped, or null if this
* map contains no mapping for the key.
*/
@Override
public V get(K key) {
return getHelper(key,root);
}
/** Returns a BSTMap rooted in p with (KEY, VALUE) added as a key-value mapping.
* Or if p is null, it returns a one node BSTMap containing (KEY, VALUE).
*/
private Node putHelper(K key, V value, Node p) {
if (p==null){
size++;
return new Node(key, value);
}
if (key.compareTo(p.key)<0)p.left=putHelper(key,value,p.left);
else if (key.compareTo(p.key)>0)p.right=putHelper(key,value,p.right);
else p.value=value;
return p;
}
/** Inserts the key KEY
* If it is already present, updates value to be VALUE.
*/
@Override
public void put(K key, V value) {
root=putHelper(key,value,root);
}
/* Returns the number of key-value mappings in this map. */
@Override
public int size() {
return size;
}
EVERYTHING BELOW THIS LINE IS OPTIONAL
/* Returns a Set view of the keys contained in this map. */
@Override
public Set<K> keySet() {
Set<K>keySet=new TreeSet<>();
keySet(root,keySet);
return keySet;
}
private void keySet(Node x,Set<K>keySet){
if (x==null)return;
keySet(x.left,keySet);
keySet.add(x.key);
keySet(x.right,keySet);
}
// private Set<Entry> EntrySet(){
// Set<Entry>EntrySet=new TreeSet<>();
// EntrySet(root,EntrySet);
// return EntrySet;
// }
// private void EntrySet(Node x,Set<Entry>EntrySet){
// if (x==null)return;
// EntrySet(x.left,EntrySet);
// EntrySet.add(new Entry(x.key,x.value));
// EntrySet(x.right,EntrySet);
// }
/** Removes KEY from the tree if present
* returns VALUE removed,
* null on failed removal.
*/
@Override
public V remove(K key) {
root=remove(key,root);
return valueRemoved;
}
private V valueRemoved;
private Node remove(K key,Node x){
if (x==null)return null;
if (key.compareTo(x.key)<0)x.left=remove(key,x.left);
else if(key.compareTo(x.key)>0)x.right=remove(key,x.right);
else{
if (x.right==null)return x.left;
if (x.left==null)return x.right;
Node t=Min(x.right);
t.right=removeMin(x.right);
t.left=x.left;
valueRemoved=x.value;
return t;
}
return x;
}
private Node Min(Node x){
if (x.left==null)return x;
return Min(x.left);
}
private Node removeMin(Node x){
if (x.left==null)return x.right;
x.left=removeMin(x.left);
size--;
return x;
}
/** Removes the key-value entry for the specified key only if it is
* currently mapped to the specified value. Returns the VALUE removed,
* null on failed removal.
**/
@Override
public V remove(K key, V value) {
if (get(key)!=value)return null;
return remove(key);
}
@Override
public Iterator<K> iterator() {
return new BSTIterator();
}
private class BSTIterator implements Iterator<K>{
private Iterator<K> cur;
public BSTIterator(){
cur=keySet().iterator();
}
@Override
public boolean hasNext() {
return cur.hasNext();
}
@Override
public K next() {
return cur.next();
}
}
}
Myhashmap
:
package lab9;
import java.lang.reflect.Array;
import java.util.Iterator;
import java.util.Set;
/**
* A hash table-backed Map implementation. Provides amortized constant time
* access to elements via get(), remove(), and put() in the best case.
*
* @author Your name here
*/
public class MyHashMap<K, V> implements Map61B<K, V> {
private static final int DEFAULT_SIZE = 16;
private static final double MAX_LF = 0.75;
private ArrayMap<K, V>[] buckets;
private int size;
private int loadFactor() {
return size / buckets.length;
}
public MyHashMap() {
buckets = new ArrayMap[DEFAULT_SIZE];
this.clear();
}
/* Removes all of the mappings from this map. */
@Override
public void clear() {
this.size = 0;
for (int i = 0; i < this.buckets.length; i += 1) {
this.buckets[i] = new ArrayMap<>();
}
}
/** Computes the hash function of the given key. Consists of
* computing the hashcode, followed by modding by the number of buckets.
* To handle negative numbers properly, uses floorMod instead of %.
*/
private int hash(K key) {
if (key == null) {
return 0;
}
int numBuckets = buckets.length;
return Math.floorMod(key.hashCode(), numBuckets);
}
/* Returns the value to which the specified key is mapped, or null if this
* map contains no mapping for the key.
*/
@Override
public V get(K key) {
return buckets[hash(key)].get(key);
}
/* Associates the specified value with the specified key in this map. */
@Override
public void put(K key, V value) {
if (loadFactor()>MAX_LF)
resize(buckets.length*2);
if (!containsKey(key))
size++;
buckets[hash(key)].put(key,value);
}
private void resize(int capacity){
ArrayMap<K,V>[]temp=buckets;
buckets=(ArrayMap<K,V>[])new ArrayMap[capacity];
this.clear();
for (int i=0;i<temp.length;i++){
Set<K>set=temp[i].keySet();
Iterator<K>it=set.iterator();
while (it.hasNext()){
K nextkey=it.next();
put(nextkey,temp[i].get(nextkey));
}
}
}
/* Returns the number of key-value mappings in this map. */
@Override
public int size() {
return size;
}
EVERYTHING BELOW THIS LINE IS OPTIONAL
/* Returns a Set view of the keys contained in this map. */
@Override
public Set<K> keySet() {
throw new UnsupportedOperationException();
}
/* Removes the mapping for the specified key from this map if exists.
* Not required for this lab. If you don't implement this, throw an
* UnsupportedOperationException. */
@Override
public V remove(K key) {
throw new UnsupportedOperationException();
}
/* Removes the entry for the specified key only if it is currently mapped to
* the specified value. Not required for this lab. If you don't implement this,
* throw an UnsupportedOperationException.*/
@Override
public V remove(K key, V value) {
throw new UnsupportedOperationException();
}
@Override
public Iterator<K> iterator() {
throw new UnsupportedOperationException();
}
}
lic V remove(K key) {
throw new UnsupportedOperationException();
}
/* Removes the entry for the specified key only if it is currently mapped to
* the specified value. Not required for this lab. If you don't implement this,
* throw an UnsupportedOperationException.*/
@Override
public V remove(K key, V value) {
throw new UnsupportedOperationException();
}
@Override
public Iterator<K> iterator() {
throw new UnsupportedOperationException();
}
}
