Python爬取天气数据及可视化动态图
爬取天气数据
大家好,接下来这篇是对Python语言程序设计课程结课作业的分析,以便同学们对爬虫应用有个认知,方便完成自己课程的Python大作业。三个环节爬取数据,数据分析,可视化,因为天气是我们常常会关注的点,可能未来工程时间的安排,以及出行的安排,未来的旅游计划等等都和天气密不可分,如果能让天气数据以图像的方式呈现在眼前,将会有更直观的视觉冲击。
网址选取
这边选取的是中国天气网,杭州的天气数据。
链接1: http://www.weather.com.cn/weather/101210101.shtml
链接2:http://www.weather.com.cn/weather15d/101210101.shtml
url = 'http://www.weather.com.cn//weather//101210101.shtml'
url8_15 = 'http://www.weather.com.cn/weather15d/101210101.shtml'
因为中国天气网是一个非盈利性的网站,所以几乎没有反爬虫措施,很适合我们新手上手尝试。
右键页面点开检查,或者Ctrl + Shift + i快捷键打开检查页面,点开网络,其中一个1.shtml文件(也就是我们的网站)访问信息
设置请求头:
headers = {
'Use-Agent':'Mozilla/5.0 (Windows NT 10.0; Win64; x64) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/125.0.0.0 Safari/537.36 Edg/125.0.0.0'}
创建request对象
引入一个request库,获取一个request对象
from urllib import request
# 获取一个request对象
req = request.Request(url,headers=headers)
response = request.urlopen(req)
req8_15 = request.Request(url8_15,headers=headers)
response8_15 = request.urlopen(req8_15)
异常处理,保存html文件
判断响应不是404(失败)就是200(成功),保存html文件,就可以分离处理,不用一直频繁访问网站,防止反爬虫措施响应。
import sys
# 判断响应结果
if response.getcode() == 200:
print("访问成功")
data = response.read()
# document.charset看网页的编码方式
data = str(data,encoding='UTF-8')
with open('data.html',mode='w',encoding='UTF-8') as f:
f.write(data)
else:
print("error")
sys.exit()
# 判断响应结果
if response8_15.getcode() == 200:
print("访问成功")
data = response8_15.read()
# document.charset看网页的编码方式
data = str(data, encoding='UTF-8')
with open('data8_15.html', mode='w', encoding='UTF-8') as f:
f.write(data)
else:
print("error")
sys.exit()
得到html文件
其中UTF-8的编码方式是可以通过网页的控制台进行查询的.
输入:document.charset
解析数据
解析数据一直是爬虫整个过程中相对比较复杂的一个过程,因为需要结合每个网站不同的特点进行特定的处理,才能过滤掉我们不需要的数据,使留下的数据能够方便的进行可视化过程。
这边我们使用的是BeautifulSoup库
from bs4 import BeautifulSoup
解析当天以及2-7天数据
通过分析网页中html代码可以得到当天数据信息在script中,以json数据形式保存
、
# 创建一个BeautifulSoup对象
bs = BeautifulSoup(html,'html.parser')
# 分析今天数据
data = bs.select(".left-div script")
text = data[3].string
# print(text)
text = text[text.index('=') + 1:-2] # 移除多余元素,保留字典
dic = eval(text)
lst = dic['od']['od2']
用json库解析也同理,这里我用的是eval特殊用法
之后进行数据分析
final_day = [] # 存放当天的数据
count = 0
for i in lst:
temp = []
if count <= 23:
temp.append(i['od21']) # 添加时间
temp.append(i['od22']) # 添加当前时刻温度
temp.append(i['od24']) # 添加当前时刻风力方向
temp.append(i['od25']) # 添加当前时刻风级
temp.append(i['od26']) # 添加当前时刻降水量
temp.append(i['od27']) # 添加当前时刻相对湿度
temp.append(i['od28']) # 添加当前时刻控制质量
# print(temp)
final_day.append(temp)
count = count + 1
同理找到2-7天的数据在ul class=“t clearfix” 之中
进行数据分析,本文统一用的都是select(CSS规则),find,find_all
# 分析后六天数据
day2_7 = bs.select(".clearfix li.sky")
# print(data2_7[1])
final = []
i = 0 # 控制爬取的天数
for day in day2_7: # 遍历找到的每一个li
if i < 7 and i > 0:
temp = [] # 临时存放每天的数据
# 存日期
date = day.find('h1').string # 得到日期
date = date[0:date.index('日')] # 取出日期号
temp.append(date)
# 存天气
inf = day.find_all('p') # 找出li下面的p标签,提取第一个p标签的值,即天气
temp.append(inf[0].string)
# 存最高气温最低气温
if inf[1].find('i') is None: # 天气预报可能没有最低气温
tem_low = None
temp.append(tem_low)
else:
tem_low = inf[1].find('i').string # 找到最低气温
temp.append(tem_low[:-1])
if inf[1].find('span') is None: # 天气预报可能没有最高气温
tem_high = None
temp.append(tem_high)
else:
tem_high = inf[1].find('span').string # 找到最高气温
temp.append(tem_high)
# 风向
wind = inf[2].find_all('span') # 找到风向
for j in wind:
temp.append(j['title'])
# 风级
wind_scale = inf[2].find('i').string # 找到风级
index1 = wind_scale.index('级')
temp.append(int(wind_scale[index1 - 1:index1]))
final.append(temp)
i += 1
解析8-15天数据
8-15天与上文同理,可以自行尝试
保存至Excel
保存Excel这边引入了一个Workbook库,可以直接对excel进行操作
from openpyxl import Workbook
# 创建工作簿Workbook对象
book = Workbook()
# 创建工作表sheet
sheet = book.create_sheet('weather1',0)
sheet2_15 = book.create_sheet('weather14',1)
# 向工作表中添加数据
sheet.append(['小时', '温度', '风力方向', '风级', '降水量', '相对湿度', '空气质量'])
sheet2_15.append(['日期', '天气', '最低气温', '最高气温', '风向1', '风向2', '风级'])
for i in data:
sheet.append(i)
for j in data2_15:
sheet2_15.append(j)
# 输出保存
book.save('weather.xlsx')
得到Excel表格
可视化处理
可视化处理是我们爬取数据,整理数据的目的所在,得到一个清晰而又全面的图形展示,这样能给我们直观的数据体验,并且能从图像中说明一些问题和道理。
引入几个库:
import matplotlib.pyplot as plt
import numpy as np
import pandas as pd
import wordcloud
from PIL import Image
import math
当天数据可视化
这里是对一天数据可视化,反映过去一天的温度,湿度,空气质量情况。
动态温度曲线
关键代码动态图:
plt.plot(xy[0:2], y[0:2], color='red', label='温度') # 画出温度曲线
plt.scatter(xy[0:2], y[0:2], color='red') # 点出每个时刻的温度点
plt.plot([0,2], [tem_ave, tem_ave], c='blue', linestyle='--', label='平均温度') # 画出平均温度虚线
for i in range(1,23):
plt.plot(xy[i:i+2], y[i:i+2], color='red') # 画出温度曲线
plt.scatter(xy[i:i+2], y[i:i+2], color='red') # 点出每个时刻的温度点
plt.plot([i,i+1], [tem_ave, tem_ave], c='blue', linestyle='--') # 画出平均温度虚线
plt.pause(0.1) # 延时0.1
plt.text(tem_max_hour, tem_max + 0.15,
