使用ViewPager2+TabLayout设计主布局

第三节：主页的设计

布局文件的设计：

<?xml version="1.0" encoding="utf-8"?>
<layout
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools">

    <androidx.constraintlayout.widget.ConstraintLayout
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        tools:context=".MainActivity">

        <androidx.viewpager2.widget.ViewPager2
            android:id="@+id/view_pager"
            android:layout_width="match_parent"
            android:layout_height="match_parent"
            app:layout_constraintBottom_toTopOf="@id/tab_layout"
            app:layout_constraintTop_toTopOf="parent"/>

        <com.google.android.material.tabs.TabLayout
            android:id="@+id/tab_layout"
            android:layout_width="match_parent"
            android:layout_height="72dp"
            app:layout_constraintBottom_toBottomOf="parent"
            android:elevation="10dp"
            app:tabIndicatorHeight="0dp"
            app:tabTextAppearance="@style/TextAppearance.AppCompat.Caption" />

    </androidx.constraintlayout.widget.ConstraintLayout>
</layout>

主Activity的调用：

import androidx.appcompat.app.AppCompatActivity
import android.os.Bundle
import androidx.core.content.ContextCompat
import androidx.databinding.DataBindingUtil
import androidx.fragment.app.Fragment
import com.google.android.material.tabs.TabLayoutMediator
import com.tian.yao.databinding.ActivityMainBinding
import com.tian.yao.three.Fragment1
import com.tian.yao.three.Fragment2
import com.tian.yao.three.Fragment3
import com.tian.yao.three.MyFragmentStateAdapter

class MainActivity : AppCompatActivity() {

    lateinit var mBinding: ActivityMainBinding
    private val icons = arrayOf(R.drawable.tab_icon_index,R.drawable.tab_icon_query,R.drawable.tab_icon_mine)

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        mBinding=DataBindingUtil.setContentView(this, R.layout.activity_main)

        var fragmentList: MutableList<Fragment> = arrayListOf(Fragment1(), Fragment2(), Fragment3())

        mBinding.apply {
            viewPager.adapter = MyFragmentStateAdapter(this@MainActivity, fragmentList)
            viewPager.isUserInputEnabled = false //禁用页面滑动

            //TabLayout与ViewPager2联动
            TabLayoutMediator(tabLayout, viewPager) { tab, position ->
                tab.text = resources.getStringArray(R.array.tabs_main)[position]
                tab.icon= ContextCompat.getDrawable(this@MainActivity,icons[position])
            }.attach()
        }
    }

}

涉及到的矢量图标可以在阿里库获取，地址是：

https://www.iconfont.cn/search/index?searchType=icon

图标布局文件的编写：

<?xml version="1.0" encoding="utf-8"?>
<selector xmlns:android="http://schemas.android.com/apk/res/android">
    <item android:drawable="@drawable/svg_index_selected" android:state_selected="true"/>
    <item android:drawable="@drawable/svg_index"/>
</selector>

Fragment的编写：

import android.os.Bundle
import android.view.LayoutInflater
import android.view.View
import android.view.ViewGroup
import androidx.fragment.app.Fragment
import com.tian.yao.R

class Fragment1 :Fragment() {

    override fun onCreateView(
        inflater: LayoutInflater,
        container: ViewGroup?,
        savedInstanceState: Bundle?
    ): View? {
        return  inflater.inflate(R.layout.fragment1,null)
    }
}

效果图：

代码链接：

链接: https://pan.baidu.com/s/1aqpcuhVgIkCr2rfnDV_6ng 提取码: rrea
