opencv3.0 xphoto模块包含了简单白平衡算法。没有注明算法原理,出自哪篇论文,很不方便。搜索之后,发现一篇博客不错,介绍了该原理。同时实现了robust color balance。
白平衡的意思就是:是图片中最亮的部分为白色,最暗的部分为黑色。其余部分进行拉伸。博客效果如下:
原图:
robust color balance:
This is the color balancing technique used in Adobe Photoshop's "auto levels" command. The idea is that in a well balanced photo, the brightest color should be white and the darkest black. Thus, we can remove the color cast from an image by scaling the histograms of each of the R, G, and B channels so that they span the complete 0-255 scale. In contrast to the other color balancing algorithms, this method does not separate the estimation and adaptation steps.
In order to deal with outliers, Simplest Color Balance saturates a certain percentage of the image's bright pixels to white and dark pixels to black. The saturation level is an adjustable parameter that affects the quality of the output. Values around 0.01 are typical.
简单的说就是:在rgb三通道上分别统计每个像素值的出现次数。将1%的最大值和最小值设置为255和0。其余值映射到(0,255),这样使得每个值通道的值在rgb中分布较均匀。达到颜色平衡的结果。.
opencv实现了简单白平衡。使用多层直方图,比单个直方图的优点,应该是速度更快。实际上并不一定要这么实现。且算法的实现应该有问题。以下是修改后代码,中文部
