将示例代码与ruby一起使用cloud vision api

Vision AI is a set of pre-trained machine learning models provided by Google. By using Cloud Vision API, you can easily integrate vision detection features within applications.

Vision AI是Google提供的一组经过预先训练的机器学习模型。 通过使用Cloud Vision API，您可以轻松地在应用程序中集成视觉检测功能。

If you are unfamiliar with the API, you might think it would be too complicated to use it in your application and give up before you read the documentation till the end. Don’t worry. I have prepared a sample code that allows you to easily use Cloud Vision API in a Ruby application.

如果您不熟悉该API，则可能会觉得太复杂而无法在您的应用程序中使用它，并在阅读文档直至最后之前放弃。 不用担心 我准备了一个示例代码，使您可以轻松地在Ruby应用程序中使用Cloud Vision API。

Before you begin, you will need to create an API key and enable Cloud Vision API. If you haven’t done it yet, please follow the official guide.

在开始之前，您需要创建一个API密钥并启用Cloud Vision API。 如果您尚未执行此操作，请按照官方指南进行操作 。

Here is a sample code:

这是一个示例代码：

*The image file used must be on your computer.

*使用的图像文件必须在您的计算机上。

require 'base64'
require 'json'
require 'net/https'# Step 1 - Set path to the image file, API key, and API URL.
IMAGE_FILE = './sample.jpg'API_KEY = 'XXXXXXXXXX' # Don't forget to protect your API key.
API_URL = "https://vision.googleapis.com/v1/images:annotate?key=#{API_KEY}"# Step 2 - Convert the image to base64 format.
base64_image = Base64.strict_encode64(File.new(IMAGE_FILE, 'rb').read)# Step 3 - Set request JSON body.
body = {
  requests: [{
    image: {
      content: base64_image
    },
    features: [
      {type: 'LABEL_DETECTION', # Details are below.
        maxResults: 3 # The number of results you would like to get
      }
    ]
  }]
}# Step 4 - Send request.
uri = URI.parse(API_URL)
https = Net::HTTP.new(uri.host, uri.port)
https.use_ssl = true
request = Net::HTTP::Post.new(uri.request_uri)
request["Content-Type"] = "application/json"
response = https.request(request, body.to_json)# Step 5 - Print the response in the console.
puts response.body

The main features that can be used with Cloud Vision API are as follows:

可以与Cloud Vision API一起使用的主要功能如下：

• TEXT_DETECTION
  TEXT_DETECTION
• CROP_HINTS
  CROP_HINTS
• FACE_DETECTION
  FACE_DETECTION
• IMAGE_PROPERTIES
  IMAGE_PROPERTIES
• LABEL_DETECTION
  LABEL_DETECTION
• LANDMARK_DETECTION
  LANDMARK_DETECTION
• LOGO_DETECTION
  LOGO_DETECTION
• OBJECT_LOCALIZATION
  OBJECT_LOCALIZATION
• SAFE_SEARCH_DETECTION
  SAFE_SEARCH_DETECTION

See the details here.

在这里查看详细信息。

Let’s try it out. Here are the results of LABEL_DETECTION, FACE_DETECTION, and OBJECT_LOCALIZATION as examples.

让我们尝试一下。 以下是LABEL_DETECTION，FACE_DETECTION和OBJECT_LOCALIZATION的结果作为示例。

LABEL_DETECTION (LABEL_DETECTION)

{
  "responses": [
    {
      "labelAnnotations": [
        {
          "mid": "/m/01yrx",
          "description": "Cat",
          "score": 0.99598557,
          "topicality": 0.99598557
        },
        {
          "mid": "/m/04rky",
          "description": "Mammal",
          "score": 0.9890478,
          "topicality": 0.9890478
        },
        {
          "mid": "/m/09686",
          "description": "Vertebrate",
          "score": 0.9851104,
          "topicality": 0.9851104
        }
      ]
    }
  ]
}

FACE_DETECTION (FACE_DETECTION)

{
  "responses": [
    {
      "faceAnnotations": [
        {
          "boundingPoly": {
            "vertices": [
              {
                "x": 85,
                "y": 32
              },
              {
                "x": 228,
                "y": 32
              },
              {
                "x": 228,
                "y": 198
              },
              {
                "x": 85,
                "y": 198
              }
            ]
          },
          "fdBoundingPoly": {
            "vertices": [
              {
                "x": 96,
                "y": 53
              },
              {
                "x": 220,
                "y": 53
              },
              {
                "x": 220,
                "y": 183
              },
              {
                "x": 96,
                "y": 183
              }
            ]
          },
          "landmarks": [
            {
              "type": "LEFT_EYE",
              "position": {
                "x": 137.98528,
                "y": 107.89613,
                "z": -0.0003142357
              }
            },
            {
              "type": "RIGHT_EYE",
              "position": {
                "x": 182.86436,
                "y": 108.30501,
                "z": 3.7897882
              }
            },
            {
              "type": "LEFT_OF_LEFT_EYEBROW",
              "position": {
                "x": 124.37836,
                "y": 98.03804,
                "z": 3.9364848
              }
            },
            {
              "type": "RIGHT_OF_LEFT_EYEBROW",
              "position": {
                "x": 151.22585,
                "y": 97.4466,
                "z": -5.1410694
              }
            },
                                 .
                                 .
                                 .],
          "rollAngle": 0.5700898,
          "panAngle": 5.027816,
          "tiltAngle": 7.44839,
          "detectionConfidence": 0.89301175,
          "landmarkingConfidence": 0.7306799,"joyLikelihood": "LIKELY", # The face seems happy!
          "sorrowLikelihood": "VERY_UNLIKELY",
          "angerLikelihood": "VERY_UNLIKELY",
          "surpriseLikelihood": "VERY_UNLIKELY",
          "underExposedLikelihood": "VERY_UNLIKELY",
          "blurredLikelihood": "VERY_UNLIKELY",
          "headwearLikelihood": "VERY_UNLIKELY"
        }
      ]
    }
  ]
}

OBJECT_LOCALIZATION (OBJECT_LOCALIZATION)

{
  "responses": [
    {
      "localizedObjectAnnotations": [
        {
          "mid": "/m/0199g",
          "name": "Bicycle",
          "score": 0.86724836,
          "boundingPoly": {
            "normalizedVertices": [
              {
                "x": 0.6728187,
                "y": 0.673309
              },
              {
                "x": 0.9256048,
                "y": 0.673309
              },
              {
                "x": 0.9256048,
                "y": 0.92176706
              },
              {
                "x": 0.6728187,
                "y": 0.92176706
              }
            ]
          }
        },
        {
          "mid": "/m/02dgv",
          "name": "Door",
          "score": 0.84919137,
          "boundingPoly": {
            "normalizedVertices": [
              {
                "x": 0.40092757,
                "y": 0.31736398
              },
              {
                "x": 0.51375383,
                "y": 0.31736398
              },
              {
                "x": 0.51375383,
                "y": 0.7087951
              },
              {
                "x": 0.40092757,
                "y": 0.7087951
              }
            ]
          }
        },
        {
          "mid": "/m/0d4v4",
          "name": "Window",
          "score": 0.8491046,
          "boundingPoly": {
            "normalizedVertices": [
              {
                "x": 0.11334894,
                "y": 0.2133823
              },
              {
                "x": 0.28181157,
                "y": 0.2133823
              },
              {
                "x": 0.28181157,
                "y": 0.5806629
              },
              {
                "x": 0.11334894,
                "y": 0.5806629
              }
            ]
          }
        }
      ]
    }
  ]
}

Voila! Now you are ready to build a Ruby application with Vision AI. I am excited to see innovative products and services in the future.

瞧！ 现在，您可以使用Vision AI构建Ruby应用程序了。 我很高兴看到未来的创新产品和服务。
