Windows线程API —CreateTimerQueueTimer/DeleteTimerQueueTimer的使用

问题代码:

登录后复制

1 #include<windows.h>
 2 #include<iostream>
 3 #include<thread>
 4 HANDLE h1;
 5 HANDLE h2;
 6
 7 void CALLBACK test(PVOID a, BOOLEAN b)
 8 {
 9     std::cout << "This a test function excuted by Thread:" << std::this_thread::get_id()<< std::endl;
10     //std::cout << "Here we try to delete timer in Thread:" << std::this_thread::get_id() << std::endl;
11     if (0 == DeleteTimerQueueTimer(NULL, h1, INVALID_HANDLE_VALUE))
12     {
13         std::cout << "Timer  Deleted Failed in Thread:" << std::this_thread::get_id() << std::endl;
14     }
15     std::cout << "Timer  Deleted Successfully in Thread:" << std::this_thread::get_id() << std::endl;
16
17 }
18 void CALLBACK test1(PVOID l, BOOLEAN t)
19 {
20     std::cout << "This a test1 function excuted by Thread:" << std::this_thread::get_id() << std::endl;
21 }
22
23 int main()
24 {
25
26     std::cout << "******This is a Test for TimeQueueTimer in Windows API******" << std::endl;
27     std::cout << "Main thread is executed by thread: " << std::this_thread::get_id() << std::endl;
28     //test(PVOID(1), TRUE);
29     try
30     {
31         CreateTimerQueueTimer(&h1, NULL, WAITORTIMERCALLBACK(test), NULL, 0, 1000, WT_EXECUTEINTIMERTHREAD);
32         //Sleep(1000);
33
34         CreateTimerQueueTimer(&h2, NULL, WAITORTIMERCALLBACK(test1), NULL, 0, 1000, WT_EXECUTEINTIMERTHREAD);
35
36
37         //CreateTimerQueueTimer(&h1, NULL, [](PVOID lpParameter, BOOLEAN TimerOrWaitFired) {
38         //    test(lpParameter, TimerOrWaitFired); // Call your original test function from within the lambda
39         //    }, NULL, 0, 1000, WT_EXECUTEINTIMERTHREAD);
40
41     }
42     catch (const std::exception& e)
43     {
44         std::cout << "something error with the timer: " << e.what() << std::endl;
45     }
46
47
48     if (std::cin.get())
49     {
50         if (0 == DeleteTimerQueueTimer(NULL, h2, INVALID_HANDLE_VALUE))
51         {
52             std::cout << "Timer  Deleted Failed in Thread:" << std::this_thread::get_id() << std::endl;
53         }
54         std::cout << "Timer  Deleted Successfully in Thread:" << std::this_thread::get_id() << std::endl;
55
56     };
57     Sleep(1000);
58
59     return 0;
60 }

• 1.
• 2.
• 3.
• 4.
• 5.
• 6.
• 7.
• 8.
• 9.
• 10.
• 11.
• 12.
• 13.
• 14.
• 15.
• 16.
• 17.
• 18.
• 19.
• 20.
• 21.
• 22.
• 23.
• 24.
• 25.
• 26.
• 27.
• 28.
• 29.
• 30.
• 31.
• 32.
• 33.
• 34.
• 35.
• 36.
• 37.
• 38.
• 39.
• 40.
• 41.
• 42.
• 43.
• 44.
• 45.
• 46.
• 47.
• 48.
• 49.
• 50.
• 51.
• 52.
• 53.
• 54.
• 55.
• 56.
• 57.
• 58.
• 59.
• 60.

Main()函数中test1回调无法执行！

问题分析：

CreateTimerQueueTimer和DeleteTimerQueueTimer 分别负责线程的开启和中止，函数定义如下：

登录后复制

BOOL CreateTimerQueueTimer(
  [out]          PHANDLE             phNewTimer,
  [in, optional] HANDLE              TimerQueue,
  [in]           WAITORTIMERCALLBACK Callback,
  [in, optional] PVOID               Parameter,
  [in]           DWORD               DueTime,
  [in]           DWORD               Period,
  [in]           ULONG               Flags
);

• 1.
• 2.
• 3.
• 4.
• 5.
• 6.
• 7.
• 8.
• 9.

登录后复制

BOOL DeleteTimerQueueTimer(
  [in, optional] HANDLE TimerQueue,
  [in]           HANDLE Timer,
  [in, optional] HANDLE CompletionEvent
);

• 1.
• 2.
• 3.
• 4.
• 5.

主线程中分别利用CreateTimerQueueTimer开启后台线程调用回调test()和test1(),并在test()调用中结束调用。由于DeleteTimerQueueTimer中CompletionEvent中使用的是INVALID_HANDLE_VALUE，导致线程会等待所有timer线程执行结束，才能返回。而当前执行回调的线程等不到自己结束，陷入死锁。因为CreateTimerQueueTimer的Flag参数使用的是WT_EXECUTEINTIMERTHREAD，导致test1回调和test使用的是同一线程，而test线程已经死锁，所以test1也无法得到执行

解决方案：

1. 不应该在回调中调用DeleteTimerQueueTimer中止线程
2. 如果必须在回调中中止线程，CompletionEvent应设为NULL，标记当前线程结束后，直接返回0（执行失败），回调执行完，不再继续执行
3. CreateTimerQueueTimer使用Flag WT_EXECUTEDEFAULT开启新线程，即使上一个timer线程死锁，第二个线程仍可以执行

原创作者: u_13709810 转载于: https://blog.51cto.com/u_13709810/11844225
