echarts中国地图如何标记散点图

工作中会遇到echarts在地图上面标记点位，后端数据传给城市名和坐标轴给你以后，如何添加到echarts上面渲染呢
echarts需要的数据
例子

{
       name: "深圳",
       value: [114.271522, 22.753644]
}

name是城市名,value是坐标轴

拿到数据后
找到echarts的配置属性->series
代码如下

    series: [
        // 常规地图
        {
            type: 'map',
            mapType: 'china',
            aspectScale: 0.85,
            layoutCenter: ["50%", "50%"], //地图位置
            layoutSize: '138%',
            zoom: 1, //当前视角的缩放比例
            // roam: true, //是否开启平游或缩放
            scaleLimit: { //滚轮缩放的极限控制
                min: 1,
                max: 2
            },
            itemStyle: {
                normal: {
                    areaColor: '#0c274b',
                    borderColor: '#1cccff',
                    borderWidth: 1.5


                },
                emphasis: {
                    areaColor: '#02102b',
                    label: {
                        color: "#fff"
                    }

                }
            },


        },
        {
            name: '天燃气',
            type: 'scatter',
            coordinateSystem: 'geo',
            data: [{ //庐阳区
                name: '首都',
                value: [116.24, 41.55, 100],
                type: 'ranqi',

            }, ],
            symbol: iconRQ,
            symbolSize: 20,
            label: {
                normal: {
                    show: false,

                },
                emphasis: {
                    show: false
                }
            },

        },
        // 区域散点图
        {
            type: 'effectScatter',
            coordinateSystem: 'geo',
            symbolSize: 5,
            rippleEffect: { //坐标点动画
                period: 3,
                scale: 5,
                brushType: 'fill'
            },
            label: {
                normal: {
                    show: true,
                    position: 'right',
                    formatter: '{b}',
                    color: '#b3e2f2',
                    fontWeight: "bold",
                    fontSize: 18
                }
            },

            data: [{
                    name: "深圳",
                    value: [114.271522, 22.753644]
                },
                {
                    name: "南京",
                    value: [118.78, 32.04]
                },
                {
                    name: "重庆",
                    value: [106.54, 29.59]
                },
                {
                    name: "北京",
                    value: [116.24, 39.55, 100]
                },
                {
                    name: "荆州",
                    value: [113.41, 29.59]
                }
            ],
            itemStyle: { //坐标点颜色
                normal: {
                    show: true,
                    color: '#fff',
                    shadowBlur: 10,
                    shadowColor: '#fff'
                },
                emphasis: {
                    areaColor: '#f00'
                }
            },

        },
        // 线 和 点
        {
            type: 'lines',
            zlevel: 1, //设置这个才会有轨迹线的小尾巴
            effect: {
                show: true,
                period: 10,
                trailLength: 0.7,
                color: '#fff',
                symbol: 'arrow',
                symbolSize: 6
            },
            lineStyle: {
                normal: {
                    color: '#fff',
                    width: 1.5,
                    curveness: 0.2,
                    shadowColor: '#fff',
                }
            },
            data: [{
                    fromName: 1,
                    toName: 1,
                    coords: [
                        [114.271522, 22.753644],
                        [116.24, 39.55],

                    ]
                },
                {
                    fromName: 1,
                    toName: 1,
                    coords: [
                        [114.271522, 22.753644],
                        [118.78, 32.04],

                    ]
                },
                {
                    fromName: 1,
                    toName: 1,
                    coords: [
                        [114.271522, 22.753644],
                        [106.54, 29.59],

                    ]
                }
            ],

        }
    ]
