Deploy Kubernetes Like a Pro: Online Setup with Kubespray 2.27.0 on Red Hat 9.5

ghostwritten

已于 2025-02-14 16:06:40 修改

阅读量1.3k

点赞数 25

分类专栏： kubernetes 文章标签： kubernetes 容器云原生

于 2025-02-06 15:10:17 首次发布

本文链接：https://blog.csdn.net/xixihahalelehehe/article/details/145474224

版权

kubernetes 专栏收录该内容

308 篇文章

订阅专栏

在这里插入图片描述

文章目录

本指南介绍如何使用 Kubespray 在多个节点上部署 Kubernetes 集群。本方案基于 Podman 运行 Kubespray 容器，并利用 Ansible 进行自动化部署，适用于希望快速搭建 Kubernetes 集群的用户。

查看kubespray v2.27.0 版本各个软件版本：https://github.com/kubernetes-sigs/kubespray/blob/v2.27.0/roles/kubespray-defaults/defaults/main/download.yml

1. 基础配置

1.1 设置主机名

在所有节点上执行以下命令，配置主机名：

192.168.21.170:
hostnamectl set-hostname bastion01
192.168.21.171:
hostnamectl set-hostname kube-master01
192.168.21.172:
hostnamectl set-hostname kube-node01
192.168.21.173:
hostnamectl set-hostname kube-node02
192.168.21.174:
hostnamectl set-hostname kube-node03
192.168.21.175:
hostnamectl set-hostname kube-node04

1.2 配置网络

在所有节点上编辑网络配置文件：

vim /etc/NetworkManager/system-connections/ens192.nmconnection

示例配置：

[connection]
id=ens192
uuid=f4dbd335-66ff-3056-9fcb-bbb3b4dd9543
type=ethernet
autoconnect-priority=-999
interface-name=ens192
timestamp=1736215902

[ethernet]

[ipv4]
address1=192.168.21.170/20,192.168.21.1
DNS=127.0.0.1
method=manual

[ipv6]
addr-gen-mode=eui64
method=auto

[proxy]

重启网络连接以使配置生效：

nmcli connection reload && nmcli connection down ens192 && nmcli connection up ens192

建议：完成所有节点的网络配置后，关机并创建快照，以便后续部署时能够快速恢复。

1.3 配置代理（仅在 bastion01 上）

为了加快 GitHub 及其他工具的访问速度，可以在 bastion01 配置代理：

vim /root/.bashrc

追加以下内容：

ENV_PROXY="http://192.168.21.101:7890"

enable_proxy() {
    export HTTP_PROXY="$ENV_PROXY"
    export HTTPS_PROXY="$ENV_PROXY"
    export ALL_PROXY="$ENV_PROXY"
    export NO_PROXY="localhost,127.0.0.1/8,10.0.0.0/8,172.16.0.0/12,192.168.0.0/16"

    export http_proxy="$ENV_PROXY"
    export https_proxy="$ENV_PROXY"
    export all_proxy="$ENV_PROXY"
    export no_proxy="$NO_PROXY"
}

disable_proxy() {
    unset HTTP_PROXY HTTPS_PROXY ALL_PROXY NO_PROXY
    unset http_proxy https_proxy all_proxy no_proxy
}

enable_proxy

使配置生效：

source /root/.bashrc

1.4 配置 SSH 互信（在 bastion01 上执行）

ssh-keygen

安装 sshpass 并批量分发公钥：

dnf -y install sshpass
for i in {170..175}; do sshpass -p 'root' ssh-copy-id -o StrictHostKeyChecking=no -i ~/.ssh/id_rsa.pub root@192.168.21.$i; done

2. Kubernetes 集群安装

2.1 运行 Kubespray 部署容器

podman run -it --net=host -v "${HOME}"/.ssh/id_rsa:/root/.ssh/id_rsa --name kubespray \
  quay.io/kubespray/kubespray:v2.27.0 bash

2.2 编写 `inventory.ini`

在 bastion01 进入 Kubespray 容器，并创建 inventory.ini：

vim inventory/sample/inventory.ini

示例内容：

[all]
kube-master01 ansible_host=192.168.21.171
kube-node01 ansible_host=192.168.21.172
kube-node02 ansible_host=192.168.21.173
kube-node03 ansible_host=192.168.21.174
kube-node04 ansible_host=192.168.21.175

[kube_control_plane]
kube-master01

[etcd]
kube-master01

[kube_node]
kube-node01
kube-node02
kube-node03
kube-node04

[calico_rr]

[k8s_cluster:children]
kube_control_plane
kube_node
calico_rr

2.3 配置 Ansible 别名

vim /root/.bashrc

追加：

alias ansible='ansible -i inventory/sample/inventory.ini'

加载配置并测试连接：

source /root/.bashrc
ansible all -m ping

2.4 配置代理（可选）

vim inventory/sample/group_vars/all/all.yml

http_proxy: "http://192.168.21.101:7890"
https_proxy: "http://192.168.21.101:7890"
no_proxy: "localhost,127.0.0.0/8,10.0.0.0/8,192.168.0.0/16,*.coding.net,*.tencentyun.com,*.myqcloud.com"

2.5 开始安装 Kubernetes 集群

ansible-playbook -i inventory/sample/inventory.ini --private-key /root/.ssh/id_rsa cluster.yml

output:

PLAY RECAP ***********************************************************************************************************************************
kube-master01              : ok=668  changed=146  unreachable=0    failed=0    skipped=1072 rescued=0    ignored=6
kube-node01                : ok=459  changed=91   unreachable=0    failed=0    skipped=669  rescued=0    ignored=1
kube-node02                : ok=459  changed=91   unreachable=0    failed=0    skipped=667  rescued=0    ignored=1
kube-node03                : ok=459  changed=91   unreachable=0    failed=0    skipped=667  rescued=0    ignored=1
kube-node04                : ok=459  changed=91   unreachable=0    failed=0    skipped=667  rescued=0    ignored=1

Thursday 06 February 2025  06:09:39 +0000 (0:00:00.054)       0:09:20.636 *****
===============================================================================
bootstrap-os : Check RHEL subscription-manager status -------------------------------------------------------------------------------- 29.99s
download : Download_container | Download image if required --------------------------------------------------------------------------- 29.44s
container-engine/containerd : Download_file | Download item -------------------------------------------------------------------------- 24.42s
download : Download_file | Download item --------------------------------------------------------------------------------------------- 17.68s
download : Download_file | Download item --------------------------------------------------------------------------------------------- 16.25s
kubernetes/kubeadm : Join to cluster if needed --------------------------------------------------------------------------------------- 15.91s
download : Download_container | Download image if required --------------------------------------------------------------------------- 15.72s
download : Download_file | Download item --------------------------------------------------------------------------------------------- 15.60s
download : Download_file | Download item --------------------------------------------------------------------------------------------- 14.57s
download : Download_container | Download image if required --------------------------------------------------------------------------- 13.46s
bootstrap-os : Install libselinux python package ------------------------------------------------------------------------------------- 13.01s
kubernetes/preinstall : Install packages requirements -------------------------------------------------------------------------------- 11.15s
download : Download_file | Download item --------------------------------------------------------------------------------------------- 10.88s
download : Download_container | Download image if required ---------------------------------------------------------------------------- 9.55s
bootstrap-os : Ensure iproute is installed -------------------------------------------------------------------------------------------- 9.50s
download : Download_container | Download image if required ---------------------------------------------------------------------------- 9.03s
download : Download_container | Download image if required ---------------------------------------------------------------------------- 8.99s
download : Download_file | Download item ---------------------------------------------------------------------------------------------- 8.97s
container-engine/crictl : Download_file | Download item ------------------------------------------------------------------------------- 8.70s
download : Download_container | Download image if required ---------------------------------------------------------------------------- 8.61s
root@bastion01:/kubespray#

2.6 配置 `kubectl`

mkdir -p /root/.kube
scp root@192.168.21.171:/usr/local/bin/kubectl /usr/local/bin/
scp root@192.168.21.171:/etc/kubernetes/admin.conf /root/.kube/config
vim /root/.kube/config

修改 server 地址为 kube-master01 的 IP：

server: https://192.168.21.171:6443

测试 Kubernetes 运行状态：

$ kubectl get node
NAME            STATUS   ROLES           AGE   VERSION
kube-master01   Ready    control-plane   8d    v1.31.4
kube-node01     Ready    <none>          8d    v1.31.4
kube-node02     Ready    <none>          8d    v1.31.4
kube-node03     Ready    <none>          8d    v1.31.4
kube-node04     Ready    <none>          8d    v1.31.4

2.7 配置 `kubectl` 命令别名

cat >> ~/.bashrc << EOF
alias kg='kubectl get'
alias k='kubectl'
alias kd='kubectl describe pods'
alias ke='kubectl explain'
alias ka='kubectl apply'
EOF
source ~/.bashrc

验证 Kubernetes 组件状态：


$ kg pod -A
NAMESPACE     NAME                                       READY   STATUS    RESTARTS   AGE
kube-system   calico-kube-controllers-5db5978889-kgckn   1/1     Running   0          7m7s
kube-system   calico-node-bx7wc                          1/1     Running   0          7m18s
kube-system   calico-node-r6njt                          1/1     Running   0          7m18s
kube-system   calico-node-r6plc                          1/1     Running   0          7m18s
kube-system   calico-node-sndfx                          1/1     Running   0          7m18s
kube-system   calico-node-zs687                          1/1     Running   0          7m18s
kube-system   coredns-d665d669-59clr                     1/1     Running   0          7m5s
kube-system   coredns-d665d669-bqgdx                     1/1     Running   0          7m3s
kube-system   dns-autoscaler-5cb4578f5f-kp5rs            1/1     Running   0          7m4s
kube-system   kube-apiserver-kube-master01               1/1     Running   1          7m58s
kube-system   kube-controller-manager-kube-master01      1/1     Running   2          7m58s
kube-system   kube-proxy-825b5                           1/1     Running   0          7m31s
kube-system   kube-proxy-cfbwt                           1/1     Running   0          7m31s
kube-system   kube-proxy-klfqm                           1/1     Running   0          7m31s
kube-system   kube-proxy-mn8gt                           1/1     Running   0          7m31s
kube-system   kube-proxy-mq5r9                           1/1     Running   0          7m31s
kube-system   kube-scheduler-kube-master01               1/1     Running   1          7m58s
kube-system   nginx-proxy-kube-node01                    1/1     Running   0          7m33s
kube-system   nginx-proxy-kube-node02                    1/1     Running   0          7m33s
kube-system   nginx-proxy-kube-node03                    1/1     Running   0          7m33s
kube-system   nginx-proxy-kube-node04                    1/1     Running   0          7m24s
kube-system   nodelocaldns-dtm75                         1/1     Running   0          7m3s
kube-system   nodelocaldns-nxdwv                         1/1     Running   0          7m3s
kube-system   nodelocaldns-pbs4v                         1/1     Running   0          7m3s
kube-system   nodelocaldns-r284k                         1/1     Running   0          7m3s
kube-system   nodelocaldns-x9qq2                         1/1     Running   0          7m3s
