<html>
<head>
<link type="text/css" rel="stylesheet" href="./jsmind.css" />
<script type="text/javascript" src="./jsmind.js"></script>
<script type="text/javascript" src="./jsmind.draggable-node.js"></script>
<style>
.m-wrap{box-shadow: 0px 0px 5px #888888; ;}
</style>
</head>
<body>
<div id="jsmind_container" style="width: 800px; height: 500px" class="m-wrap"></div>
<script type="text/javascript">
var mind = {
/* 元数据，定义思维导图的名称、作者、版本等信息 */
meta: {
name: 'jsMind-demo-tree',
author: 'hizzgdev@163.com',
version: '0.2',
},
/* 数据格式声明 */
format: 'node_tree',
/* 数据内容 */
data: {
id: 'root',
topic: 'jsMind',
children: [
{
id: 'easy',
topic: 'Easy',
direction: 'left',
expanded: false,
children: [
{ id: 'easy1', topic: 'Easy to show' },
{ id: 'easy2', topic: 'Easy to edit' },
{ id: 'easy3', topic: 'Easy to store' },
{ id: 'easy4', topic: 'Easy to embed' },
],
},
{
id: 'open',
topic: 'Open Source',
direction: 'right',
expanded: true,
children: [
{ id: 'open1', topic: 'on GitHub' },
{ id: 'open2', topic: 'BSD License' },
],
},
{
id: 'powerful',
topic: 'Powerful',
direction: 'right',
children: [
{ id: 'powerful1', topic: 'Base on Javascript' },
{ id: 'powerful2', topic: 'Base on HTML5' },
{ id: 'powerful3', topic: 'Depends on you' },
],
},
{
id: 'other',
topic: 'test node',
direction: 'left',
children: [
{ id: 'other1', topic: "I'm from local variable" },
{ id: 'other2', topic: 'I can do everything' },
],
},
],
},
}
var options = {
container: 'jsmind_container',
theme: 'primary',
editable: true,
view: {
engine: 'canvas',
draggable: true, // 启用拖动画布功能
hide_scrollbars_when_draggable: true, // 启用拖动时隐藏滚动条
},
}
var jm = new jsMind(options)
jm.show(mind)
</script>
</body>
</html>
jsmind.css:
/**
* @license BSD
* @copyright 2014-2023 hizzgdev@163.com
*
* Project Home:
* https://github.com/hizzgdev/jsmind/
*/
/* important section */
.jsmind-inner {
position: relative;
overflow: auto;
width: 100%;
height: 100%;
outline: none;
} /*box-shadow:0 0 2px #000;*/
.jsmind-inner {
moz-user-select: -moz-none;
-moz-user-select: none;
-o-user-select: none;
-khtml-user-select: none;
-webkit-user-select: none;
-ms-user-select: none;
user-select: none;
}
.jsmind-inner canvas {
position: absolute;
}
/* z-index:1 */
svg.jsmind {
position: absolute;
z-index: 1;
}
canvas.jsmind {
position: absolute;
z-index: 1;
}
/* z-index:2 */
jmnodes {
position: absolute;
z-index: 2;
background-color: rgba(0, 0, 0, 0);
} /*background color is necessary*/
jmnode {
position: absolute;
cursor: default;
max-width: 400px;
}
jmexpander {
position: absolute;
width: 11px;
height: 11px;
display: block;
overflow: hidden;
line-height: 12px;
font-size: 10px;
text-align: center;
border-radius: 6px;
border-width: 1px;
border-style: solid;
cursor: pointer;
}
.jmnode-overflow-wrap jmnodes {
min-width: 420px;
}
.jmnode-overflow-hidden jmnode {
white-space: nowrap;
overflow: hidden;
text-overflow: ellipsis;
}
/* default theme */
jmnode {
padding: 10px;
background-color: #fff;
color: #333;
border-radius: 5px;
box-shadow: 1px 1px 1px #666;
font: 16px/1.125 Verdana, Arial, Helvetica, sans-serif;
}
jmnode:hover {
box-shadow: 2px 2px 8px #000;
background-color: #ebebeb;
color: #333;
}
jmnode.selected {
background-color: #11f;
color: #fff;
box-shadow: 2px 2px 8px #000;
}
jmnode.root {
font-size: 24px;
}
jmexpander {
border-color: gray;
}
jmexpander:hover {
border-color: #000;
}
@media screen and (max-device-width: 1024px) {
jmnode {
padding: 5px;
border-radius: 3px;
font-size: 14px;
}
jmnode.root {
font-size: 21px;
}
}
/* primary theme */
jmnodes.theme-primary jmnode {
background-color: #428bca;
color: #fff;
border-color: #357ebd;
}
jmnodes.theme-primary jmnode:hover {
background-color: #3276b1;
border-color: #285e8e;
}
jmnodes.theme-primary jmnode.selected {
background-color: #f1c40f;
color: #fff;
}
jmnodes.theme-primary jmnode.root {
}
jmnodes.theme-primary jmexpander {
}
jmnodes.theme-primary jmexpander:hover {
}
/* warning theme */
jmnodes.theme-warning jmnode {
background-color: #f0ad4e;
border-color: #eea236;
color: #fff;
}
jmnodes.theme-warning jmnode:hover {
background-color: #ed9c28;
border-color: #d58512;
}
jmnodes.theme-warning jmnode.selected {
background-color: #11f;
color: #fff;
}
jmnodes.theme-warning jmnode.root {
}
jmnodes.theme-warning jmexpander {
}
jmnodes.theme-warning jmexpander:hover {
}
/* danger theme */
jmnodes.theme-danger jmnode {
background-color: #d9534f;
border-color: #d43f3a;
color: #fff;
}
jmnodes.theme-danger jmnode:hover {
background-color: #d2322d;
border-color: #ac2925;
}
jmnodes.theme-danger jmnode.selected {
background-color: #11f;
color: #fff;
}
jmnodes.theme-danger jmnode.root {
}
jmnodes.theme-danger jmexpander {
}
jmnodes.theme-danger jmexpander:hover {
}
/* success theme */
jmnodes.theme-success jmnode {
background-color: #5cb85c;
border-color: #4cae4c;
color: #fff;
}
jmnodes.theme-success jmnode:hover {
background-color: #47a447;
border-color: #398439;
}
jmnodes.theme-success jmnode.selected {
background-color: #11f;
color: #fff;
}
jmnodes.theme-success jmnode.root {
}
jmnodes.theme-success jmexpander {
}
jmnodes.theme-success jmexpander:hover {
}
/* info theme */
jmnodes.theme-info jmnode {
background-color: #5dc0de;
border-color: #46b8da;
color: #fff;
}
jmnodes.theme-info jmnode:hover {
background-color: #39b3d7;
border-color: #269abc;
}
jmnodes.theme-info jmnode.selected {
background-color: #11f;
color: #fff;
}
jmnodes.theme-info jmnode.root {
}
jmnodes.theme-info jmexpander {
}
jmnodes.theme-info jmexpander:hover {
}
/* greensea theme */
jmnodes.theme-greensea jmnode {
background-color: #1abc9c;
color: #fff;
}
jmnodes.theme-greensea jmnode:hover {
background-color: #16a085;
}
jmnodes.theme-greensea jmnode.selected {
background-color: #11f;
color: #fff;
}
jmnodes.theme-greensea jmnode.root {
}
jmnodes.theme-greensea jmexpander {
}
jmnodes.theme-greensea jmexpander:hover {
}
/* nephrite theme */
jmnodes.theme-nephrite jmnode {
background-color: #2ecc71;
color: #fff;
}
jmnodes.theme-nephrite jmnode:hover {
background-color: #27ae60;
}
jmnodes.theme-nephrite jmnode.selected {
background-color: #11f;
color: #fff;
}
jmnodes.theme-nephrite jmnode.root {
}
jmnodes.theme-nephrite jmexpander {
}
jmnodes.theme-nephrite jmexpander:hover {
}
/* belizehole theme */
jmnodes.theme-belizehole jmnode {
background-color: #3498db;
color: #fff;
}
jmnodes.theme-belizehole jmnode:hover {
background-color: #2980b9;
}
jmnodes.theme-belizehole jmnode.selected {
background-color: #11f;
color: #fff;
}
jmnodes.theme-belizehole jmnode.root {
}
jmnodes.theme-belizehole jmexpander {
}
jmnodes.theme-belizehole jmexpander:hover {
}
/* wisteria theme */
jmnodes.theme-wisteria jmnode {
background-color: #9b59b6;
color: #fff;
}
jmnodes.theme-wisteria jmnode:hover {
background-color: #8e44ad;
}
jmnodes.theme-wisteria jmnode.selected {
background-color: #11f;
color: #fff;
}
jmnodes.theme-wisteria jmnode.root {
}
jmnodes.theme-wisteria jmexpander {
}
jmnodes.theme-wisteria jmexpander:hover {
}
/* asphalt theme */
jmnodes.theme-asphalt jmnode {
background-color: #34495e;
color: #fff;
}
jmnodes.theme-asphalt jmnode:hover {
background-color: #2c3e50;
}
jmnodes.theme-asphalt jmnode.selected {
background-color: #11f;
color: #fff;
}
jmnodes.theme-asphalt jmnode.root {
}
jmnodes.theme-asphalt jmexpander {
}
jmnodes.theme-asphalt jmexpander:hover {
}
/* orange theme */
jmnodes.theme-orange jmnode {
background-color: #f1c40f;
color: #fff;
}
jmnodes.theme-orange jmnode:hover {
background-color: #f39c12;
}
jmnodes.theme-orange jmnode.selected {
background-color: #11f;
color: #fff;
}
jmnodes.theme-orange jmnode.root {
}
jmnodes.theme-orange jmexpander {
}
jmnodes.theme-orange jmexpander:hover {
}
/* pumpkin theme */
jmnodes.theme-pumpkin jmnode {
background-color: #e67e22;
color: #fff;
}
jmnodes.theme-pumpkin jmnode:hover {
background-color: #d35400;
}
jmnodes.theme-pumpkin jmnode.selected {
background-color: #11f;
color: #fff;
}
jmnodes.theme-pumpkin jmnode.root {
}
jmnodes.theme-pumpkin jmexpander {
}
jmnodes.theme-pumpkin jmexpander:hover {
}
/* pomegranate theme */
jmnodes.theme-pomegranate jmnode {
background-color: #e74c3c;
color: #fff;
}
jmnodes.theme-pomegranate jmnode:hover {
background-color: #c0392b;
}
jmnodes.theme-pomegranate jmnode.selected {
background-color: #11f;
color: #fff;
}
jmnodes.theme-pomegranate jmnode.root {
}
jmnodes.theme-pomegranate jmexpander {
}
jmnodes.theme-pomegranate jmexpander:hover {
}
/* clouds theme */
jmnodes.theme-clouds jmnode {
background-color: #ecf0f1;
color: #333;
}
jmnodes.theme-clouds jmnode:hover {
background-color: #bdc3c7;
}
jmnodes.theme-clouds jmnode.selected {
background-color: #11f;
color: #fff;
}
jmnodes.theme-clouds jmnode.root {
}
jmnodes.theme-clouds jmexpander {
}
jmnodes.theme-clouds jmexpander:hover {
}
/* asbestos theme */
jmnodes.theme-asbestos jmnode {
background-color: #95a5a6;
color: #fff;
}
jmnodes.theme-asbestos jmnode:hover {
background-color: #7f8c8d;
}
jmnodes.theme-asbestos jmnode.selected {
background-color: #11f;
color: #fff;
}
jmnodes.theme-asbestos jmnode.root {
}
jmnodes.theme-asbestos jmexpander {
}
jmnodes.theme-asbestos jmexpander:hover {
}
jsmind.js:
/**
* @license BSD-3-Clause
* @copyright 2014-2023 hizzgdev@163.com
*
* Project Home:
* https://github.com/hizzgdev/jsmind/
*/
//# sourceMappingURL=jsmind.js.map
jsmind.draggable-node.js:
/**
* @license BSD-3-Clause
* @copyright 2014-2023 hizzgdev@163.com
*
* Project Home:
* https://github.com/hizzgdev/jsmind/
*/
!function(t,e){"object"==typeof exports&&"undefined"!=typeof module?e(require("jsmind")):"function"==typeof define&&define.amd?define(["jsmind"],e):e((t="undefined"!=typeof globalThis?globalThis:t||self).jsMind)}(this,(function(t){"use strict";function e(t){return t&&"object"==typeof t&&"default"in t?t:{default:t}}var i=e(t);if(!i.default)throw new Error("jsMind is not defined");const s=i.default.$,o="getSelection"in s.w?function(){s.w.getSelection().removeAllRanges()}:function(){s.d.selection.empty()},n={line_width:5,line_color:"rgba(0,0,0,0.3)",line_color_invalid:"rgba(255,51,51,0.6)",lookup_delay:200,lookup_interval:100,scrolling_trigger_width:20,scrolling_step_length:10,shadow_node_class_name:"jsmind-draggable-shadow-node"};class h{constructor(t,e){var s={};i.default.util.json.merge(s,n),i.default.util.json.merge(s,e),this.version="0.4.0",this.jm=t,this.options=s,this.e_canvas=null,this.canvas_ctx=null,this.shadow=null,this.shadow_p_x=0,this.shadow_p_y=0,this.shadow_w=0,this.shadow_h=0,this.active_node=null,this.target_node=null,this.target_direct=null,this.client_w=0,this.client_h=0,this.offset_x=0,this.offset_y=0,this.hlookup_delay=0,this.hlookup_timer=0,this.capture=!1,this.moved=!1,this.canvas_draggable=t.get_view_draggable(),this.view_panel=t.view.e_panel,this.view_panel_rect=null}init(){this.create_canvas(),this.create_shadow(),this.event_bind()}resize(){this.jm.view.e_nodes.appendChild(this.shadow),this.e_canvas.width=this.jm.view.size.w,this.e_canvas.height=this.jm.view.size.h}create_canvas(){var t=s.c("canvas");this.jm.view.e_panel.appendChild(t);var e=t.getContext("2d");this.e_canvas=t,this.canvas_ctx=e}create_shadow(){var t=s.c("jmnode");t.style.visibility="hidden",t.style.zIndex="3",t.style.cursor="move",t.style.opacity="0.7",t.className=this.options.shadow_node_class_name,this.shadow=t}reset_shadow(t){var e=this.shadow.style;this.shadow.innerHTML=t.innerHTML,e.left=t.style.left,e.top=t.style.top,e.width=t.style.width,e.height=t.style.height,e.backgroundImage=t.style.backgroundImage,e.backgroundSize=t.style.backgroundSize,e.transform=t.style.transform,this.shadow_w=this.shadow.clientWidth,this.shadow_h=this.shadow.clientHeight}show_shadow(){this.moved||(this.shadow.style.visibility="visible")}hide_shadow(){this.shadow.style.visibility="hidden"}magnet_shadow(t,e,i){this.canvas_ctx.lineWidth=this.options.line_width,this.canvas_ctx.strokeStyle=i?this.options.line_color_invalid:this.options.line_color,this.canvas_ctx.lineCap="round",this.clear_lines(),this.canvas_lineto(t.x,t.y,e.x,e.y)}clear_lines(){this.canvas_ctx.clearRect(0,0,this.jm.view.size.w,this.jm.view.size.h)}canvas_lineto(t,e,i,s){this.canvas_ctx.beginPath(),this.canvas_ctx.moveTo(t,e),this.canvas_ctx.lineTo(i,s),this.canvas_ctx.stroke()}event_bind(){var t=this,e=this.jm.view.container;s.on(e,"mousedown",(function(e){0===e.button&&t.dragstart.call(t,e)})),s.on(e,"mousemove",(function(e){0===e.movementX&&0===e.movementY||t.drag.call(t,e)})),s.on(e,"mouseup",(function(e){t.dragend.call(t,e)})),s.on(e,"touchstart",(function(e){t.dragstart.call(t,e)})),s.on(e,"touchmove",(function(e){t.drag.call(t,e)})),s.on(e,"touchend",(function(e){t.dragend.call(t,e)}))}dragstart(t){if(this.jm.get_editable()&&!this.capture){var e=this.jm.view;if(!e.is_editing()){this.active_node=null,this.view_draggable=this.jm.get_view_draggable();var i=this.find_node_element(t.target);if(i){this.view_draggable&&this.jm.disable_view_draggable();var o=e.get_binded_nodeid(i);if(o){var n=this.jm.get_node(o);if(!n.isroot){this.reset_shadow(i),this.view_panel_rect=this.view_panel.getBoundingClientRect(),this.active_node=n,this.offset_x=(t.clientX||t.touches[0].clientX)/e.zoom_current-i.offsetLeft,this.offset_y=(t.clientY||t.touches[0].clientY)/e.zoom_current-i.offsetTop,this.client_hw=Math.floor(i.clientWidth/2),this.client_hh=Math.floor(i.clientHeight/2),0!=this.hlookup_delay&&s.w.clearTimeout(this.hlookup_delay),0!=this.hlookup_timer&&s.w.clearInterval(this.hlookup_timer);var h=this;this.hlookup_delay=s.w.setTimeout((function(){h.hlookup_delay=0,h.hlookup_timer=s.w.setInterval((function(){h.lookup_target_node.call(h)}),h.options.lookup_interval)}),this.options.lookup_delay),h.capture=!0}}}}}}drag(t){if(this.jm.get_editable()&&this.capture){t.preventDefault(),this.show_shadow(),this.moved=!0,o();var e=this.jm.view,i=(t.clientX||t.touches[0].clientX)/e.zoom_current-this.offset_x,s=(t.clientY||t.touches[0].clientY)/e.zoom_current-this.offset_y;t.clientY-this.view_panel_rect.top<this.options.scrolling_trigger_width&&this.view_panel.scrollTop>this.options.scrolling_step_length?(this.view_panel.scrollBy(0,-this.options.scrolling_step_length),this.offset_y+=this.options.scrolling_step_length/e.zoom_current):this.view_panel_rect.bottom-t.clientY<this.options.scrolling_trigger_width&&this.view_panel.scrollTop<this.view_panel.scrollHeight-this.view_panel_rect.height-this.options.scrolling_step_length&&(this.view_panel.scrollBy(0,this.options.scrolling_step_length),this.offset_y-=this.options.scrolling_step_length/e.zoom_current),t.clientX-this.view_panel_rect.left<this.options.scrolling_trigger_width&&this.view_panel.scrollLeft>this.options.scrolling_step_length?(this.view_panel.scrollBy(-this.options.scrolling_step_length,0),this.offset_x+=this.options.scrolling_step_length/e.zoom_current):this.view_panel_rect.right-t.clientX<this.options.scrolling_trigger_width&&this.view_panel.scrollLeft<this.view_panel.scrollWidth-this.view_panel_rect.width-this.options.scrolling_step_length&&(this.view_panel.scrollBy(this.options.scrolling_step_length,0),this.offset_x-=this.options.scrolling_step_length/e.zoom_current),this.shadow.style.left=i+"px",this.shadow.style.top=s+"px",o()}}dragend(t){if(this.jm.get_editable()){if(this.view_draggable&&this.jm.enable_view_draggable(),this.capture){if(0!=this.hlookup_delay&&(s.w.clearTimeout(this.hlookup_delay),this.hlookup_delay=0,this.clear_lines()),0!=this.hlookup_timer&&(s.w.clearInterval(this.hlookup_timer),this.hlookup_timer=0,this.clear_lines()),this.moved){var e=this.active_node,i=this.target_node,o=this.target_direct;this.move_node(e,i,o)}this.hide_shadow()}this.view_panel_rect=null,this.moved=!1,this.capture=!1}}find_node_element(t){return t===this.jm.view.e_nodes||t===this.jm.view.e_panel||t===this.jm.view.container?null:"jmnode"===t.tagName.toLowerCase()?t:this.find_node_element(t.parentNode)}lookup_target_node(){let t=this.shadow.offsetLeft,e=this.shadow.offsetTop;if(t===this.shadow_p_x&&e===this.shadow_p_y)return;this.shadow_p_x=t,this.shadow_p_y=e;let s=this.shadow_p_x+this.shadow_w/2>=this.get_root_x()?i.default.direction.right:i.default.direction.left,o=this.lookup_overlapping_node_parent(s)||this.lookup_close_node(s);if(o){let t=this.calc_point_of_node(o,s),e=i.default.node.inherited(this.active_node,o);this.magnet_shadow(t.sp,t.np,e),this.target_node=o,this.target_direct=s}}get_root_x(){let t=this.jm.get_root(),e=t.get_location(),i=t.get_size();return e.x+i.w/2}lookup_overlapping_node_parent(t){let e=this.shadow.getBoundingClientRect(),i=e.x+e.width*(1-t)/2,s=(this.jm.options.layout.hspace+this.jm.options.layout.pspace)*t,o=e.height,n=[[i,e.y],[i,e.y+o/2],[i,e.y+o],[i+s/2,e.y],[i+s/2,e.y+o/2],[i+s/2,e.y+o],[i+s,e.y],[i+s,e.y+o/2],[i+s,e.y+o]];for(const t of n){let e=this.lookup_node_parent_by_location(t[0],t[1]);if(e)return e}}lookup_node_parent_by_location(t,e){return s.d.elementsFromPoint(t,e).filter((t=>"JMNODE"===t.tagName&&t.className!==this.options.shadow_node_class_name)).map((t=>this.jm.view.get_binded_nodeid(t))).map((t=>t&&this.jm.mind.nodes[t])).map((t=>t&&t.parent)).find((t=>t))}lookup_close_node(t){return Object.values(this.jm.mind.nodes).filter((e=>e.direction==t||e.isroot)).filter((t=>this.jm.layout.is_visible(t))).filter((e=>this.shadow_on_target_side(e,t))).map((e=>({node:e,distance:this.shadow_to_node(e,t)}))).reduce(((t,e)=>t.distance<e.distance?t:e),{node:this.jm.get_root(),distance:Number.MAX_VALUE}).node}shadow_on_target_side(t,e){return e==i.default.direction.right&&this.shadow_to_right_of_node(t)>0||e==i.default.direction.left&&this.shadow_to_left_of_node(t)>0}shadow_to_right_of_node(t){return this.shadow_p_x-t.get_location().x-t.get_size().w}shadow_to_left_of_node(t){return t.get_location().x-this.shadow_p_x-this.shadow_w}shadow_to_base_line_of_node(t){return this.shadow_p_y+this.shadow_h/2-t.get_location().y-t.get_size().h/2}shadow_to_node(t,e){return(e===i.default.direction.right?Math.abs(this.shadow_to_right_of_node(t)):Math.abs(this.shadow_to_left_of_node(t)))+Math.abs(this.shadow_to_base_line_of_node(t))}calc_point_of_node(t,e){let i=t.get_size(),s=t.get_location(),o=t.isroot?s.x+i.w/2:s.x+i.w*(1+e)/2+this.options.line_width*e,n=s.y+i.h/2;return{sp:{x:this.shadow_p_x+this.shadow_w*(1-e)/2-this.options.line_width*e,y:this.shadow_p_y+this.shadow_h/2},np:{x:o,y:n}}}move_node(t,e,s){var o=this.shadow.offsetTop;if(e&&t&&!i.default.node.inherited(t,e)){for(var n=e.children,h=n.length,l=null,a=Number.MAX_VALUE,_=null,d="_last_";h--;)if((l=n[h]).direction==s&&l.id!=t.id){var r=l.get_location().y-o;r>0&&r<a&&(a=r,_=l,d="_first_")}_&&(d=_.id),this.jm.move_node(t.id,d,e.id,s)}this.active_node=null,this.target_node=null,this.target_direct=null}jm_event_handle(t,e){t===i.default.event_type.resize&&this.resize()}}var l=new i.default.plugin("draggable_node",(function(t,e){var i=new h(t,e);i.init(),t.add_event_listener((function(t,e){i.jm_event_handle.call(i,t,e)}))}));i.default.register_plugin(l)}));
//# sourceMappingURL=jsmind.draggable-node.js.map
