Android Glide 优化用户体验

目录(?)[+]

在上篇文章中,我们介绍了 Glide 怎样加载图片以及处理加载的图片,这篇文章我会从用户的体验角度来介绍 Glide。不过 Glide 提供的优化体验的方法,并不适用所有情况,所以根据实际情况选择到底用不用以及怎么用。

placeholder()默认图片

在没有加载图片前,界面会出现一个空白 ,有的应用会加一个圆形的 ProgerssBar,如果有多个图片短时间加载不出来 ,那么就有很多个圆圈在那里转,是不是看着很烦。 那么我们可以在没有加载网络图片之前,显示一张默认图片.

Glide.placeholder() 加载默认图片

Glide.with(MainActivity.this)
        .load(Images.urls[position])
        .placeholder(R.mipmap.ic_launcher)
        .centerCrop()
        .into(holder.mImageView);


  • 1
  • 2
  • 3
  • 4
  • 5
  • 1
  • 2
  • 3
  • 4
  • 5

error()加载出错图片

有时候你会告诉用户没有加载出来,Glide.error() 可以显示一张加载出错的图片。

Glide.with(MainActivity.this)
        .load(Images.urls[position])
        .placeholder(R.mipmap.ic_launcher)
        .error(R.mipmap.ic_launcher)
        .centerCrop()
        .into(holder.mImageView);


  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 1
  • 2
  • 3
  • 4
  • 5
  • 6

crossFade()图片之间显示加入过渡动画

如果你添加了默认的图片,在网络图片加载完成后,就会显示网络图片,那么这中间你可能想平滑的加载,Glide.crossFade() 可以达到效果。

Glide.with(MainActivity.this)
        .load(Images.urls[position])
        .placeholder(R.mipmap.ic_launcher)
        .error(R.mipmap.ic_launcher)
        .crossFade()
        .centerCrop()
        .into(holder.mImageView);


  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7

这个 crossFade() 在3.0后是默认加载的,所以我们也可以不要这个效果:Glide.dontAnimate()

animate()提供自定义的加载动画

既然有默认的加载动画,那么我们也可以自定义加载动画。在 Glide 2.0 时候引入 view animations,在 Glide 3.0 才支持 property animation。不过有人会问,那还需要 view animations 吗? 需要! 什么情况下需要? 听我一句:能用 view animations 达到效果的就用 view animations。

Glide 加载动画方法
1. animate(int animationId)
2. animate(Animation animation) -> Deprecated
3. animate(ViewPropertyAnimation.Animator animator)

第一种就是加载 view animations,第三种就是加载 property animation的, 第二种方法也是加载 view animations 但是已经废弃了。

加载 View Animation

Glide.with(MainActivity.this)
        .load(Images.urls[position])
        .error(R.mipmap.ic_launcher)
        .animate(R.anim.glide_slide_in_left_bounce
        .centerCrop()
        .into(holder.mImageView);


  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 1
  • 2
  • 3
  • 4
  • 5
  • 6

glide_slide_in_left_bounce.xml

<?xml version="1.0" encoding="utf-8"?>
<set xmlns:android="http://schemas.android.com/apk/res/android" android:duration="2000"
     android:interpolator="@android:anim/bounce_interpolator">
    <alpha android:fromAlpha="0.0" android:toAlpha="1.0"/>
    <translate android:fromXDelta="-100%p" android:toXDelta="0"/>
</set>


  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 1
  • 2
  • 3
  • 4
  • 5
  • 6

我们也可以用系统中的内置的 View Animation,如 Glide.animate(Android.R.anim.slide_in_left)

看下网络图片从左边滑入回弹效果

左侧滑入回弹效果

加载 Property Animation

ViewPropertyAnimation.Animator animatorSet = new ViewPropertyAnimation.Animator() {
    @Override
    public void animate(View view) {
        ObjectAnimator scaleX = ObjectAnimator.ofFloat(view, "scaleX", 0f, 1f);
        ObjectAnimator scaleY = ObjectAnimator.ofFloat(view, "scaleY", 0f, 1f);
        ObjectAnimator rotation = ObjectAnimator.ofFloat(view, "rotation", 0f, 360f);
        AnimatorSet set = new AnimatorSet();
        set.playTogether(scaleX,scaleY,rotation);
        set.setDuration(500);
        set.start();
    }
};

Glide.with(MainActivity.this)
        .load(Images.urls[position])
        .error(R.mipmap.ic_launcher)
        .animate(animatorSet)
        .centerCrop()
        .into(holder.mImageView);


  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8
  • 9
  • 10
  • 11
  • 12
  • 13
  • 14
  • 15
  • 16
  • 17
  • 18
  • 19
  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8
  • 9
  • 10
  • 11
  • 12
  • 13
  • 14
  • 15
  • 16
  • 17
  • 18
  • 19

旋转放大效果

加载监听 Listener

既然有加载成功,也有加载失败,那么当然就可以设置监听接口 RequestListener

RequestListener<String, GlideDrawable> listener = new RequestListener<String, GlideDrawable>() {
    @Override
    public boolean onException(Exception e, String model, Target<GlideDrawable> target, boolean isFirstResource) {
        return false;
    }

    @Override
    public boolean onResourceReady(GlideDrawable resource, String model, Target<GlideDrawable> target, boolean isFromMemoryCache, boolean isFirstResource) {
        return false;
    }
};
Glide.with(MainActivity.this)
        .load(Images.urls[position])
        .error(R.mipmap.ic_launcher)
        .animate(alphaAnimator)
        .listener(listener)
        .centerCrop()
        .into(holder.mImageView);


  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8
  • 9
  • 10
  • 11
  • 12
  • 13
  • 14
  • 15
  • 16
  • 17
  • 18
  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8
  • 9
  • 10
  • 11
  • 12
  • 13
  • 14
  • 15
  • 16
  • 17
  • 18

结束语

这篇主要介绍优化加载,增强用户体验。 这篇文章只是给出几片动画的例子以供参考 ,如果你想玩点花样,动手试试吧! 那么在下篇,我将介绍如果加载的不是 ImageView ,例如自定义的 View ,我们该如何处理。
