代码效果:
完整代码:
<template>
<div>
<button @click="run" class="btn">run</button>
<div class="container" ref="container" />
</div>
</template>
<script>
import * as THREE from 'three'
export default {
name: 'ThreeTest',
data() {
return {
container: null,
camera: null,
scene: null,
renderer: null,
mesh: null,
timer: null
}
},
mounted() {
this.init()
// this.run()
},
methods: {
setScene() {
this.scene = new THREE.Scene()
},
setCamera() {
// 照相机
this.camera = new THREE.PerspectiveCamera(70, this.container.clientWidth / this.container.clientHeight, 0.01, 10)
this.camera.position.z = 2
this.camera.position.y = 1
// this.camera.lookAt(new Three.Vector3(0, -0.01, 0.1))
},
setHelper() {
this.scene.add(new THREE.AxesHelper(30))
const gridHelper = new THREE.GridHelper(100, 30, 0x2C2C2C, 0x888888)
gridHelper.position.y = -1
this.scene.add(gridHelper)
},
setRender() {
// 渲染:反锯齿
this.renderer = new THREE.WebGLRenderer({ antialias: true })
this.renderer.setSize(this.container.clientWidth, this.container.clientHeight)
this.container.appendChild(this.renderer.domElement)
},
init() {
this.container = this.$refs.container
// 照相机
this.setCamera()
// 场景
this.setScene()
// 辅助线
this.setHelper()
// 渲染
this.setRender()
},
run() {
// 几何体
// const geometry = new Three.BoxGeometry(0.2, 0.2, 0.2)
const geometry = new THREE.CylinderGeometry(0, 0.1, 0.2)
// 网格法向量材质 rgb
const material = new THREE.MeshNormalMaterial()
// 网格对象
this.mesh = new THREE.Mesh(geometry, material)
this.scene.add(this.mesh)
this.timer = setInterval(() => {
if (this.mesh.scale.y < 3) {
this.mesh.scale.y += 0.1
this.mesh.position.y += 0.01
} else {
this.stop()
this.run2()
}
this.renderer.render(this.scene, this.camera)
}, 30)
},
run2() {
const mesh = new THREE.Mesh(new THREE.CylinderGeometry(0, 0.1 * 0.7, 0.2), new THREE.MeshNormalMaterial())
mesh.position.set(-0.05, 0.05, 0)// 设置网格模型几何中心三维坐标
mesh.rotateZ(Math.PI / 4)// 绕x轴旋转π/4
this.scene.add(mesh)
this.timer = setInterval(() => {
if (mesh.scale.y < 2) {
mesh.scale.y += 0.1
mesh.position.x -= 0.01
mesh.position.y += 0.01
} else {
this.stop()
this.run3()
}
this.renderer.render(this.scene, this.camera)
}, 30)
},
run3() {
const mesh = new THREE.Mesh(new THREE.CylinderGeometry(0, 0.1 * 0.5, 0.2), new THREE.MeshNormalMaterial())
mesh.position.set(0.05, 0.2, 0)
mesh.rotateZ(-Math.PI / 4)
this.scene.add(mesh)
this.timer = setInterval(() => {
if (mesh.scale.y < 1.5) {
mesh.scale.y += 0.1
mesh.position.x += 0.01
mesh.position.y += 0.01
} else {
this.stop()
}
this.renderer.render(this.scene, this.camera)
}, 30)
},
stop() {
clearInterval(this.timer)
this.timer = null
}
// animate() {
// requestAnimationFrame(this.animate)
// this.mesh.rotation.x += 0.01
// this.mesh.rotation.y += 0.02
// this.renderer.render(this.scene, this.camera)
// }
}
}
</script>
<style scoped>
.container {
height: 80vh;
}
.btn{
position: fixed;
top: 50vh;
left: 50vw;
}
</style>
ps:超级Mini版,不能说一模一样,只能说毫不相干,跟想实现的效果差了十万八千里hahahaaa…
仅有一个视频参考,不知道拿什么写的有没有自己建模,真好奇啊。
前置参考:
Vue页面引入ThreeJS
ThreeJS:模型生长
接下去做的话可能要参考下面这些,存个档
使用 Three.js 绘制三维树模型
利用JavaScript在canvas中画一棵树
Three.js 树枝随机生长模拟动画
