Odin Attributes 为Unity开发者提供了更多的自定义选项,使得开发过程更加高效和愉悦。通过使用这些特性,开发者可以创建更加专业和用户友好的编辑器界面,从而提升整个开发团队的工作效率。
Validate Input 特性: 用于任何属性,并允许验证来自 Inspector 的输入,灵活实现多种监测规则。
1. 常规写法,实参输入一个方法的名称,一个对应的消息
[ValidateInput("MustBeNull", "这个字段应该为空。")]
public MyScripty DefaultMessage;
private bool MustBeNull(MyScripty scripty)
{
return scripty == null;
}
2. 可以使用$特殊标识符引用一个字段动态显示提示信息,而且也可以明确指出需要提示信息的类型
[ReadOnly]
public string dynamicMessage = "这个物体不应该为空!";
[ValidateInput("CheckGameObject", "$dynamicMessage", InfoMessageType.None)]
public GameObject targetObj_None = null;
[ValidateInput("CheckGameObject", "$dynamicMessage", InfoMessageType.Info)]
public GameObject targetObj_Info = null;
[ValidateInput("CheckGameObject", "$dynamicMessage", InfoMessageType.Warning)]
public GameObject targetObj_Warning = null;
[ValidateInput("CheckGameObject", "$dynamicMessage", InfoMessageType.Error)]
public GameObject targetObj_Error = null;
private bool CheckGameObject(GameObject tempObj)
{
return tempObj != null;
}
当然也可以这么用
[ValidateInput("IfNullIsFalse", "$Message", InfoMessageType.Warning)]
public string Message = "Dynamic ValidateInput message";
private bool IfNullIsFalse(string value)
{
return string.IsNullOrEmpty(value);
}
3. 可以覆盖默认的提示消息和消息类型
[ValidateInput("HasMeshRendererDynamicMessage", "对应的函数中已经有消息,所以这个默认消息已经没用")]
public GameObject DynamicMessage;
private bool HasMeshRendererDynamicMessage(GameObject gameObject, ref string errorMessage)
{
if (gameObject == null) return true;
if (gameObject.GetComponentInChildren() == null)
{
errorMessage = "\"" + gameObject.name + "\" 这玩应必须有一个 MeshRenderer 组件";//如果设置消息,则默认消息会被覆盖
return false;
}
return true;
}
[ValidateInput("HasMeshRendererDynamicMessageAndType", "对应的函数中已经有消息和类型,所以这个默认消息和类型已经没用")]
public GameObject DynamicMessageAndType;
[InfoBox("Change GameObject value to update message type", InfoMessageType.Info)]
public InfoMessageType MessageType;
private bool HasMeshRendererDynamicMessageAndType(GameObject gameObject, ref string errorMessage, ref InfoMessageType? messageType)
{
if (gameObject == null) return true;
if (gameObject.GetComponentInChildren() == null)
{
errorMessage = "\"" + gameObject.name + "\" 要有一个 MeshRenderer 组件";//如果设置消息,则默认消息会被覆盖
messageType = this.MessageType;//如果设置消息类型,则默认消息类型会被覆盖
return false;
}
return true;
}
完整示例代码
using Sirenix.OdinInspector;
using UnityEngine;
public class ValidateInputAttributeExample : MonoBehaviour
{
[ValidateInput("MustBeNull", "这个字段应该为空。")]
public MyScripty DefaultMessage;
private bool MustBeNull(MyScripty scripty)
{
return scripty == null;
}
[ReadOnly]
public string dynamicMessage = "这个物体不应该为空!";
[ValidateInput("CheckGameObject", "$dynamicMessage", InfoMessageType.None)]
public GameObject targetObj_None = null;
[ValidateInput("CheckGameObject", "$dynamicMessage", InfoMessageType.Info)]
public GameObject targetObj_Info = null;
[ValidateInput("CheckGameObject", "$dynamicMessage", InfoMessageType.Warning)]
public GameObject targetObj_Warning = null;
[ValidateInput("CheckGameObject", "$dynamicMessage", InfoMessageType.Error)]
public GameObject targetObj_Error = null;
private bool CheckGameObject(GameObject tempObj)
{
return tempObj != null;
}
[ValidateInput("IfNullIsFalse", "$Message", InfoMessageType.Warning)]
public string Message = "Dynamic ValidateInput message";
private bool IfNullIsFalse(string value)
{
return string.IsNullOrEmpty(value);
}
[ValidateInput("HasMeshRendererDynamicMessage", "对应的函数中已经有消息,所以这个默认消息已经没用")]
public GameObject DynamicMessage;
private bool HasMeshRendererDynamicMessage(GameObject gameObject, ref string errorMessage)
{
if (gameObject == null) return true;
if (gameObject.GetComponentInChildren() == null)
{
errorMessage = "\"" + gameObject.name + "\" 这玩应必须有一个 MeshRenderer 组件";//如果设置消息,则默认消息会被覆盖
return false;
}
return true;
}
[ValidateInput("HasMeshRendererDynamicMessageAndType", "对应的函数中已经有消息和类型,所以这个默认消息和类型已经没用")]
public GameObject DynamicMessageAndType;
[InfoBox("Change GameObject value to update message type", InfoMessageType.Info)]
public InfoMessageType MessageType;
private bool HasMeshRendererDynamicMessageAndType(GameObject gameObject, ref string errorMessage, ref InfoMessageType? messageType)
{
if (gameObject == null) return true;
if (gameObject.GetComponentInChildren() == null)
{
errorMessage = "\"" + gameObject.name + "\" 要有一个 MeshRenderer 组件";//如果设置消息,则默认消息会被覆盖
messageType = this.MessageType;//如果设置消息类型,则默认消息类型会被覆盖
return false;
}
return true;
}
private bool HasMeshRendererDefaultMessage(GameObject gameObject)
{
if (gameObject == null) return true;
return gameObject.GetComponentInChildren() != null;
}
}
