2.1.1.4 测评

在训练完成后，我们尝试进行下一步。一方面是需要验证网络，使用验证集对训练好的神经网络进行验证。如果网络的表现不好，需要重新调整网络的参数。另外一方面是需要测试网络，最终使用测试集对训练好的神经网络进行测试，以评估网络的性能。

为做到上述两方面，我们设计了eval.py来实现这一功能，代码如下：

import tensorflow as tf

print(tf.__version__)

#import matplotlib.pyplot as plt

import numpy as np

from datetime import datetime

from graphnnSiamese import graphnn

from utils import *

import os

import argparse

import json



parser = argparse.ArgumentParser()

parser.add_argument('--device', type=str, default='0',

        help='visible gpu device')

parser.add_argument('--fea_dim', type=int, default=7,

        help='feature dimension')

parser.add_argument('--embed_dim', type=int, default=64,

        help='embedding dimension')

parser.add_argument('--embed_depth', type=int, default=2,

        help='embedding network depth')

parser.add_argument('--output_dim', type=int, default=64,

        help='output layer dimension')

parser.add_argument('--iter_level', type=int, default=5,

        help='iteration times')

parser.add_argument('--lr', type=float, default=1e-4,

        help='learning rate')

parser.add_argument('--epoch', type=int, default=100,

        help='epoch number')

parser.add_argument('--batch_size', type=int, default=5,

        help='batch size')

parser.add_argument('--load_path', type=str,

        default='./saved_model/graphnn-model_best',

        help='path for model loading, "#LATEST#" for the latest checkpoint')

parser.add_argument('--log_path', type=str, default=None,

        help='path for training log')









if __name__ == '__main__':

    args = parser.parse_args()

    args.dtype = tf.float32

    print("=================================")

    print(args)

    print("=================================")



    os.environ["CUDA_VISIBLE_DEVICES"]=args.device

    Dtype = args.dtype

    NODE_FEATURE_DIM = args.fea_dim

    EMBED_DIM = args.embed_dim

    EMBED_DEPTH = args.embed_depth

    OUTPUT_DIM = args.output_dim

    ITERATION_LEVEL = args.iter_level

    LEARNING_RATE = args.lr

    MAX_EPOCH = args.epoch

    BATCH_SIZE = args.batch_size

    LOAD_PATH = args.load_path

    LOG_PATH = args.log_path



    SHOW_FREQ = 1

    TEST_FREQ = 1

    SAVE_FREQ = 5

    DATA_FILE_NAME = './data/acfgSSL_{}/'.format(NODE_FEATURE_DIM)

    SOFTWARE=('openssl-1.0.1f-', 'openssl-1.0.1u-')

    OPTIMIZATION=('-O0', '-O1','-O2','-O3')

    COMPILER=('armeb-linux', 'i586-linux', 'mips-linux')

    VERSION=('v54',)



    FUNC_NAME_DICT = {}



    # Process the input graphs

    F_NAME = get_f_name(DATA_FILE_NAME, SOFTWARE, COMPILER,

            OPTIMIZATION, VERSION)

    FUNC_NAME_DICT = get_f_dict(F_NAME)





    Gs, classes = read_graph(F_NAME, FUNC_NAME_DICT, NODE_FEATURE_DIM)

    print("{} graphs, {} functions".format(len(Gs), len(classes)))





    if os.path.isfile('data/class_perm.npy'):

        perm = np.load('data/class_perm.npy')

    else:

        perm = np.random.permutation(len(classes))

        np.save('data/class_perm.npy', perm)

    if len(perm) < len(classes):

        perm = np.random.permutation(len(classes))

        np.save('data/class_perm.npy', perm)



    Gs_train, classes_train, Gs_dev, classes_dev, Gs_test, classes_test =\

            partition_data(Gs,classes,[0.8,0.1,0.1],perm)



    print("Train: {} graphs, {} functions".format(

            len(Gs_train), len(classes_train)))

    print("Dev: {} graphs, {} functions".format(

            len(Gs_dev), len(classes_dev)))

    print("Test: {} graphs, {} functions".format(

            len(Gs_test), len(classes_test)))



    # Fix the pairs for validation and testing

    if os.path.isfile('data/valid.json'):

        with open('data/valid.json') as inf:

            valid_ids = json.load(inf)

        valid_epoch = generate_epoch_pair(

                Gs_dev, classes_dev, BATCH_SIZE, load_id=valid_ids)

    else:

        valid_epoch, valid_ids = generate_epoch_pair(

                Gs_dev, classes_dev, BATCH_SIZE, output_id=True)

        with open('data/valid.json', 'w') as outf:

            json.dump(valid_ids, outf)



    if os.path.isfile('data/test.json'):

        with open('data/test.json') as inf:

            test_ids = json.load(inf)

        test_epoch = generate_epoch_pair(

                Gs_test, classes_test, BATCH_SIZE, load_id=test_ids)

    else:

        test_epoch, test_ids = generate_epoch_pair(

                Gs_test, classes_test, BATCH_SIZE, output_id=True)

        with open('data/test.json', 'w') as outf:

            json.dump(test_ids, outf)



    # Model

    gnn = graphnn(

            N_x = NODE_FEATURE_DIM,

            Dtype = Dtype,

            N_embed = EMBED_DIM,

            depth_embed = EMBED_DEPTH,

            N_o = OUTPUT_DIM,

            ITER_LEVEL = ITERATION_LEVEL,

            lr = LEARNING_RATE

        )

    gnn.init(LOAD_PATH, LOG_PATH)



    # Test

    val_auc, fpr, tpr, thres = get_auc_epoch(

            gnn, Gs_dev, classes_dev, BATCH_SIZE, load_data=valid_epoch)

    gnn.say( "AUC on validation set: {}".format(val_auc) )

    test_auc, fpr, tpr, thres = get_auc_epoch(

            gnn, Gs_test, classes_test, BATCH_SIZE, load_data=test_epoch)

    gnn.say( "AUC on testing set: {}".format(test_auc) )
