带边框的ImageView

       应该说这是canvas绘图最基本的应用了，当时看到网上实现带边框的Imgeview大多是通过设置XML来设置ImageView的Padding实现边框效果，老实说边框的效果会受到很大的限制，分享下我的一个小例子吧，代码很短，100行不到，实现原理，首先在ImageView里面绘制背景图片

然后在绘制主图片

package com.example.borderimageviewdemo;

import java.text.AttributedCharacterIterator.Attribute;

import android.content.Context;
import android.graphics.Bitmap;
import android.graphics.Canvas;
import android.graphics.Paint;
import android.graphics.PorterDuff.Mode;
import android.graphics.PorterDuffXfermode;
import android.graphics.Rect;
import android.graphics.RectF;
import android.graphics.Xfermode;
import android.graphics.drawable.Drawable;
import android.util.AttributeSet;
import android.widget.ImageView;

public class BorderImageView extends ImageView{
    private Rect m_outRect;
    private Rect m_innerRect;
//    private RectF m_outRectF;
    private Drawable m_outDrawable;
    private Drawable m_innerDrawable;
//    private PorterDuffXfermode m_XferMode;
//    private Paint mPaint;
	public BorderImageView(Context context) {
		super(context);
		// TODO Auto-generated constructor stubneex
//		m_XferMode = new Por/erDuffXfermode(Mode.SRC_IN);)
	}
	public BorderImageView(Context context,AttributeSet attribute)
	{
		super(context, attribute);
    	m_outRect = new Rect(0,0,getWidth(),getHeight());
    	m_innerRect = new Rect(10,10,getWidth()-10,getHeight()-10);
	}
    public void onDraw(Canvas canvas)
    {

//   	m_outRectF = new RectF(0,0,getWidth(),getHeight());;
 //   	mPaint = new Paint();
//    	mPaint.setXfermode(m_XferMode);
    	DrawBorder(canvas);
//    	canvas.saveLayer(m_outRectF, mPaint,Canvas.ALL_SAVE_FLAG);
//    	canvas.restore();
    	DrawInner(canvas);
    }
    public void DrawBorder(Canvas canvas)
    {
    	if(m_outDrawable == null)
    		return;
    	m_outDrawable.setBounds(m_outRect);
        m_outDrawable.draw(canvas);
    }
    private void DrawInner(Canvas canvas)
    {
    	if(m_innerDrawable ==null)
    		return;
    	m_innerDrawable.setBounds(m_innerRect);
    	m_innerDrawable.draw(canvas);
    }
    public void SetBorderImageById(int resId)
    {
    	m_outDrawable= getResources().getDrawable(resId);
    }
    public void SetImageDrawable(int d)
    {
    	m_innerDrawable = getResources().getDrawable(d);
    }
}

要实现背景图片有边框的效果只需要设置背景图片绘制的Rect大于主图片绘制Rect即可，我这里设置的是背景图片边距大于主图片5个px,自定义ImageVIEW控件的代码如下，工程的DEMO稍后上传。0分下载，自己跑一跑，看看效果吧

DEMO地址
