echarts官网有很多的炫酷的3D模型
来尝试实现下，使用原本的柱状图或者折线图代码创建echarts示例,使用cdn的方式引入echarts
<!DOCTYPE html>
<html lang="en">
<head>
<meta charset="UTF-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<script src="https://cdn.jsdelivr.net/npm/echarts@5.3.0/dist/echarts.min.js"></script>
<title>ECharts Pie Chart with Click Event</title>
</head>
<body>
<div id="pieChart" style="width: 600px; height: 400px"></div>
<script>
const data = [
{ value: 335, name: "Category 1" },
{ value: 310, name: "Category 2" },
{ value: 234, name: "Category 3" },
{ value: 135, name: "Category 4" },
{ value: 1548, name: "Category 5" },
];
// 初始化 ECharts 实例
const myChart = echarts.init(document.getElementById("pieChart"));
// 配置饼图
const option = {
series: [
{
name: "Pie Chart",
type: "pie",
radius: "55%",
center: ["50%", "60%"],
data: data,
emphasis: {
itemStyle: {
shadowBlur: 10,
shadowOffsetX: 0,
shadowColor: "rgba(0, 0, 0, 0.5)",
},
},
},
],
};
// 将配置设置到 ECharts 实例中
myChart.setOption(option);
</script>
</body>
</html>
就会得到一个饼图
使用这个案例：Examples - Apache ECharts
在官网案例添加代码查看模型的数据
还需要引入echarts-gl的cdn, 应用中安装echarts-gl，只引入就好，不需要做额外的操作，会自动扩展echarts的功能
<!DOCTYPE html>
<html lang="en">
<head>
<meta charset="UTF-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<script src="https://cdn.jsdelivr.net/npm/echarts@5.4.2/dist/echarts.min.js"></script>
<script src="https://cdn.jsdelivr.net/npm/echarts-gl@2.0.9/dist/echarts-gl.min.js"></script>
<title>ECharts Pie Chart with Click Event</title>
</head>
<body>
<div
id="pieChart"
style="width: 600px; height: 600px; border: 5px solid red"
></div>
<script>
const list = 这里放从官网复制过来的数组
// 初始化 ECharts 实例
const myChart = echarts.init(document.getElementById("pieChart"));
// 将配置设置到 ECharts 实例中
let option = {
grid3D: {},
tooltip: {},
xAxis3D: {
type: "category",
},
yAxis3D: {
type: "category",
},
zAxis3D: {},
visualMap: {
max: 1e8,
dimension: "Population",
},
dataset: {
dimensions: [
"Income",
"Life Expectancy",
"Population",
"Country",
{ name: "Year", type: "ordinal" },
],
source: list,
},
series: [
{
type: "bar3D",
// symbolSize: symbolSize,
shading: "lambert",
encode: {
x: "Year",
y: "Country",
z: "Life Expectancy",
tooltip: [0, 1, 2, 3, 4],
},
},
],
};
// 将配置设置到 ECharts 实例中
myChart.setOption(option);
</script>
</body>
</html>
看下是很大的
看下效果
今天在看react-hooks的时候发现了这个：
发现他是一整块的echarts
代码示例：
<!DOCTYPE html>
<html lang="en">
<head>
<meta charset="UTF-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<script src="https://cdn.jsdelivr.net/npm/echarts@5.5.0/dist/echarts.min.js"></script>
<title>ECharts Pie Chart with Click Event</title>
</head>
<body>
<div id="pieChart" style="width: 600px; height: 400px; border: 1px solid red; background-color: black"></div>
<script>
const ranking1 =
const ranking2 =
const ranking3 =
const ranking4 =
const colors = ["#1089E7", "#F57474", "#56D0E3", "#F8B448", "#8B78F6"];
const data = [
{
value: 79999,
name: "峨眉山",
percentage: "80%",
maxValue: 100000
},
{
value: 59999,
name: "稻城亚丁",
percentage: "60%",
maxValue: 100000
},
{
value: 49999,
name: "九寨沟",
percentage: "50%",
maxValue: 100000
},
{
value: 39999,
name: "万里长城",
percentage: "40%",
maxValue: 100000
},
{
value: 29999,
name: "北京故宫",
percentage: "30%",
maxValue: 100000
}
];
// 初始化 ECharts 实例
const myChart = echarts.init(document.getElementById("pieChart"));
// 配置饼图
const option = {
grid: {
top: "5%",
left: "7%",
right: "4%",
bottom: "1%",
containLabel: true
},
xAxis: {
type: "value",
axisLine: {
show: false,
lineStyle: {
color: "white"
}
},
nameGap: 1,
splitLine: {
show: false
},
axisTick: {
show: false
},
axisLabel: {
show: false,
fontSize: 16
},
// boundaryGap: ["3%", "2%"],
// splitNumber: 4,
triggerEvent: false
},
yAxis: [
{
show: true,
data: data.map(val => val.name),
inverse: true,
axisLine: {
show: false
},
splitLine: {
show: false
},
axisTick: {
show: false
},
axisLabel: {
color: "#fff",
formatter: function (value) {
let str = value.length > 6 ? value.slice(0, 6) + "..." : value;
let index = data.map(item => item.name).indexOf(value) + 1;
return ["{" + (index > 3 ? "lg" : "lg" + index) + "|NO." + index + "}", "{title|" + str + "}"].join(" ");
},
rich: {
lg1: {
width: 60,
backgroundColor: {
image: ranking1
},
color: "#fff",
align: "center",
height: 20,
fontSize: 13
},
lg2: {
width: 60,
backgroundColor: {
image: ranking2
},
color: "#fff",
align: "center",
height: 20,
fontSize: 13
},
lg3: {
width: 60,
backgroundColor: {
image: ranking3
},
color: "#fff",
align: "center",
height: 20,
fontSize: 13
},
lg: {
width: 60,
backgroundColor: {
image: ranking4
},
color: "#fff",
align: "center",
height: 20,
fontSize: 13
},
title: {
width: 60,
fontSize: 13,
align: "center",
padding: [0, 10, 0, 15]
}
}
},
triggerEvent: false
},
{
show: true,
inverse: true,
data: data,
axisLabel: {
fontSize: 14,
color: "#fff",
// align: "right",
margin: 20,
formatter: value => {
return value >= 10000 ? (value / 10000).toFixed(2) + "w" : value;
}
},
axisLine: {
show: false
},
splitLine: {
show: false
},
axisTick: {
show: false
},
triggerEvent: false
}
],
series: [
{
name: "条",
type: "bar",
yAxisIndex: 0,
data: data,
barWidth: 12,
itemStyle: {
borderRadius: 30,
color: function (params) {
let num = colors.length;
return colors[params.dataIndex % num];
}
},
label: {
show: true,
position: [12, 0],
lineHeight: 14,
color: "#fff",
formatter: params => {
return params.data.percentage;
}
}
},
{
name: "框",
type: "bar",
yAxisIndex: 1,
data: data.map(val => {
if (!val.maxValue) {
return 5;
}
return val.maxValue;
}),
barWidth: 18,
itemStyle: {
color: "none",
borderColor: "#00c1de",
borderWidth: 1,
borderRadius: 15
},
silent: true
}
]
};
// 将配置设置到 ECharts 实例中
myChart.setOption(option);
</script>
</body>
</html>
