前言

1、背景介绍

今天给大家带来的是python + ttkbootstrap、pywin32实现的Excel文件批量转PDF文件，在日常办公可以带来很大的便利，可以节约不少时间。

2、库的安装

库	用途	安装
ttkbootstrap	创建现代GUI	pip insatll ttkbootstrap
pywin32	调用windows API	pipi install pywin32

3、完整代码

import os
import win32com.client
import tkinter as tk
from tkinter import ttk
from ttkbootstrap import Style
from tkinter import filedialog, messagebox
from threading import Thread


class ExcelToPDFConverter:
    def __init__(self, master):
        self.master = master
        self.master.title("Excel转PDF工具 - 专业版")
        self.master.geometry("600x400")

        # 应用ttkbootstrap主题
        self.style = Style(theme='morph')
        self.style.configure('TButton', font=('微软雅黑', 10))

        # 界面组件
        self.create_widgets()
        self.running = False

    def create_widgets(self):
        """创建界面组件"""
        # 文件选择区域
        frame_files = ttk.Frame(self.master)
        frame_files.pack(pady=10, padx=20, fill='x')

        self.btn_select = ttk.Button(
            frame_files,
            text="选择Excel文件",
            command=self.select_files,
            style='primary'
        )
        self.btn_select.pack(side='left', padx=5)

        self.lbl_files = ttk.Label(frame_files, text="未选择文件")
        self.lbl_files.pack(side='left', fill='x', expand=True)

        # 输出目录区域
        frame_output = ttk.Frame(self.master)
        frame_output.pack(pady=10, padx=20, fill='x')

        self.btn_output = ttk.Button(
            frame_output,
            text="选择保存位置",
            command=self.select_output,
            style='info'
        )
        self.btn_output.pack(side='left', padx=5)

        self.lbl_output = ttk.Label(frame_output, text="未选择目录")
        self.lbl_output.pack(side='left', fill='x', expand=True)

        # 进度条
        self.progress = ttk.Progressbar(
            self.master,
            orient='horizontal',
            mode='determinate'
        )
        self.progress.pack(pady=15, padx=20, fill='x')

        # 日志区域
        self.log_text = tk.Text(
            self.master,
            height=8,
            state='disabled',
            font=('Consolas', 9)
        )
        self.log_text.pack(pady=10, padx=20, fill='both', expand=True)

        # 操作按钮
        frame_btn = ttk.Frame(self.master)
        frame_btn.pack(pady=10)

        self.btn_start = ttk.Button(
            frame_btn,
            text="开始转换",
            command=self.start_conversion,
            style='success'
        )
        self.btn_start.pack(side='left', padx=10)

        self.btn_clear = ttk.Button(
            frame_btn,
            text="清空日志",
            command=self.clear_log,
            style='warning'
        )
        self.btn_clear.pack(side='left', padx=10)

    def select_files(self):
        """选择Excel文件"""
        files = filedialog.askopenfilenames(
            filetypes=[("Excel文件", "*.xls *.xlsx")]
        )
        if files:
            self.file_paths = files
            self.lbl_files.config(text=f"已选择 {len(files)} 个文件")

    def select_output(self):
        """选择输出目录"""
        folder = filedialog.askdirectory()
        if folder:
            self.output_folder = folder
            self.lbl_output.config(text=folder)

    def log_message(self, msg):
        """记录日志"""
        self.log_text.config(state='normal')
        self.log_text.insert('end', msg + '\n')
        self.log_text.see('end')
        self.log_text.config(state='disabled')

    def clear_log(self):
        """清空日志"""
        self.log_text.config(state='normal')
        self.log_text.delete(1.0, 'end')
        self.log_text.config(state='disabled')

    def start_conversion(self):
        """启动转换线程"""
        if not hasattr(self, 'file_paths'):
            messagebox.showwarning("警告", "请先选择Excel文件")
            return
        if not hasattr(self, 'output_folder'):
            messagebox.showwarning("警告", "请选择输出目录")
            return

        if not self.running:
            self.running = True
            Thread(target=self.convert_files).start()

    def convert_files(self):
        """执行转换"""
        total = len(self.file_paths)
        excel = win32com.client.Dispatch("Excel.Application")
        excel.Visible = False
        excel.DisplayAlerts = False

        try:
            for i, file_path in enumerate(self.file_paths, 1):
                if not self.running:
                    break

                self.progress['value'] = (i / total) * 100
                self.master.title(f"转换中... {i}/{total}")

                try:
                    # 转换逻辑
                    workbook = excel.Workbooks.Open(file_path)
                    file_name = os.path.splitext(os.path.basename(file_path))[0]
                    output_path = os.path.join(self.output_folder, f"{file_name}.pdf")
                    workbook.ExportAsFixedFormat(0, output_path)
                    self.log_message(f"✓ 成功: {file_name}")
                except Exception as e:
                    self.log_message(f"✗ 失败: {os.path.basename(file_path)} - {str(e)}")
                finally:
                    if 'workbook' in locals():
                        workbook.Close(False)

            messagebox.showinfo("完成", "所有文件转换完成！")
        finally:
            excel.Quit()
            self.running = False
            self.master.title("Excel转PDF工具 - 专业版")
            self.progress['value'] = 0


if __name__ == "__main__":
    # 安装依赖：pip install ttkbootstrap pywin32
    root = tk.Tk()
    app = ExcelToPDFConverter(root)
    root.mainloop()
