取像测试1

$$取像测试1$$

#include <stdio.h>
#include <process.h>
#include <conio.h>
#include "windows.h"
#include "MvCameraControl.h"
#include <opencv2/opencv.hpp>
#include <iostream>
using namespace cv;


HWND g_hwnd = NULL;
bool g_bExit = false;
unsigned int g_nPayloadSize = 0;
void* handle = NULL;

void WaitForKeyPress(void)
{
	while (!_kbhit())
	{
		Sleep(10);
	}
	_getch();
}


/***

打印设备信息

***/
bool PrintDeviceInfo(MV_CC_DEVICE_INFO* pstMVDevInfo)
{
	if (NULL == pstMVDevInfo)
	{
		printf("The Pointer of pstMVDevInfo is NULL!\n");
		return false;
	}
	if (pstMVDevInfo->nTLayerType == MV_GIGE_DEVICE)
	{
		int nIp1 = ((pstMVDevInfo->SpecialInfo.stGigEInfo.nCurrentIp & 0xff000000) >> 24);
		int nIp2 = ((pstMVDevInfo->SpecialInfo.stGigEInfo.nCurrentIp & 0x00ff0000) >> 16);
		int nIp3 = ((pstMVDevInfo->SpecialInfo.stGigEInfo.nCurrentIp & 0x0000ff00) >> 8);
		int nIp4 = (pstMVDevInfo->SpecialInfo.stGigEInfo.nCurrentIp & 0x000000ff);

		printf("CurrentIp: %d.%d.%d.%d\n", nIp1, nIp2, nIp3, nIp4);
		printf("UserDefinedName: %s\n\n", pstMVDevInfo->SpecialInfo.stGigEInfo.chUserDefinedName);
	}
	else if (pstMVDevInfo->nTLayerType == MV_USB_DEVICE)
	{
		printf("UserDefinedName: %s\n", pstMVDevInfo->SpecialInfo.stUsb3VInfo.chUserDefinedName);
		printf("Serial Number: %s\n", pstMVDevInfo->SpecialInfo.stUsb3VInfo.chSerialNumber);
		printf("Device Number: %d\n\n", pstMVDevInfo->SpecialInfo.stUsb3VInfo.nDeviceNumber);
	}
	else
	{
		printf("Not support.\n");
	}

	return true;
}



LRESULT CALLBACK WndProc(HWND hWnd, UINT msg, WPARAM wParam, LPARAM lParam)
{
	switch (msg)
	{
	case WM_DESTROY:
		PostQuitMessage(0);
		g_hwnd = NULL;
		break;
	}

	return DefWindowProc(hWnd, msg, wParam, lParam);
}

static  unsigned int __stdcall CreateRenderWindow(void* pUser)
{
	HINSTANCE hInstance = ::GetModuleHandle(NULL);
	WNDCLASSEX wc;
	wc.cbSize = sizeof(wc);
	wc.style = CS_HREDRAW | CS_VREDRAW;
	wc.cbClsExtra = 0;
	wc.cbWndExtra = 0;
	wc.hInstance = hInstance;
	wc.hIcon = ::LoadIcon(NULL, IDI_APPLICATION);
	wc.hIconSm = ::LoadIcon(NULL, IDI_APPLICATION);
	wc.hbrBackground = (HBRUSH)(COLOR_WINDOW + 1);
	wc.hCursor = ::LoadCursor(NULL, IDC_ARROW);
	wc.lpfnWndProc = WndProc;
	wc.lpszMenuName = NULL;
	wc.lpszClassName = "RenderWindow";

	if (!RegisterClassEx(&wc))
	{
		return 0;
	}

	DWORD style = WS_OVERLAPPEDWINDOW;
	DWORD styleEx = WS_EX_APPWINDOW | WS_EX_WINDOWEDGE;
	RECT rect = { 0, 0, 640, 480 };

	AdjustWindowRectEx(&rect, style, false, styleEx);

	HWND hWnd = CreateWindowEx(styleEx, "RenderWindow", "Display", style, 0, 0,
		rect.right - rect.left, rect.bottom - rect.top, NULL, NULL, hInstance, NULL);
	if (hWnd == NULL)
	{
		return 0;
	}

	::UpdateWindow(hWnd);
	::ShowWindow(hWnd, SW_SHOW);

	g_hwnd = hWnd;

	MSG msg = { 0 };
	while (msg.message != WM_QUIT)
	{
		if (PeekMessage(&msg, 0, 0, 0, PM_REMOVE))
		{
			TranslateMessage(&msg);
			DispatchMessage(&msg);
		}
	}

	return 0;
}

static  unsigned int __stdcall WorkThread(void* pUser)
{
	int nRet = MV_OK;

	MV_FRAME_OUT_INFO_EX stImageInfo = { 0 };
	MV_DISPLAY_FRAME_INFO stDisplayInfo = { 0 };
	unsigned char* pData = (unsigned char*)malloc(sizeof(unsigned char) * (g_nPayloadSize));
	if (pData == NULL)
	{
		return 0;
	}
	unsigned int nDataSize = g_nPayloadSize;

	while (1)
	{
		nRet = MV_CC_GetOneFrameTimeout(pUser, pData, nDataSize, &stImageInfo, 1000);

		if (nRet == MV_OK)
		{
			printf("Get One Frame: Width[%d], Height[%d], nFrameNum[%d]\n",
				stImageInfo.nWidth, stImageInfo.nHeight, stImageInfo.nFrameNum);

			if (g_hwnd)
			{
				stDisplayInfo.hWnd = g_hwnd;
				stDisplayInfo.pData = pData;
				stDisplayInfo.nDataLen = stImageInfo.nFrameLen;
				stDisplayInfo.nWidth = stImageInfo.nWidth;
				stDisplayInfo.nHeight = stImageInfo.nHeight;
				stDisplayInfo.enPixelType = stImageInfo.enPixelType;

				MV_CC_DisplayOneFrame(pUser, &stDisplayInfo);
			}
		}
		else
		{
			printf("No data[0x%x]\n", nRet);
		}
		if (g_bExit)
		{
			break;
		}
	}

	free(pData);

	return 0;
}

int RGB2BGR(unsigned char* pRgbData, unsigned int nWidth, unsigned int nHeight)
{
	if (NULL == pRgbData)
	{
		return MV_E_PARAMETER;
	}

	for (unsigned int j = 0; j < nHeight; j++)
	{
		for (unsigned int i = 0; i < nWidth; i++)
		{
			unsigned char red = pRgbData[j * (nWidth * 3) + i * 3];
			pRgbData[j * (nWidth * 3) + i * 3] = pRgbData[j * (nWidth * 3) + i * 3 + 2];
			pRgbData[j * (nWidth * 3) + i * 3 + 2] = red;
		}
	}

	return MV_OK;
}


bool Convert2Mat(MV_FRAME_OUT_INFO_EX* pstImageInfo, unsigned char* pData, cv::Mat& srcImage)
{
	//if (pstImageInfo->enPixelType == PixelType_Gvsp_Mono8)
	//{
	//	srcImage = cv::Mat(pstImageInfo->nHeight, pstImageInfo->nWidth, CV_8UC1, pData);
	//}
	//else if (pstImageInfo->enPixelType == PixelType_Gvsp_RGB8_Packed)
	//{


		// RGB2BGR(pData, pstImageInfo->nWidth, pstImageInfo->nHeight);
		srcImage = cv::Mat(200, 200, CV_8UC3, pData);


	//}
	//else
	//{
	//	printf("unsupported pixel format\n");
	//	return false;
	//}

	//if (NULL == srcImage.data)
	//{
	//	return false;
	//}

	return true;
}


int test_grab_a_frame()
{
	unsigned char* pData = (unsigned char*)malloc(sizeof(unsigned char) * (g_nPayloadSize));
	if (pData == nullptr)
	{
		return -1;
	}
	unsigned int nDataSize = g_nPayloadSize;
	MV_FRAME_OUT_INFO_EX stImageInfo = { 0 };

	int nRet = MV_OK;
	nRet = MV_CC_GetOneFrameTimeout(handle, pData, nDataSize, &stImageInfo, 1000);
	if (nRet == MV_OK)
	{
		printf("Get One Frame: Width[%d], Height[%d], nFrameNum[%d]\n",
			stImageInfo.nWidth, stImageInfo.nHeight, stImageInfo.nFrameNum);

		Mat srcImage;
		srcImage = Mat(1000, 1000, CV_8UC3, pData);
		//bool convertSuccess = Convert2Mat(&stImageInfo, pData, srcImage);
		//assert(convertSuccess);

		//Size ResImgSiz = Size(200,200);
		//Mat ResImg = Mat(ResImgSiz, srcImage.type());
		//Mat Img = srcImage;

		//resize(srcImage, ResImg, ResImgSiz, CV_INTER_CUBIC);
		imwrite("srcImage000000.bmp", srcImage);
	}

}


int initDevice()
{
	int nRet = MV_OK;

	do
	{
		// 1.1、枚举设备
		MV_CC_DEVICE_INFO_LIST stDeviceList = { 0 };
		nRet = MV_CC_EnumDevices(MV_GIGE_DEVICE | MV_USB_DEVICE, &stDeviceList);

		if (MV_OK != nRet)
		{
			printf("Enum Devices fail! nRet [0x%x]\n", nRet);
			break;
		}

		// 1.2、打印设备信息
		if (stDeviceList.nDeviceNum > 0)
		{
			for (unsigned int i = 0; i < stDeviceList.nDeviceNum; i++)
			{
				printf("Device %d Info:\n", i);
				MV_CC_DEVICE_INFO* pDeviceInfo = stDeviceList.pDeviceInfo[i];
				if (NULL == pDeviceInfo)
				{
					break;
				}
				PrintDeviceInfo(pDeviceInfo);
			}
		}
		else
		{
			printf("Find No Devices!\n");
			return -1;
		}


		unsigned int nIndex = 0;

		// 2、创建句柄
		nRet = MV_CC_CreateHandle(&handle, stDeviceList.pDeviceInfo[nIndex]);
		if (MV_OK != nRet)
		{
			printf("Create Handle fail! nRet [0x%x]\n", nRet);
			break;
		}

		// 3、打开设备
		nRet = MV_CC_OpenDevice(handle);
		if (MV_OK != nRet)
		{
			printf("Open Device fail! nRet [0x%x]\n", nRet);
			break;
		}

		if (stDeviceList.pDeviceInfo[nIndex]->nTLayerType == MV_GIGE_DEVICE)
		{
			int nPacketSize = MV_CC_GetOptimalPacketSize(handle);    // 获取最佳的packet size，该接口目前只支持GigE相机
			if (nPacketSize > 0)
			{
				nRet = MV_CC_SetIntValue(handle, "GevSCPSPacketSize", nPacketSize);  // 设置Integer型属性值
				if (nRet != MV_OK)
				{
					printf("Warning: Set Packet Size fail nRet [0x%x]!", nRet);
				}
			}
			else
			{
				printf("Warning: Get Packet Size fail nRet [0x%x]!", nPacketSize);
			}
		}

		// 相机触发打开或关闭
		nRet = MV_CC_SetEnumValue(handle, "TriggerMode", 0);  // MV_TRIGGER_MODE_ON     MV_TRIGGER_MODE_OFF
		if (MV_OK != nRet)
		{
			printf("Set Trigger Mode fail! nRet [0x%x]\n", nRet);
			break;
		}

		// 获取Int属性值
		MVCC_INTVALUE stParam = { 0 };
		nRet = MV_CC_GetIntValue(handle, "PayloadSize", &stParam);
		if (MV_OK != nRet)
		{
			printf("Get PayloadSize fail! nRet [0x%x]\n", nRet);
			break;
		}
		g_nPayloadSize = stParam.nCurValue;


		nRet = MV_CC_StartGrabbing(handle);
		if (MV_OK != nRet)
		{
			printf("Start Grabbing fail! nRet [0x%x]\n", nRet);
			break;
		}

	} while (0);


	if (nRet != MV_OK)
	{
		if (handle != NULL)
		{
			MV_CC_DestroyHandle(handle);
			handle = NULL;
		}

		return -1;
	}
	printf("加载设备成功！");
	return 0;

}

int main()
{
	initDevice();
	test_grab_a_frame();
}

关闭相机

// 成功关闭相机返回0，关闭失败返回-1
int closeDevice()
{
    int nRet = MV_OK;

    do
    {
        nRet = MV_CC_StopGrabbing(g_handle);
        if (MV_OK != nRet)
        {
            printf("Stop Grabbing fail! nRet [0x%x]\n", nRet);
            break;
        }

        nRet = MV_CC_CloseDevice(g_handle);
        if (MV_OK != nRet)
        {
            printf("Close Device fail! nRet [0x%x]\n", nRet);
            break;
        }

        nRet = MV_CC_DestroyHandle(g_handle);
        if (MV_OK != nRet)
        {
            printf("Destroy Handle fail! nRet [0x%x]\n", nRet);
            break;
        }

    } while (0);


    if (nRet != MV_OK)
    {
        if (g_handle != NULL)
        {
            MV_CC_DestroyHandle(g_handle);
            g_handle = NULL;
        }

        return -1;
    }

    return 0;
}
