一、介绍
- 简要介绍
KubeHealthy 是一个用于 Kubernetes 集群的开源工具，用于监控和评估集群中的应用程序和组件的健康状态。它旨在帮助 Kubernetes 用户确保其应用程序在集群中正常运行，并提供有关应用程序和集群健康状态的可视化和报告。
- 应用场景
（1）Kubernetes 应用健康监控： KubeHealthy 可用于监控运行在 Kubernetes 集群中的应用程序和微服务的健康状态。它可以定期运行各种健康检查，以确保应用程序的各个组件正常工作，如容器、服务、数据库连接等。
（2）故障检测和通知： KubeHealthy 具备故障检测功能，能够检测应用程序或集群组件的异常状态。当发现问题时，它可以触发警报和通知，以通知管理员或运维团队，帮助他们快速响应和解决问题。
（3）性能优化和容量规划： 通过持续监控应用程序的健康状态，KubeHealthy 可以帮助您了解应用程序的性能瓶颈，并支持容量规划决策。它可以帮助您确定何时需要增加资源，以确保应用程序能够满足预期的性能需求。
二、架构原理
工作原理
以下说明了 Kuberhealthy 如何配置和操作检查器 Pod。流程如下图所示：
- An admin creates a
KuberhealthyCheck resource that calls for a synthetic Kubernetes daemonset to be deployed and tested every 15 minutes. This will ensure that all nodes in the Kubernetes cluster can provision containers properly. 管理员创建一个 KuberhealthyCheck 资源，该资源要求每 15 分钟部署和测试一个合成 Kubernetes 守护进程集。这将确保 Kubernetes 集群中的所有节点都可以正确配置容器。 - Kuberhealthy observes this new
KuberhealthyCheck resource. Kuberhealthy 观察这个新的 KuberhealthyCheck 资源。 - Kuberhealthy schedules a checker pod to manage the lifecycle of this check. Kuberhealthy 安排一个检查器 pod 来管理此检查的生命周期。
- The checker pod creates a daemonset using the Kubernetes API. 检查器 Pod 使用 Kubernetes API 创建一个守护进程集。
- The checker pod observes the daemonset and waits for all daemonset pods to become
Readychecker pod 观察 daemonset 并等待所有 daemonset pod 变为 Ready - The checker pod deletes the daemonset using the Kubernetes API. 检查器 pod 使用 Kubernetes API 删除守护进程集。
- The checker pod observes the daemonset being fully cleaned up and removed. 检查器 pod 观察到守护进程集已被完全清理和删除。
- The checker pod reports a successful test result back to Kuberhealthy's API. 检查器 Pod 向 Kuberhealthy 的 API 报告成功的测试结果。
- Kuberhealthy stores this check's state and makes it available to various metrics systems. Kuberhealthy 存储此检查的状态并使其可用于各种指标系统。
三、使用指南
使用软硬环境
硬件要求
无特殊要求，KubeHealthy 主要运行在 Kubernetes 集群中，只要可以正常运行k8s集群即可。
实验硬件
| 类型 | 实验使用 |
| 服务器 |
【注：有其他特殊要求的请在列表下面添加行，如内存: 不小于16G】
软件要求
依赖软件列表
| 类型 | 要求版本 |
| Kubernetes 或 Helm | Kubernetes1.16 或更高版本 或 Helm3或更高版本 |
实验软件版本
| 类型 | 实验版本 |
| Kubernetes | v1.21.6 |
| 操作系统 | ubuntu20.04 |
安装部署
（1）使用YAML文件安装
注：yaml文件位于https://github.com/Comcast/kuberhealthy/blob/master/deploy 下
# If you don't use Prometheus:
# 没有使用Prometheus
# 1 在Kubernetes集群/上下文中创建命名空间“kuberhealthy”
kubectl create namespace kuberhealthy
# 2 部署kuberhealthy
kubectl apply -f https://raw.githubusercontent.com/kuberhealthy/kuberhealthy/master/deploy/kuberhealthy.yaml
# If you use Prometheus, but not with Prometheus Operator:
# 使用Prometheus，但没使用Prometheus Operator
# 1 在Kubernetes集群/上下文中创建命名空间“kuberhealthy”
kubectl create namespace kuberhealthy
# 2 部署kuberhealthy
kubectl apply -f https://raw.githubusercontent.com/kuberhealthy/kuberhealthy/master/deploy/kuberhealthy-prometheus.yaml
# If you use Prometheus Operator:
# 使用Prometheus Operator
# 1 在Kubernetes集群/上下文中创建命名空间“kuberhealthy”
kubectl create namespace kuberhealthy
# 2 部署kuberhealthy
kubectl apply -f https://raw.githubusercontent.com/kuberhealthy/kuberhealthy/master/deploy/kuberhealthy-prometheus-operator.yaml3个YAML文件如下：
（1）没有使用Prometheus
---
apiVersion: apiextensions.k8s.io/v1
kind: CustomResourceDefinition
metadata:
annotations:
controller-gen.kubebuilder.io/version: v0.6.2
creationTimestamp: null
name: khchecks.comcast.github.io
spec:
group: comcast.github.io
names:
kind: KuberhealthyCheck
listKind: KuberhealthyCheckList
plural: khchecks
shortNames:
- khc
singular: khcheck
scope: Namespaced
preserveUnknownFields: false
versions:
- name: v1
schema:
openAPIV3Schema:
description: KuberhealthyCheck represents the data in the CRD for configuring
an external check for Kuberhealthy
properties:
apiVersion:
description: 'APIVersion defines the versioned schema of this representation
of an object. Servers should convert recognized schemas to the latest
internal value, and may reject unrecognized values. More info: https://git.k8s.io/community/contributors/devel/sig-architecture/api-conventions.md#resources'
type: string
kind:
description: 'Kind is a string value representing the REST resource this
object represents. Servers may infer this from the endpoint the client
submits requests to. Cannot be updated. In CamelCase. More info: https://git.k8s.io/community/contributors/devel/sig-architecture/api-conventions.md#types-kinds'
type: string
metadata:
type: object
spec:
description: Spec holds the desired state of the KuberhealthyCheck (from
the client).
properties:
extraAnnotations:
additionalProperties:
type: string
type: object
extraLabels:
additionalProperties:
type: string
type: object
podSpec:
description: PodSpec is a description of a pod.
properties:
activeDeadlineSeconds:
description: Optional duration in seconds the pod may be active
on the node relative to StartTime before the system will actively
try to mark it failed and kill associated containers. Value
must be a positive integer.
format: int64
type: integer
affinity:
description: If specified, the pod's scheduling constraints
properties:
nodeAffinity:
description: Describes node affinity scheduling rules for
the pod.
properties:
preferredDuringSchedulingIgnoredDuringExecution:
description: The scheduler will prefer to schedule pods
to nodes that satisfy the affinity expressions specified
by this field, but it may choose a node that violates
one or more of the expressions. The node that is most
preferred is the one with the greatest sum of weights,
i.e. for each node that meets all of the scheduling
requirements (resource request, requiredDuringScheduling
affinity expressions, etc.), compute a sum by iterating
through the elements of this field and adding "weight"
to the sum if the node matches the corresponding matchExpressions;
the node(s) with the highest sum are the most preferred.
items:
description: An empty preferred scheduling term matches
all objects with implicit weight 0 (i.e. it's a no-op).
A null preferred scheduling term matches no objects
(i.e. is also a no-op).
properties:
preference:
description: A node selector term, associated with
the corresponding weight.
properties:
matchExpressions:
description: A list of node selector requirements
by node's labels.
items:
description: A node selector requirement is
a selector that contains values, a key,
and an operator that relates the key and
values.
properties:
key:
description: The label key that the selector
applies to.
type: string
operator:
description: Represents a key's relationship
to a set of values. Valid operators
are In, NotIn, Exists, DoesNotExist.
Gt, and Lt.
type: string
values:
description: An array of string values.
If the operator is In or NotIn, the
values array must be non-empty. If the
operator is Exists or DoesNotExist,
the values array must be empty. If the
operator is Gt or Lt, the values array
must have a single element, which will
be interpreted as an integer. This array
is replaced during a strategic merge
patch.
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
matchFields:
description: A list of node selector requirements
by node's fields.
items:
description: A node selector requirement is
a selector that contains values, a key,
and an operator that relates the key and
values.
properties:
key:
description: The label key that the selector
applies to.
type: string
operator:
description: Represents a key's relationship
to a set of values. Valid operators
are In, NotIn, Exists, DoesNotExist.
Gt, and Lt.
type: string
values:
description: An array of string values.
If the operator is In or NotIn, the
values array must be non-empty. If the
operator is Exists or DoesNotExist,
the values array must be empty. If the
operator is Gt or Lt, the values array
must have a single element, which will
be interpreted as an integer. This array
is replaced during a strategic merge
patch.
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
type: object
weight:
description: Weight associated with matching the
corresponding nodeSelectorTerm, in the range 1-100.
format: int32
type: integer
required:
- preference
- weight
type: object
type: array
requiredDuringSchedulingIgnoredDuringExecution:
description: If the affinity requirements specified by
this field are not met at scheduling time, the pod will
not be scheduled onto the node. If the affinity requirements
specified by this field cease to be met at some point
during pod execution (e.g. due to an update), the system
may or may not try to eventually evict the pod from
its node.
properties:
nodeSelectorTerms:
description: Required. A list of node selector terms.
The terms are ORed.
items:
description: A null or empty node selector term
matches no objects. The requirements of them are
ANDed. The TopologySelectorTerm type implements
a subset of the NodeSelectorTerm.
properties:
matchExpressions:
description: A list of node selector requirements
by node's labels.
items:
description: A node selector requirement is
a selector that contains values, a key,
and an operator that relates the key and
values.
properties:
key:
description: The label key that the selector
applies to.
type: string
operator:
description: Represents a key's relationship
to a set of values. Valid operators
are In, NotIn, Exists, DoesNotExist.
Gt, and Lt.
type: string
values:
description: An array of string values.
If the operator is In or NotIn, the
values array must be non-empty. If the
operator is Exists or DoesNotExist,
the values array must be empty. If the
operator is Gt or Lt, the values array
must have a single element, which will
be interpreted as an integer. This array
is replaced during a strategic merge
patch.
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
matchFields:
description: A list of node selector requirements
by node's fields.
items:
description: A node selector requirement is
a selector that contains values, a key,
and an operator that relates the key and
values.
properties:
key:
description: The label key that the selector
applies to.
type: string
operator:
description: Represents a key's relationship
to a set of values. Valid operators
are In, NotIn, Exists, DoesNotExist.
Gt, and Lt.
type: string
values:
description: An array of string values.
If the operator is In or NotIn, the
values array must be non-empty. If the
operator is Exists or DoesNotExist,
the values array must be empty. If the
operator is Gt or Lt, the values array
must have a single element, which will
be interpreted as an integer. This array
is replaced during a strategic merge
patch.
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
type: object
type: array
required:
- nodeSelectorTerms
type: object
type: object
podAffinity:
description: Describes pod affinity scheduling rules (e.g.
co-locate this pod in the same node, zone, etc. as some
other pod(s)).
properties:
preferredDuringSchedulingIgnoredDuringExecution:
description: The scheduler will prefer to schedule pods
to nodes that satisfy the affinity expressions specified
by this field, but it may choose a node that violates
one or more of the expressions. The node that is most
preferred is the one with the greatest sum of weights,
i.e. for each node that meets all of the scheduling
requirements (resource request, requiredDuringScheduling
affinity expressions, etc.), compute a sum by iterating
through the elements of this field and adding "weight"
to the sum if the node has pods which matches the corresponding
podAffinityTerm; the node(s) with the highest sum are
the most preferred.
items:
description: The weights of all of the matched WeightedPodAffinityTerm
fields are added per-node to find the most preferred
node(s)
properties:
podAffinityTerm:
description: Required. A pod affinity term, associated
with the corresponding weight.
properties:
labelSelector:
description: A label query over a set of resources,
in this case pods.
properties:
matchExpressions:
description: matchExpressions is a list
of label selector requirements. The requirements
are ANDed.
items:
description: A label selector requirement
is a selector that contains values,
a key, and an operator that relates
the key and values.
properties:
key:
description: key is the label key
that the selector applies to.
type: string
operator:
description: operator represents a
key's relationship to a set of values.
Valid operators are In, NotIn, Exists
and DoesNotExist.
type: string
values:
description: values is an array of
string values. If the operator is
In or NotIn, the values array must
be non-empty. If the operator is
Exists or DoesNotExist, the values
array must be empty. This array
is replaced during a strategic merge
patch.
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
matchLabels:
additionalProperties:
type: string
description: matchLabels is a map of {key,value}
pairs. A single {key,value} in the matchLabels
map is equivalent to an element of matchExpressions,
whose key field is "key", the operator
is "In", and the values array contains
only "value". The requirements are ANDed.
type: object
type: object
namespaceSelector:
description: A label query over the set of namespaces
that the term applies to. The term is applied
to the union of the namespaces selected by
this field and the ones listed in the namespaces
field. null selector and null or empty namespaces
list means "this pod's namespace". An empty
selector ({}) matches all namespaces. This
field is alpha-level and is only honored when
PodAffinityNamespaceSelector feature is enabled.
properties:
matchExpressions:
description: matchExpressions is a list
of label selector requirements. The requirements
are ANDed.
items:
description: A label selector requirement
is a selector that contains values,
a key, and an operator that relates
the key and values.
properties:
key:
description: key is the label key
that the selector applies to.
type: string
operator:
description: operator represents a
key's relationship to a set of values.
Valid operators are In, NotIn, Exists
and DoesNotExist.
type: string
values:
description: values is an array of
string values. If the operator is
In or NotIn, the values array must
be non-empty. If the operator is
Exists or DoesNotExist, the values
array must be empty. This array
is replaced during a strategic merge
patch.
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
matchLabels:
additionalProperties:
type: string
description: matchLabels is a map of {key,value}
pairs. A single {key,value} in the matchLabels
map is equivalent to an element of matchExpressions,
whose key field is "key", the operator
is "In", and the values array contains
only "value". The requirements are ANDed.
type: object
type: object
namespaces:
description: namespaces specifies a static list
of namespace names that the term applies to.
The term is applied to the union of the namespaces
listed in this field and the ones selected
by namespaceSelector. null or empty namespaces
list and null namespaceSelector means "this
pod's namespace"
items:
type: string
type: array
topologyKey:
description: This pod should be co-located (affinity)
or not co-located (anti-affinity) with the
pods matching the labelSelector in the specified
namespaces, where co-located is defined as
running on a node whose value of the label
with key topologyKey matches that of any node
on which any of the selected pods is running.
Empty topologyKey is not allowed.
type: string
required:
- topologyKey
type: object
weight:
description: weight associated with matching the
corresponding podAffinityTerm, in the range 1-100.
format: int32
type: integer
required:
- podAffinityTerm
- weight
type: object
type: array
requiredDuringSchedulingIgnoredDuringExecution:
description: If the affinity requirements specified by
this field are not met at scheduling time, the pod will
not be scheduled onto the node. If the affinity requirements
specified by this field cease to be met at some point
during pod execution (e.g. due to a pod label update),
the system may or may not try to eventually evict the
pod from its node. When there are multiple elements,
the lists of nodes corresponding to each podAffinityTerm
are intersected, i.e. all terms must be satisfied.
items:
description: Defines a set of pods (namely those matching
the labelSelector relative to the given namespace(s))
that this pod should be co-located (affinity) or not
co-located (anti-affinity) with, where co-located
is defined as running on a node whose value of the
label with key <topologyKey> matches that of any node
on which a pod of the set of pods is running
properties:
labelSelector:
description: A label query over a set of resources,
in this case pods.
properties:
matchExpressions:
description: matchExpressions is a list of label
selector requirements. The requirements are
ANDed.
items:
description: A label selector requirement
is a selector that contains values, a key,
and an operator that relates the key and
values.
properties:
key:
description: key is the label key that
the selector applies to.
type: string
operator:
description: operator represents a key's
relationship to a set of values. Valid
operators are In, NotIn, Exists and
DoesNotExist.
type: string
values:
description: values is an array of string
values. If the operator is In or NotIn,
the values array must be non-empty.
If the operator is Exists or DoesNotExist,
the values array must be empty. This
array is replaced during a strategic
merge patch.
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
matchLabels:
additionalProperties:
type: string
description: matchLabels is a map of {key,value}
pairs. A single {key,value} in the matchLabels
map is equivalent to an element of matchExpressions,
whose key field is "key", the operator is
"In", and the values array contains only "value".
The requirements are ANDed.
type: object
type: object
namespaceSelector:
description: A label query over the set of namespaces
that the term applies to. The term is applied
to the union of the namespaces selected by this
field and the ones listed in the namespaces field.
null selector and null or empty namespaces list
means "this pod's namespace". An empty selector
({}) matches all namespaces. This field is alpha-level
and is only honored when PodAffinityNamespaceSelector
feature is enabled.
properties:
matchExpressions:
description: matchExpressions is a list of label
selector requirements. The requirements are
ANDed.
items:
description: A label selector requirement
is a selector that contains values, a key,
and an operator that relates the key and
values.
properties:
key:
description: key is the label key that
the selector applies to.
type: string
operator:
description: operator represents a key's
relationship to a set of values. Valid
operators are In, NotIn, Exists and
DoesNotExist.
type: string
values:
description: values is an array of string
values. If the operator is In or NotIn,
the values array must be non-empty.
If the operator is Exists or DoesNotExist,
the values array must be empty. This
array is replaced during a strategic
merge patch.
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
matchLabels:
additionalProperties:
type: string
description: matchLabels is a map of {key,value}
pairs. A single {key,value} in the matchLabels
map is equivalent to an element of matchExpressions,
whose key field is "key", the operator is
"In", and the values array contains only "value".
The requirements are ANDed.
type: object
type: object
namespaces:
description: namespaces specifies a static list
of namespace names that the term applies to. The
term is applied to the union of the namespaces
listed in this field and the ones selected by
namespaceSelector. null or empty namespaces list
and null namespaceSelector means "this pod's namespace"
items:
type: string
type: array
topologyKey:
description: This pod should be co-located (affinity)
or not co-located (anti-affinity) with the pods
matching the labelSelector in the specified namespaces,
where co-located is defined as running on a node
whose value of the label with key topologyKey
matches that of any node on which any of the selected
pods is running. Empty topologyKey is not allowed.
type: string
required:
- topologyKey
type: object
type: array
type: object
podAntiAffinity:
description: Describes pod anti-affinity scheduling rules
(e.g. avoid putting this pod in the same node, zone, etc.
as some other pod(s)).
properties:
preferredDuringSchedulingIgnoredDuringExecution:
description: The scheduler will prefer to schedule pods
to nodes that satisfy the anti-affinity expressions
specified by this field, but it may choose a node that
violates one or more of the expressions. The node that
is most preferred is the one with the greatest sum of
weights, i.e. for each node that meets all of the scheduling
requirements (resource request, requiredDuringScheduling
anti-affinity expressions, etc.), compute a sum by iterating
through the elements of this field and adding "weight"
to the sum if the node has pods which matches the corresponding
podAffinityTerm; the node(s) with the highest sum are
the most preferred.
items:
description: The weights of all of the matched WeightedPodAffinityTerm
fields are added per-node to find the most preferred
node(s)
properties:
podAffinityTerm:
description: Required. A pod affinity term, associated
with the corresponding weight.
properties:
labelSelector:
description: A label query over a set of resources,
in this case pods.
properties:
matchExpressions:
description: matchExpressions is a list
of label selector requirements. The requirements
are ANDed.
items:
description: A label selector requirement
is a selector that contains values,
a key, and an operator that relates
the key and values.
properties:
key:
description: key is the label key
that the selector applies to.
type: string
operator:
description: operator represents a
key's relationship to a set of values.
Valid operators are In, NotIn, Exists
and DoesNotExist.
type: string
values:
description: values is an array of
string values. If the operator is
In or NotIn, the values array must
be non-empty. If the operator is
Exists or DoesNotExist, the values
array must be empty. This array
is replaced during a strategic merge
patch.
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
matchLabels:
additionalProperties:
type: string
description: matchLabels is a map of {key,value}
pairs. A single {key,value} in the matchLabels
map is equivalent to an element of matchExpressions,
whose key field is "key", the operator
is "In", and the values array contains
only "value". The requirements are ANDed.
type: object
type: object
namespaceSelector:
description: A label query over the set of namespaces
that the term applies to. The term is applied
to the union of the namespaces selected by
this field and the ones listed in the namespaces
field. null selector and null or empty namespaces
list means "this pod's namespace". An empty
selector ({}) matches all namespaces. This
field is alpha-level and is only honored when
PodAffinityNamespaceSelector feature is enabled.
properties:
matchExpressions:
description: matchExpressions is a list
of label selector requirements. The requirements
are ANDed.
items:
description: A label selector requirement
is a selector that contains values,
a key, and an operator that relates
the key and values.
properties:
key:
description: key is the label key
that the selector applies to.
type: string
operator:
description: operator represents a
key's relationship to a set of values.
Valid operators are In, NotIn, Exists
and DoesNotExist.
type: string
values:
description: values is an array of
string values. If the operator is
In or NotIn, the values array must
be non-empty. If the operator is
Exists or DoesNotExist, the values
array must be empty. This array
is replaced during a strategic merge
patch.
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
matchLabels:
additionalProperties:
type: string
description: matchLabels is a map of {key,value}
pairs. A single {key,value} in the matchLabels
map is equivalent to an element of matchExpressions,
whose key field is "key", the operator
is "In", and the values array contains
only "value". The requirements are ANDed.
type: object
type: object
namespaces:
description: namespaces specifies a static list
of namespace names that the term applies to.
The term is applied to the union of the namespaces
listed in this field and the ones selected
by namespaceSelector. null or empty namespaces
list and null namespaceSelector means "this
pod's namespace"
items:
type: string
type: array
topologyKey:
description: This pod should be co-located (affinity)
or not co-located (anti-affinity) with the
pods matching the labelSelector in the specified
namespaces, where co-located is defined as
running on a node whose value of the label
with key topologyKey matches that of any node
on which any of the selected pods is running.
Empty topologyKey is not allowed.
type: string
required:
- topologyKey
type: object
weight:
description: weight associated with matching the
corresponding podAffinityTerm, in the range 1-100.
format: int32
type: integer
required:
- podAffinityTerm
- weight
type: object
type: array
requiredDuringSchedulingIgnoredDuringExecution:
description: If the anti-affinity requirements specified
by this field are not met at scheduling time, the pod
will not be scheduled onto the node. If the anti-affinity
requirements specified by this field cease to be met
at some point during pod execution (e.g. due to a pod
label update), the system may or may not try to eventually
evict the pod from its node. When there are multiple
elements, the lists of nodes corresponding to each podAffinityTerm
are intersected, i.e. all terms must be satisfied.
items:
description: Defines a set of pods (namely those matching
the labelSelector relative to the given namespace(s))
that this pod should be co-located (affinity) or not
co-located (anti-affinity) with, where co-located
is defined as running on a node whose value of the
label with key <topologyKey> matches that of any node
on which a pod of the set of pods is running
properties:
labelSelector:
description: A label query over a set of resources,
in this case pods.
properties:
matchExpressions:
description: matchExpressions is a list of label
selector requirements. The requirements are
ANDed.
items:
description: A label selector requirement
is a selector that contains values, a key,
and an operator that relates the key and
values.
properties:
key:
description: key is the label key that
the selector applies to.
type: string
operator:
description: operator represents a key's
relationship to a set of values. Valid
operators are In, NotIn, Exists and
DoesNotExist.
type: string
values:
description: values is an array of string
values. If the operator is In or NotIn,
the values array must be non-empty.
If the operator is Exists or DoesNotExist,
the values array must be empty. This
array is replaced during a strategic
merge patch.
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
matchLabels:
additionalProperties:
type: string
description: matchLabels is a map of {key,value}
pairs. A single {key,value} in the matchLabels
map is equivalent to an element of matchExpressions,
whose key field is "key", the operator is
"In", and the values array contains only "value".
The requirements are ANDed.
type: object
type: object
namespaceSelector:
description: A label query over the set of namespaces
that the term applies to. The term is applied
to the union of the namespaces selected by this
field and the ones listed in the namespaces field.
null selector and null or empty namespaces list
means "this pod's namespace". An empty selector
({}) matches all namespaces. This field is alpha-level
and is only honored when PodAffinityNamespaceSelector
feature is enabled.
properties:
matchExpressions:
description: matchExpressions is a list of label
selector requirements. The requirements are
ANDed.
items:
description: A label selector requirement
is a selector that contains values, a key,
and an operator that relates the key and
values.
properties:
key:
description: key is the label key that
the selector applies to.
type: string
operator:
description: operator represents a key's
relationship to a set of values. Valid
operators are In, NotIn, Exists and
DoesNotExist.
type: string
values:
description: values is an array of string
values. If the operator is In or NotIn,
the values array must be non-empty.
If the operator is Exists or DoesNotExist,
the values array must be empty. This
array is replaced during a strategic
merge patch.
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
matchLabels:
additionalProperties:
type: string
description: matchLabels is a map of {key,value}
pairs. A single {key,value} in the matchLabels
map is equivalent to an element of matchExpressions,
whose key field is "key", the operator is
"In", and the values array contains only "value".
The requirements are ANDed.
type: object
type: object
namespaces:
description: namespaces specifies a static list
of namespace names that the term applies to. The
term is applied to the union of the namespaces
listed in this field and the ones selected by
namespaceSelector. null or empty namespaces list
and null namespaceSelector means "this pod's namespace"
items:
type: string
type: array
topologyKey:
description: This pod should be co-located (affinity)
or not co-located (anti-affinity) with the pods
matching the labelSelector in the specified namespaces,
where co-located is defined as running on a node
whose value of the label with key topologyKey
matches that of any node on which any of the selected
pods is running. Empty topologyKey is not allowed.
type: string
required:
- topologyKey
type: object
type: array
type: object
type: object
automountServiceAccountToken:
description: AutomountServiceAccountToken indicates whether a
service account token should be automatically mounted.
type: boolean
containers:
description: List of containers belonging to the pod. Containers
cannot currently be added or removed. There must be at least
one container in a Pod. Cannot be updated.
items:
description: A single application container that you want to
run within a pod.
properties:
args:
description: 'Arguments to the entrypoint. The docker image''s
CMD is used if this is not provided. Variable references
$(VAR_NAME) are expanded using the container''s environment.
If a variable cannot be resolved, the reference in the
input string will be unchanged. The $(VAR_NAME) syntax
can be escaped with a double $$, ie: $$(VAR_NAME). Escaped
references will never be expanded, regardless of whether
the variable exists or not. Cannot be updated. More info:
https://kubernetes.io/docs/tasks/inject-data-application/define-command-argument-container/#running-a-command-in-a-shell'
items:
type: string
type: array
command:
description: 'Entrypoint array. Not executed within a shell.
The docker image''s ENTRYPOINT is used if this is not
provided. Variable references $(VAR_NAME) are expanded
using the container''s environment. If a variable cannot
be resolved, the reference in the input string will be
unchanged. The $(VAR_NAME) syntax can be escaped with
a double $$, ie: $$(VAR_NAME). Escaped references will
never be expanded, regardless of whether the variable
exists or not. Cannot be updated. More info: https://kubernetes.io/docs/tasks/inject-data-application/define-command-argument-container/#running-a-command-in-a-shell'
items:
type: string
type: array
env:
description: List of environment variables to set in the
container. Cannot be updated.
items:
description: EnvVar represents an environment variable
present in a Container.
properties:
name:
description: Name of the environment variable. Must
be a C_IDENTIFIER.
type: string
value:
description: 'Variable references $(VAR_NAME) are
expanded using the previous defined environment
variables in the container and any service environment
variables. If a variable cannot be resolved, the
reference in the input string will be unchanged.
The $(VAR_NAME) syntax can be escaped with a double
$$, ie: $$(VAR_NAME). Escaped references will never
be expanded, regardless of whether the variable
exists or not. Defaults to "".'
type: string
valueFrom:
description: Source for the environment variable's
value. Cannot be used if value is not empty.
properties:
configMapKeyRef:
description: Selects a key of a ConfigMap.
properties:
key:
description: The key to select.
type: string
name:
description: 'Name of the referent. More info:
https://kubernetes.io/docs/concepts/overview/working-with-objects/names/#names
TODO: Add other useful fields. apiVersion,
kind, uid?'
type: string
optional:
description: Specify whether the ConfigMap
or its key must be defined
type: boolean
required:
- key
type: object
fieldRef:
description: 'Selects a field of the pod: supports
metadata.name, metadata.namespace, `metadata.labels[''<KEY>'']`,
`metadata.annotations[''<KEY>'']`, spec.nodeName,
spec.serviceAccountName, status.hostIP, status.podIP,
status.podIPs.'
properties:
apiVersion:
description: Version of the schema the FieldPath
is written in terms of, defaults to "v1".
type: string
fieldPath:
description: Path of the field to select in
the specified API version.
type: string
required:
- fieldPath
type: object
resourceFieldRef:
description: 'Selects a resource of the container:
only resources limits and requests (limits.cpu,
limits.memory, limits.ephemeral-storage, requests.cpu,
requests.memory and requests.ephemeral-storage)
are currently supported.'
properties:
containerName:
description: 'Container name: required for
volumes, optional for env vars'
type: string
divisor:
anyOf:
- type: integer
- type: string
description: Specifies the output format of
the exposed resources, defaults to "1"
pattern: ^(\+|-)?(([0-9]+(\.[0-9]*)?)|(\.[0-9]+))(([KMGTPE]i)|[numkMGTPE]|([eE](\+|-)?(([0-9]+(\.[0-9]*)?)|(\.[0-9]+))))?$
x-kubernetes-int-or-string: true
resource:
description: 'Required: resource to select'
type: string
required:
- resource
type: object
secretKeyRef:
description: Selects a key of a secret in the
pod's namespace
properties:
key:
description: The key of the secret to select
from. Must be a valid secret key.
type: string
name:
description: 'Name of the referent. More info:
https://kubernetes.io/docs/concepts/overview/working-with-objects/names/#names
TODO: Add other useful fields. apiVersion,
kind, uid?'
type: string
optional:
description: Specify whether the Secret or
its key must be defined
type: boolean
required:
- key
type: object
type: object
required:
- name
type: object
type: array
envFrom:
description: List of sources to populate environment variables
in the container. The keys defined within a source must
be a C_IDENTIFIER. All invalid keys will be reported as
an event when the container is starting. When a key exists
in multiple sources, the value associated with the last
source will take precedence. Values defined by an Env
with a duplicate key will take precedence. Cannot be updated.
items:
description: EnvFromSource represents the source of a
set of ConfigMaps
properties:
configMapRef:
description: The ConfigMap to select from
properties:
name:
description: 'Name of the referent. More info:
https://kubernetes.io/docs/concepts/overview/working-with-objects/names/#names
TODO: Add other useful fields. apiVersion, kind,
uid?'
type: string
optional:
description: Specify whether the ConfigMap must
be defined
type: boolean
type: object
prefix:
description: An optional identifier to prepend to
each key in the ConfigMap. Must be a C_IDENTIFIER.
type: string
secretRef:
description: The Secret to select from
properties:
name:
description: 'Name of the referent. More info:
https://kubernetes.io/docs/concepts/overview/working-with-objects/names/#names
TODO: Add other useful fields. apiVersion, kind,
uid?'
type: string
optional:
description: Specify whether the Secret must be
defined
type: boolean
type: object
type: object
type: array
image:
description: 'Docker image name. More info: https://kubernetes.io/docs/concepts/containers/images
This field is optional to allow higher level config management
to default or override container images in workload controllers
like Deployments and StatefulSets.'
type: string
imagePullPolicy:
description: 'Image pull policy. One of Always, Never, IfNotPresent.
Defaults to Always if :latest tag is specified, or IfNotPresent
otherwise. Cannot be updated. More info: https://kubernetes.io/docs/concepts/containers/images#updating-images'
type: string
lifecycle:
description: Actions that the management system should take
in response to container lifecycle events. Cannot be updated.
properties:
postStart:
description: 'PostStart is called immediately after
a container is created. If the handler fails, the
container is terminated and restarted according to
its restart policy. Other management of the container
blocks until the hook completes. More info: https://kubernetes.io/docs/concepts/containers/container-lifecycle-hooks/#container-hooks'
properties:
exec:
description: One and only one of the following should
be specified. Exec specifies the action to take.
properties:
command:
description: Command is the command line to
execute inside the container, the working
directory for the command is root ('/') in
the container's filesystem. The command is
simply exec'd, it is not run inside a shell,
so traditional shell instructions ('|', etc)
won't work. To use a shell, you need to explicitly
call out to that shell. Exit status of 0 is
treated as live/healthy and non-zero is unhealthy.
items:
type: string
type: array
type: object
httpGet:
description: HTTPGet specifies the http request
to perform.
properties:
host:
description: Host name to connect to, defaults
to the pod IP. You probably want to set "Host"
in httpHeaders instead.
type: string
httpHeaders:
description: Custom headers to set in the request.
HTTP allows repeated headers.
items:
description: HTTPHeader describes a custom
header to be used in HTTP probes
properties:
name:
description: The header field name
type: string
value:
description: The header field value
type: string
required:
- name
- value
type: object
type: array
path:
description: Path to access on the HTTP server.
type: string
port:
anyOf:
- type: integer
- type: string
description: Name or number of the port to access
on the container. Number must be in the range
1 to 65535. Name must be an IANA_SVC_NAME.
x-kubernetes-int-or-string: true
scheme:
description: Scheme to use for connecting to
the host. Defaults to HTTP.
type: string
required:
- port
type: object
tcpSocket:
description: 'TCPSocket specifies an action involving
a TCP port. TCP hooks not yet supported TODO:
implement a realistic TCP lifecycle hook'
properties:
host:
description: 'Optional: Host name to connect
to, defaults to the pod IP.'
type: string
port:
anyOf:
- type: integer
- type: string
description: Number or name of the port to access
on the container. Number must be in the range
1 to 65535. Name must be an IANA_SVC_NAME.
x-kubernetes-int-or-string: true
required:
- port
type: object
type: object
preStop:
description: 'PreStop is called immediately before a
container is terminated due to an API request or management
event such as liveness/startup probe failure, preemption,
resource contention, etc. The handler is not called
if the container crashes or exits. The reason for
termination is passed to the handler. The Pod''s termination
grace period countdown begins before the PreStop hooked
is executed. Regardless of the outcome of the handler,
the container will eventually terminate within the
Pod''s termination grace period. Other management
of the container blocks until the hook completes or
until the termination grace period is reached. More
info: https://kubernetes.io/docs/concepts/containers/container-lifecycle-hooks/#container-hooks'
properties:
exec:
description: One and only one of the following should
be specified. Exec specifies the action to take.
properties:
command:
description: Command is the command line to
execute inside the container, the working
directory for the command is root ('/') in
the container's filesystem. The command is
simply exec'd, it is not run inside a shell,
so traditional shell instructions ('|', etc)
won't work. To use a shell, you need to explicitly
call out to that shell. Exit status of 0 is
treated as live/healthy and non-zero is unhealthy.
items:
type: string
type: array
type: object
httpGet:
description: HTTPGet specifies the http request
to perform.
properties:
host:
description: Host name to connect to, defaults
to the pod IP. You probably want to set "Host"
in httpHeaders instead.
type: string
httpHeaders:
description: Custom headers to set in the request.
HTTP allows repeated headers.
items:
description: HTTPHeader describes a custom
header to be used in HTTP probes
properties:
name:
description: The header field name
type: string
value:
description: The header field value
type: string
required:
- name
- value
type: object
type: array
path:
description: Path to access on the HTTP server.
type: string
port:
anyOf:
- type: integer
- type: string
description: Name or number of the port to access
on the container. Number must be in the range
1 to 65535. Name must be an IANA_SVC_NAME.
x-kubernetes-int-or-string: true
scheme:
description: Scheme to use for connecting to
the host. Defaults to HTTP.
type: string
required:
- port
type: object
tcpSocket:
description: 'TCPSocket specifies an action involving
a TCP port. TCP hooks not yet supported TODO:
implement a realistic TCP lifecycle hook'
properties:
host:
description: 'Optional: Host name to connect
to, defaults to the pod IP.'
type: string
port:
anyOf:
- type: integer
- type: string
description: Number or name of the port to access
on the container. Number must be in the range
1 to 65535. Name must be an IANA_SVC_NAME.
x-kubernetes-int-or-string: true
required:
- port
type: object
type: object
type: object
livenessProbe:
description: 'Periodic probe of container liveness. Container
will be restarted if the probe fails. Cannot be updated.
More info: https://kubernetes.io/docs/concepts/workloads/pods/pod-lifecycle#container-probes'
properties:
exec:
description: One and only one of the following should
be specified. Exec specifies the action to take.
properties:
command:
description: Command is the command line to execute
inside the container, the working directory for
the command is root ('/') in the container's
filesystem. The command is simply exec'd, it is
not run inside a shell, so traditional shell instructions
('|', etc) won't work. To use a shell, you need
to explicitly call out to that shell. Exit status
of 0 is treated as live/healthy and non-zero is
unhealthy.
items:
type: string
type: array
type: object
failureThreshold:
description: Minimum consecutive failures for the probe
to be considered failed after having succeeded. Defaults
to 3. Minimum value is 1.
format: int32
type: integer
httpGet:
description: HTTPGet specifies the http request to perform.
properties:
host:
description: Host name to connect to, defaults to
the pod IP. You probably want to set "Host" in
httpHeaders instead.
type: string
httpHeaders:
description: Custom headers to set in the request.
HTTP allows repeated headers.
items:
description: HTTPHeader describes a custom header
to be used in HTTP probes
properties:
name:
description: The header field name
type: string
value:
description: The header field value
type: string
required:
- name
- value
type: object
type: array
path:
description: Path to access on the HTTP server.
type: string
port:
anyOf:
- type: integer
- type: string
description: Name or number of the port to access
on the container. Number must be in the range
1 to 65535. Name must be an IANA_SVC_NAME.
x-kubernetes-int-or-string: true
scheme:
description: Scheme to use for connecting to the
host. Defaults to HTTP.
type: string
required:
- port
type: object
initialDelaySeconds:
description: 'Number of seconds after the container
has started before liveness probes are initiated.
More info: https://kubernetes.io/docs/concepts/workloads/pods/pod-lifecycle#container-probes'
format: int32
type: integer
periodSeconds:
description: How often (in seconds) to perform the probe.
Default to 10 seconds. Minimum value is 1.
format: int32
type: integer
successThreshold:
description: Minimum consecutive successes for the probe
to be considered successful after having failed. Defaults
to 1. Must be 1 for liveness and startup. Minimum
value is 1.
format: int32
type: integer
tcpSocket:
description: 'TCPSocket specifies an action involving
a TCP port. TCP hooks not yet supported TODO: implement
a realistic TCP lifecycle hook'
properties:
host:
description: 'Optional: Host name to connect to,
defaults to the pod IP.'
type: string
port:
anyOf:
- type: integer
- type: string
description: Number or name of the port to access
on the container. Number must be in the range
1 to 65535. Name must be an IANA_SVC_NAME.
x-kubernetes-int-or-string: true
required:
- port
type: object
terminationGracePeriodSeconds:
description: Optional duration in seconds the pod needs
to terminate gracefully upon probe failure. The grace
period is the duration in seconds after the processes
running in the pod are sent a termination signal and
the time when the processes are forcibly halted with
a kill signal. Set this value longer than the expected
cleanup time for your process. If this value is nil,
the pod's terminationGracePeriodSeconds will be used.
Otherwise, this value overrides the value provided
by the pod spec. Value must be non-negative integer.
The value zero indicates stop immediately via the
kill signal (no opportunity to shut down). This is
an alpha field and requires enabling ProbeTerminationGracePeriod
feature gate.
format: int64
type: integer
timeoutSeconds:
description: 'Number of seconds after which the probe
times out. Defaults to 1 second. Minimum value is
1. More info: https://kubernetes.io/docs/concepts/workloads/pods/pod-lifecycle#container-probes'
format: int32
type: integer
type: object
name:
description: Name of the container specified as a DNS_LABEL.
Each container in a pod must have a unique name (DNS_LABEL).
Cannot be updated.
type: string
ports:
description: List of ports to expose from the container.
Exposing a port here gives the system additional information
about the network connections a container uses, but is
primarily informational. Not specifying a port here DOES
NOT prevent that port from being exposed. Any port which
is listening on the default "0.0.0.0" address inside a
container will be accessible from the network. Cannot
be updated.
items:
description: ContainerPort represents a network port in
a single container.
properties:
containerPort:
description: Number of port to expose on the pod's
IP address. This must be a valid port number, 0
< x < 65536.
format: int32
type: integer
hostIP:
description: What host IP to bind the external port
to.
type: string
hostPort:
description: Number of port to expose on the host.
If specified, this must be a valid port number,
0 < x < 65536. If HostNetwork is specified, this
must match ContainerPort. Most containers do not
need this.
format: int32
type: integer
name:
description: If specified, this must be an IANA_SVC_NAME
and unique within the pod. Each named port in a
pod must have a unique name. Name for the port that
can be referred to by services.
type: string
protocol:
default: TCP
description: Protocol for port. Must be UDP, TCP,
or SCTP. Defaults to "TCP".
type: string
required:
- containerPort
type: object
type: array
x-kubernetes-list-map-keys:
- containerPort
- protocol
x-kubernetes-list-type: map
readinessProbe:
description: 'Periodic probe of container service readiness.
Container will be removed from service endpoints if the
probe fails. Cannot be updated. More info: https://kubernetes.io/docs/concepts/workloads/pods/pod-lifecycle#container-probes'
properties:
exec:
description: One and only one of the following should
be specified. Exec specifies the action to take.
properties:
command:
description: Command is the command line to execute
inside the container, the working directory for
the command is root ('/') in the container's
filesystem. The command is simply exec'd, it is
not run inside a shell, so traditional shell instructions
('|', etc) won't work. To use a shell, you need
to explicitly call out to that shell. Exit status
of 0 is treated as live/healthy and non-zero is
unhealthy.
items:
type: string
type: array
type: object
failureThreshold:
description: Minimum consecutive failures for the probe
to be considered failed after having succeeded. Defaults
to 3. Minimum value is 1.
format: int32
type: integer
httpGet:
description: HTTPGet specifies the http request to perform.
properties:
host:
description: Host name to connect to, defaults to
the pod IP. You probably want to set "Host" in
httpHeaders instead.
type: string
httpHeaders:
description: Custom headers to set in the request.
HTTP allows repeated headers.
items:
description: HTTPHeader describes a custom header
to be used in HTTP probes
properties:
name:
description: The header field name
type: string
value:
description: The header field value
type: string
required:
- name
- value
type: object
type: array
path:
description: Path to access on the HTTP server.
type: string
port:
anyOf:
- type: integer
- type: string
description: Name or number of the port to access
on the container. Number must be in the range
1 to 65535. Name must be an IANA_SVC_NAME.
x-kubernetes-int-or-string: true
scheme:
description: Scheme to use for connecting to the
host. Defaults to HTTP.
type: string
required:
- port
type: object
initialDelaySeconds:
description: 'Number of seconds after the container
has started before liveness probes are initiated.
More info: https://kubernetes.io/docs/concepts/workloads/pods/pod-lifecycle#container-probes'
format: int32
type: integer
periodSeconds:
description: How often (in seconds) to perform the probe.
Default to 10 seconds. Minimum value is 1.
format: int32
type: integer
successThreshold:
description: Minimum consecutive successes for the probe
to be considered successful after having failed. Defaults
to 1. Must be 1 for liveness and startup. Minimum
value is 1.
format: int32
type: integer
tcpSocket:
description: 'TCPSocket specifies an action involving
a TCP port. TCP hooks not yet supported TODO: implement
a realistic TCP lifecycle hook'
properties:
host:
description: 'Optional: Host name to connect to,
defaults to the pod IP.'
type: string
port:
anyOf:
- type: integer
- type: string
description: Number or name of the port to access
on the container. Number must be in the range
1 to 65535. Name must be an IANA_SVC_NAME.
x-kubernetes-int-or-string: true
required:
- port
type: object
terminationGracePeriodSeconds:
description: Optional duration in seconds the pod needs
to terminate gracefully upon probe failure. The grace
period is the duration in seconds after the processes
running in the pod are sent a termination signal and
the time when the processes are forcibly halted with
a kill signal. Set this value longer than the expected
cleanup time for your process. If this value is nil,
the pod's terminationGracePeriodSeconds will be used.
Otherwise, this value overrides the value provided
by the pod spec. Value must be non-negative integer.
The value zero indicates stop immediately via the
kill signal (no opportunity to shut down). This is
an alpha field and requires enabling ProbeTerminationGracePeriod
feature gate.
format: int64
type: integer
timeoutSeconds:
description: 'Number of seconds after which the probe
times out. Defaults to 1 second. Minimum value is
1. More info: https://kubernetes.io/docs/concepts/workloads/pods/pod-lifecycle#container-probes'
format: int32
type: integer
type: object
resources:
description: 'Compute Resources required by this container.
Cannot be updated. More info: https://kubernetes.io/docs/concepts/configuration/manage-resources-containers/'
properties:
limits:
additionalProperties:
anyOf:
- type: integer
- type: string
pattern: ^(\+|-)?(([0-9]+(\.[0-9]*)?)|(\.[0-9]+))(([KMGTPE]i)|[numkMGTPE]|([eE](\+|-)?(([0-9]+(\.[0-9]*)?)|(\.[0-9]+))))?$
x-kubernetes-int-or-string: true
description: 'Limits describes the maximum amount of
compute resources allowed. More info: https://kubernetes.io/docs/concepts/configuration/manage-resources-containers/'
type: object
requests:
additionalProperties:
anyOf:
- type: integer
- type: string
pattern: ^(\+|-)?(([0-9]+(\.[0-9]*)?)|(\.[0-9]+))(([KMGTPE]i)|[numkMGTPE]|([eE](\+|-)?(([0-9]+(\.[0-9]*)?)|(\.[0-9]+))))?$
x-kubernetes-int-or-string: true
description: 'Requests describes the minimum amount
of compute resources required. If Requests is omitted
for a container, it defaults to Limits if that is
explicitly specified, otherwise to an implementation-defined
value. More info: https://kubernetes.io/docs/concepts/configuration/manage-resources-containers/'
type: object
type: object
securityContext:
description: 'Security options the pod should run with.
More info: https://kubernetes.io/docs/concepts/policy/security-context/
More info: https://kubernetes.io/docs/tasks/configure-pod-container/security-context/'
properties:
allowPrivilegeEscalation:
description: 'AllowPrivilegeEscalation controls whether
a process can gain more privileges than its parent
process. This bool directly controls if the no_new_privs
flag will be set on the container process. AllowPrivilegeEscalation
is true always when the container is: 1) run as Privileged
2) has CAP_SYS_ADMIN'
type: boolean
capabilities:
description: The capabilities to add/drop when running
containers. Defaults to the default set of capabilities
granted by the container runtime.
properties:
add:
description: Added capabilities
items:
description: Capability represent POSIX capabilities
type
type: string
type: array
drop:
description: Removed capabilities
items:
description: Capability represent POSIX capabilities
type
type: string
type: array
type: object
privileged:
description: Run container in privileged mode. Processes
in privileged containers are essentially equivalent
to root on the host. Defaults to false.
type: boolean
procMount:
description: procMount denotes the type of proc mount
to use for the containers. The default is DefaultProcMount
which uses the container runtime defaults for readonly
paths and masked paths. This requires the ProcMountType
feature flag to be enabled.
type: string
readOnlyRootFilesystem:
description: Whether this container has a read-only
root filesystem. Default is false.
type: boolean
runAsGroup:
description: The GID to run the entrypoint of the container
process. Uses runtime default if unset. May also be
set in PodSecurityContext. If set in both SecurityContext
and PodSecurityContext, the value specified in SecurityContext
takes precedence.
format: int64
type: integer
runAsNonRoot:
description: Indicates that the container must run as
a non-root user. If true, the Kubelet will validate
the image at runtime to ensure that it does not run
as UID 0 (root) and fail to start the container if
it does. If unset or false, no such validation will
be performed. May also be set in PodSecurityContext. If
set in both SecurityContext and PodSecurityContext,
the value specified in SecurityContext takes precedence.
type: boolean
runAsUser:
description: The UID to run the entrypoint of the container
process. Defaults to user specified in image metadata
if unspecified. May also be set in PodSecurityContext. If
set in both SecurityContext and PodSecurityContext,
the value specified in SecurityContext takes precedence.
format: int64
type: integer
seLinuxOptions:
description: The SELinux context to be applied to the
container. If unspecified, the container runtime will
allocate a random SELinux context for each container. May
also be set in PodSecurityContext. If set in both
SecurityContext and PodSecurityContext, the value
specified in SecurityContext takes precedence.
properties:
level:
description: Level is SELinux level label that applies
to the container.
type: string
role:
description: Role is a SELinux role label that applies
to the container.
type: string
type:
description: Type is a SELinux type label that applies
to the container.
type: string
user:
description: User is a SELinux user label that applies
to the container.
type: string
type: object
seccompProfile:
description: The seccomp options to use by this container.
If seccomp options are provided at both the pod &
container level, the container options override the
pod options.
properties:
localhostProfile:
description: localhostProfile indicates a profile
defined in a file on the node should be used.
The profile must be preconfigured on the node
to work. Must be a descending path, relative to
the kubelet's configured seccomp profile location.
Must only be set if type is "Localhost".
type: string
type:
description: "type indicates which kind of seccomp
profile will be applied. Valid options are: \n
Localhost - a profile defined in a file on the
node should be used. RuntimeDefault - the container
runtime default profile should be used. Unconfined
- no profile should be applied."
type: string
required:
- type
type: object
windowsOptions:
description: The Windows specific settings applied to
all containers. If unspecified, the options from the
PodSecurityContext will be used. If set in both SecurityContext
and PodSecurityContext, the value specified in SecurityContext
takes precedence.
properties:
gmsaCredentialSpec:
description: GMSACredentialSpec is where the GMSA
admission webhook (https://github.com/kubernetes-sigs/windows-gmsa)
inlines the contents of the GMSA credential spec
named by the GMSACredentialSpecName field.
type: string
gmsaCredentialSpecName:
description: GMSACredentialSpecName is the name
of the GMSA credential spec to use.
type: string
runAsUserName:
description: The UserName in Windows to run the
entrypoint of the container process. Defaults
to the user specified in image metadata if unspecified.
May also be set in PodSecurityContext. If set
in both SecurityContext and PodSecurityContext,
the value specified in SecurityContext takes precedence.
type: string
type: object
type: object
startupProbe:
description: 'StartupProbe indicates that the Pod has successfully
initialized. If specified, no other probes are executed
until this completes successfully. If this probe fails,
the Pod will be restarted, just as if the livenessProbe
failed. This can be used to provide different probe parameters
at the beginning of a Pod''s lifecycle, when it might
take a long time to load data or warm a cache, than during
steady-state operation. This cannot be updated. More info:
https://kubernetes.io/docs/concepts/workloads/pods/pod-lifecycle#container-probes'
properties:
exec:
description: One and only one of the following should
be specified. Exec specifies the action to take.
properties:
command:
description: Command is the command line to execute
inside the container, the working directory for
the command is root ('/') in the container's
filesystem. The command is simply exec'd, it is
not run inside a shell, so traditional shell instructions
('|', etc) won't work. To use a shell, you need
to explicitly call out to that shell. Exit status
of 0 is treated as live/healthy and non-zero is
unhealthy.
items:
type: string
type: array
type: object
failureThreshold:
description: Minimum consecutive failures for the probe
to be considered failed after having succeeded. Defaults
to 3. Minimum value is 1.
format: int32
type: integer
httpGet:
description: HTTPGet specifies the http request to perform.
properties:
host:
description: Host name to connect to, defaults to
the pod IP. You probably want to set "Host" in
httpHeaders instead.
type: string
httpHeaders:
description: Custom headers to set in the request.
HTTP allows repeated headers.
items:
description: HTTPHeader describes a custom header
to be used in HTTP probes
properties:
name:
description: The header field name
type: string
value:
description: The header field value
type: string
required:
- name
- value
type: object
type: array
path:
description: Path to access on the HTTP server.
type: string
port:
anyOf:
- type: integer
- type: string
description: Name or number of the port to access
on the container. Number must be in the range
1 to 65535. Name must be an IANA_SVC_NAME.
x-kubernetes-int-or-string: true
scheme:
description: Scheme to use for connecting to the
host. Defaults to HTTP.
type: string
required:
- port
type: object
initialDelaySeconds:
description: 'Number of seconds after the container
has started before liveness probes are initiated.
More info: https://kubernetes.io/docs/concepts/workloads/pods/pod-lifecycle#container-probes'
format: int32
type: integer
periodSeconds:
description: How often (in seconds) to perform the probe.
Default to 10 seconds. Minimum value is 1.
format: int32
type: integer
successThreshold:
description: Minimum consecutive successes for the probe
to be considered successful after having failed. Defaults
to 1. Must be 1 for liveness and startup. Minimum
value is 1.
format: int32
type: integer
tcpSocket:
description: 'TCPSocket specifies an action involving
a TCP port. TCP hooks not yet supported TODO: implement
a realistic TCP lifecycle hook'
properties:
host:
description: 'Optional: Host name to connect to,
defaults to the pod IP.'
type: string
port:
anyOf:
- type: integer
- type: string
description: Number or name of the port to access
on the container. Number must be in the range
1 to 65535. Name must be an IANA_SVC_NAME.
x-kubernetes-int-or-string: true
required:
- port
type: object
terminationGracePeriodSeconds:
description: Optional duration in seconds the pod needs
to terminate gracefully upon probe failure. The grace
period is the duration in seconds after the processes
running in the pod are sent a termination signal and
the time when the processes are forcibly halted with
a kill signal. Set this value longer than the expected
cleanup time for your process. If this value is nil,
the pod's terminationGracePeriodSeconds will be used.
Otherwise, this value overrides the value provided
by the pod spec. Value must be non-negative integer.
The value zero indicates stop immediately via the
kill signal (no opportunity to shut down). This is
an alpha field and requires enabling ProbeTerminationGracePeriod
feature gate.
format: int64
type: integer
timeoutSeconds:
description: 'Number of seconds after which the probe
times out. Defaults to 1 second. Minimum value is
1. More info: https://kubernetes.io/docs/concepts/workloads/pods/pod-lifecycle#container-probes'
format: int32
type: integer
type: object
stdin:
description: Whether this container should allocate a buffer
for stdin in the container runtime. If this is not set,
reads from stdin in the container will always result in
EOF. Default is false.
type: boolean
stdinOnce:
description: Whether the container runtime should close
the stdin channel after it has been opened by a single
attach. When stdin is true the stdin stream will remain
open across multiple attach sessions. If stdinOnce is
set to true, stdin is opened on container start, is empty
until the first client attaches to stdin, and then remains
open and accepts data until the client disconnects, at
which time stdin is closed and remains closed until the
container is restarted. If this flag is false, a container
processes that reads from stdin will never receive an
EOF. Default is false
type: boolean
terminationMessagePath:
description: 'Optional: Path at which the file to which
the container''s termination message will be written is
mounted into the container''s filesystem. Message written
is intended to be brief final status, such as an assertion
failure message. Will be truncated by the node if greater
than 4096 bytes. The total message length across all containers
will be limited to 12kb. Defaults to /dev/termination-log.
Cannot be updated.'
type: string
terminationMessagePolicy:
description: Indicate how the termination message should
be populated. File will use the contents of terminationMessagePath
to populate the container status message on both success
and failure. FallbackToLogsOnError will use the last chunk
of container log output if the termination message file
is empty and the container exited with an error. The log
output is limited to 2048 bytes or 80 lines, whichever
is smaller. Defaults to File. Cannot be updated.
type: string
tty:
description: Whether this container should allocate a TTY
for itself, also requires 'stdin' to be true. Default
is false.
type: boolean
volumeDevices:
description: volumeDevices is the list of block devices
to be used by the container.
items:
description: volumeDevice describes a mapping of a raw
block device within a container.
properties:
devicePath:
description: devicePath is the path inside of the
container that the device will be mapped to.
type: string
name:
description: name must match the name of a persistentVolumeClaim
in the pod
type: string
required:
- devicePath
- name
type: object
type: array
volumeMounts:
description: Pod volumes to mount into the container's filesystem.
Cannot be updated.
items:
description: VolumeMount describes a mounting of a Volume
within a container.
properties:
mountPath:
description: Path within the container at which the
volume should be mounted. Must not contain ':'.
type: string
mountPropagation:
description: mountPropagation determines how mounts
are propagated from the host to container and the
other way around. When not set, MountPropagationNone
is used. This field is beta in 1.10.
type: string
name:
description: This must match the Name of a Volume.
type: string
readOnly:
description: Mounted read-only if true, read-write
otherwise (false or unspecified). Defaults to false.
type: boolean
subPath:
description: Path within the volume from which the
container's volume should be mounted. Defaults to
"" (volume's root).
type: string
subPathExpr:
description: Expanded path within the volume from
which the container's volume should be mounted.
Behaves similarly to SubPath but environment variable
references $(VAR_NAME) are expanded using the container's
environment. Defaults to "" (volume's root). SubPathExpr
and SubPath are mutually exclusive.
type: string
required:
- mountPath
- name
type: object
type: array
workingDir:
description: Container's working directory. If not specified,
the container runtime's default will be used, which might
be configured in the container image. Cannot be updated.
type: string
required:
- name
type: object
type: array
dnsConfig:
description: Specifies the DNS parameters of a pod. Parameters
specified here will be merged to the generated DNS configuration
based on DNSPolicy.
properties:
nameservers:
description: A list of DNS name server IP addresses. This
will be appended to the base nameservers generated from
DNSPolicy. Duplicated nameservers will be removed.
items:
type: string
type: array
options:
description: A list of DNS resolver options. This will be
merged with the base options generated from DNSPolicy. Duplicated
entries will be removed. Resolution options given in Options
will override those that appear in the base DNSPolicy.
items:
description: PodDNSConfigOption defines DNS resolver options
of a pod.
properties:
name:
description: Required.
type: string
value:
type: string
type: object
type: array
searches:
description: A list of DNS search domains for host-name lookup.
This will be appended to the base search paths generated
from DNSPolicy. Duplicated search paths will be removed.
items:
type: string
type: array
type: object
dnsPolicy:
description: Set DNS policy for the pod. Defaults to "ClusterFirst".
Valid values are 'ClusterFirstWithHostNet', 'ClusterFirst',
'Default' or 'None'. DNS parameters given in DNSConfig will
be merged with the policy selected with DNSPolicy. To have DNS
options set along with hostNetwork, you have to specify DNS
policy explicitly to 'ClusterFirstWithHostNet'.
type: string
enableServiceLinks:
description: 'EnableServiceLinks indicates whether information
about services should be injected into pod''s environment variables,
matching the syntax of Docker links. Optional: Defaults to true.'
type: boolean
ephemeralContainers:
description: List of ephemeral containers run in this pod. Ephemeral
containers may be run in an existing pod to perform user-initiated
actions such as debugging. This list cannot be specified when
creating a pod, and it cannot be modified by updating the pod
spec. In order to add an ephemeral container to an existing
pod, use the pod's ephemeralcontainers subresource. This field
is alpha-level and is only honored by servers that enable the
EphemeralContainers feature.
items:
description: An EphemeralContainer is a container that may be
added temporarily to an existing pod for user-initiated activities
such as debugging. Ephemeral containers have no resource or
scheduling guarantees, and they will not be restarted when
they exit or when a pod is removed or restarted. If an ephemeral
container causes a pod to exceed its resource allocation,
the pod may be evicted. Ephemeral containers may not be added
by directly updating the pod spec. They must be added via
the pod's ephemeralcontainers subresource, and they will appear
in the pod spec once added. This is an alpha feature enabled
by the EphemeralContainers feature flag.
properties:
args:
description: 'Arguments to the entrypoint. The docker image''s
CMD is used if this is not provided. Variable references
$(VAR_NAME) are expanded using the container''s environment.
If a variable cannot be resolved, the reference in the
input string will be unchanged. The $(VAR_NAME) syntax
can be escaped with a double $$, ie: $$(VAR_NAME). Escaped
references will never be expanded, regardless of whether
the variable exists or not. Cannot be updated. More info:
https://kubernetes.io/docs/tasks/inject-data-application/define-command-argument-container/#running-a-command-in-a-shell'
items:
type: string
type: array
command:
description: 'Entrypoint array. Not executed within a shell.
The docker image''s ENTRYPOINT is used if this is not
provided. Variable references $(VAR_NAME) are expanded
using the container''s environment. If a variable cannot
be resolved, the reference in the input string will be
unchanged. The $(VAR_NAME) syntax can be escaped with
a double $$, ie: $$(VAR_NAME). Escaped references will
never be expanded, regardless of whether the variable
exists or not. Cannot be updated. More info: https://kubernetes.io/docs/tasks/inject-data-application/define-command-argument-container/#running-a-command-in-a-shell'
items:
type: string
type: array
env:
description: List of environment variables to set in the
container. Cannot be updated.
items:
description: EnvVar represents an environment variable
present in a Container.
properties:
name:
description: Name of the environment variable. Must
be a C_IDENTIFIER.
type: string
value:
description: 'Variable references $(VAR_NAME) are
expanded using the previous defined environment
variables in the container and any service environment
variables. If a variable cannot be resolved, the
reference in the input string will be unchanged.
The $(VAR_NAME) syntax can be escaped with a double
$$, ie: $$(VAR_NAME). Escaped references will never
be expanded, regardless of whether the variable
exists or not. Defaults to "".'
type: string
valueFrom:
description: Source for the environment variable's
value. Cannot be used if value is not empty.
properties:
configMapKeyRef:
description: Selects a key of a ConfigMap.
properties:
key:
description: The key to select.
type: string
name:
description: 'Name of the referent. More info:
https://kubernetes.io/docs/concepts/overview/working-with-objects/names/#names
TODO: Add other useful fields. apiVersion,
kind, uid?'
type: string
optional:
description: Specify whether the ConfigMap
or its key must be defined
type: boolean
required:
- key
type: object
fieldRef:
description: 'Selects a field of the pod: supports
metadata.name, metadata.namespace, `metadata.labels[''<KEY>'']`,
`metadata.annotations[''<KEY>'']`, spec.nodeName,
spec.serviceAccountName, status.hostIP, status.podIP,
status.podIPs.'
properties:
apiVersion:
description: Version of the schema the FieldPath
is written in terms of, defaults to "v1".
type: string
fieldPath:
description: Path of the field to select in
the specified API version.
type: string
required:
- fieldPath
type: object
resourceFieldRef:
description: 'Selects a resource of the container:
only resources limits and requests (limits.cpu,
limits.memory, limits.ephemeral-storage, requests.cpu,
requests.memory and requests.ephemeral-storage)
are currently supported.'
properties:
containerName:
description: 'Container name: required for
volumes, optional for env vars'
type: string
divisor:
anyOf:
- type: integer
- type: string
description: Specifies the output format of
the exposed resources, defaults to "1"
pattern: ^(\+|-)?(([0-9]+(\.[0-9]*)?)|(\.[0-9]+))(([KMGTPE]i)|[numkMGTPE]|([eE](\+|-)?(([0-9]+(\.[0-9]*)?)|(\.[0-9]+))))?$
x-kubernetes-int-or-string: true
resource:
description: 'Required: resource to select'
type: string
required:
- resource
type: object
secretKeyRef:
description: Selects a key of a secret in the
pod's namespace
properties:
key:
description: The key of the secret to select
from. Must be a valid secret key.
type: string
name:
description: 'Name of the referent. More info:
https://kubernetes.io/docs/concepts/overview/working-with-objects/names/#names
TODO: Add other useful fields. apiVersion,
kind, uid?'
type: string
optional:
description: Specify whether the Secret or
its key must be defined
type: boolean
required:
- key
type: object
type: object
required:
- name
type: object
type: array
envFrom:
description: List of sources to populate environment variables
in the container. The keys defined within a source must
be a C_IDENTIFIER. All invalid keys will be reported as
an event when the container is starting. When a key exists
in multiple sources, the value associated with the last
source will take precedence. Values defined by an Env
with a duplicate key will take precedence. Cannot be updated.
items:
description: EnvFromSource represents the source of a
set of ConfigMaps
properties:
configMapRef:
description: The ConfigMap to select from
properties:
name:
description: 'Name of the referent. More info:
https://kubernetes.io/docs/concepts/overview/working-with-objects/names/#names
TODO: Add other useful fields. apiVersion, kind,
uid?'
type: string
optional:
description: Specify whether the ConfigMap must
be defined
type: boolean
type: object
prefix:
description: An optional identifier to prepend to
each key in the ConfigMap. Must be a C_IDENTIFIER.
type: string
secretRef:
description: The Secret to select from
properties:
name:
description: 'Name of the referent. More info:
https://kubernetes.io/docs/concepts/overview/working-with-objects/names/#names
TODO: Add other useful fields. apiVersion, kind,
uid?'
type: string
optional:
description: Specify whether the Secret must be
defined
type: boolean
type: object
type: object
type: array
image:
description: 'Docker image name. More info: https://kubernetes.io/docs/concepts/containers/images'
type: string
imagePullPolicy:
description: 'Image pull policy. One of Always, Never, IfNotPresent.
Defaults to Always if :latest tag is specified, or IfNotPresent
otherwise. Cannot be updated. More info: https://kubernetes.io/docs/concepts/containers/images#updating-images'
type: string
lifecycle:
description: Lifecycle is not allowed for ephemeral containers.
properties:
postStart:
description: 'PostStart is called immediately after
a container is created. If the handler fails, the
container is terminated and restarted according to
its restart policy. Other management of the container
blocks until the hook completes. More info: https://kubernetes.io/docs/concepts/containers/container-lifecycle-hooks/#container-hooks'
properties:
exec:
description: One and only one of the following should
be specified. Exec specifies the action to take.
properties:
command:
description: Command is the command line to
execute inside the container, the working
directory for the command is root ('/') in
the container's filesystem. The command is
simply exec'd, it is not run inside a shell,
so traditional shell instructions ('|', etc)
won't work. To use a shell, you need to explicitly
call out to that shell. Exit status of 0 is
treated as live/healthy and non-zero is unhealthy.
items:
type: string
type: array
type: object
httpGet:
description: HTTPGet specifies the http request
to perform.
properties:
host:
description: Host name to connect to, defaults
to the pod IP. You probably want to set "Host"
in httpHeaders instead.
type: string
httpHeaders:
description: Custom headers to set in the request.
HTTP allows repeated headers.
items:
description: HTTPHeader describes a custom
header to be used in HTTP probes
properties:
name:
description: The header field name
type: string
value:
description: The header field value
type: string
required:
- name
- value
type: object
type: array
path:
description: Path to access on the HTTP server.
type: string
port:
anyOf:
- type: integer
- type: string
description: Name or number of the port to access
on the container. Number must be in the range
1 to 65535. Name must be an IANA_SVC_NAME.
x-kubernetes-int-or-string: true
scheme:
description: Scheme to use for connecting to
the host. Defaults to HTTP.
type: string
required:
- port
type: object
tcpSocket:
description: 'TCPSocket specifies an action involving
a TCP port. TCP hooks not yet supported TODO:
implement a realistic TCP lifecycle hook'
properties:
host:
description: 'Optional: Host name to connect
to, defaults to the pod IP.'
type: string
port:
anyOf:
- type: integer
- type: string
description: Number or name of the port to access
on the container. Number must be in the range
1 to 65535. Name must be an IANA_SVC_NAME.
x-kubernetes-int-or-string: true
required:
- port
type: object
type: object
preStop:
description: 'PreStop is called immediately before a
container is terminated due to an API request or management
event such as liveness/startup probe failure, preemption,
resource contention, etc. The handler is not called
if the container crashes or exits. The reason for
termination is passed to the handler. The Pod''s termination
grace period countdown begins before the PreStop hooked
is executed. Regardless of the outcome of the handler,
the container will eventually terminate within the
Pod''s termination grace period. Other management
of the container blocks until the hook completes or
until the termination grace period is reached. More
info: https://kubernetes.io/docs/concepts/containers/container-lifecycle-hooks/#container-hooks'
properties:
exec:
description: One and only one of the following should
be specified. Exec specifies the action to take.
properties:
command:
description: Command is the command line to
execute inside the container, the working
directory for the command is root ('/') in
the container's filesystem. The command is
simply exec'd, it is not run inside a shell,
so traditional shell instructions ('|', etc)
won't work. To use a shell, you need to explicitly
call out to that shell. Exit status of 0 is
treated as live/healthy and non-zero is unhealthy.
items:
type: string
type: array
type: object
httpGet:
description: HTTPGet specifies the http request
to perform.
properties:
host:
description: Host name to connect to, defaults
to the pod IP. You probably want to set "Host"
in httpHeaders instead.
type: string
httpHeaders:
description: Custom headers to set in the request.
HTTP allows repeated headers.
items:
description: HTTPHeader describes a custom
header to be used in HTTP probes
properties:
name:
description: The header field name
type: string
value:
description: The header field value
type: string
required:
- name
- value
type: object
type: array
path:
description: Path to access on the HTTP server.
type: string
port:
anyOf:
- type: integer
- type: string
description: Name or number of the port to access
on the container. Number must be in the range
1 to 65535. Name must be an IANA_SVC_NAME.
x-kubernetes-int-or-string: true
scheme:
description: Scheme to use for connecting to
the host. Defaults to HTTP.
type: string
required:
- port
type: object
tcpSocket:
description: 'TCPSocket specifies an action involving
a TCP port. TCP hooks not yet supported TODO:
implement a realistic TCP lifecycle hook'
properties:
host:
description: 'Optional: Host name to connect
to, defaults to the pod IP.'
type: string
port:
anyOf:
- type: integer
- type: string
description: Number or name of the port to access
on the container. Number must be in the range
1 to 65535. Name must be an IANA_SVC_NAME.
x-kubernetes-int-or-string: true
required:
- port
type: object
type: object
type: object
livenessProbe:
description: Probes are not allowed for ephemeral containers.
properties:
exec:
description: One and only one of the following should
be specified. Exec specifies the action to take.
properties:
command:
description: Command is the command line to execute
inside the container, the working directory for
the command is root ('/') in the container's
filesystem. The command is simply exec'd, it is
not run inside a shell, so traditional shell instructions
('|', etc) won't work. To use a shell, you need
to explicitly call out to that shell. Exit status
of 0 is treated as live/healthy and non-zero is
unhealthy.
items:
type: string
type: array
type: object
failureThreshold:
description: Minimum consecutive failures for the probe
to be considered failed after having succeeded. Defaults
to 3. Minimum value is 1.
format: int32
type: integer
httpGet:
description: HTTPGet specifies the http request to perform.
properties:
host:
description: Host name to connect to, defaults to
the pod IP. You probably want to set "Host" in
httpHeaders instead.
type: string
httpHeaders:
description: Custom headers to set in the request.
HTTP allows repeated headers.
items:
description: HTTPHeader describes a custom header
to be used in HTTP probes
properties:
name:
description: The header field name
type: string
value:
description: The header field value
type: string
required:
- name
- value
type: object
type: array
path:
description: Path to access on the HTTP server.
type: string
port:
anyOf:
- type: integer
- type: string
description: Name or number of the port to access
on the container. Number must be in the range
1 to 65535. Name must be an IANA_SVC_NAME.
x-kubernetes-int-or-string: true
scheme:
description: Scheme to use for connecting to the
host. Defaults to HTTP.
type: string
required:
- port
type: object
initialDelaySeconds:
description: 'Number of seconds after the container
has started before liveness probes are initiated.
More info: https://kubernetes.io/docs/concepts/workloads/pods/pod-lifecycle#container-probes'
format: int32
type: integer
periodSeconds:
description: How often (in seconds) to perform the probe.
Default to 10 seconds. Minimum value is 1.
format: int32
type: integer
successThreshold:
description: Minimum consecutive successes for the probe
to be considered successful after having failed. Defaults
to 1. Must be 1 for liveness and startup. Minimum
value is 1.
format: int32
type: integer
tcpSocket:
description: 'TCPSocket specifies an action involving
a TCP port. TCP hooks not yet supported TODO: implement
a realistic TCP lifecycle hook'
properties:
host:
description: 'Optional: Host name to connect to,
defaults to the pod IP.'
type: string
port:
anyOf:
- type: integer
- type: string
description: Number or name of the port to access
on the container. Number must be in the range
1 to 65535. Name must be an IANA_SVC_NAME.
x-kubernetes-int-or-string: true
required:
- port
type: object
terminationGracePeriodSeconds:
description: Optional duration in seconds the pod needs
to terminate gracefully upon probe failure. The grace
period is the duration in seconds after the processes
running in the pod are sent a termination signal and
the time when the processes are forcibly halted with
a kill signal. Set this value longer than the expected
cleanup time for your process. If this value is nil,
the pod's terminationGracePeriodSeconds will be used.
Otherwise, this value overrides the value provided
by the pod spec. Value must be non-negative integer.
The value zero indicates stop immediately via the
kill signal (no opportunity to shut down). This is
an alpha field and requires enabling ProbeTerminationGracePeriod
feature gate.
format: int64
type: integer
timeoutSeconds:
description: 'Number of seconds after which the probe
times out. Defaults to 1 second. Minimum value is
1. More info: https://kubernetes.io/docs/concepts/workloads/pods/pod-lifecycle#container-probes'
format: int32
type: integer
type: object
name:
description: Name of the ephemeral container specified as
a DNS_LABEL. This name must be unique among all containers,
init containers and ephemeral containers.
type: string
ports:
description: Ports are not allowed for ephemeral containers.
items:
description: ContainerPort represents a network port in
a single container.
properties:
containerPort:
description: Number of port to expose on the pod's
IP address. This must be a valid port number, 0
< x < 65536.
format: int32
type: integer
hostIP:
description: What host IP to bind the external port
to.
type: string
hostPort:
description: Number of port to expose on the host.
If specified, this must be a valid port number,
0 < x < 65536. If HostNetwork is specified, this
must match ContainerPort. Most containers do not
need this.
format: int32
type: integer
name:
description: If specified, this must be an IANA_SVC_NAME
and unique within the pod. Each named port in a
pod must have a unique name. Name for the port that
can be referred to by services.
type: string
protocol:
default: TCP
description: Protocol for port. Must be UDP, TCP,
or SCTP. Defaults to "TCP".
type: string
required:
- containerPort
type: object
type: array
readinessProbe:
description: Probes are not allowed for ephemeral containers.
properties:
exec:
description: One and only one of the following should
be specified. Exec specifies the action to take.
properties:
command:
description: Command is the command line to execute
inside the container, the working directory for
the command is root ('/') in the container's
filesystem. The command is simply exec'd, it is
not run inside a shell, so traditional shell instructions
('|', etc) won't work. To use a shell, you need
to explicitly call out to that shell. Exit status
of 0 is treated as live/healthy and non-zero is
unhealthy.
items:
type: string
type: array
type: object
failureThreshold:
description: Minimum consecutive failures for the probe
to be considered failed after having succeeded. Defaults
to 3. Minimum value is 1.
format: int32
type: integer
httpGet:
description: HTTPGet specifies the http request to perform.
properties:
host:
description: Host name to connect to, defaults to
the pod IP. You probably want to set "Host" in
httpHeaders instead.
type: string
httpHeaders:
description: Custom headers to set in the request.
HTTP allows repeated headers.
items:
description: HTTPHeader describes a custom header
to be used in HTTP probes
properties:
name:
description: The header field name
type: string
value:
description: The header field value
type: string
required:
- name
- value
type: object
type: array
path:
description: Path to access on the HTTP server.
type: string
port:
anyOf:
- type: integer
- type: string
description: Name or number of the port to access
on the container. Number must be in the range
1 to 65535. Name must be an IANA_SVC_NAME.
x-kubernetes-int-or-string: true
scheme:
description: Scheme to use for connecting to the
host. Defaults to HTTP.
type: string
required:
- port
type: object
initialDelaySeconds:
description: 'Number of seconds after the container
has started before liveness probes are initiated.
More info: https://kubernetes.io/docs/concepts/workloads/pods/pod-lifecycle#container-probes'
format: int32
type: integer
periodSeconds:
description: How often (in seconds) to perform the probe.
Default to 10 seconds. Minimum value is 1.
format: int32
type: integer
successThreshold:
description: Minimum consecutive successes for the probe
to be considered successful after having failed. Defaults
to 1. Must be 1 for liveness and startup. Minimum
value is 1.
format: int32
type: integer
tcpSocket:
description: 'TCPSocket specifies an action involving
a TCP port. TCP hooks not yet supported TODO: implement
a realistic TCP lifecycle hook'
properties:
host:
description: 'Optional: Host name to connect to,
defaults to the pod IP.'
type: string
port:
anyOf:
- type: integer
- type: string
description: Number or name of the port to access
on the container. Number must be in the range
1 to 65535. Name must be an IANA_SVC_NAME.
x-kubernetes-int-or-string: true
required:
- port
type: object
terminationGracePeriodSeconds:
description: Optional duration in seconds the pod needs
to terminate gracefully upon probe failure. The grace
period is the duration in seconds after the processes
running in the pod are sent a termination signal and
the time when the processes are forcibly halted with
a kill signal. Set this value longer than the expected
cleanup time for your process. If this value is nil,
the pod's terminationGracePeriodSeconds will be used.
Otherwise, this value overrides the value provided
by the pod spec. Value must be non-negative integer.
The value zero indicates stop immediately via the
kill signal (no opportunity to shut down). This is
an alpha field and requires enabling ProbeTerminationGracePeriod
feature gate.
format: int64
type: integer
timeoutSeconds:
description: 'Number of seconds after which the probe
times out. Defaults to 1 second. Minimum value is
1. More info: https://kubernetes.io/docs/concepts/workloads/pods/pod-lifecycle#container-probes'
format: int32
type: integer
type: object
resources:
description: Resources are not allowed for ephemeral containers.
Ephemeral containers use spare resources already allocated
to the pod.
properties:
limits:
additionalProperties:
anyOf:
- type: integer
- type: string
pattern: ^(\+|-)?(([0-9]+(\.[0-9]*)?)|(\.[0-9]+))(([KMGTPE]i)|[numkMGTPE]|([eE](\+|-)?(([0-9]+(\.[0-9]*)?)|(\.[0-9]+))))?$
x-kubernetes-int-or-string: true
description: 'Limits describes the maximum amount of
compute resources allowed. More info: https://kubernetes.io/docs/concepts/configuration/manage-resources-containers/'
type: object
requests:
additionalProperties:
anyOf:
- type: integer
- type: string
pattern: ^(\+|-)?(([0-9]+(\.[0-9]*)?)|(\.[0-9]+))(([KMGTPE]i)|[numkMGTPE]|([eE](\+|-)?(([0-9]+(\.[0-9]*)?)|(\.[0-9]+))))?$
x-kubernetes-int-or-string: true
description: 'Requests describes the minimum amount
of compute resources required. If Requests is omitted
for a container, it defaults to Limits if that is
explicitly specified, otherwise to an implementation-defined
value. More info: https://kubernetes.io/docs/concepts/configuration/manage-resources-containers/'
type: object
type: object
securityContext:
description: SecurityContext is not allowed for ephemeral
containers.
properties:
allowPrivilegeEscalation:
description: 'AllowPrivilegeEscalation controls whether
a process can gain more privileges than its parent
process. This bool directly controls if the no_new_privs
flag will be set on the container process. AllowPrivilegeEscalation
is true always when the container is: 1) run as Privileged
2) has CAP_SYS_ADMIN'
type: boolean
capabilities:
description: The capabilities to add/drop when running
containers. Defaults to the default set of capabilities
granted by the container runtime.
properties:
add:
description: Added capabilities
items:
description: Capability represent POSIX capabilities
type
type: string
type: array
drop:
description: Removed capabilities
items:
description: Capability represent POSIX capabilities
type
type: string
type: array
type: object
privileged:
description: Run container in privileged mode. Processes
in privileged containers are essentially equivalent
to root on the host. Defaults to false.
type: boolean
procMount:
description: procMount denotes the type of proc mount
to use for the containers. The default is DefaultProcMount
which uses the container runtime defaults for readonly
paths and masked paths. This requires the ProcMountType
feature flag to be enabled.
type: string
readOnlyRootFilesystem:
description: Whether this container has a read-only
root filesystem. Default is false.
type: boolean
runAsGroup:
description: The GID to run the entrypoint of the container
process. Uses runtime default if unset. May also be
set in PodSecurityContext. If set in both SecurityContext
and PodSecurityContext, the value specified in SecurityContext
takes precedence.
format: int64
type: integer
runAsNonRoot:
description: Indicates that the container must run as
a non-root user. If true, the Kubelet will validate
the image at runtime to ensure that it does not run
as UID 0 (root) and fail to start the container if
it does. If unset or false, no such validation will
be performed. May also be set in PodSecurityContext. If
set in both SecurityContext and PodSecurityContext,
the value specified in SecurityContext takes precedence.
type: boolean
runAsUser:
description: The UID to run the entrypoint of the container
process. Defaults to user specified in image metadata
if unspecified. May also be set in PodSecurityContext. If
set in both SecurityContext and PodSecurityContext,
the value specified in SecurityContext takes precedence.
format: int64
type: integer
seLinuxOptions:
description: The SELinux context to be applied to the
container. If unspecified, the container runtime will
allocate a random SELinux context for each container. May
also be set in PodSecurityContext. If set in both
SecurityContext and PodSecurityContext, the value
specified in SecurityContext takes precedence.
properties:
level:
description: Level is SELinux level label that applies
to the container.
type: string
role:
description: Role is a SELinux role label that applies
to the container.
type: string
type:
description: Type is a SELinux type label that applies
to the container.
type: string
user:
description: User is a SELinux user label that applies
to the container.
type: string
type: object
seccompProfile:
description: The seccomp options to use by this container.
If seccomp options are provided at both the pod &
container level, the container options override the
pod options.
properties:
localhostProfile:
description: localhostProfile indicates a profile
defined in a file on the node should be used.
The profile must be preconfigured on the node
to work. Must be a descending path, relative to
the kubelet's configured seccomp profile location.
Must only be set if type is "Localhost".
type: string
type:
description: "type indicates which kind of seccomp
profile will be applied. Valid options are: \n
Localhost - a profile defined in a file on the
node should be used. RuntimeDefault - the container
runtime default profile should be used. Unconfined
- no profile should be applied."
type: string
required:
- type
type: object
windowsOptions:
description: The Windows specific settings applied to
all containers. If unspecified, the options from the
PodSecurityContext will be used. If set in both SecurityContext
and PodSecurityContext, the value specified in SecurityContext
takes precedence.
properties:
gmsaCredentialSpec:
description: GMSACredentialSpec is where the GMSA
admission webhook (https://github.com/kubernetes-sigs/windows-gmsa)
inlines the contents of the GMSA credential spec
named by the GMSACredentialSpecName field.
type: string
gmsaCredentialSpecName:（2）使用Prometheus，但没使用Prometheus Operator（内容太多，只展示名字）
kuberhealthy-prometheus.yaml
（3）使用Prometheus Operator（内容太多，只展示名字）
kuberhealthy-prometheus-operator.yaml
（2）使用Helm安装
# 步骤一 在Kubernetes集群/上下文中创建命名空间“kuberhealthy”：
kubectl create namespace kuberhealthy
# 步骤二 将kuberhealthy repo添加到Helm
helm repo add kuberhealthy https://kuberhealthy.github.io/kuberhealthy/helm-repos步骤三：根据你的Prometheus实现，使用适当的命令为你的集群安装kuberhealthy：
（1）如果有Prometheus，而没使用Prometheus操作器
helm install --set prometheus.enabled=true -n kuberhealthy kuberhealthy kuberhealthy/kuberhealthy（2）如果使用Prometheus操作器
helm install --set prometheus.enabled=true --set prometheus.serviceMonitor.enabled=true -n kuberhealthy kuberhealthy kuberhealthy/kuberhealthy使用步骤
3.1 查看Kuberhealthy pod
使用下面的命令查看Kuberhealthy pod
kubectl -n kuberhealthy get pod
3.2 配置额外的检查
接下来，你可以运行下面的命令，你应该会看到三个Kuberhealthy检查默认安装:
kubectl get khchecks.comcast.github.io -n kuberhealthy
- daemonset：部署并拆除一个daemonset，以确保集群中的所有节点都能正常工作。
- deployment：创建部署，然后触发滚动更新。测试部署是否可以通过服务访问，然后删除所有内容。此过程中的任何问题都将导致此检查报告失败。
- dn-status-internal：验证内部集群DNS是否按预期运行。
3.3 状态查看
kuberhealthy默认会提供一个json格式的状态页面和metrics端点供我们查看状态。
之前部署之后会创建一个service，type类型为loadblance，我们实际使用可能需要修改
（1）访问json格式的状态页面
首先使用下面命令查看创建的的service
kubectl -n kuberhealthy get svc
接着访问json状态页面
（2）访问metrices
四、常见问题
Q1：使用yaml文件方式安装时，执行kubectl apply -f kuberhealthy.yaml遇到以下问题：
分析：
该yaml文件中需要拉取DockerHub的镜像包，但由于本地环境无法联网导致拉取镜像包失败
解决：
通过可以联网的主机下载镜像包后，移动到本地环境，手动加载镜像包
五、资料出处
- https://github.com/kuberhealthy/kuberhealthy
- https://cloud.tencent.com/developer/article/1638832
- https://cloud.tencent.com/developer/article/1661209
- Kuberhealthy 一个还不错的健康检查 operator
- https://mp.weixin.qq.com/s/jqROe-HQnDcHw2VPaAw-1g
- https://github.com/kuberhealthy/kuberhealthy/blob/master/docs/K8s-KPIs-with-Kuberhealthy.md
扫一扫
321
被折叠的 条评论
为什么被折叠?
到【灌水乐园】发言
