frameworks/base/packages/SettingsProvider/res/values/defaults.xml

<bool name="def_bluetooth_on">false</bool>

将 def_bluetooth_on 的值设为true,打开蓝牙

adb动态设置

adb shell settings put global bluetooth_on 0 #关闭
adb shell settings put global bluetooth_on 1 #打开
adb shell settings get global bluetooth_on #查询

打开蓝牙

am start -a android.bluetooth.adapter.action.REQUEST_ENABLE

查看蓝牙状态

service list | grep bluetooth
dumpsys package com.android.bluetooth | grep "version"
dumpsys bluetooth_manager
logcat -s BluetoothManager

问题：为什么Settings界面的打开蓝牙图标，测试机不能Scan到对端设备？
Android默认的行为是：只有在setting->bluetooth界面，才会开启蓝牙的可见性。
只在 status bar打开BT的话，是不会开启蓝牙可见性的。还需要可见性设置，确保已经将可见性设置为“可被发现”或“可连接和可被发现”

打开bluetooth可见性，设置为可连接和可被发现

android12/packages/apps/Bluetooth/src/com/android/bluetooth/btservice/AdapterProperties.java

    void onBluetoothReady() {
        debugLog("onBluetoothReady, state=" + BluetoothAdapter.nameForState(getState())
                + ", ScanMode=" + mScanMode);

        synchronized (mObject) {
            // Reset adapter and profile connection states
            setConnectionState(BluetoothAdapter.STATE_DISCONNECTED);
            mProfileConnectionState.clear();
            invalidateGetProfileConnectionStateCache();
            mProfilesConnected = 0;
            mProfilesConnecting = 0;
            mProfilesDisconnecting = 0;
            // adapterPropertyChangedCallback has already been received.  Set the scan mode.
            // setScanMode(AbstractionLayer.BT_SCAN_MODE_CONNECTABLE);/*可连接*/
            setScanMode(AbstractionLayer.BT_SCAN_MODE_CONNECTABLE_DISCOVERABLE); /*可连接和可被发现*/
            // This keeps NV up-to date on first-boot after flash.
            setDiscoverableTimeout(mDiscoverableTimeout);
        }
    }
