开售RV1126B

RV1126B 视觉处理器规格
CPU
• Quad core ARM Cortex-A53
• RISC-V MCU 300MHz
NPU
• 3Tops, support INT8/ INT16/FP16
Memory
• 32bit DDR3/DDR3L/LPDDR3/
DDR4/LPDDR4
• Support eMMC 4.51, SPI Flash, Nand Flash
• Support fast booting
Display
• MIPI-DSI/RGB interface，up to 1080P60fps
2D Graphics Engine
• Support rotation , x-mirror , y-mirror
• Support alpha blending
• Support scale down/up
Multi-Media
• 12M AI-ISP 3.x with 2F HDR(Line-based/Frame- based/DCG)
• Support 4*MIPI CSI /sub LVDS
• DVP interface with BT.656/BT.1120
• 4K H.264/H.265 30fps video encoder
• 3840 x 2160@30 fps+720p@30 fps encoding
• 4K H.264/H.265 30fps video decoder
• 3840 x 2160@30 encoding + 3840 x
2160@30 fps decoding
External interface
• RGMII interface with TSO network acceleration,
embedded RMII Ethernet PHY
• USB 3.0 OTG and USB 2.0 host
• Dual SDIO 3.0 interface for Wi-Fi and SD card
Availability
• ES 2025 Q1
• RV1126B1 pin2pin RV1126
• RV1126B2 fully functional
