【软件模块】适用于所有单片机的按键扫描算法

---

前言

单片机按键扫描是指利用微控制器（MCU）的数字输入口，定期检测按键的电平状态并进行去抖动处理（防止误操作），判断按键是否被按下或松开。

常用的按键有两种：自复式按键和自锁式按键。自复式按键按下就通，松开就断，不会锁住。自锁式按键按下一次就通并锁住，再按一次就断并弹回，需要两次操作。

本文介绍一种用于自复式按键的扫描算法，它有软件消抖功能，可以检测按键的短按和长按检测。

---

一、算法设计

针对每一个独立按键，使用三个bits来标志按键的各个状态的转换：

1. TrigFlag：按键被按下的触发标志，仅在按键被第一次检测到按下时置位为1，其它状态保持为0
2. IdleFlag：按键被松开的触发标志，仅在按键被第一次检测到松开时置位为1，其它状态保持为0
3. ContFlag：按键实时的状态标志，按键被检测到按下时为1，被检测到松开时为0
4. ReadBit：扫描检测到的按键状态，按下时为1，松开时为0

以下一次按键过程中，这三个标志的状态变化情况：

过程分析：

1. 初始状态下，扫描按键状态ReadBit = 0，状态标志TrigFlag = 0,IdleFlag = 0,ContFlag = 0;
2. 按下按键后，扫描按键状态ReadBit = 1，经计算处理TrigFlag = 1,IdleFlag = 0,ContFlag = 1;
3. 再次扫描按键状态（消抖）ReadBit = 1，经计算处理TrigFlag = 0,IdleFlag = 0,ContFlag = 1，
   标志由TrigFlag = 1,IdleFlag = 0,ContFlag = 1变到TrigFlag = 0,IdleFlag = 0,ContFlag = 1可以判断按键被按下;
4. 保持按键按下，扫描按键状态ReadBit = 1，状态标志也将保持TrigFlag = 0,IdleFlag = 0,ContFlag = 1不再变化;
5. 状态标志将保持为TrigFlag = 0,IdleFlag = 0,ContFlag = 1的时间达到设置的按键长按时间，可以判断按键被长按;
6. 当松开按键后，扫描按键状态ReadBit = 0，经计算处理TrigFlag = 0,IdleFlag = 1,ContFlag = 0;
7. 再次扫描按键状态（消抖）ReadBit = 0，经计算处理TrigFlag = 0,IdleFlag = 0,ContFlag = 0，
   标志由TrigFlag = 0,IdleFlag = 1,ContFlag = 0变到TrigFlag = 0,IdleFlag = 0,ContFlag = 1可以判断按键被松开;
8. 最后，按键状态将回到初始的松开状态ReadBit = 0，状态标志TrigFlag = 0,IdleFlag = 0,ContFlag = 0.

根据上述过程的第3，5，7步的状态变化，就确定出按键的真实工作状态。

二、代码实现

根据上述原理，使用C语言实现了该按键扫描算法，完整代码如下：

头文件：bsp_key.h

/**
 * @file bsp_key.h
 * @author Sean
 * @brief The header file of key-scanning driver.
 * @version 0.1
 * @date 2023-02-28
 *
 * @copyright Copyright (c) 2023
 *
 */
#ifndef __BSP_KEY_H__
#define __BSP_KEY_H__

#include <stdint.h>

// typedef for interface: function for scanning the key, return 1 means the key is pressed, 0 means the key is not pressed.
typedef uint8_t (*key_scan)(void);
// typedef for interface: function for callback when short press the key.
typedef void (*key_call_trig)(void);
// typedef for interface: function for callback when long press the key.
typedef void (*key_call_cont)(void);

// typedef for key config bit struct
typedef struct
{
    // User set this bit for enable/disable the key keep press callback function.
    uint8_t bitEnableTrig : 1;
    // User set this bit for enable/disable the key long press callback function.
    uint8_t bitEnableCont : 1;

    // Handle task will use this bits, user not need to handle it.
    uint8_t bitTrigLast : 1;
    uint8_t bitIdleLast : 1;
    uint8_t bitContLast : 1;
    uint8_t bitTrig : 1;
    uint8_t bitIdle : 1;
    uint8_t bitCont : 1;
} KeyConfig_b;

// typedef for key handle struct
typedef struct
{
    // key config bit struct.
    KeyConfig_b bitKeyConfig;
    // Time for trigger long press = u16LongTrig * time between key_handle() calls.
    const uint16_t u16LongTrig;

    // Define the interface function.
    key_scan key_scan_func;
    key_call_trig key_call_trig_func;
    key_call_cont key_call_cont_func;
} key_config_t;

// Handle key task, this function should be called every 5-10ms generally.
void key_handle(key_config_t *ctx);

#endif // __BSP_KEY_H__

源文件：bsp_key.c

/**
 * @file bsp_key.c
 * @author Sean
 * @brief The source file of key-scanning driver.
 * @version 0.1
 * @date 2023-02-28
 *
 * @copyright Copyright (c) 2023
 *
 */

#include "bsp_key.h"

/**
 * @brief Handle key task.
 *
 * @warning This function should be called every 5-10ms generally, you can also make adjustments based on your keys.
 *
 * @param ctx Interface definitions.(ptr)
 *
 */
void key_handle(key_config_t *ctx)
{
    uint8_t u8ReadKey = 0;
    static uint8_t u8PressType = 0;
    static uint16_t u16LongTrig = 0;

    // Check if interface functions are set.
    if (ctx->key_scan_func == NULL || ctx->key_call_trig_func == NULL || ctx->key_call_cont_func == NULL)
    {
        return;
    }

    // Backup last states of keys.
    ctx->bitKeyConfig.bitTrigLast = ctx->bitKeyConfig.bitTrig;
    ctx->bitKeyConfig.bitIdleLast = ctx->bitKeyConfig.bitIdle;
    ctx->bitKeyConfig.bitContLast = ctx->bitKeyConfig.bitCont;

    // Scan the states of keys and handle the current states of the keys.
    u8ReadKey = (ctx->key_scan_func() == 0 ? 0 : 1);
    ctx->bitKeyConfig.bitTrig = u8ReadKey & (u8ReadKey ^ ctx->bitKeyConfig.bitCont);
    ctx->bitKeyConfig.bitIdle = u8ReadKey ^ (u8ReadKey | ctx->bitKeyConfig.bitCont);
    ctx->bitKeyConfig.bitCont = u8ReadKey;

    // Check if the key is pressed.
    if (ctx->bitKeyConfig.bitTrigLast == 1 && ctx->bitKeyConfig.bitIdleLast == 0 && ctx->bitKeyConfig.bitContLast == 1)
    {
        if (ctx->bitKeyConfig.bitTrig == 0 && ctx->bitKeyConfig.bitIdle == 0 && ctx->bitKeyConfig.bitCont == 1)
        {
            // check short press.
            if (ctx->bitKeyConfig.bitEnableTrig == 1)
            {
                if(ctx->bitKeyConfig.bitEnableCont == 1)
                    u8PressType = 1;
                else
                    ctx->key_call_trig_func();
            }
        }
    }

    // Check if the key is keep pressed.
    if (ctx->bitKeyConfig.bitTrigLast == 0 && ctx->bitKeyConfig.bitIdleLast == 0 && ctx->bitKeyConfig.bitContLast == 1)
    {
        if (ctx->bitKeyConfig.bitTrig == 0 && ctx->bitKeyConfig.bitIdle == 0 && ctx->bitKeyConfig.bitCont == 1)
        {
            // check long press.
            if (ctx->bitKeyConfig.bitEnableCont == 1)
            {
                if (u16LongTrig < ctx->u16LongTrig)
                {
                    if (++u16LongTrig >= ctx->u16LongTrig)
                    {
                        u8PressType = 0;
                        ctx->key_call_cont_func();
                    }
                }
            }
        }
    }

    // Check if the key is released.
    if (ctx->bitKeyConfig.bitTrigLast == 0 && ctx->bitKeyConfig.bitIdleLast == 1 && ctx->bitKeyConfig.bitContLast == 0)
    {
        if (ctx->bitKeyConfig.bitTrig == 0 && ctx->bitKeyConfig.bitIdle == 0 && ctx->bitKeyConfig.bitCont == 0)
        {
            if(u8PressType == 1)
                ctx->key_call_trig_func();

            //ctx->key_call_idle_func();
            u8PressType = 0;
            u16LongTrig = 0;
        }
    }
}

注意：如果只使能按键短按检测，按键短按的回调函数将在按键被按下时调用；如果只使能按键长按检测，按键长按的回调函数将在按键被按下到达设定的时间后调用；如果同时使能按键短按和长按检测，按键短按的回调函数将在按键被松开时调用，按键长按的回调函数将在按键被按下到达设定的时间后调用。

使用方法

1. 将代码文件拷贝到工程目录，并包含bsp_key.h头文件。

#include "bsp_key.h"

2. 先实现自己的按键状态检测函数uint8_t u8KeyScan(void), 按键短按回调函数void vKeyShort(void)和按键长按回调函数void vKeyLong(void)，然后定义一个按键配置的结构体pkey_config，结构体中pkey_config.bitKeyConfig.bitEnableTrig为使能按键短按检测控制位，pkey_config.bitKeyConfig.bitEnableCont为使能按键长按检测控制位，pkey_config.u16LongTrig为设置按键长按检测时间（实际时间 = key_handle()函数调用间隔时间 * pkey_config.u16LongTrig），pkey_config.key_scan_func,pkey_config.key_call_trig_func和pkey_config.key_call_cont_func分别为注册自己实现的三个接口函数。

// Function list
uint8_t u8KeyScan(void);
void vKeyShort(void);
void vKeyLong(void);

// Global variable
key_config_t pkey_config = {
    .bitKeyConfig = {
        .bitEnableTrig = 1,  // Enable button short prass detection
        .bitEnableCont = 1,  // Enable button long prass detection
    },
    .u16LongTrig = 1000,  // Set long prass detection time = 1000 * 5ms(key_handle() is called every 5ms)
    .key_scan_func = u8KeyScan,  // Register interface function
    .key_call_trig_func = vKeyShort,  // Register callback function
    .key_call_cont_func = vKeyLong};  // Register callback function

/**
 * @brief The interface of key scan.
 *
 * @return uint8_t The state of key, 1: key down, 0: key up.
 */
uint8_t u8KeyScan(void)
{
    return (get_boot_key() == 0 ? 0x01 : 0x00);
}

/**
 * @brief The callback interface of key short.
 *
 */
void vKeyShort(void)
{
    led_toggle(LED5);
    ESP_LOGI(TAG, "Key has been short pressed, Led5 have been toggle.");
}

/**
 * @brief The callback interface of key long.
 *
 */
void vKeyLong(void)
{
    led_toggle(LED4);
    ESP_LOGI(TAG, "Key has been long pressed, Led4 have been toggle.");
}

3. 在main（）函数中定时调用key_handle（）函数，注意具体间隔时间可能需要按照使用按键的类型做一定调整。

/**
 * @brief Main function.
 *
 * @param pvParameters
 */
void main(void)
{
    // Initialize the gpio of key.
    gpio_init();
    while (1)
    {
        // put your main code here, to run Keepedly.
        key_handle(&pkey_config);
        vDelay_ms(5);
    }
}

---

参考资料

1.新型的按键扫描程序，仅三行程序：https://www.amobbs.com/thread-4308630-1-1.html
