Android 录音/切换麦克风

Android 录音/切换麦克风

    private AudioRecord getAudioRecord() {
        final int SAMPLE_RATE = 16000;
        final int WAVE_FRAM_SIZE = 20 * 2 * 16000 / 1000; //20ms audio for 16k/16bit/mono
        try {
            int bufferSize = AudioRecord.getMinBufferSize(16000, AudioFormat.CHANNEL_IN_MONO, AudioFormat.ENCODING_PCM_16BIT);
//            AudioRecord recorder = new AudioRecord(MediaRecorder.AudioSource.DEFAULT, 16000, AudioFormat.CHANNEL_IN_MONO, AudioFormat.ENCODING_PCM_16BIT, bufferSize);

            AudioRecord recorder = new AudioRecord(MediaRecorder.AudioSource.DEFAULT, SAMPLE_RATE,
                    AudioFormat.CHANNEL_IN_MONO, AudioFormat.ENCODING_PCM_16BIT, WAVE_FRAM_SIZE * 4);

            if (recorder.getState() == AudioRecord.STATE_INITIALIZED) {
                return recorder;
            }
        } catch (Exception e) {
            Log.e(TAG, "Error in Audio Record");
        }
        return null;
    }

切换麦克风

当设备中有多个麦克风时，我们希望切换到另一个麦克风，可以采用此方法。

AudioRecord audioRecord = new AudioRecord(MediaRecorder.AudioSource.MIC, 16000, AudioFormat.CHANNEL_IN_MONO, AudioFormat.ENCODING_PCM_16BIT, 16000 * 4);

        AudioManager audioManager = (AudioManager) MainApplication.getContext().getSystemService(Context.AUDIO_SERVICE);
        AudioDeviceInfo[] audioDeviceInfos = new AudioDeviceInfo[]{};
        audioDeviceInfos = audioManager.getDevices(AudioManager.GET_DEVICES_INPUTS);
        for (AudioDeviceInfo device : audioDeviceInfos) {
            if (device.getType() == AudioDeviceInfo.TYPE_USB_DEVICE && device.getProductName().equals("USB-Audio - USB PnP Sound Device")) {
                audioRecord.setPreferredDevice(device);
                Log.d(TAG, "Set microphone: " + device.getProductName());
            }

            Log.d(TAG, device.getId() + " | " + device.getProductName() + " | " + device.getType());
        }
        audioRecord.startRecording();
        Log.d(TAG, "AudioRecord state: " + audioRecord.getState());

        if (audioRecord.getState() != AudioRecord.STATE_INITIALIZED) {
            Log.e(TAG, "audio recorder not init");
        } else {
            byte[] audioData = new byte[1024];
            for (int i = 0; i < 100; i++) {
                int ret = audioRecord.read(audioData, 0, 1024);
                Log.d(TAG, String.valueOf(audioData));
            }
        }

 声卡


rk3288:/ $ cd /dev/snd/
rk3288:/dev/snd $ ls
controlC0 pcmC0D0c pcmC0D0p pcmC0D1p timer



3.5.1. 播放

播放测试


aiv8167sm3_bsp:/storage/emulated/0 # tinyplay zai.wav
Playing sample: 1 ch, 16000 hz, 16 bit




tinyplay netkiller.wav -D 0 -d 0 -r 48000 -c 2

aiv8167sm3_bsp:/storage/emulated/0 # tinyplay zai.wav -D 0 -d 0 -r 48000
Playing sample: 1 ch, 16000 hz, 16 bit




neo@MacBook-Pro-M2 tmp % adb shell tinyplay /sdcard/zai.wav
Playing sample: 1 ch, 16000 hz, 16 bit



3.5.2. 录音

录音测试


tinycap netkiller.wav -D 0 -d 0 -c 1 -r 48000




-D  card        声卡

-d  device     设备

-c  channels  通道

-r  rate   采样率

-b  bits   pcm 位宽

-p  period_size   一次中断的帧数

-n  n_periods     周期数

例子： tinycap /sdcard/test.pcm -D 0 -d 0 -c 4 -r 48000 -b 32 -p 768 -n 10

声卡0；设备0；四通道；48K采样率；32位位宽；一帧数据存储大小；采样n次



查看录音设备


neo@MacBook-Pro-M2 tmp % adb shell ls "/dev/snd/pcmC*c"
/dev/snd/pcmC0D10c
/dev/snd/pcmC0D1c
/dev/snd/pcmC0D2c
/dev/snd/pcmC0D4c
/dev/snd/pcmC0D6c
/dev/snd/pcmC0D8c
/dev/snd/pcmC0D9c



默认录音参数 Capturing sample: 2 ch, 44100 hz, 16 bit


neo@MacBook-Pro-M2 tmp % adb shell tinycap /sdcard/file.pcm -D 0 -d 2 -T 5
Capturing sample: 2 ch, 44100 hz, 16 bit
Captured 0 frames



指定参数


neo@MacBook-Pro-M2 tmp % adb pull /sdcard/file.pcm
/sdcard/file.wav: 1 file pulled, 0 skipped. 14.6 MB/s
