流量监控工具iftop简单安装、使用

系统：Centos7

安装

• 安装依赖

  yum install -y flex byacc libpcap ncurses-devel libpcap-devel gcc


• 下载安装包

   wget http://www.ex-parrot.com/pdw/iftop/download/iftop-1.0pre4.tar.gz


• 编译安装

  tar zxvf iftop-1.0pre4.tar.gz
  cd iftop-1.0pre4
  ./configure
  make && make install


使用

• 测试

  iftop -B  ()




• 控制台打印说明

  <="与"=>"，表示的是流量的方向
  "TX"：出站的流量
  "RX"：进站流量
  "TOTAL"：发送接收总流量
  "rates"：流量平均速率


• 命令行参数

  iftop: display bandwidth usage on an interface by host

  Synopsis: iftop -h | [-npblNBP] [-i interface] [-f filter code]
                                 [-F net/mask] [-G net6/mask6]

     -h                  display this message
     -n                  don't do hostname lookups
     -N                  don't convert port numbers to services
     -p                  run in promiscuous mode (show traffic between other
                         hosts on the same network segment)
     -b                  don't display a bar graph of traffic
     -B                  Display bandwidth in bytes
     -i interface        listen on named interface
     -f filter code      use filter code to select packets to count
                         (default: none, but only IP packets are counted)
     -F net/mask         show traffic flows in/out of IPv4 network
     -G net6/mask6       show traffic flows in/out of IPv6 network
     -l                  display and count link-local IPv6 traffic (default: off)
     -P                  show ports as well as hosts
     -m limit            sets the upper limit for the bandwidth scale
     -c config file      specifies an alternative configuration file
     -t                  use text interface without ncurses

     Sorting orders:
     -o 2s                Sort by first column (2s traffic average)
     -o 10s               Sort by second column (10s traffic average) [default]
     -o 40s               Sort by third column (40s traffic average)
     -o source            Sort by source address
     -o destination       Sort by destination address

     The following options are only available in combination with -t
     -s num              print one single text output afer num seconds, then quit
     -L num              number of lines to print

  iftop, version 1.0pre4


• 查询固定某一IP流量的命令示例

  iftop -B -F 10.58.22.71/32
