Style Transfer

风格迁移首次提出来自这篇论文：A Neural Algorithm of Artistic Style。文中作者提出了一个假设：图像的内容(content)和风格(style)可分离。在一个收敛的深度神经网络中，例如VGG19、Inception等等中，1.图像的内容(content)信息主要保留在模型每层输出中。2.图像的风格(style)在模型多层次输出共同表示。基于这个假设，作者通过一个简单的图像重建实验来证明以上假设。内容重建：基于模型浅层输出矩阵重建图像可以很好的还原图，基于模型深层输出矩阵重建的图像只能还原图像的整体轮廓，但是细节是缺失的。风格重建：基于模型多个不同层次的输出(由浅到深)重建图像，不同尺度输入越多，图像重建的风格跟原图越匹配，但是全局排列信息丢失。

基于假设和实验作者提出的图像合成方法：

首先准备一个训练好的图像识别模型例如：VGG19,只用到卷积、池化和激活后输出的特征表示(矩阵)
$\vec{x}$ ,噪声图像输入模型后特征响应的输出，每层特征映射(矩阵)数量记为： $N_l$ ，每层特征矩阵大小记为： $M_l$
- 每层的特征表示记为： $F^l \in \mathcal{R}^{N_l \times M_l}$ , $F_{ij}^l$ :表示为第 $l$ 层，第 $i$ 的卷积第 $j$ 个位置的卷积输出
- $\vec{p}$ : 表示目标内容图像输入模型后各层特征输出， $P^l$ : 目标图像第 $l$ 层特征输出
然后通过梯度下降算法，找到一个跟目标图像特征响应(表示)匹配的图像，通过最下化输入图像和目标图像特征响应之间的距离(误差）
内容损失函数(content loss)
- $\mathcal{L}_{content}(\vec{x},\vec{p},l) = \frac{1}{2}\sum_{i,j}(F_{ij}^l - P_{ij}^l)^2$

$\vec{a}$ : 目标风格图像输入CNN模型后各层的特征响应输出
风格表示：风格量化，计算各层输出之间的相关性，Gram 矩阵来表示： $\in \mathcal{R}^{N_l \times N_l}$
- $G^l$ 第 $l$ 层特征响应之间的Gram矩阵，特征向量之间的内积： $G_{ij}^l = \sum_k F_{ik}^l F_{jk}^l$
$A^l$ : 目标风格图像各层特征响应的Gram矩阵
$G^l$ : 输入噪声图像各层特征响应的Gram矩阵
同上基于梯度下降算法找到一个跟目标图像风格匹配的图像，通过最小化输入图像和生成目标图像的特征响应的Gram 矩阵间的距离
风格损失函数(style loss)
- $E_l = \frac{1}{4N_l^2M_l^2}\sum_{i,j}(G^l_{ij} - A^l_{ij})^2$
- $\mathcal{L}_{style}(\vec{x}, \vec{a}) = \sum_{l}^L w_l E_l$
- $E_l$ ：各层风格损失
- $w_l$ : 各层损失权重

内容和风格的混合，同时最小化Content Loss 和 Style Loss

$\mathcal{L}_{total}(\vec{x},\vec{p},\vec{a}) = \alpha \mathcal{L}_{content}(\vec{x},\vec{p}) + \beta \mathcal{L}_{style}(\vec{x},\vec{a})$

$\alpha、\beta$ 内容和风格的权重

import numpy as np
import tensorflow as tf
import matplotlib.pyplot as plt
from tqdm.notebook import tqdm_notebook
from tensorflow.keras import Model
from tensorflow.keras.preprocessing.image import load_img, img_to_array
from tensorflow.keras.applications.vgg19 import VGG19, preprocess_input

风格迁移

_gram_matirx : 量化计算图像style
_calc_outputs : 计算图像的content和style
_compute_loss : MSE损失
_compute_total_loss : $\alpha \mathcal{Loss}_{content} + \beta \mathcal{Loss}_{style}$
_train_one_step : 计算整体损失和梯度，修改图像
_train : 多轮迭代最小化误差，收集损失，返回结果图像
_post_processing : 图像的后处理

class StyleTransferer:
    def __init__(self, content_layers, style_layers, base_model, optimizer, style_weight = 1e-2, content_weight = 1e4):
        self.content_layers = content_layers
        self.style_layers = style_layers
        self.model = base_model
        self.model.trainable = False
        self.content_weight = content_weight
        self.style_weight = style_weight
        outputs = [self.model.get_layer(name).output for name in (self.content_layers+self.style_layers)]
        self.transfer_model = Model([self.model.input], outputs)
        self.optimizer = optimizer

    def _gram_matrix(self, input_tensor):
        result = tf.linalg.einsum('bijc,bijd->bcd', input_tensor, input_tensor)
        input_shape = tf.shape(input_tensor)
        num_locations = tf.reduce_prod(input_shape[1:3])
        num_locations = tf.cast(num_locations, tf.float32)
        result = result / num_locations
        return result

    def _calc_outputs(self, inputs):
        inputs = inputs * 255.
        preprocessed_input = preprocess_input(inputs)
        outputs = self.transfer_model(preprocessed_input)
        content_outputs = outputs[:len(self.content_layers)]
        style_outputs = outputs[len(self.content_layers):]
        style_outputs = [self._gram_matrix(style_output) for style_output in style_outputs]
        content_dict = {content_name : value for content_name, value in zip(self.content_layers, content_outputs)}
        style_dict = {style_name : value for style_name , value in zip(self.style_layers, style_outputs)}
        return {'content':content_dict, 'style': style_dict}

    def _clip_0_1(self, image):
        return tf.clip_by_value(image, clip_value_min=0.0, clip_value_max=1.0)

    def _compute_loss(self, outputs, targets):
        return tf.add_n([tf.reduce_mean((outputs[key] - targets[key])**2) for key in outputs.keys()])

    def _compute_total_loss(self, outputs, content_targets, style_targets):
        style_outputs = outputs['style']
        content_outputs = outputs['content']
        n_style_layers = len(self.style_layers)
        style_loss = self._compute_loss(style_outputs, style_targets)
        style_loss *= self.style_weight / n_style_layers
        n_content_layers = len(self.content_layers)
        content_loss = self._compute_loss(content_outputs, content_targets)
        content_loss *= self.content_weight / n_content_layers
        return style_loss + content_loss

    @tf.function()
    def _train_one_step(self, image, content_targets, style_targets):
        with tf.GradientTape() as tape:
            outputs = self._calc_outputs(image)
            loss = self._compute_total_loss(outputs, content_targets, style_targets)
        gradient = tape.gradient(loss, image)
        self.optimizer.apply_gradients([(gradient, image)])
        image.assign(self._clip_0_1(image))
        return image, loss

    def _train(self, image, content_targets, style_targets, run_steps):
        loss_history = []
        for _ in tqdm_notebook(range(run_steps)):
            image, loss = self._train_one_step(image, content_targets, style_targets)
            loss_history.append(loss)
        return image, loss_history

    def _post_processing(self, image):
        image = image * 255
        image = np.array(image, dtype=np.uint8)
        if np.ndim(image) > 3:
            image = image[0]
        return image

    def transfer(self, content_image, style_image, run_steps=100):
        content_targets = self._calc_outputs(content_image)['content']
        style_targets = self._calc_outputs(style_image)['style']
        image = tf.Variable(content_image)
        image, loss_history = self._train(image, content_targets, style_targets, run_steps)
        image = self._post_processing(image)
        return image, loss_history

加载VGG19

vgg19 = VGG19(weights="~/keras_weights/vgg19_weights_tf_dim_ordering_tf_kernels_notop.h5", include_top=False)

vgg19.summary()

Model: "vgg19"
_________________________________________________________________
Layer (type)                 Output Shape              Param #
=================================================================
input_1 (InputLayer)         [(None, None, None, 3)]   0
_________________________________________________________________
block1_conv1 (Conv2D)        (None, None, None, 64)    1792
_________________________________________________________________
block1_conv2 (Conv2D)        (None, None, None, 64)    36928
_________________________________________________________________
block1_pool (MaxPooling2D)   (None, None, None, 64)    0
_________________________________________________________________
block2_conv1 (Conv2D)        (None, None, None, 128)   73856
_________________________________________________________________
block2_conv2 (Conv2D)        (None, None, None, 128)   147584
_________________________________________________________________
block2_pool (MaxPooling2D)   (None, None, None, 128)   0
_________________________________________________________________
block3_conv1 (Conv2D)        (None, None, None, 256)   295168
_________________________________________________________________
block3_conv2 (Conv2D)        (None, None, None, 256)   590080
_________________________________________________________________
block3_conv3 (Conv2D)        (None, None, None, 256)   590080
_________________________________________________________________
block3_conv4 (Conv2D)        (None, None, None, 256)   590080
_________________________________________________________________
block3_pool (MaxPooling2D)   (None, None, None, 256)   0
_________________________________________________________________
block4_conv1 (Conv2D)        (None, None, None, 512)   1180160
_________________________________________________________________
block4_conv2 (Conv2D)        (None, None, None, 512)   2359808
_________________________________________________________________
block4_conv3 (Conv2D)        (None, None, None, 512)   2359808
_________________________________________________________________
block4_conv4 (Conv2D)        (None, None, None, 512)   2359808
_________________________________________________________________
block4_pool (MaxPooling2D)   (None, None, None, 512)   0
_________________________________________________________________
block5_conv1 (Conv2D)        (None, None, None, 512)   2359808
_________________________________________________________________
block5_conv2 (Conv2D)        (None, None, None, 512)   2359808
_________________________________________________________________
block5_conv3 (Conv2D)        (None, None, None, 512)   2359808
_________________________________________________________________
block5_conv4 (Conv2D)        (None, None, None, 512)   2359808
_________________________________________________________________
block5_pool (MaxPooling2D)   (None, None, None, 512)   0
=================================================================
Total params: 20,024,384
Trainable params: 20,024,384
Non-trainable params: 0
_________________________________________________________________

测试用例

content image : 《办公室》剧照
style image : 梵高《星空》

在这里插入图片描述

合成图像

$Content_{img}\times \alpha + Style_{img} \times \beta = New_{img}$

eager 模式下运行

tf.config.experimental_run_functions_eagerly(True)

transferer = StyleTransferer(content_layers=['block5_conv2'],
                             style_layers=['block1_conv1', 'block2_conv1', 'block3_conv1', 'block4_conv1', 'block5_conv1'],
                             base_model=vgg19,
                             optimizer= tf.optimizers.Adam(learning_rate=2e-2, beta_1=0.99, epsilon=0.1))

加载并重置图像大小

def load_image(image_path):
    dimension = 540
    image = tf.io.read_file(image_path)
    image = tf.image.decode_jpeg(image, channels=3)
    image = tf.image.convert_image_dtype(image, tf.float32)
    shape = tf.cast(tf.shape(image)[:-1], tf.float32)
    longest_dimension = max(shape)
    scale = dimension / longest_dimension
    new_shape = tf.cast(shape * scale, tf.int32)
    image = tf.image.resize(image, new_shape)
    return image[tf.newaxis,:]

content_img = load_image('./content_image.png')

style_img = load_image('./style_image.jpg')

new_image, loss_history = transferer.transfer(content_img, style_img, run_steps=500)

在这里插入图片描述

合成视频

video_office
