Surface Reference API（表面参考API）：
surf1Dread()：

template<class Type>
Type surf1Dread(surface<void, cudaSurfaceType1D> surfRef,
    int x,
    boundaryMode = cudaBoundaryModeTrap);
template<class Type>
void surf1Dread(Type data,
    surface<void, cudaSurfaceType1D> surfRef,
    int x,
    boundaryMode = cudaBoundaryModeTrap);

使用坐标x读取绑定到一维曲面参考surfRef的CUDA数组。
surf1Dwrite（）：

template<class Type>
void surf1Dwrite(Type data,
    surface<void, cudaSurfaceType1D> surfRef,
    int x,
    boundaryMode = cudaBoundaryModeTrap);

将值数据写入绑定到坐标x处的一维表面参考surfRef的CUDA数组。
surf2Dread()：

template<class Type>
Type surf2Dread(surface<void, cudaSurfaceType2D> surfRef,
    int x, int y,
    boundaryMode = cudaBoundaryModeTrap);
template<class Type>
void surf2Dread(Type* data,
    surface<void, cudaSurfaceType2D> surfRef,
    int x, int y,
    boundaryMode = cudaBoundaryModeTrap);

使用坐标x和y读取绑定到二维曲面参考surfRef的CUDA数组。
surf2Dwrite()：

template<class Type>
void surf3Dwrite(Type data,
    surface<void, cudaSurfaceType3D> surfRef,
    int x, int y, int z,
    boundaryMode = cudaBoundaryModeTrap);

将值数据写入绑定到二维表面参考surfRef的坐标x和y处的CUDA数组。
surf3Dread()：

template<class Type>
Type surf3Dread(surface<void, cudaSurfaceType3D> surfRef,
    int x, int y, int z,
    boundaryMode = cudaBoundaryModeTrap);
template<class Type>
void surf3Dread(Type* data,
    surface<void, cudaSurfaceType3D> surfRef,
    int x, int y, int z,
    boundaryMode = cudaBoundaryModeTrap);

使用坐标x，y和z读取绑定到三维曲面参考surfRef的CUDA数组。
surf3Dwrite()：

template<class Type>
void surf3Dwrite(Type data,
    surface<void, cudaSurfaceType3D> surfRef,
    int x, int y, int z,
    boundaryMode = cudaBoundaryModeTrap);

将值数据写入绑定到坐标x，y和z的三维表面参考surfRef的CUDA数组。
surf1DLayeredread()：

template<class Type>
Type surf1DLayeredread(
    surface<void, cudaSurfaceType1DLayered> surfRef,
    int x, int layer,
    boundaryMode = cudaBoundaryModeTrap);
template<class Type>
void surf1DLayeredread(Type data,
    surface<void, cudaSurfaceType1DLayered> surfRef,
    int x, int layer,
    boundaryMode = cudaBoundaryModeTrap);

使用坐标x和索引层读取绑定到一维分层表面参考surfRef的CUDA数组。
surf1DLayeredwrite()：

template<class Type>
void surf1DLayeredwrite(Type data,
    surface<void, cudaSurfaceType1DLayered> surfRef,
    int x, int layer,
    boundaryMode = cudaBoundaryModeTrap);

将值数据写入绑定到坐标x和索引层的二维分层表面参考surfRef的CUDA数组。
surf2DLayeredread()：

template<class Type>
Type surf2DLayeredread(
    surface<void, cudaSurfaceType2DLayered> surfRef,
    int x, int y, int layer,
    boundaryMode = cudaBoundaryModeTrap);
template<class Type>
void surf2DLayeredread(Type data,
    surface<void, cudaSurfaceType2DLayered> surfRef,
    int x, int y, int layer,
    boundaryMode = cudaBoundaryModeTrap);

使用坐标x和y以及索引层读取绑定到二维分层表面参考surfRef的CUDA数组。
surf2DLayeredwrite()：

template<class Type>
void surf2DLayeredwrite(Type data,
    surface<void, cudaSurfaceType2DLayered> surfRef,
    int x, int y, int layer,
    boundaryMode = cudaBoundaryModeTrap);

将值数据写入绑定到一维分层表面参考surfRef的坐标x和y处的CUDA数组，以及索引层。
surfCubemapread()：

template<class Type>
Type surfCubemapread(
    surface<void, cudaSurfaceTypeCubemap> surfRef,
    int x, int y, int face,
    boundaryMode = cudaBoundaryModeTrap);
template<class Type>
void surfCubemapread(Type data,
    surface<void, cudaSurfaceTypeCubemap> surfRef,
    int x, int y, int face,
    boundaryMode = cudaBoundaryModeTrap);

使用坐标x和y读取绑定到立方体贴图表面参考surfRef的CUDA数组，并使用面对索引面。
surfCubemapwrite()：

template<class Type>
void surfCubemapwrite(Type data,
    surface<void, cudaSurfaceTypeCubemap> surfRef,
    int x, int y, int face,
    boundaryMode = cudaBoundaryModeTrap);

将值数据写入绑定到坐标x和y处的立方体贴图参考surfRef的CUDA数组，并且面对索引面。
surfCubemapLayeredread()：

template<class Type>
Type surfCubemapLayeredread(
    surface<void, cudaSurfaceTypeCubemapLayered> surfRef,
    int x, int y, int layerFace,
    boundaryMode = cudaBoundaryModeTrap);
template<class Type>
void surfCubemapLayeredread(Type data,
    surface<void, cudaSurfaceTypeCubemapLayered> surfRef,
    int x, int y, int layerFace,
    boundaryMode = cudaBoundaryModeTrap);

使用坐标x和y以及索引layerFace读取绑定到立方体贴图分层曲面参考surfRef的CUDA数组。
surfCubemapLayeredwrite()：

template<class Type>
void surfCubemapLayeredwrite(Type data,
    surface<void, cudaSurfaceTypeCubemapLayered> surfRef,
    int x, int y, int layerFace,
    boundaryMode = cudaBoundaryModeTrap);

将值数据写入绑定到cubemap分层参考surfRef的坐标x和y处的CUDA数组，以及index layerFace。
