Apache RocketMQ作为阿里开源的一款高性能、高吞吐量的分布式消息中间件,它的通信能力已得到业界的公认。它的通信层是借助于异步网络框架Netty实现的。在开发网络游戏的时候,Netty也常用于游戏服务器或网关的通信层框架,所以,可以通过学习RocketMQ是如何使用Netty框架,从中借鉴一此应用技巧。
在RocketMQ中的rocketmq-remoting项目就是针对网络层封装的项目,其实使用Netty的时候,最主要的就是以下几个部分:
- 线程池的划分
- 是否使用Epoll
- Netty服务启动的相关配置
- Netty内存池的使用。
- 使用共享的Handler
- 服务优雅的关闭
线程池的划分
RocketMQ的服务端Netty启动类是NettyRemotingServer
,在这里声明了四个线程池
//这个其实就是netty中的work线程池,默认用来处理Handler方法的调用 private final EventLoopGroup eventLoopGroupSelector; // Netty的Boss线程 private final EventLoopGroup eventLoopGroupBoss; // 公共线程池,这里用来处理RocketMQ的业务调用,这个有Netty没有什么关系 private final ExecutorService publicExecutor; // 用来处理Handler的线程池 private DefaultEventExecutorGroup defaultEventExecutorGroup;
RocketMQ的Netty启动代码
下面是RocketMQ的Netty服务启动代码,如果我们自己想要创建一个Netty服务,直接抄下面的代码,修改一下相关的配置和Handler就可以了:
ServerBootstrap childHandler = this.serverBootstrap.group(this.eventLoopGroupBoss, this.eventLoopGroupSelector) .channel(useEpoll() ? EpollServerSocketChannel.class : NioServerSocketChannel.class) .option(ChannelOption.SO_BACKLOG, 1024) .option(ChannelOption.SO_REUSEADDR, true) .option(ChannelOption.SO_KEEPALIVE, false) .childOption(ChannelOption.TCP_NODELAY, true) .childOption(ChannelOption.SO_SNDBUF, nettyServerConfig.getServerSocketSndBufSize()) .childOption(ChannelOption.SO_RCVBUF, nettyServerConfig.getServerSocketRcvBufSize()) .localAddress(new InetSocketAddress(this.nettyServerConfig.getListenPort())) .childHandler(new ChannelInitializer() { @Override public void initChannel(SocketChannel ch) throws Exception { ch.pipeline() .addLast(defaultEventExecutorGroup, HANDSHAKE_HANDLER_NAME, handshakeHandler) .addLast(defaultEventExecutorGroup, encoder, new NettyDecoder(), new IdleStateHandler(0, 0, nettyServerConfig.getServerChannelMaxIdleTimeSeconds()), connectionManageHandler, serverHandler ); } }); if (nettyServerConfig.isServerPooledByteBufAllocatorEnable()) { childHandler.childOption(ChannelOption.ALLOCATOR, PooledByteBufAllocator.DEFAULT); } try { ChannelFuture sync = this.serverBootstrap.bind().sync(); InetSocketAddress addr = (InetSocketAddress) sync.channel().localAddress(); this.port = addr.getPort(); } catch (InterruptedException e1) { throw new RuntimeException("this.serverBootstrap.bind().sync() InterruptedException", e1); }
尽量使用Epoll
epoll是Linux下多路复用IO接口select/poll的增强版本,它能显著减少程序在大量并发连接中只有少量活跃的情况下的系统CPU利用率。先不管epoll的原理是什么,这都是底层的实现,只需要知道epoll的效率比其它的方式高就可以,在能使用epoll的情况下,就应该选择使用Netty socket的Epoll模式。从RocketMQ的Netty启动代码来看,在选择使用的ServerSocketChannel时,它使用了一个方法来判断是否使用Epoll。
private boolean useEpoll() { return RemotingUtil.isLinuxPlatform() && nettyServerConfig.isUseEpollNativeSelector() && Epoll.isAvailable(); }
nettyServerConfig.isUseEpollNativeSelector可以让使用者在可以使用epoll的环境下,强制不使用epoll。
使用Netty的ByteBuf内存池
使用Netty的内存池可以减少对象的创建和内存分配,进而减少gc的量。在RocketMQ的服务中,默认是netty开启使用netty的内存池的。
if (nettyServerConfig.isServerPooledByteBufAllocatorEnable()) { childHandler.childOption(ChannelOption.ALLOCATOR, PooledByteBufAllocator.DEFAULT); }
使用共享的Handler
在netty中,使用Handler处理网络的消息,不管是接收网络消息,还是返回网络消息,都会经过Handler的处理方法。在一个网络连接创建channel时,channel初始化时就会添加相应的Handler。如果每个Handler内都没有共用的对象,那么这些Handler最好标记为共享的,这样可以减少Handler对象的创建。比如RocketMQ的编码Handler
@ChannelHandler.Sharablepublic class NettyEncoder extends MessageToByteEncoder { private static final InternalLogger log = InternalLoggerFactory.getLogger(RemotingHelper.ROCKETMQ_REMOTING); @Override public void encode(ChannelHandlerContext ctx, RemotingCommand remotingCommand, ByteBuf out) throws Exception { try { ByteBuffer header = remotingCommand.encodeHeader(); out.writeBytes(header); byte[] body = remotingCommand.getBody(); if (body != null) { out.writeBytes(body); } } catch (Exception e) { log.error("encode exception, " + RemotingHelper.parseChannelRemoteAddr(ctx.channel()), e); if (remotingCommand != null) { log.error(remotingCommand.toString()); } RemotingUtil.closeChannel(ctx.channel()); } }}
在服务启动时,会只在NettyRemotingServer创建一个NettyEncoder对象实例,所有的channel实例共同使用这个编码实例。
服务优雅的关闭
所谓服务优雅的关闭,是指在服务需要关闭的时候,在关闭之前,需要把任务处理完,而且在收到关闭时,不再接收新的任务。在所有的Netty业务中,有业务相关的线程池就是NettyRemotingServer中创建的四个线程池,所以在关闭服务的时候,只需要关闭这几个线程池即可。并等待线程池中的任务处理完。在NettyRemotingServer中有一个shutdown()方法。
@Override public void shutdown() { try { if (this.timer != null) { this.timer.cancel(); } this.eventLoopGroupBoss.shutdownGracefully(); this.eventLoopGroupSelector.shutdownGracefully(); if (this.nettyEventExecutor != null) { this.nettyEventExecutor.shutdown(); } if (this.defaultEventExecutorGroup != null) { this.defaultEventExecutorGroup.shutdownGracefully(); } } catch (Exception e) { log.error("NettyRemotingServer shutdown exception, ", e); } if (this.publicExecutor != null) { try { this.publicExecutor.shutdown(); } catch (Exception e) { log.error("NettyRemotingServer shutdown exception, ", e); } } }
这里面调用的shutdownGracefully()就是
@Override public Future> shutdownGracefully() { return shutdownGracefully(2, 15, TimeUnit.SECONDS); }
它会等待执行完线程池中当前已所有任务,然后再关闭线程池。那么,何时调用的这个shutdown()方法呢。在RocketMQ服务启动的时候,会添加一个回调钩子,比如Namesrv服务在启动的时候会执行下面的代码:
Runtime.getRuntime().addShutdownHook(new ShutdownHookThread(log, new Callable() { @Override public Void call() throws Exception { controller.shutdown(); return null; } }));
这样在服务器关闭的时候,就会触发controller.shudown()。然后执行关闭线程池的操作。注意,关闭服务器一般使用kill pid的命令,RocketMQ的发布包里面的bin下面,有一个mqshutdown的脚本,就是使用的kill pid 命令。
pid=`ps ax | grep -i 'org.apache.rocketmq.namesrv.NamesrvStartup' |grep java | grep -v grep | awk '{print $1}'` if [ -z "$pid" ] ; then echo "No mqnamesrv running." exit -1; fi echo "The mqnamesrv(${pid}) is running..." kill ${pid}
首先是使用脚本获取进程名的pid,然后使用 kill pid将进程杀死。但是不能使用kill -9 pid,因为这个命令不会给进程执行回调的机会,就把进程杀死了。
