- bug1:使用普通点标记超过1000就会卡顿甚至卡死,所以使用高德的海量点标记api
- bug2:页面初始化就显示点,需要在地图加载后再掉接口获取点在调标记方法,否则会出现标记点的时候地图还没有加载完成的情况
- 重点:循环创建点对象赋值给数组的属性,方便删除;其他项目这样存储点,点击事件数据出现错乱,建一个新数组,将点赋值给arr[i]即可
import AMapLoader from "@amap/amap-jsapi-loader";
import icon1 from "./components/img/index4-tab1.png";
import icon2 from "./components/img/index4-tab2.png";
import icon3 from "./components/img/index4-tab3.png";
import icon4 from "./components/img/index4-tab4.png";
import icon5 from "./components/img/index4-tab5.png";
import icon6 from "./components/img/index4-tab6.png";
import fireIcon from "./components/img/3d-red.png";
//秘钥
window._AMapSecurityConfig = {
securityJsCode: "秘钥",
};
// -----------地图--------------
initAMap() {
AMapLoader.load({
key: "130cca3be68a2ff0fd5ebb6de25e4eac", // 申请好的Web端开发者Key,首次调用 load 时必填
// version: "v1.4.15", // 指定要加载的 JSAPI 的版本,缺省时默认为 1.4.15
// plugins: [
// "AMap.ControlBar",
// "AMap.ToolBar",
// "AMap.Weather",
// "AMap.CitySearch",
// "AMap.Marker",
// "AMap.MouseTool",
// "AMap.PolyEditor",
// "AMap.Driving",
// "AMap.Polyline",
// "AMap.Geolocation",
// "AMap.GraspRoad",
// "AMap.Geocoder",
// "AMap.GeometryUtil.ringArea",
// "AMap.DistrictSearch",
// "AMap.MoveAnimation",
// ], // 需要使用的的插件列表,如比例尺'AMap.Scale'等
})
.then((AMap) => {
this.map = new AMap.Map("containerMap", {
// 设置地图容器id
rotateEnable: true,
pitchEnable: true,
zoom: 13,
pitch: 50,
rotation: -15,
viewMode: "3D", //开启3D视图,默认为关闭
zooms: [2, 20],
center: [119.419251, 32.400703],
mapStyle: "amap://styles/blue", //设置地图的显示样式
});
// 工具条
// var controlBar = new AMap.ControlBar({
// position: {
// right: "10px",
// top: "10px",
// },
// });
// this.map.addControl(controlBar);
// var toolBar = new AMap.ToolBar({
// position: {
// right: '40px',
// top: '110px'
// }
// });
// this.map.addControl(toolBar)
this.map.on("complete", () => {
console.log("地图加载完成");
// *****海量点标记-------
// 创建 AMap.LabelsLayer 图层
this.layer = new AMap.LabelsLayer({
zooms: [2, 20],
zIndex: 1000,
collision: false,
});
// 将图层添加到地图
this.map.add(this.layer);
// -----掉接口获取点信息,然后调取标记点的方法-----
getFireStationListApi({
unitLevel: 3,
}).then((res) => {
res.data.forEach((item) => {
item.type = 2;
item.marker = null;
});
this.$set(this.tab[1], "list", res.data);
this.createMarker(res.data);
});
});
})
.catch((e) => {
console.log(e);
});
},
// 创建海量点标记
createMarker(arr = []) {
if (arr.length != 0) {
// 清除地图上所有图形
// this.map.clearMap();
arr.map((item) => {
item.marker = new AMap.LabelMarker({
// 手动纠偏坐标
position: new AMap.LngLat(
item.type == 3 ? item.longitude * 1 + 0.0054 : item.longitude * 1,
item.type == 3 ? item.latitude * 1 - 0.0018 : item.latitude * 1
),
zIndex: 16,
rank: 1, //避让优先级
icon: {
type: "image", //图标类型,现阶段只支持 image 类型
image: [icon1, icon2, icon3, icon4, icon5][item.type - 1],
size: [
[40, 40],
[30, 30],
[20, 20],
[30, 30],
][item.type * 1 - 1], //图片尺寸
anchor: "center", //图片相对 position 的锚点,默认为 bottom-center
},
text: {
content: [
item.name,
item.deptName,
"",
"",
// item.resourcesName,
// item.resourcesName,
][item.type - 1], //要展示的文字内容
direction: "bottom", //文字方向,有 icon 时为围绕文字的方向,没有 icon 时,则为相对 position 的位置
offset: [-2, 0], //在 direction 基础上的偏移量
//文字样式
style: {
fontSize: 12, //字体大小
fillColor: "cyan", //字体颜色
strokeColor: "#fff", //描边颜色
strokeWidth: 0, //描边宽度
},
},
});
if (item.type == 1) {
// 为marker绑定click事件
item.marker.on("click", (e) => {
});
}
if (item.type == 3) {
// 为marker绑定click事件
item.marker.on("click", (e) => {
console.log(item);
});
}
this.layer.add(item.marker);
});
//自动适配到合适视野范围
//无参数,默认包括所有覆盖物的情况
// this.map.setFitView();
this.map.setCenter(this.position || [119.419251, 32.400703]); //设置地图中心点
}
},
// 删除海量点
removeMarkers(arr = []) {
arr.forEach((item) => {
this.layer.remove(item.marker);
item.marker = null;
});
this.map.setCenter(this.position || [119.419251, 32.400703]); //设置地图中心点
},
